YAMAHA XVS1100A 2000 Workshop Manual

PERIODIC MAINTENANCE AND MINOR REPAIR
6-2
6
EAU00473
Periodic maintenance and lubrication chart
CP-02ENO. ITEM CHECKS AND MAINTENANCE JOBSInitial
1,000 kmEvery Every
Annual
check
6,000 km 12,000 km
1
*Fuel line• Check fuel hoses for cracks or damage.
• Replace if necessary. ÖÖ
2*Fuel filter• Check condition.
• Replace if necessary.Ö
3 Spark plugs• Check condition.
• Clean, regap or replace if necessary.Ö
4*Valves • Check valve clearance.
• Adjust if necessary.Ö
5 Air filter• Clean or replace if necessary.Ö
6Clutch• Check operation.
• Adjust or replace cable.ÖÖ
7*Front brake• Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-4.)
• Correct accordingly.
• Replace brake pads if necessary.ÖÖ Ö
8*Rear brake• Check operation, fluid level and vehicle for fluid leakage.
(See NOTE on page 6-4.)
• Correct accordingly.
• Replace brake pads if necessary.ÖÖ Ö
9*Wheels• Check balance, runout, spoke tightness and for damage.
• Tighten spokes and rebalance, replace if necessary.Ö
10*Brake hoses• Check for cracks or damage.
• Replace if necessary.ÖÖ
11*Tires• Check tread depth and for damage.
• Replace if necessary.
• Check air pressure.
• Correct if necessary.Ö
E_5KS.book Page 2 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-3
6
12
*Wheel bearings• Check bearing for looseness or damage.
• Replace if necessary. Ö
13*Swingarm• Check swingarm pivoting point for play.
• Correct if necessary.
• Lubricate with molybdenum disulfide grease every 24,000 km or
24 months (whichever comes first).Ö
14*Steering bearings• Check bearing play and steering for roughness.
• Correct accordingly.
• Lubricate with lithium soap base grease every 24,000 km or
24 months (whichever comes first).ÖÖÖ
15*Chassis fasteners• Make sure that all nuts, bolts and screws are properly tightened.
• Tighten if necessary.ÖÖ
16 Sidestand• Check operation.
• Lubricate and repair if necessary.ÖÖ
17*Sidestand switch• Check operation.
• Replace if necessary.ÖÖ Ö
18*Front fork• Check operation and for oil leakage.
• Correct accordingly.Ö
19*Rear shock absorber
assembly• Check operation and shock absorber for oil leakage.
• Replace shock absorber assembly if necessary. Ö
20*Carburetors• Check engine idling speed, synchronization and starter operation.
• Adjust if necessary.ÖÖ Ö
21 Engine oil• Check oil level and vehicle for oil leakage.
• Correct if necessary.
• Change. (Warm engine before draining.)ÖÖ Ö
22*Engine oil filter element•Replace.ÖÖ
23 Final gear oil• Check oil level and vehicle for oil leakage.
• Change oil at initial 1,000 km and thereafter every 24,000 km or
24 months (whichever comes first).ÖÖÖ
24 Moving parts and cables• Lubricate if necessary.ÖÖ NO. ITEM CHECKS AND MAINTENANCE JOBSInitial
1,000 kmEvery Every
Annual
check
6,000 km 12,000 km
E_5KS.book Page 3 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-4
6
* Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service.
EAU03206
NOTE:@ l
The annual checks must be performed every year except if a 6,000 km or 12,000 km maintenance is performed instead.
l
The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
l
Hydraulic brake service
• Regularly check and, if necessary, correct the brake fluid level.
• Every two years replace the internal components of the brake master cylinder and caliper, and change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged.
@ 25
*Air induction system• Check the air cut valve and reed valve for damage.
• Replace the entire air induction system if necessary.Ö
26*Lights, signals and
switches• Check operation.
• Correct if necessary.
• Adjust headlight beam if necessary.ÖÖ Ö NO. ITEM CHECKS AND MAINTENANCE JOBSInitial
1,000 kmEvery Every
Annual
check
6,000 km 12,000 km
E_5KS.book Page 4 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-5
6
EAU01777
Removing and installing the
panel The panel shown above needs to be
removed to perform some of the main-
tenance jobs described in this chapter.
Refer to this section each time the pan-
el needs to be removed and installed.
EAU00491
Panel A
To remove the panelRemove the bolt, and then pull the pan-
el off as shown.To install the panel
Place the panel in the original position,
and then install the bolt.
1. Panel A
1. Bolt
E_5KS.book Page 5 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-6
6
EAU01673
Checking the spark plugs The spark plugs are important engine
components, which are easy to check.
Since heat and deposits will cause any
spark plug to slowly erode, the spark
plugs should be removed and checked
in accordance with the periodic mainte-
nance and lubrication chart. In addition,
the condition of the spark plugs can re-
veal the condition of the engine.
To remove a spark plug
1. Remove the appropriate spark
plug cover (rear right or front left)
by pulling it off as shown.
2. Remove the spark plug cap.3. Remove the spark plug as shown,
with the spark plug wrench includ-
ed in the owner’s tool kit.
To check the spark plugs
1. Check that the porcelain insulator
around the center electrode on
each spark plug is a medi-
um-to-light tan (the ideal color
when the motorcycle is ridden nor-
mally).
2. Check that all spark plugs installed
in the engine have the same color.
NOTE:@ If any spark plug shows a distinctly dif-
ferent color, the engine could be defec-
tive. Do not attempt to diagnose such
problems yourself. Instead, have a
Yamaha dealer check the motorcycle. @3. Check each spark plug for elec-
trode erosion and excessive car-
bon or other deposits, and replace
it if necessary.
1. Spark plug cover
1. Spark plug wrench
Specified spark plug:
BPR7ES (NGK) or
W22EPR-U (DENSO)
E_5KS.book Page 6 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-7
6To install a spark plug
1. Measure the spark plug gap with a
wire thickness gauge and, if nec-
essary, adjust the gap to specifica-
tion.
2. Clean the surface of the spark
plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
3. Install the spark plug with the
spark plug wrench, and then tight-
en it to the specified torque.
NOTE:@ If a torque wrench is not available when
installing a spark plug, a good estimate
of the correct torque is 1/4–1/2 turn
past finger tight. However, the spark
plug should be tightened to the speci-
fied torque as soon as possible. @4. Install the spark plug cap.
5. Place the spark plug cover in the
original position.
EAU01712
Engine oil and oil filter
element The engine oil level should be checked
before each ride. In addition, the oil
must be changed and the oil filter ele-
ment replaced at the intervals specified
in the periodic maintenance and lubri-
cation chart.
To check the engine oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.
a. Spark plug gapSpark plug gap:
0.7–0.8 mm
Tightening torque:
Spark plug:
20 Nm (2.0 m·kg)
1. Oil level check window
2. Maximum level mark
3. Minimum level mark
E_5KS.book Page 7 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-8
6
NOTE:Make sure that the motorcycle is posi-
tioned straight up when checking the oil
level. A slight tilt to the side can result in
a false reading. @2. Start the engine, warm it up for sev-
eral minutes, and then turn it off.
3. Wait a few minutes until the oil set-
tles, and then check the oil level
through the check window located
at the bottom-left side of the crank-
case.NOTE:@ The engine oil should be between the
minimum and maximum level marks.@4. If the engine oil is below the mini-
mum level mark, add sufficient oil
of the recommended type to raise
it to the correct level.To change the engine oil without oil
filter element replacement
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the engine
to collect the used oil.
3. Remove the engine oil filler cap
and drain bolt to drain the oil from
the crankcase.4. Install the engine oil drain bolt, and
then tighten it to the specified
torque.
5. Add the specified amount of the
recommended engine oil, and
then install and tighten the oil filler
cap.
1. Engine oil filler cap
1. Engine oil drain boltTightening torque:
Engine oil drain bolt:
43 Nm (4.3 m·kg)
E_5KS.book Page 8 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-9
6
EC000072
CAUTION:@ l
In order to prevent clutch slip-
page (since the engine oil also
lubricates the clutch), do not
mix any chemical additives
with the oil or use oils of a
higher grade than “CD”. In ad-
dition, do not use oils labeled
“ENERGY CONSERVING II” or
higher.
l
Make sure that no foreign mate-
rial enters the crankcase.
@
6. Start the engine, and then let it idle
for several minutes while checking
it for oil leakage. If oil is leaking,
immediately turn the engine off
and check for the cause.NOTE:@ After the engine is started, the engine
oil level warning light should go off if the
oil level is sufficient. @
EC000067
CAUTION:@ If the oil level warning light flickers
or remains on, immediately turn the
engine off and have a Yamaha deal-
er check the vehicle. @7. Turn the engine off, and then
check the oil level and correct it if
necessary.NOTE:@ Have a Yamaha dealer replace the oil
filter element when necessary. @
EAU02943
Final gear oil The final gear case must be checked
for oil leakage before each ride. If any
leakage is found, have a Yamaha deal-
er check and repair the motorcycle. In
addition, the final gear oil level must be
checked and the oil changed as follows
at the intervals specified in the periodic
maintenance and lubrication chart.
EW000066
WARNING
@ l
Make sure that no foreign mate-
rial enters the final gear case.
l
Make sure that no oil gets on
the tire or wheel.
@
Recommended engine oil:
See page 8-1.
Oil quantity:
Without oil filter element replace-
ment:
3.0 L
With oil filter element replace-
ment:
3.1 L
Total amount (dry engine):
3.6 L
E_5KS.book Page 9 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-10
6 To check the final gear oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.
NOTE:@ l
The final gear oil level must be
checked on a cold engine.
l
Make sure that the motorcycle is
positioned straight up when check-
ing the oil level. A slight tilt to the
side can result in a false reading.
@2. Remove the oil filler bolt, and then
check the oil level in the final gear
case.
NOTE:@ The oil level should be at the brim of
the filler hole. @3. If the oil is below the brim of the fill-
er hole, add sufficient oil of the rec-
ommended type to raise it to the
correct level.
To change the final gear oil
1. Place an oil pan under the final
gear case to collect the used oil.
2. Remove the oil filler bolt and drain
bolt to drain the oil from the final
gear case.
3. Install the final gear oil drain bolt,
and then tighten it to the specified
torque.
4. Add the recommended final gear
oil to the brim of the filler hole.
NOTE:@ GL4 is a quality rating. Hypoid gear oils
rated GL5 or GL6 may also be used. @5. Install and tighten the filler bolt to
the specified torque.
6. Check the final gear case for oil
leakage. If oil is leaking, check for
the cause.
1. Final gear oil drain bolt
2. Final gear oil filler bolt
3. Proper oil level
Tightening torque:
Final gear oil drain bolt:
23 Nm (2.3 m·kg)
Recommended final gear oil:
Hypoid gear oil SAE 80 (API GL4)
or multigrade hypoid gear oil SAE
80W-90
Oil quantity:
0.2 L
Tightening torque:
Final gear oil filler bolt:
23 Nm (2.3 m·kg)
E_5KS.book Page 10 Monday, August 21, 2000 10:48 AM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-11
6
EAU03195
Cleaning the air filter element The air filter element should be cleaned
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart. Clean the air filter element
more frequently if you are riding in un-
usually wet or dusty areas.
1. Remove the air filter case cover by
removing the screws.
2. Pull the air filter element out.3. Lightly tap the air filter element to
remove most of the dust and dirt,
and then blow the remaining dirt
out with compressed air as shown.
If the air filter element is damaged,
replace it.4. Insert the air filter element into the
air filter case as shown.
EC000082
CAUTION:@ l
Make sure that the air filter ele-
ment is properly seated in the
air filter case.
l
The engine should never be op-
erated without the air filter ele-
ment installed, otherwise the
piston(s) and/or cylinder(s) may
become excessively worn.
@5. Install the air filter case cover by
installing the screws.
1. Air filter case cover
2. Screw (´ 3)
1. Air filter element
2. Projection
3. Tab
E_5KS.book Page 11 Monday, August 21, 2000 10:48 AM
