Scooter care and stora ge
7-3
7
After cleanin
g
1. Dry the scooter with a chamois or an absorbing cloth.
2. Use a chrome polish to shine chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
3. To prevent corrosion, it is recom- mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
4. Use spray oil as a universal clean- er to remove any remaining dirt.
5. Touch up minor paint damage caused by stones, etc.
6. Wax all painted surfaces.
7. Let the scooter dry completely be- fore storing or covering it.
WARNING
EWA10943
Contaminants on the b rakes or tires
can cause loss of control.  Make sure that there is no oil or
wax on the brakes or tires. If
necessary, clean the brake d
iscs an d b rake linin gs with a
re gular brake disc cleaner or
acetone, an d wash the tires with
warm water an d a mil d d eter-
g ent.
 Before operatin g the scooter
test its brakin g performance
an d cornerin g b ehavior.
NOTICE
ECAU0022
 Apply spray oil an d wax spar-
in gly an d make sure to wipe off
any excess.
 Never apply oil or wax to any
rubber parts, plastic parts or
hea dlig ht, tailli ght and meter
lenses, but treat them with a
suita ble care pro duct.
 Avoi d using abrasive polishin g
compoun ds as they will wear
away the paint.TIP Consult a Yamaha dealer for ad-
vice on what products to use.
 Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight on for a short period of time will
help remove the moisture from the
lens.
U2DSE0E0.book Page 3 Thursday, March 19, 2015 10:34 AM

Scooter care and stora ge
7-4
7
EAU36564
Stora geShort-term
Always store your scooter in a cool, dry
place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the
scooter.NOTICE
ECA10821
 Storin g the scooter in a poorly
ventilate d room or coverin g it
with a tarp, while it is still wet,
will allow water an d humi dity to
seep in an d cause rust.
 To prevent corrosion, avoi d
d amp cellars, sta bles ( because
of the presence of ammonia)
an d areas where stron g chemi-
cals are stored .Long-term
Before storing your scooter for several
months: 1. Follow all the instructions in the “Care” section of this chapter. 2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to protect the cylinder, piston rings,
etc. from corrosion.a. Remove the spark plug cap and spark plug.
b. Pour a teaspoonful of engine oil into the spark plug bore.
c. Install the spark plug cap onto the spark plug, and then place
the spark plug on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder wall with oil.)
e. Remove the spark plug cap from the spark plug, and then
install the spark plug and the
spark plug cap. WARNING! To
prevent dama ge or injury
from sparkin g, make sure to
g roun d the spark plu g elec-
tro des while turnin g the en-
g ine over.
[EWA10952]
4. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the scooter so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
6-28.TIPMake any necessary repairs before
storing the scooter.
U2DSE0E0.book Page 4 Thursday, March 19, 2015 10:34 AM

Specifications
8-1
8
Dimensions:Overall length:1955 mm (77.0 in)
Overall width:
740 mm (29.1 in)
Overall height: 1115 mm (43.9 in)
Seat height: 765 mm (30.1 in)
Wheelbase:
1350 mm (53.1 in)
Ground clearance: 135 mm (5.31 in)
Minimum turning radius: 2000 mm (78.7 in)Wei ght:Curb weight:
127 kg (280 lb)Engine:Engine type:
Liquid cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 125 cm3
Bore × stroke:
52.0 × 58.7 mm (2.05 × 2.31 in)
Compression ratio: 11.2 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
Engine oil:Recommended brand:
YAMALUBE
Type:
SAE 10W-40 or 20W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA or MB
Engine oil quantity: Periodic oil change:
0.90 L (0.95 US qt, 0.79 Imp.qt)Final transmission oil:Type:YAMALUBE 10W-40 or SAE 10W-30 type SE motor oil
Quantity: 0.15 L (0.16 US qt, 0.13 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 0.46 L (0.49 US qt, 0.40 Imp.qt)
Air filter:Air filter element:Oil-coated paper elementFuel:Recommended fuel:Regular unleaded gasoline (Gasohol (E10)
acceptable)
Fuel tank capacity: 6.6 L (1.74 US gal, 1.45 Imp.gal)Fuel injection:Throttle body:
ID mark:2DS1 00Spark plu g(s):Manufacturer/model:
NGK/CPR8EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Dry, centrifugal automaticTransmission:Primary reduction ratio:
1.000
Final drive: Gear
Secondary reduction ratio: 10.208 (56/16 x 35/12)
Transmission type:
V-belt automaticChassis:Frame type:Underbone
010305070 90110
130 ˚F
-20 -10 0 10 20 3040
50 ˚C
SAE 10W-40
SAE 20W-40
U2DSE0E0.book Page 1 Thursday, March 19, 2015 10:34 AM

Specifications
8-2
8
Caster angle:26.00 °
Trail: 92 mm (3.6 in)Front tire:Type:Tubeless
Size: 110/70-13M/C 48P
Manufacturer/model:
DUNLOP/SCOOTSMARTRear tire:Type:Tubeless
Size:
130/70-13M/C 63P
Manufacturer/model: DUNLOP/SCOOTSMARTLoa din g:Maximum load:
168 kg (370 lb)
(Total weight of rider, passenger, cargo
and accessories)Tire air pressure (measure d on col d
tires):
Front (1 person):
150 kPa (1.50 kgf/cm2, 22 psi)
Rear (1 person): 250 kPa (2.50 kgf/cm2, 36 psi)
Front (2 persons):
150 kPa (1.50 kgf/cm2, 22 psi)
Rear (2 persons): 250 kPa (2.50 kgf/cm2, 36 psi)
Front wheel:Wheel type:Cast wheel
Rim size:
13M/C x MT3.00Rear wheel:Wheel type:Cast wheel
Rim size:
13M/C x MT3.50Front brake:Type:
Single disc brake
Operation:
Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Single disc brake
Operation: Left hand operation
Specified brake fluid: DOT 4Front suspension:Type:Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel:
100 mm (3.9 in)Rear suspension:Type:Unit swing Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 90 mm (3.5 in)
Electrical system:System voltage:12 V
Ignition system: TCI
Charging system:
AC magnetoBattery:Model:YTZ7V
Voltage, capacity:
12 V, 6.0 AhBul b volta ge, watta ge × quantity:Headlight:
LED
Brake/tail light:
12 V, LED/10.0 W × 1
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light:
12 V, 5.0 W × 2
Meter lighting: LED
High beam indicator light: LED
Turn signal indicator light:
LED
U2DSE0E0.book Page 2 Thursday, March 19, 2015 10:34 AM

Specifications
8-3
8
Coolant temperature warning light:LED
Engine trouble warning light: LED
ABS warning light:
LEDFuses:Main fuse 1:15.0 A
Main fuse 2:
7.5 A
Taillight fuse: 7.5 A
Signaling system fuse: 7.5 A
ABS control unit fuse:
7.5 A
ABS motor fuse: 30.0 A
ABS solenoid fuse: 15.0 A
U2DSE0E0.book Page 3 Thursday, March 19, 2015 10:34 AM

Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26411
Vehicle i dentification num ber
The vehicle identification number is
stamped into the frame.TIPThe vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensing
authority in your area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26501
Mo del la bel
1. Vehicle identification number1
1. Engine serial number
1. Model label
11
U2DSE0E0.book Page 1 Thursday, March 19, 2015 10:34 AM

Consumer information
9-2
9
The model label is affixed to the inside
of the rear storage compartment. (See
page 3-16.) Record the information on
this label in the space provided. This
information will be needed when order-
ing spare parts from a Yamaha dealer.
U2DSE0E0.book Page 2 Thursday, March 19, 2015 10:34 AM

10-1
10
IndexAABS ....................................................... 3-11
ABS warning light ................................... 3-3
Acceleration and deceleration ................ 5-2
Air filter and V-belt case air filter
elements ............................................. 6-16
Auxiliary light bulb, replacing ................ 6-31BBattery .................................................. 6-28
Brake fluid, changing ............................ 6-24
Brake fluid level, checking .................... 6-22
Brake lever, front .................................. 3-10
Brake lever, rear.................................... 3-11
Brake levers, lubricating ....................... 6-25
Brake light ............................................. 6-32
Braking.................................................... 5-2CCables, checking and lubricating ......... 6-24
Care ........................................................ 7-1
Catalytic converter ................................ 3-14
Centerstand and sidestand, checking and lubricating .................... 6-26
Coolant ................................................. 6-13
Coolant temperature warning light ......... 3-3DDimmer switch ...................................... 3-10EEngine break-in....................................... 5-3
Engine oil and oil strainer...................... 6-10
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-3FFinal transmission oil ............................ 6-12 Front and rear brake lever free play,
checking............................................. 6-21
Front and rear brake pads, checking ... 6-22
Front fork, checking ............................. 6-26
Fuel ....................................................... 3-13
Fuel consumption, tips for reducing ...... 5-3
Fuel tank cap ........................................ 3-12
Fuel tank overflow hose ....................... 3-14
Fuses, replacing ................................... 6-29
HHandlebar switches .............................. 3-10
Headlight .............................................. 6-30
High beam indicator light ....................... 3-3
Horn switch .......................................... 3-10IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-17
Indicator lights and warning lights ......... 3-2KKeyhole shutter ...................................... 3-2MMain switch/steering lock....................... 3-1
Maintenance and lubrication, periodic ... 6-3
Maintenance, emission control system.................................................. 6-2
Matte color, caution ............................... 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-4PPanels, removing and installing .............. 6-7
Parking ................................................... 5-4
Part locations ......................................... 2-1SSafe-riding points ................................... 1-5 Safety information ...................................1-1
Seat .......................................................3-15
Sidestand ..............................................3-17
Spark plug, checking ..............................6-8
Specifications .........................................8-1
Starting off ..............................................5-2
Starting the engine ..................................5-1
Start switch ...........................................3-10
Steering, checking ................................6-27
Storage ...................................................7-4
Storage compartments .........................3-16
TTaillight bulb, replacing .........................6-32
Throttle grip and cable,
checking and lubricating ....................6-25
Throttle grip free play, checking ...........6-18
Tires ......................................................6-19
Tool kit ....................................................6-1
Troubleshooting ....................................6-36
Troubleshooting charts .........................6-37
Turn signal indicator lights ......................3-2
Turn signal light bulb (front),
replacing .............................................6-34
Turn signal light bulb (rear), replacing .............................................6-35
Turn signal switch .................................3-10VValve clearance .....................................6-19
V-belt, checking ....................................6-24
Vehicle identification number ..................9-1WWheel bearings, checking .....................6-27
Wheels ..................................................6-21
U2DSE0E0.book Page 1 Thursday, March 19, 2015 10:34 AM

U2DSE0E0.book Page 2 Thursday, March 19, 2015 10:34 AM

DIC183
PRINTED IN INDONESIA2015.04-*.*×1 CR
Original instructions
