MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
67
8
9After cleaning
1.Dry the motorcycle with a
chamois or an absorbing cloth.
2.Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3.Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally
induced discoloring of stainless-
steel exhaust systems can be
removed through polishing.)
4.To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all (even
chrome- and nickel-plated) metal
surfaces.
5.Use spray oil as a universal
cleaner to remove any remaining
dirt.
6.Touch up minor paint damage
caused by stones, etc.
7.Wax all painted surfaces.
8.Let the motorcycle dry complete-
ly before storing it or covering it.
EWA00001
wMake sure that there is no oil or
wax on the brakes and tires. If nec-
essary, clean the brake discs and
linings with a regular brake disc
cleaner or acetone, and wash the
tires with warm water and mild
soap. Then, carefully test the
motorcycle for its braking perfor-
mance and cornering behavior.
ECA00013
cC8
8
Apply spray oil and wax spar-
ingly and wipe off any excess.
8 8
Never apply oil or wax on rub-
ber and plastic parts, but treat
them with a suitable care prod-
uct.
8 8
Avoid using abrasive polish-
ing compounds as they wear
away the paint.
NOTE:
Consult a Yamaha dealer for advice
on what products to use.
3MB-9-E7 12/27/00 2:52 PM Page 80

7-4
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
67
8
9
StorageShort-term
Always store your motorcycle in a
cool, dry place and, if necessary, pro-
tect it against dust with a porous
cover.
ECA00014
cC8
8
Storing the motorcycle in a
poorly ventilated room or cov-
ering it with a tarp while it is
still wet will allow water and
humidity to seep in and cause
rust.
8 8
To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-
cals are stored.
Long-term
Before storing your motorcycle for
several months:
1.Follow all the instructions in the
ÒCareÓ section of this chapter.
2.Drain the carburetor float cham-
ber by loosening the drain bolt;
this will prevent fuel deposits
from building up. Pour the
drained fuel into the fuel tank.
3.Only for motorcycles equipped
with a fuel cock which has an
ÒOFFÓ position: Turn the fuel
cock to ÒOFFÓ.
4.Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
5.Perform the following steps to
protect the cylinder, piston rings,
etc. from corrosion.a.Remove the spark plug cap and
spark plug.
b.Pour a teaspoonful of engine oil
into the spark plug bore.
c.Install the spark plug cap onto
the spark plug and place the
spark plug on the cylinder head
so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d.Turn the engine over several
times with the starter. (This will
coat the cylinder wall with oil.)
e.Remove the spark plug cap from
the spark plug, install the spark
plug and then the spark plug
cap.
EWA00003
wWhen turning the engine over, be
sure to ground the spark plug elec-
trodes to prevent damage or injury
from sparking.
3MB-9-E7 12/27/00 2:52 PM Page 81

7-5
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
67
8
96.Lubricate all control cables and
the pivoting points of all levers
and pedals as well as of the
sidestand/centerstand.
7.Check and, if necessary, correct
the tire air pressure, then raise
the motorcycle so that both of its
wheels are off the ground.
Alternatively, turn the wheels a
little every month in order to pre-
vent the tires from becoming
degraded in one spot.
8.Cover up the muffler outlet with a
plastic bag to prevent moisture
from entering.9.Remove the battery and fully
charge it. Store it in a cool, dry
place and recharge it once a
month. Do not store the battery
in an excessively cold or warm
place (less than 0 ¡C or more
than 30 ¡C). For more informa-
tion, see ÒBattery storageÓ in the
chapter ÒPERIODIC MAINTE-
NANCE AND MINOR
REPAIRSÓ.
NOTE:
Make any necessary repairs before
storing the motorcycle.
3MB-9-E7 12/27/00 2:52 PM Page 82

8-1
1
2
3
4
5
6
78
9
EAU01038
SPECIFICATIONS
Specifications
ModelDT125R
Dimensions
Overall length2,170 mm
2,235 mm (N, S, SF, CH, A only)
Overall width830 mm
Overall height1,255 mm
Seat height885 mm
Wheel base1,415 mm
Ground clearance315 mm
Minimum turning radius2,100 mm
Basic weight (with oil and
full fuel tank)127 kg
129 kg (CH, A only)
Engine
Engine typeLiquid-cooled 2-stroke
Cylinder arrangementForward-inclined single
cylinder
Displacement124 cm
3
Bore ´Stroke56.0 ´50.7 mm Compression ratio6.7:1
Starting systemKick starter
Lubrication systemSeparate lubrication
(Yamaha autolube)
Engine oil (2-cycle)
Type2 stroke engine oil
Capacity
Total amount1.2 L
Transmission oil
TypeSAE 10W30 type SE motor oil
Capacity
Periodic oil change0.75 L
Total amount0.8 L
Radiator capacity
(Including all routes)0.92 L
Air filterWet type element
Fuel
TypeRegular unleaded gasoline
Fuel tank capacity10 L
Reserve amount1.8 L
3MB-9-E7 12/27/00 2:52 PM Page 83

SPECIFICATIONS
8-2
1
2
3
4
5
6
78
9
Carburetor
Type ´ quantityTM28SS ´ 1
ManufacturerMIKUNI
Spark plug
Manufacturer / typeNGK / BR9ES
NGK / BR8ES (CH, A only)
Spark plug gap0.7 ~ 0.8 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction systemHelical gear
Primary reduction ratio71/22 (3.227)
Secondary reduction systemChain drive
Secondary reduction ratio57/16 (3.563)
Transmission typeConstant mesh 6-speed
OperationLeft foot operation
Gear ratio1st2.833
2nd1.875
3rd1.412
4th1.143
5th0.957
6th0.818Chassis
Frame typeSemi double cradle
Caster angle27¡30Õ
Trail113 mm
Tire
TypeWith tube
Front
Size2.75-21 45P
Manufacturer/BRIDGESTONE / TW25
model
Rear
Size4.10-18 59P
Manufacturer/BRIDGESTONE / TW44
model
Maximum load*180 kg
178 kg (CH, A only)
Air pressure (cold tire)
up to 90 kg load*
Front125 kPa (1.25 kg/cm
2, 1.25 bar)
Rear150 kPa (1.50 kg/cm2, 1.50 bar)
3MB-9-E7 12/27/00 2:52 PM Page 84

8-3
1
2
3
4
5
6
78
9
SPECIFICATIONS
90 kg load ~ maximum
load*
Front150 kPa (1.50 kg/cm
2, 1.50 bar)
Rear175 kPa (1.75 kg/cm2, 1.75 bar)
Off-road riding
Front125 kPa (1.25 kg/cm2, 1.25 bar)
Rear150 kPa (1.50 kg/cm2, 1.50 bar)
* Load is total weight of cargo, rider, passenger and accessories.
Wheels
Front
TypeSpoke wheel
Size1.60 ´21
Rear
TypeSpoke wheel
Size1.85 ´18
Brakes
Front
TypeSingle disc brake
OperationRight hand operation
FluidDOT 3 or DOT 4Rear
TypeSingle disc brake
OperationRight foot operation
FluidDOT 3 or DOT 4
Suspension
FrontTelescopic fork
RearSwingarm (link suspension)
Shock absorber
FrontCoil spring/oil damper
RearCoil-gas spring/oil damper
Wheel travel
Front270 mm
Rear260 mm
Electrical
Ignition systemC.D.I.
Charging system
TypeC.D.I. magneto
3MB-9-E7 12/27/00 2:52 PM Page 85

SPECIFICATIONS
1
2
3
4
5
6
78
9
8-4 Battery
TypeGM3-3B
Voltage, capacity12 V, 3 AH
Headlight typeConventional incandescent bulb
Bulb voltage, wattage ´quantity
Headlight12 V, 45/40 W ´1
Tail / Brake light12 V, 5/21 W ´1
Front flasher light12 V, 21 W ´2
Rear flasher light12 V, 21 W ´2
Auxiliary light12 V, 4 W ´1
12 V, 3.4 W ´1 (GB only)
Meter light12 V, 3.4 W ´2
Neutral indicator light12 V, 3.4 W ´1
High beam indicator light12 V, 3.4 W ´1
Oil level indicator light12 V, 3.4 W ´1
Turn indicator light12 V, 3.4 W ´1
Fuse
Main10 A
3MB-9-E7 12/27/00 2:52 PM Page 86

8-5
1
2
3
4
5
6
78
9
SPECIFICATIONS
EAU01064
HOW TO USE THE CONVERSION TABLEAll specification data in this manual are listed in SI and
METRIC UNITS.
Use this table to convert METRIC unit data to
IMPERIAL unit data.
Ex.
METRICMULTIPLIERIMPERIAL
** mm´0.03937=** in
2 mm´0.03937=0.08 in
METRIC TO IMPERIAL
Metric unitMultiplierImperial unit
m¥kg7.233ft¥lb
Torquem¥kg86.794in¥lb
cm¥kg0.0723ft¥lb
cm¥kg0.8679in¥lb
Weightkg2.205lbg0.03527oz
Speedkm/hr0.6214mph
km0.6214mi
m3.281ft
Distancem1.094yd
cm0.3937in
mm0.03937in
cc (cm3)0.03527oz (IMP liq.)
Volume/cc (cm3)0.06102cu¥in
Capacitylt (liter)0.8799qt (IMP liq.)lt (liter)0.2199gal (IMP liq.)
kg/mm55.997lb/in
Misc.kg/cm214.2234psi (lb/in2)Centigrade(¡C)
9/5 + 32
Fahrenheit(¡F)
CONVERSION TABLE
3MB-9-E7 12/27/00 2:52 PM Page 87

1
2
3
4
5
6
7
89
9-1
EAU01039
CONSUMER INFORMATION
1
1
EAU02944
Identification number
recordsRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided for assistance when order-
ing spare parts from a Yamaha deal-
er or for reference in case the vehicle
is stolen.
1.KEY IDENTIFICATION
NUMBER:
2.VEHICLE IDENTIFICATION
NUMBER:
3.MODEL LABEL INFORMATION:
EAU01042
Key identification numberThe key identification number is
stamped on the key.
Record this number in the space pro-
vided and use it for reference when
obtaining a new key.
EAU01043
Vehicle identification
numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in
your state.
1.Key identification number1.Vehicle identification number
1
6
3MB-9-E7 12/27/00 2:52 PM Page 88

9-2
CONSUMER INFORMATION
1
2
3
4
5
6
7
89
1
EAU01049
Model labelThe model label is affixed to the loca-
tion shown in the figure. Record the
information on this label in the space
provided. This information will be
needed to order spare parts from
your Yamaha dealer.1.Model label
3MB-9-E7 12/27/00 2:52 PM Page 89
