6-3
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU03685
Periodic maintenance and lubrication chart
NOTE:
8The annual checks must be performed every year, except if a kilometer-based maintenance is performed instead.
8From 50,000 km, repeat the maintenance intervals starting from 10,000 km.
8Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and
technical skills.NO.ITEMCHECK OR MAINTENANCE JOBODOMETER READING (´ 1,000 km)
ANNUAL
CHECK
110203040
1
*Fuel line¥Check fuel hoses for cracks or damage.ÖÖÖÖÖ
2Spark plug¥Check condition.
¥Clean and regap.ÖÖ
¥Replace.ÖÖ
3*Valves¥Check valve clearance.
¥Adjust.ÖÖÖÖ
4Air filter element¥Clean.ÖÖ
¥Replace.ÖÖ
5Clutch¥Check operation.
¥Adjust.ÖÖÖÖÖ
6*Front brake¥Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-5.)ÖÖÖÖÖÖ
¥Replace brake pads.Whenever worn to the limit
7*Rear brake¥Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-5.)ÖÖÖÖÖÖ
¥Replace brake pads.Whenever worn to the limit
8*Brake hoses¥Check for cracks or damage.ÖÖÖÖÖ
¥Replace. (See NOTE on page 6-5.)Every 4 years
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 4

Inspection
The spark plug is an important
engine component and is easy to
inspect. The condition of the spark
plug can indicate the condition of the
engine.
The ideal color on the white insulator
around the center electrode is a
medium-to-light tan color for a motor-
cycle that is being ridden normally.
Do not attempt to diagnose such
problems yourself. Instead, take the
motorcycle to a Yamaha dealer. You
should periodically remove and
inspect the spark plug because heat
and deposits will cause any spark
plug to slowly break down and erode.
If electrode erosion becomes exces-
sive, or if carbon and other deposits
are excessive, you should replace
the spark plug with the specified plug.Installation
1.Measure the electrode gap with
a wire thickness gauge and, if
necessary, adjust the gap to
specification.
2.Clean the gasket surface. Wipe
off any grime from the threads.
3.Install the spark plug and tighten
it to the specified torque.
NOTE:
If a torque wrench is not available
when you are installing a spark plug,
a good estimate of the correct torque
is 1/4 to 1/2 turn past finger tight.
Have the spark plug tightened to the
specified torque as soon as possible.4.Install the spark plug cap.
6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
Specified spark plug:
DPR8EA-9 or
DPR9EA-9 (NGK)
Spark plug gap:
0.8 ~ 0.9 mmTightening torque:
Spark plug:
17.5 Nm (1.75 m0kg)
1
1.Spark plug gap
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 10

6-16
EW000083
wProper loading of your motorcycle
is important for several character-
istics of your motorcycle, such as
handling, braking, performance
and safety. Do not carry loosely
packed items that can shift.
Securely pack your heaviest items
close to the center of the motorcy-
cle, and distribute the weight even-
ly from side to side. Properly
adjust the suspension for your
load, and check the condition and
pressure of your tires. NEVER
OVERLOAD YOUR MOTORCYCLE.
Make sure the total weight of the
cargo, rider, passenger, and
accessories (fairing, saddlebags,
etc. if approved for this model)
does not exceed the maximum
load of the motorcycle. Operation
of an overloaded motorcycle could
cause tire damage, an accident, or
even injury.
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
1
2
Tire inspection
Always check the tires before operat-
ing the motorcycle. If center tread
depth reaches the limit as shown, if
the tire has a nail or glass fragments
in it, or if the side wall is cracked,
contact a Yamaha dealer immediate-
ly and have the tire replaced.1.Tread depth
2.Side wall
EW000078
wAfter extensive tests, the tires
mentioned below have been
approved by Yamaha Motor Co.,
Ltd. for this model. No guarantee
for handling characteristics can be
given if tire combinations other
than what is approved are used on
this motorcycle. The front and rear
tires should be of the same manu-
facture and design.ManufacturerSizeTypeBRIDGESTONE90/90-21 54STW47
DUNLOP90/90-21 54STRAIL MAX LFRONTManufacturerSizeTypeBRIDGESTONE120/90-17 64STW48
DUNLOP120/90-17 64STRAIL MAXREAR
Minimum tire tread
depth 0.8 mm
(front and rear)
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 17

6-17
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU00685
WheelsTo ensure maximum performance,
long service, and safe operation, note
the following:
8Always inspect the wheels
before a ride. Check for cracks,
bends or warpage of the wheel.
Be sure the spokes are tight and
undamaged. If any abnormal
condition exists in a wheel, con-
sult a Yamaha dealer. Do not
attempt even small repairs to the
wheel. If a wheel is deformed or
cracked, it must be replaced.
8Tires and wheels should be bal-
anced whenever either one is
changed or replaced. Failure to
have a wheel balanced can
result in poor performance,
adverse handling characteristics,
and shortened tire life.
8Ride at moderate speeds after
changing a tire since the tire sur-
face must first be broken in for it
to develop its optimal character-
istics.
EAU00681
w8 8
Operating the motorcycle with
excessively worn tires
decrease riding stability and
can lead to loss of control.
Have excessively worn tires
replaced by a Yamaha dealer
immediately. Brakes, tires, and
related wheel parts replace-
ment should be left to a
Yamaha Service Technician.
8 8
Patching a punctured tube is
not recommended. If it is
absolutely necessary to do so,
use great care and replace the
tube as soon as possible with
a good quality replacement.
NOTE:
These limits may be different by regu-
lation from country to country. If so,
conform to the limits specified by the
regulations of your own country.
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 18

6-24
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EC000097
cCBe sure to oil the chain after wash-
ing the motorcycle or riding in the
rain.
EAU00773
Throttle cable and grip
lubricationThe throttle twist grip assembly
should be greased at the time that
the cable is lubricated, since the grip
must be removed to get at the end of
the throttle cable. After removing the
screws, hold the end of the cable up
in the air and put in several drops of
lubricant. With the throttle grip disas-
sembled, coat the metal surface of
the grip assembly with a suitable all-
purpose grease.
EAU02962
Cable inspection and
lubrication
EW000112
wDamage to the outer housing of
cables may lead to internal rusting
and interfere with the cable move-
ment. Replace damaged cables as
soon as possible to prevent unsafe
conditions.Lubricate the cables and cable ends.
If a cable does not operate smoothly,
ask a Yamaha dealer to replace it.
Recommended lubricant:
Engine oil
4PT-9-E6 (ENG) 6 12/27/00 1:29 PM Page 25

EW000115
wSecurely support the motorcycle
so there is no danger of it falling
over.
6-27
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
56
7
8
9
EAU01144
Wheel bearingsIf there is play in the front or rear
wheel hub or if the wheel does not
turn smoothly, have a Yamaha dealer
inspect the wheel bearings.
EAU00794
Steering inspectionPeriodically inspect the condition of
the steering. Worn out or loose steer-
ing bearings may be dangerous.
Place a stand under the engine to
raise the front wheel off the ground.
Hold the lower end of the front forks
and try to move them forward and
backward. If any free play can be felt,
ask a Yamaha dealer to inspect and
adjust the steering. Inspection is eas-
ier if the front wheel is removed.
