SPECIFICATIONS
8-2
8
5th:1.042 (25/24)
Chassis:Frame type:
Double cradle
Caster angle: 32.16 °
Trail: 145 mm (5.7 in)Front tire:Type:Tubeless
Size: 130/70-18M/C 63H
Manufacturer/model:
BRIDGESTONE/EXEDRA G721 J
Manufacturer/model: DUNLOP/D404FRear tire:Type:
Tubeless
Size: 170/70B16M/C 75H
Manufacturer/model: BRIDGESTONE/EXEDRA G722 J
Manufacturer/model:
DUNLOP/K555Loading:Maximum load: 210 kg (463 lb)
(Total weight of rider, passenger, cargo and
accessories)
Tire air pressure (measured on cold
tires):Loading condition:
0–90 kg (0 –198 lb)
Front: 225 kPa (2.25 kgf/cm ², 33 psi)
Rear: 250 kPa (2.50 kgf/cm ², 36 psi)
Loading condition:
90– 210 kg (198 –463 lb)
Front: 225 kPa (2.25 kgf/cm ², 33 psi)
Rear: 250 kPa (2.50 kgf/cm ², 36 psi)Front wheel:Wheel type:
Cast wheel
Rim size: 18M/C x MT3.50Rear wheel:Wheel type:Cast wheel
Rim size: 16M/C x MT4.50Front brake:Type:Single disc brake
Operation: Right hand operation
Specified brake fluid:
DOT 4Rear brake:Type:Single disc brake Operation:
Right foot operation
Specified brake fluid: DOT 4
Front suspension:Type:Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel:
135.0 mm (5.31 in)Rear suspension:Type:Swingarm (link suspension)
Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel: 110.0 mm (4.33 in)Electrical system:Ignition system:
TCI
Charging system: AC magnetoBattery:Model:
YTZ14S
Voltage, capacity: 12 V, 11.2 AhHeadlight:Bulb type:
Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 60 W/55 W × 1
U26PE3E0.book Page 2 Tuesday, June 7, 2011 5:19 PM

SPECIFICATIONS
8-3
8
Tail/brake light:12 V, 5.0 W/21.0 W × 1
Front turn signal light: 12 V, 21.0 W × 2
Rear turn signal light:
12 V, 21.0 W × 2
Auxiliary light: 12 V, 5.0 W × 1
License plate light: 12 V, 5.0 W × 2
Meter lighting:
LED
Neutral indicator light: LED
High beam indicator light: LED
Oil level warning light:
LED
Turn signal indicator light: LED
Fuel level warning light: LED
Engine trouble warning light:
LED
Immobilizer system indicator light: LEDFuses:Main fuse:
40.0 A
Headlight fuse: 20.0 A
Signaling system fuse: 10.0 A Ignition fuse:
15.0 A
Parking lighting fuse: 10.0 A
Fuel injection system fuse:
10.0 A
Backup fuse: 10.0 A
U26PE3E0.book Page 3 Tuesday, June 7, 2011 5:19 PM

CONSUMER INFORMATION
9-1
9
EAU48612
Identification numbers Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26470
Model label
The model label is affixed to the frame
under the rider seat. (See page 3-14.)
Record the information on this label in
the space provided. This information
will be needed when ordering spare
parts from a Yamaha dealer.
1. Vehicle identification number
1
1. Model label
1
U26PE3E0.book Page 1 Tuesday, June 7, 2011 5:19 PM

INDEXAAir filter element, replacing ................... 6-12
Auxiliary light bulb, replacing ................ 6-31BBattery................................................... 6-25
Brake and clutch levers, checking and lubricating ........................................... 6-22
Brake and shift pedals, checking and lubricating ........................................... 6-21
Brake fluid, changing ............................ 6-19
Brake fluid level, checking .................... 6-18
Brake lever ............................................ 3-11
Brake lever free play, adjusting............. 6-16
Brake light switches .............................. 6-17
Brake pedal ........................................... 3-11CCables, checking and lubricating .......... 6-21
Care ........................................................ 7-1
Catalytic converter ................................ 3-14
Clutch lever ........................................... 3-10
Clutch lever free play, adjusting ............ 6-15DDimmer switch ........................................ 3-9
Drive belt slack...................................... 6-20EEngine break-in ....................................... 5-3
Engine oil and oil filter cartridge .............. 6-9
Engine stop switch .................................. 3-9
Engine trouble warning light.................... 3-5FFront and rear brake pads, checking .... 6-17
Front fork, checking .............................. 6-24
Fuel ....................................................... 3-12
Fuel consumption, tips for reducing ........ 5-3 Fuel level warning light ........................... 3-4
Fuel tank breather/overflow hose ......... 3-13
Fuel tank cap ........................................ 3-11
Fuses, replacing ................................... 6-26
HHandlebar switches ................................ 3-8
Hazard switch ......................................... 3-9
Headlight bulb, replacing ...................... 6-28
Helmet holder ....................................... 3-15
High beam indicator light ........................ 3-4
Horn switch ............................................. 3-9IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ................ 3-18
Immobilizer system ................................. 3-1
Immobilizer system indicator light........... 3-5
Indicator lights and warning lights .......... 3-4LLicense plate light bulb, replacing ........ 6-30MMain switch/steering lock........................ 3-2
Maintenance and lubrication, periodic .... 6-4
Maintenance, emission control system... 6-3
Matte color, caution ................................ 7-1
Model label ............................................. 9-1
Multi-function meter unit ......................... 3-5NNeutral indicator light .............................. 3-4OOil level warning light.............................. 3-4PPanel, removing and installing................ 6-8
Parking ................................................... 5-4
Part locations .......................................... 2-1Pass switch ............................................. 3-9
RRear suspension, lubricating ................. 6-23
RESET switch ....................................... 3-10
Rider seat .............................................. 3-14SSafety information ................................... 1-1
SELECT switch ....................................... 3-9
Shifting .................................................... 5-2
Shift pedal ............................................. 3-10
Shock absorber assembly, adjusting .... 3-16
Sidestand .............................................. 3-17
Sidestand, checking and lubricating...... 6-23
Spark plugs, checking ............................. 6-8
Specifications .......................................... 8-1
Starting the engine .................................. 5-1
Start switch.............................................. 3-9
Steering, checking................................. 6-24
Storage.................................................... 7-3
Supporting the motorcycle .................... 6-32
Swingarm pivots, lubricating ................. 6-23TTail/brake light bulb, replacing .............. 6-29
Throttle grip and cable, checking and
lubricating ........................................... 6-21
Throttle grip free play, checking ............ 6-13
Tires ...................................................... 6-13
Tool kit..................................................... 6-2
Troubleshooting .................................... 6-33
Troubleshooting chart ........................... 6-34
Turn signal indicator light ........................ 3-4
Turn signal light bulb, replacing ............ 6-30
Turn signal switch ................................... 3-9
U26PE3E0.book Page 1 Tuesday, June 7, 2011 5:19 PM

INDEX
VValve clearance .................................... 6-13
Vehicle identification number.................. 9-1WWheel bearings, checking .................... 6-25
Wheels.................................................. 6-15
U26PE3E0.book Page 2 Tuesday, June 7, 2011 5:19 PM

A5-yoko_Blank.fm Page 1 Tuesday, April 8, 2003 11:43 AM

A5-yoko_Blank.fm Page 1 Tuesday, April 8, 2003 11:43 AM

PRINTED IN JAPAN2011.06-0.3×1 CR (E)
DIC183
PRINTED ON RECYCLED PAPER
