EAU01038
SPECIFICATIONS
Specifications
Model XV125S
Dimensions
Overall length 2,190 mm
Overall width 805 mm
Overall height 1,140 mm
Seat height 685 mm
Wheel base 1,495 mm
Ground clearance 145 mm
Minimum turning radius 2,800 mm
Basic weight (with oil and full
fuel tank)147 kg
Engine
Engine type Air-cooled 4-stroke, SOHC,
gasoline
Cylinder arrangement V-type 2-cylinder
Displacement 124 cm
3
Bore ´Stroke 41.0 ´47.0 mm
Compression ratio 10.7:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Type
Recommended engine oil
classification API Service SE, SF, SG type
or higher
cC
Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled “Energy
Conserving”) contain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting in reduced
component life and poor engine performance.
Quantity
Periodic oil change 1.4 L
With oil filter replacement 1.6 L
Total amount 1.7 L
Air filterWet type element
8-1
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
