TABLE OF CONTENTS
Adjusting the clutch lever free play ................. 6-19
Adjusting the brake lever free play .................. 6-20
Adjusting the brake pedal position and
free play ....................................................... 6-20
Adjusting the rear brake light switch ............... 6-22
Checking the front brake pads and
rear brake shoes ......................................... 6-22
Checking the brake fluid level ......................... 6-23
Changing the brake fluid ................................. 6-24
Drive chain slack ............................................. 6-24
Lubricating the drive chain .............................. 6-26
Checking and lubricating the cables ............... 6-27
Checking and lubricating the brake and
shift pedals .................................................. 6-27
Checking and lubricating the brake and
clutch levers ................................................ 6-28
Checking and lubricating the sidestand .......... 6-28
Checking the front fork .................................... 6-28
Checking the steering ..................................... 6-29
Checking the wheel bearings .......................... 6-30
Battery ............................................................. 6-30
Replacing the fuses ........................................ 6-32
Replacing the headlight bulb ........................... 6-33
Replacing the tail/brake light bulb ................... 6-35
Replacing a turn signal light bulb .................... 6-36
Supporting the motorcycle .............................. 6-36
Front wheel ..................................................... 6-37
Rear wheel ...................................................... 6-39Troubleshooting .............................................. 6-40
Troubleshooting chart ..................................... 6-41
MOTORCYCLE CARE AND STORAGE ............. 7-1
Care .................................................................. 7-1
Storage ............................................................. 7-4
SPECIFICATIONS ............................................... 8-1
Specifications .................................................... 8-1
Conversion table ............................................... 8-5
CONSUMER INFORMATION.............................. 9-1
Identification numbers ....................................... 9-1
Key identification number .................................. 9-1
Vehicle identification number ............................ 9-1
Model label ........................................................ 9-2
789
E_5kr.book Page 2 Tuesday, September 12, 2000 4:46 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-33
6
EAU03188
Replacing the headlight bulb This motorcycle is equipped with a
quartz bulb headlight. If the headlight
bulb burns out, replace it as follows.
1. Remove the headlight unit by re-
moving the screws.2. Disconnect the headlight coupler,
and then remove the headlight unit
and bulb cover.1. Screw (´ 2)
1. Headlight coupler
1. Headlight bulb cover
E_5kr.book Page 33 Tuesday, September 12, 2000 4:46 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-34
63. Unhook the headlight bulb holder,
and then remove the defective
bulb.
EW000119
WARNING
_ Headlight bulbs get very hot. There-
fore, keep flammable products away
from a lit headlight bulb, and do not
touch the bulb until it has cooled
down. _4. Place a new bulb into position, and
then secure it with the bulb holder.
EC000105
CAUTION:_ Do not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the bulb,
and the bulb life will be adversely af-
fected. Thoroughly clean off any dirt
and fingerprints on the headlight
bulb using a cloth moistened with
alcohol or thinner. _5. Install the bulb cover, and then
connect the coupler.6. Install the headlight unit by install-
ing the screws.
7. Have a Yamaha dealer adjust the
headlight beam if necessary.
1. Headlight bulb holder
1. Do not touch this area.
E_5kr.book Page 34 Tuesday, September 12, 2000 4:46 PM

SPECIFICATIONS
8-3
8
Maximum load* 180 kg
Tire air pressure (measured
on cold tires)
Up to 90 kg*
Front 175 kPa (1.75 kg/cm
2, 1.75 bar)
Rear 200 kPa (2.00 kg/cm2, 2.00 bar)
90 kg–maximum*
Front 225 kPa (2.25 kg/cm2, 2.25 bar)
Rear 225 kPa (2.25 kg/cm2, 2.25 bar)
* Total weight of rider, passenger, cargo and accessories
Wheels
Fron t
Type Spoke wheel
Size 18 ´ 1.60
Rear
Type Spoke wheel
Size 15 M/C ´ MT 3.00
Brakes
Front
Type Single disc brake
Operation Right hand
Fluid DOT 4Rear
Type Drum brake
Operation Right foot
Suspension
Front Telescopic fork
Rear Swingarm
Spring/shock absorber
Front Coil spring / oil damper
Rear Coil spring / oil damper
Wheel travel
Front 140 mm
Rear 100 mm
Electrical system
Ignition system T.C.I (digital)
Charging system
Type A.C. magneto
Standard output 14 V, 23 A @ 5,000 r/min
Battery
Model GT6B-3
Voltage, capacity 12 V, 6 Ah
Headlight typeQuartz bulb (halogen)
E_5kr.book Page 3 Tuesday, September 12, 2000 4:46 PM

SPECIFICATIONS
8-4
8
Bulb voltage, wattage ´ quantity
Headlight 12 V, 60/55 W ´ 1
Tail/brake light 12 V, 5/21 W ´ 1
Turn signal light 12 V, 21 W ´ 4
Auxiliary light 12 V, 4 W ´ 1
Meter lighting 12 V, 1.7 W ´ 1
Neutral indicator light 12 V, 1.7 W ´ 1
High beam indicator light 12 V, 1.7 W ´ 1
Turn signal indicator light 12 V, 1.7 W ´ 1
Engine trouble warning light 12 V, 1.7 W ´ 1
Fuses
Main fuse 30 A
Headlight fuse 15 A
Signaling system fuse 10 A
Ignition fuse 10 A
Carburetor heater fuse 10 A
