- Twist the bulb holder counterclockwise, and withdraw it.
- Fit a new bulb.
- Fit the bulb holder in place and twist it clockwise.
- Refit the speaker and press in the red tab.
- Press the speaker grille back into position.
High level brake light
These bulbs are of a special type. We recommend that you ask your Volvo \
retailer to replace this bulb.
pg. 204 Maintenance and servicing
Replacing bulbs
License plate lights
- Switch off the ignition.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (28 of 38)12/30/200\
6 5:51:43 PM

2007 Volvo XC70
- Loosen the screws with a torx screwdriver.
- Carefully pull out the lamp housing.
- Turn the bulb holder counterclockwise and pull it out.
- Pull out the defective bulb and insert a new one.
- Reinsert the bulb holder into the housing and turn it clockwise.
- Reinstall the housing and screw it in place.
Door step courtesy lights
The door step courtesy lights are located under the dash on the driver's\
and passenger's sides. To replace
a bulb:
- Carefully insert a screwdriver and pry out the lens.
- Replace the defective bulb.
- Reinstall the lens.
Vanity mirror
- Carefully insert a screwdriver and pry out the lens.
- Pry out the defective bulb and replace it.
- Carefully press the lower edge of the lens onto the four tabs and pres\
s the upper edge of the lens into
place.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (29 of 38)12/30/200\
6 5:51:43 PM

2007 Volvo XC70
NOTE: Other bulbs may be difficult for you to replace yourself. Let an author\
ized Volvo retailer
replace these bulbs if necessary.
pg. 205 Maintenance and servicing
Fuses
Replacing fuses
If an electrical component fails to function, it is possible that a fuse\
has blown.
Fuses are located in four different places:
1. Relays/fuse box in the engine compartment
2. Fuse box in the passenger compartment, behind plastic cover
3. Fuse box in the passenger compartment, on the edge of the dashboard
4. Fuse box in the cargo area
A label on the inside of each cover indicates the amperage and the elect\
rical components that are
connected to each fuse.
The easiest way to see if a fuse is blown is to remove it. Pull the fuse\
straight out. If a fuse is difficult to
remove, you will find a special fuse removal tool (and several extra fu\
ses) in the passenger compartment
fuse box on the driver's end of dashboard. From the side, examine the cu\
rved metal wire (see next page)
to see if it is broken. If so, put in a new fuse of the same color and amperage (written on the fuse).
Spare fuses are stored in the fuse box in the passenger compartment. If \
fuses burn out repeatedly, have
the electrical system inspected by an authorized Volvo retailer.
WARNING!
Never use fuses with higher amperage than those stated on the following \
pages. Doing so could
overload the vehicle's electrical system.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (30 of 38)12/30/200\
6 5:51:43 PM

2007 Volvo XC70
pg. 206 Maintenance and servicing
Fuses
Relay/Fuse box in the engine compartment
When replacing fuses, be sure to replace a blown fuse with a new one of \
the same color and amperage
(written on the fuse).
Fuses in the engine compartment No. Amperage
1. ABS 30
2. ABS 30
3. -
4. -
5. Auxiliary lights (option) 20
6. Starter motor relay 35
7. Windshield wipers 25
8. Fuel pump 15
9. Transmission control module (R-models) 15
10. Ignition coils, engine control module 20
11. Throttle pedal sensor, A/C compressor, e-box fan 10
12. Engine control module, fuel injectors, mass airflow sensor 15
13. Throttle housing control module 10
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (31 of 38)12/30/200\
6 5:51:43 PM

2007 Volvo XC70
14. Heated oxygen sensor20
15. Crankcase ventilation heater, solenoid valves 10
16. Driver's side low beam headlight 20
17. Passenger's side low beam headlight 20
18. -
19. Engine control module feed, engine relay 5
20. Parking lights 15
21. -
pg. 207 Maintenance and servicing
Fuses
Fuse box in the passenger compartment, behind the plastic cover
This fuse box is located behind the plastic cover below the steering whe\
el. When replacing a blown fuse,
be sure to replace it with a new one of the same color and amperage (wr\
itten on the fuse).
No. Amperage
1. Heated passenger's seat (option) 15
2. Heated driver's seat (option) 15
3. Horn 15
4. -
5. -
6. -
7. -
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (32 of 38)12/30/200\
6 5:51:44 PM

2007 Volvo XC70
8. Alarm siren5
9. Brake light switch feed 5
10. Instrument panel, climate system, power driver's seat (option),
occupant weight sensor 10
11. 12-volt sockets - front and rear seats 15
12. -
13. -
14. Headlight wipers (V70 R) 15
15. ABS, STC/DSTC 5
16. Power steering, Active Bi-Xenon headlights (option) 10
17. Driver's side front foglight (option) 7.5
18. Passenger's side front foglight (option) 7.5
19. -
20. -
21. Transmission control module, reverse gear block (M66) 10
22. Driver's side high beam 10
23. Passenger's side high beam 10
24. -
25. -
26. -
27. -
28. Power passenger's seat (option), audio system 5
29. -
30. -
31. -
32. -
33. Vacuum pump 20
34. Washer pump - headlight wipers (V70 R) 15
35. -
36. -
pg. 208 Maintenance and servicing
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (33 of 38)12/30/200\
6 5:51:44 PM

2007 Volvo XC70
Fuses
Fuse box on the edge of the dashboard
Fuses are located inside the access panel on the edge of the dashboard. \
There are also a number of spare
fuses. No. Amperage
1. Power driver's seat (option) 25
2. Power passenger's seat (option) 25
3. Climate system blower 30
4. Control module - front passenger's door 25
5. Control module - driver's door 25
6. Ceiling lighting, upper electrical control module 10
7. Moon roof (option) 15
8. Ignition switch, SRS system, engine control module, immobilizer,
transmission control module (R-models) 7.5
9. Onboard diagnostics, headlight switch, steering wheel angle sensor,
steering wheel control module 5
10. Audio system 20
11. Audio system amplifier 30
12. Navigation system display (option) 10
13. -
14. -
15. -
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (34 of 38)12/30/200\
6 5:51:44 PM

2007 Volvo XC70
16. -
17. -
18. -
19. -
20. -
21. -
22. -
23. -
24. -
25. -
26. -
27. -
28. -
29. -
30. -
31. -
32. -
33. -
34. -
35. -
36. -
37. -
38. -
pg. 209 Maintenance and servicing
Fuses
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (35 of 38)12/30/200\
6 5:51:44 PM

2007 Volvo XC70
Fuses in the cargo area
The fuses in the cargo area are located behind the panel on the driver's\
side of the cargo compartment.
When replacing a blown fuse, be sure to replace it with a new one of the\
same color and amperage
(written on the fuse). No. Amperage
1. Backup lights 10
2. Parking lights, foglights, cargo area lighting, license plate lightin\
g,
brake lights 20
3. Accessory control module 15
4. -
5. Rear Electronic Module 10
6. CD-changer (option), Navigation system (option) 7.5
7. Trailer wiring (30-feed) 15
8. 12-volt socket - cargo area 15
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (36 of 38)12/30/200\
6 5:51:44 PM

2007 Volvo XC70
9. Rear passenger's side door - power window, power window cutout
function 20
10. Rear driver's side door - power window, power window cutout
function 20
11. -
12. -
13. -
14. Subwoofer (option) 15
15. -
16. -
17. Accessory audio 5
18. -
19. Tailgate wiper 15
pg. 210 Maintenance and servicing
Fuses
No.Amperage
20. Trailer wiring (15-feed) 20
21. -
22. -
23. All Wheel Drive 7.5
24. Four-C chassis system (option) 15
25. -
26. Park assist (option) 5
27. Main fuse: trailer wiring, Four-C, park assist, All Wheel Drive 30
28. Central locking system 15
29. Driver's side trailer lighting: parking lights, turn signal 25
30. Passenger's side trailer lighting: parking light, brake light, fog
light, turn signal 25
31. Main fuse: fuses 37 and 38 40
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (37 of 38)12/30/200\
