DESCRIPTION
2-2
2
3
4
5
6
7
8
9

EAU10420
Right view
1
3
4
5
7
6
8
92

1. Battery (page 6-27)
2. Fuses (page 6-29)
3. Owner’s tool kit (page 6-1)
4. Front storage compartment (page 3-17)
5. Air filter element (page 6-16)
6. Coolant level check window (page 6-15)
7. V-belt air filter element (right)
8. Centerstand (page 6-25)9. Passenger footrest

INSTRUMENT AND CONTROL FUNCTIONS
3-3
2
34
5
6
7
8
9
To unlock the steering
Push the key in, and then turn it to
“OFF” while still pushing it.
WARNING

EWA10060
Never turn the key to “OFF” or
“LOCK” while the vehicle is moving,
otherwise the electrical systems will
be switched off, which may result in
loss of control or an accident. Make
sure that the vehicle is stopped be-
fore turning the key to “OFF” or
“LOCK”.
EAU33491
(Parking)
The steering is locked, and the taillights
and auxiliary lights are on. The hazard
light and turn signal lights can be turned
on, but all other electrical systems are
off. The key can be removed.
The steering must be locked before the
key can be turned to “ ”.
CAUTION:

ECA11020
Do not use the parking position for
an extended length of time, other-
wise the battery may discharge.
EAU11002
Indicator and warning lights
EAU11030
Turn signal indicator lights “” and
“”
The corresponding indicator light flash-
es when the turn signal switch is
pushed to the left or right.
EAU11080
High beam indicator light “”
This indicator light comes on when the
1. Turn signal indicator lights “ ” and “ ”
2. High beam indicator light “ ”
3. Immobilizer system indicator light “ ”
4. Engine trouble warning light “ ”
5. Anti-lock Brake System (ABS) warning
light “ ” (for ABS models)
1
2
3
4
5
ABS

INSTRUMENT AND CONTROL FUNCTIONS
3-10
1
2
3
4
5
6
7
8
9Right

EAU12360
Pass switch “PASS”
Press this switch to flash the headlight.
EAU12400
Dimmer switch “/”
Set this switch to “” for the high
beam and to “” for the low beam.
EAU12460
Turn signal switch “/”
To signal a right-hand turn, push this
switch to “”. To signal a left-hand
turn, push this switch to “”. When re-leased, the switch returns to the center
position. To cancel the turn signal
lights, push the switch in after it has re-
turned to the center position.
EAU12500
Horn switch “”
Press this switch to sound the horn.
EAU12660
Engine stop switch “/”
Set this switch to “” before starting
the engine. Set this switch to “” to
stop the engine in case of an emergen-
cy, such as when the vehicle overturns
or when the throttle cable is stuck.
EAU12720
Start switch “”
With the sidestand up, push this switch
while applying the front or rear brake to
crank the engine with the starter.
CAUTION:

ECA10050
See page 5-1 for starting instruc-
tions prior to starting the engine.
EAU12731
Hazard switch “”
With the key in the “ON” or “” posi-
tion, use this switch to turn on the haz-
ard light (simultaneous flashing of all
turn signal lights).
The hazard light is used in case of an
emergency or to warn other drivers
when your vehicle is stopped where it
might be a traffic hazard.
CAUTION:

ECA10060
Do not use the hazard light for an ex-
tended length of time, otherwise the
battery may discharge.
1. Engine stop switch “/”
2. Hazard switch “”
3. Start switch “”
123

INSTRUMENT AND CONTROL FUNCTIONS
3-17
2
34
5
6
7
8
9

EAU14502
Storage compartments
Front storage compartment
To open the front storage compart-
ment, slide the lever up, and then pull
on the lever.
To close the front storage compart-
ment, push the lid into the original posi-
tion.
WARNING

EWA11160
Do not store heavy items in this
compartment.
Rear storage compartment
A helmet can be stored in the rear stor-
age compartment under the seat. (Seepage 3-15.) To store a helmet in the
rear storage compartment, place the
helmet upside-down with the front fac-
ing forward.
NOTE:


Some helmets cannot be stored in
the rear storage compartment be-
cause of their size or shape.

Do not leave your scooter unat-
tended with the seat open.
CAUTION:

ECA10080
Keep the following points in mind
when using the storage compart-
ment.

Since the storage compartmentaccumulates heat when ex-
posed to the sun, do not store
anything susceptible to heat in-
side it.

To avoid humidity from spread-
ing through the storage com-
partment, wrap wet articles in a
plastic bag before storing them
in the compartment.

Since the storage compartment
may get wet while the scooter is
being washed, wrap any articles
stored in the compartment in a
plastic bag.

Do not keep anything valuable
or breakable in the storage com-
partment.
CAUTION:

ECA11270
Do not leave the seat open for an ex-
tended period of time, otherwise the
light may cause the battery to dis-
charge.
WARNING

EWA11241

Do not exceed the load limit of
1. Storage compartment opening lever
2. Lid
1
2

1. Rear storage compartment
1

5-1
1
2
3
4
5
6
7
8
9

OPERATION AND IMPORTANT RIDING POINTS
EAU15970
WARNING

EWA11250

Become thoroughly familiar
with all operating controls and
their functions before riding.
Consult a Yamaha dealer re-
garding any control or function
that you do not thoroughly un-
derstand.

Never start the engine or oper-
ate it in a closed area for any
length of time. Exhaust fumes
are poisonous, and inhaling
them can cause loss of con-
sciousness and death within a
short time. Always make sure
that there is adequate ventila-
tion.

For safety, always start the en-
gine with the centerstand down.

When the centerstand is down
and the engine is idling, keep
your hands and feet away from
the rear wheel.
EAU36510
Starting the engine
CAUTION:

ECA10250
See page 5-4 for engine break-in in-
structions prior to operating the ve-
hicle for the first time.
In order for the ignition circuit cut-off
system to enable starting, the side-
stand must be up.
WARNING

EWA10290

Before starting the engine,
check the function of the igni-
tion circuit cut-off system ac-
cording to the procedure
described on page 3-19.

Never ride with the sidestand
down.
1. Turn the key to “ON” and make
sure that the engine stop switch is
set to “”.
CAUTION:

ECA15020
The following warning lights, indica-
tor light and indicators should comeon for a few seconds, then go off.

Engine trouble warning light

ABS warning light (for ABS
models)

Immobilizer system indicator
light

V-belt replacement indicator

Oil change indicator
If a warning light, indicator light or
indicator does not go off, see page
3-3 or 3-5 for the corresponding
warning light, indicator light or indi-
cator circuit check.
2. Close the throttle completely.
3. Start the engine by pushing the
start switch while applying the front
or rear brake.
NOTE:

If the engine does not start, release the
start switch, wait a few seconds, and
then try again. Each starting attempt
should be as short as possible to pre-
serve the battery. Do not crank the en-
gine more than 10 seconds on any one
attempt.

PERIODIC MAINTENANCE AND MINOR REPAIR
6-7
2
3
4
5
67
8
9
2. Remove the cowling screws and
bolts.
3. Unhook the cowling from the hold-
er at the bottom.
4. Unhook the front of the cowling by
pushing it up, and then pull the
cowling out.
To install the cowling
1. Place the cowling in the original
position, and then install the
screws and bolts.2. Install panels C and E.
Cowling C
To remove the cowling
1. Remove the battery cover by re-
moving the screws.
2. Remove the cowling bolts, andthen pull the cowling off.
To install the cowling
1. Place the cowling in the original
position, and then install the bolts.
2. Install the battery cover by install-
ing the screws.

EAU33431
Panels A and D
To remove one of the panels
1. Remove panel C (right side) or
panel E (left side).
2. Remove the panel screws.
3. Pull outward on the front of the
panel.
To install the panelPlace the panel in the original position,

1. Bolt
2. Screw
1(×2)2(×2)

1. Bolt
2. Screw
1
2

1. Screw
1(x6)
1

PERIODIC MAINTENANCE AND MINOR REPAIR
6-27
2
3
4
5
67
8
9

EAU23290
Checking the wheel bearings
The front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer check
the wheel bearings.
EAU23411
Battery
This model is equipped with a
sealed-type (MF) battery, which does
not require any maintenance. There is
no need to check the electrolyte or to
add distilled water.
To access the battery
1. Open the seat. (See page 3-15.)
2. Remove the battery cover by re-
moving the screws.
1. Screw
2. Battery cover
1
2

PERIODIC MAINTENANCE AND MINOR REPAIR
6-28
1
2
3
4
5
6
7
8
9To charge the battery
Have a Yamaha dealer charge the bat-
tery as soon as possible if it seems to
have discharged. Keep in mind that the
battery tends to discharge more quickly
if the vehicle is equipped with optional
electrical accessories.
WARNING

EWA10760

Electrolyte is poisonous and
dangerous since it contains sul-
furic acid, which causes severe
burns. Avoid any contact with
skin, eyes or clothing and al-
ways shield your eyes when
working near batteries. In caseof contact, administer the fol-
lowing FIRST AID.

EXTERNAL: Flush with plenty
of water.

INTERNAL: Drink large quan-
tities of water or milk and im-
mediately call a physician.

EYES: Flush with water for 15
minutes and seek prompt
medical attention.

Batteries produce explosive hy-
drogen gas. Therefore, keep
sparks, flames, cigarettes, etc.,
away from the battery and pro-
vide sufficient ventilation when
charging it in an enclosed
space.

KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
To store the battery
1. If the vehicle will not be used for
more than one month, remove the
battery, fully charge it, and then
place it in a cool, dry place.
2. If the battery will be stored for morethan two months, check it at least
once a month and fully charge it if
necessary.
3. Fully charge the battery before in-
stallation.
4. After installation, make sure that
the battery leads are properly con-
nected to the battery terminals.
CAUTION:

ECA10630

Always keep the battery
charged. Storing a discharged
battery can cause permanent
battery damage.

To charge a sealed-type (MF)
battery, a special (constant-volt-
age) battery charger is required.
Using a conventional battery
charger will damage the battery.
If you do not have access to a
sealed-type (MF) battery charg-
er, have a Yamaha dealer
charge your battery.
1. Battery
1

PERIODIC MAINTENANCE AND MINOR REPAIR
6-29
2
3
4
5
67
8
9

EAU36542
Replacing the fuses
The main fuse box is located beside the
battery and can be accessed as fol-
lows:
1. Open the seat. (See page 3-15.)
2. Remove the battery cover. (See
page 6-27.)
3. Disconnect the negative battery
lead, and then lift the battery as
shown.
For non-ABS modelsFor ABS models
The fuse box, which contains the fuses
for the individual circuits, is located un-
der the battery cover and can be ac-
cessed as follows.
1. Open the seat. (See page 3-15.)
2. Remove the battery cover.
For non-ABS models

1. Main fuse
2. Spare main fuse
3. Negative battery lead
4. Fuse box
5. Parking lighting fuse
3
2
4
51

1. Main fuse
2. Spare main fuse
3. Negative battery lead
4. Fuse box
5. ABS control unit fuse (for ABS models)
6. Parking lighting fuse
7. Spare fuse
8. ABS motor fuse (for ABS models)
3
2
4
1
8
765

1. Signaling system fuse
2. Headlight fuse
3. Ignition fuse
4. Radiator fan fuse
5. Electronic fuel injection fuse
6. Backup fuse (for odometer and clock)
7. Spare fuse
7
123456
