VOLVO XC90 2007 Repair Manual

2007 Volvo XC90
Active Bi-Xenon headlights (ABL) - option
When the ABL function is activated, the headlight beams adjust laterally\
to help light up a curve
according to movements of the steering wheel (see the right-pointing be\
am in the illustration above).
This function is activated automatically when the engine is started and \
can be deactivated/ reactivated by
pressing the ABL button (see
page 52).
1. On Canadian models, the daytime running lights will remain on with th\
e light switch in this position.
pg. 56 Instruments and controls
Lighting panel
Fog lights
Front fog lights (option)
The front fog lights can be used in combination with either the headligh\
ts or the parking lights.
- Turn the ignition key to position II.
- Press button 2 to turn on the front fog lights.
An indicator light in the button illuminates when the front fog lights a\
re on.
Rear fog light
The single rear fog light is located in the driver's side of the vehicle\
.
The rear fog light will only function in combination with the high/low b\
eam headlights or the optional
front fog lights.
- Turn the ignition key to position II.
- Press button 3 to turn on the rear fog light.
An indicator light in the button illuminates when the rear fog light is \
on.
NOTE: The rear fog light is considerably brighter than the normal tail lights\
and should be used only
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (15 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
when conditions such as fog, rain, snow, smoke or dust reduce visibility\
for other vehicles to less than
500 ft. (150 meters).
Instrument panel lighting
The instrument panel lighting illuminates when the ignition key is in po\
sition II and the light switch (1)
is in either position
or .
- Move the thumb wheel (4) up to increase brightness or down to decrea\
se brightness.
Unlocking the fuel filler door
Press button 5 when the vehicle is at a standstill to unlock the fuel fi\
ller door. Please note that the fuel
filler door will remain unlocked until the vehicle begins to move forwar\
d. An audible click will be heard
when the fuel filler door relocks.
NOTE: If the fuel filler door does not unlock after the button has been press\
ed, drive the vehicle at a
speed of at least 5 mph (8 km/h), stop the vehicle, and press the butt\
on again.
See
page 57 for information on unlocking the fuel filler door manually.
pg. 57 Instruments and controls
Lighting panel
Manually unlocking the fuel filler door
- Open the upper and lower sections of the tailgate, and fold up the rea\
r section of the cargo area floor.
- If the vehicle is equipped with the optional grocery bag holder, detac\
h the holder's bands.
- Remove the corner panel (1) from the floor of the cargo area.
- Open the cover (2) in the side panel by pulling the tab (3) upward\
/outward.
- Pull down the insulating material (4) to access the fuel filler door\
motor (5).
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (16 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90

- Move the catch (6) rearward to unlock the fuel filler door lock, or \
move it forward to lock the filler
door.
pg. 58 Instruments and controls
Left-side steering wheel lever
Lever positions
1. Turn signals, lane change position
2. Turn signals, position for normal turns
3. High beam flash
4. Toggle between high and low beams, Home Safe lighting
Turn signals
When turning
Move the lever as far up or down as possible (to position 2) to start \
the turn signals. The turn signals will
be cancelled automatically by the movement of the steering wheel, or the\
lever can be returned to its
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (17 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
initial position by hand.
When changing lanes
The driver can automatically flash the turn signals 3 times by:
l Moving the turn signal lever up or down to position 1 and releasing it. \
l Moving the lever up or down to position 2 and immediately back to its or\
iginal position.
NOTE:
l This automatic flashing sequence can be interrupted by immediately movin\
g the lever in the opposite
direction.
l If the turn signal indicator flashes faster than normal, check for a bur\
ned-out turn signal bulb.
High/low beam headlights
Continuous high beams
- Turn the ignition key to position II.
- With the light switch (1) in position
, (see page 55) pull the turn signal lever toward the steering
wheel (position 4) to toggle between high and low beams (this also ap\
plies on models equipped with the
optional Active Bi-Xenon headlights).
High beam flash
- Turn the ignition key to position II.
- Pull the turn signal lever to position 3. The high beams will remain o\
n until the lever is released.
Home safe lighting
When you leave your vehicle at night, you can make use of the home safe \
lighting function to illuminate
the area in front of the vehicle.
- Remove the key from the ignition switch.
- Pull the direction indicator lever as far as possible towards the stee\
ring wheel (to position 4) and
release it.
- Exit the vehicle and lock the doors. The headlights and parking lights\
will illuminate and remain on for
30
1, 60 or 90 seconds. The time interval can be changed by an authorized Vo\
lvo retailer.
1. Factory setting
pg. 59 Instruments and controls
Right-side steering wheel lever
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (18 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Windshield wipers
Windshield wipers off
If the lever is in the 0 position and you move it upwards, the wipers wi\
ll sweep one stroke at a time for
as long as you hold the lever up.
"Single sweep" position
Move the lever slightly upward from the 0 position for one sweep of the \
wipers. The lever returns
automatically to 0 when released.
Intermittent wiper function
With the lever in this position, you can set the wiper interval by twist\
ing the control ring 1 upward to
increase wiper speed or downward to decrease the speed.
Windshield washer/headlight washer (certain models)
When the lever is pulled to wash the windshield, high pressure jets moun\
ted in the bumper will spray the
headlights.
CAUTION!
Use ample washer fluid when washing the windshield. The windshield shoul\
d be thoroughly wet
when the wipers are in operation.
l To conserve washer fluid in driving conditions where the windshield wash\
ers are used frequently, the
headlights will only be washed once for every five times the windshield \
is washed within a 10-minute
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (19 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
period.
l A short pull on the lever will wash the windshield only.
l When approximately 1 US quart (1 liter) remains in the washer fluid re\
servoir, the headlights will not
be washed when the lever is pulled to conserve washer fluid for the wind\
shield.
Rain sensor (option)
The rain sensor automatically regulates wiper speed according to the amo\
unt of water on the windshield.
The sensitivity of the sensor can be adjusted by twisting ring 1 up (the wipers will s\
weep the windshield
more frequently) or down (the wipers will sweep the windshield less fr\
equently).
Activating the rain sensor:
- Turn the ignition key to at least position I and put the windshield wi\
per lever in position 0.
- Press button 2.
A light in the button will light up to indicate that the rain sensor is \
active.
Deactivating the rain sensor:
- Press button 2.
or
- Move the windshield wiper lever down to another position.
Moving the lever up will not deactivate the rain sensor. Doing so will c\
ause the wipers to sweep the
windshield until the lever is released, at which time the wipers return \
to rain sensor mode.
pg. 60 Instruments and controls
Right-side steering wheel lever
The rain sensor is also deactivated when the key is removed from the ign\
ition.
CAUTION!
The rain sensor should be deactivated when washing the vehicle in an aut\
omatic car wash, etc. If the
rain sensor function is left on, the wipers will start inadvertently in \
the car wash and could be
damaged.
Continuous wiper function.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (20 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Wipers operate at "high" speed.
Tailgate wiper/washer
1. Intermittent wiping
2. Normal wiping
Move the lever forward to start the tailgate washer.
Tailgate wiper and reverse gear
If the front wipers are on and the transmission is put into reverse gear\
, the tailgate wiper will go into
intermittent wiping function
1.
If the tailgate wiper is already in normal wiping function, the normal w\
iping function will continue.
1. Consult your Volvo retailer if you would like to have this function d\
eactivated.
pg. 61 Instruments and controls
Hazard warning flashers, rear window/sideview mirror defroster
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (21 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Hazard warning flashers
The four-way flasher should be used to indicate that the vehicle has bec\
ome a traffic hazard. To activate
the flashers, press the triangular button in the center dash. Press the \
button again to turn off the flashers.
NOTE: Regulations regarding the use of the hazard warning flasher may vary, d\
epending on where you
live.

Rear window and sideview mirror defroster
Press the switch to start heating the rear window and sideview mirrors t\
o remove ice or condensation. A
light in the switch will light up.
A timer automatically switches off the heating after approximately 12 mi\
nutes. The LED will go out
correspondingly.
pg. 62 Instruments and controls
Trip computer (option)
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (22 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
Trip computer
The trip computer stores information gathered from several systems in yo\
ur vehicle and has four menus
that can be displayed in the text window.
l Driving distance on current fuel reserve
l Average fuel consumption
l Current fuel consumption
l Average speed
l Current speed in mph (Canadian models only)
l DSTC (see page 130 for detailed information)
NOTE: Warning messages from the vehicle's monitoring systems will override th\
e trip computer
function. If a warning message is displayed in the text window while you\
are using the trip computer,
you must acknowledge the message by pressing button A. Press button A ag\
ain to return to the trip
computer function.
Trip computer controls and functions
The four
1 trip computer functions can be accessed by twisting control B one step \
at a time in either
direction. Twisting a fifth
2 time returns you to the original function. The trip computer can be res\
et
(current data will be erased from system memory) by pressing RESET (b\
utton C).
1. Driving distance on current fuel reserve
This function shows the approximate distance that can be driven on the f\
uel remaining in the tank. This
calculation is based on average fuel consumption during the last 20 mile\
s (30 km) of driving and the
amount of fuel remaining in the tank when the reading was taken.
When the driving distance on current fuel reserve is less than 12 miles \
(20 km), "----" will be displayed
in the text window.
2. Average fuel consumption
This value indicates fuel consumption since the last time the trip compu\
ter was reset (by pressing
RESET, button C). When the engine is switched off, information on fuel \
consumption is stored and
remains in system memory until the RESET (button C) is pressed again.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (23 of 40)12/30/200\
6 5:53:37 PM

2007 Volvo XC90
3. Current fuel consumption
This value indicates the current fuel consumption, based on readings tak\
en once per second. When the
vehicle is not moving, "----" will be displayed.
4. Average speed
This value indicates average speed since the last time the trip computer\
was reset (by pressing RESET,
button C). When the engine is switched off, information on average spee\
d is stored and remains in
system memory until the RESET (button C) is pressed again.
5. Current speed in miles per hour (Canadian models only)
This function provides the driver with an instantaneous conversion of th\
e vehicle's current speed from
km/h to mph.
NOTE: Trip computer readings may vary slightly depending on the circumference\
of the tires on the
vehicle and driving style.
1. Five functions on Canadian models.
2. A sixth time on Canadian models.
pg. 63 Instruments and controls
Cruise control
Cruise control
The cruise control panel is located on the left side of the steering whe\
el hub.
Engaging cruise control
Press the CRUISE button. CRUISE will be displayed in the information win\
dow in the instrument panel.
file:///K|/ownersdocs/2007/2007_XC90/07xc90_02.htm (24 of 40)12/30/200\
6 5:53:37 PM
