INTRODUCTION
EAU41803
Congratulations on your purchase of the Yamaha TT-R50E/TT-R50EY. This model is the result of Yamaha’s vast experience
in the production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship
and reliability that have made Yamaha a leader in these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance of this motorcycle. If you
have any questions concerning the operation or maintenance of your motorcycle, please consult a Yamaha dealer.
The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for clean air applicable at
the date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation of the
motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the
recommended maintenance schedules and operating instructions contained within this manual.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10031
Please read this manual carefully and completely before operating this motorcycle.
WARNING
EWA14351
This motorcycle is designed and manufactured for off-road use only. It is illegal to operate this motorcycle on any
public street, road or highway. Such use is prohibited by law. This motorcycle complies with almost all state off-
highway noise level and spark arrester laws and regulations. Please check your local riding laws and regulationsbefore operating this motorcycle.
AN IMPORTANT SAFETY MESSAGE:

Read this manual completely before operating your motorcycle. Make sure you understand all instructions.


Pay close attention to the warning and notice labels on the motorcycle.


Never operate a motorcycle without proper training or instruction.


Weight of the rider should not exceed 40.0 kg (88 lb).
U1P683E0.book Page 1 Tuesday, April 29, 2008 2:05 PM

INTRODUCTIONAN IMPORTANT NOTE TO PARENTS:
This motorcycle is not a toy. Before you let your child ride this motorcycle, you should understand the instructions and warn-
ings in this Owner’s Manual. Then be sure your child understands and will follow them. Children differ in skills, physical abil-
ities, and judgment. Some children may not be able to operate a motorcycle safely. Parents should supervise their child’s
use of the motorcycle at all times. Parents should permit continued use only if they determine that the child has the ability to
operate the motorcycle safely.
Your motorcycle was delivered with an adjustable speed limiter. Yamaha recommends that all beginners start off with the
speed limiter adjusting screw turned in to limit the amount of speed available while they learn. The adjusting screw may be
gradually turned out to increase maximum speed as the beginner becomes more familiar with operating the motorcycle. Par-
ents should decide when to adjust the motorcycle for more power as their youngster’s riding skills improve.
Motorcycles are single track vehicles. Their safe use and operation are dependent upon the use of proper riding
techniques as well as the expertise of the operator. Every operator should know the following requirements before
riding this motorcycle.
He or she should:

Obtain thorough instructions from a competent source on all aspects of motorcycle operation.


Observe the warnings and maintenance requirements in this Owner’s Manual.


Obtain qualified training in safe and proper riding techniques.


Obtain professional technical service as indicated in this Owner’s Manual and/or when made necessary by mechanical
conditions.
U1P683E0.book Page 2 Tuesday, April 29, 2008 2:05 PM

IMPORTANT MANUAL INFORMATION
EAU10132
Particularly important information is distinguished in this manual by the following notations:
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICETIP
U1P683E0.book Page 1 Tuesday, April 29, 2008 2:05 PM

IMPORTANT MANUAL INFORMATION
EAU37230
TT-R50E/TT-R50EY
OW N E R’S MANUAL
©2008 by Yamaha Motor Co., Ltd.
1st edition, April 2008
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in China.
U1P683E0.book Page 2 Tuesday, April 29, 2008 2:05 PM

TABLE OF CONTENTS
SAFETY INFORMATION .................. 1-1
DESCRIPTION .................................. 2-1
Left view .......................................... 2-1
Right view ........................................ 2-2
Controls and instruments ................2-3
INSTRUMENT AND CONTROL
FUNCTIONS....................................... 3-1
Main switch ..................................... 3-1
Handlebar switches ........................ 3-1
Speed limiter .................................. 3-2
Shift pedal ......................................3-3
Brake lever ..................................... 3-3
Brake pedal .................................... 3-3
Fuel tank cap .................................. 3-4
Fuel ................................................ 3-4
Fuel tank breather hose ................. 3-6
Fuel cock ........................................ 3-6
Starter (choke) lever ....................... 3-7
Seat ................................................ 3-7
Sidestand ....................................... 3-8
Starting circuit cut-off system ......... 3-8
FOR YOUR SAFETY –
PRE-OPERATION CHECKS.............. 4-1
Pre-operation check list .................. 4-2OPERATION AND IMPORTANT
RIDING POINTS................................ 5-1
Starting and warming up a cold
engine ......................................... 5-1
Starting a warm engine .................. 5-2
Shifting ........................................... 5-2
Engine break-in .............................. 5-3
Parking ........................................... 5-4
PERIODIC MAINTENANCE AND
ADJUSTMENT................................... 6-1
Periodic maintenance chart for
the emission control system ....... 6-2
General maintenance and
lubrication chart .......................... 6-3
Checking the spark plug ................ 6-5
Engine oil ....................................... 6-6
Cleaning the air filter element ........ 6-8
Cleaning the spark arrester ........... 6-9
Adjusting the carburetor ............... 6-10
Adjusting the engine idling
speed ........................................ 6-11
Adjusting the throttle cable free
play ........................................... 6-11
Valve clearance ........................... 6-12
Tires ............................................. 6-12
Spoke wheels .............................. 6-14
Adjusting the clutch free play ....... 6-14
Adjusting the brake lever free
play ........................................... 6-15Adjusting the brake pedal free
play ........................................... 6-16
Checking the shift pedal ............... 6-16
Checking the front and rear brake
shoes ........................................ 6-17
Drive chain slack .......................... 6-17
Cleaning and lubricating the drive
chain ......................................... 6-19
Checking and lubricating
the cables ................................. 6-20
Checking and lubricating
the throttle grip and cable ......... 6-20
Checking and lubricating
the brake lever .......................... 6-20
Checking and lubricating
the brake pedal ......................... 6-21
Checking and lubricating
the sidestand ............................ 6-21
Lubricating the swingarm pivots ... 6-21
Checking the front fork ................. 6-22
Checking the steering .................. 6-22
Checking the wheel bearings ....... 6-23
Battery .......................................... 6-23
Replacing the fuse ....................... 6-25
Supporting the motorcycle ........... 6-25
Front wheel .................................. 6-26
Rear wheel ................................... 6-28
Troubleshooting ........................... 6-29
Troubleshooting chart .................. 6-31
U1P683E0.book Page 1 Tuesday, April 29, 2008 2:05 PM

TABLE OF CONTENTSMOTORCYCLE CARE AND
STORAGE..........................................7-1
Matte color caution .........................7-1
Care ................................................7-1
Storage ...........................................7-3
SPECIFICATIONS .............................8-1
CONSUMER INFORMATION.............9-1
Identification numbers ....................9-1U1P683E0.book Page 2 Tuesday, April 29, 2008 2:05 PM
