YAMAHA YXZ1000R SS 2020 Owners Manual

9-14
9
4. Remove the passenger seat cushion.(See page 5-25.)
5. Remove the passenger seat by removing the bolts. 6. Remove the quick fastener screws and
the bolts, and then pull the panel off as
shown.1. Top cover
2. Bolt
3. Quick fastener screw
2
3
1
1. Passenger seat
2. Bolt
3. Seat belt
1
3
2
2
UBAS7AE0.book Page 14 Wednesday, June 19, 2019 11:51 AM

9-15
9
To install the panel1. Place the panel in the original position,and then install the bolts and the quick
fastener screws. 2. Install the passenger seat by installing the
bolts, and then tighten them to the spec-
ified torque.
TIPMake sure that the seat frame is properly
secured.
1. Panel B
2. Quick fastener screw
3. Bolt
1
2
2
3
2
3
3
1. Panel BTightening torque:
Passenger seat bolt:32 N·m (3.2 kgf·m, 24 lb·ft)
1
UBAS7AE0.book Page 15 Wednesday, June 19, 2019 11:51 AM

9-16
9
Place the passenger seat belt in the original
position. 3. Install the passenger seat cushion.
4. Install the top cover by installing the bolts
and quick fastener screw.
5. Install panel A and the hood.
Panels C and D
To remove a panel1. Pull the tab on the panel lock up, and then turn the panel lock 1/4 turn clock-
wise.
1. Panel C
2. Panel D
3. Tab
1. Tab
2. Panel lock
1
3
2
3
1
2
UBAS7AE0.book Page 16 Wednesday, June 19, 2019 11:51 AM

9-17
9
2. Remove the panel as shown.To install a panel
1. Place the panel in the original position.
1. Panel C
1. Panel D
1
1
1. Panel C
1. Panel D
1
1
UBAS7AE0.book Page 17 Wednesday, June 19, 2019 11:51 AM

9-18
9
2. Turn the panel lock 1/4 turn counter-clockwise, and then push the tab on the
p a n e l l o c k d o w n s o t h a t i t i s p o i n t i n g r e a r -
ward.EBU3543AEngine oil and oil filterCheck the engine oil level before each opera-
tion. In addition, change the oil and the oil fil-
ter cartridge at the intervals specified in the
periodic maintenance chart.
NOTICEECB03020 Do not use oils with a diesel specifica-
tion of “CD” or oils of a higher quality
than specified. In addition, do not use
oils labeled “ENERGY CONSERVING II”
or higher.
 Make sure that no foreign material en-
ters the oil tank. To check the engine oil level
1. Park the vehicle on a level surface.
2. Remove panel D. (See page 9-11.)
3. Start the engine and warm it up to a nor- mal operating temperature (the engine oil
temperature should reach 60 °C [140 °F]),
then let the engine idle for a minimum of
ten seconds before turning the engine off.TIPIf the engine is cold, take the vehicle for a
short drive or let it idle for approximately ten
minutes before checking the engine oil level.
Recommended engine oil:YA M A L U B E5W-30, 10W-30, 10W-40, 15W-40, 20W-
40, 20W-50
Oil quantity: Oil change only:2.50 L (2.64 US qt, 2.20 Imp.qt)
Oil change and filter replacement: 2.70 L (2.85 US qt, 2.38 Imp.qt)
UBAS7AE0.book Page 18 Wednesday, June 19, 2019 11:51 AM

9-19
9
4. Remove the engine oil tank filler cap andwipe the dipstick with a clean rag.
5. Insert the dipstick back into the oil tank (without screwing it in), and then remove
it again to check the oil level.
6. If the oil level is below the tip of the dip- stick, add oil.
TIPAdd oil a little at a time so as not to overfill be-
yond the maximum level mark. 7. Check the O-ring for damage, and re-place it if necessary.
8. Install the engine oil tank filler cap.
9. Install the panel.
To change the engine oil 1. Park the vehicle on a level surface.
2. Remove panel D. (See page 9-11.)
3. Remove the engine oil tank cover by re- moving the bolts.
1. Engine oil tank filler cap
2. O-ring
3. Engine oil dipstick
4. Maximum level mark
5. Tip of the engine oil dipstick
45
32
1
UBAS7AE0.book Page 19 Wednesday, June 19, 2019 11:51 AM

9-20
9
4. Start the engine, warm it up for severalminutes, and then turn it off.
5. Remove the engine oil tank filler cap and the cylinder head cap.
6. Place an oil pan under the oil tank to col-lect the used engine oil.1. Engine oil tank cover
2. Bolt
1
2
1. Engine oil tank filler cap
1. Cylinder head cap
1
1
UBAS7AE0.book Page 20 Wednesday, June 19, 2019 11:51 AM

9-21
9
7. Remove the oil tank drain bolt and usedgasket.
8. Place an oil pan under the engine to col- lect the used engine oil.
9. Remove the engine oil drain bolt and used gasket.
TIPA “ ” mark is stamped on the crankcase
near the engine oil drain bolt. 10. Install the engine oil drain bolt with new gasket, the oil tank drain bolt with new
gasket, and then tighten the bolts to the
specified torques.
1. Engine oil tank drain bolt
2. Gasket
2
1
1. Engine oil drain bolt
2. Gasket
3. “ ” mark
1 2
3
UBAS7AE0.book Page 21 Wednesday, June 19, 2019 11:51 AM

9-22
9
11. Add 2.00 L (2.11 US qt, 1.76 Imp.qt) ofthe recommended engine oil to the oil
tank.
12. Check the O-ring for damage, and re- place it if necessary. 13. Install and tighten the engine oil tank filler
cap and the cylinder head cap.
14. Start the engine, warm it up for several minutes, and then turn it off.
15. Remove the engine oil tank filler cap, and then add sufficient oil of the recommend-
ed type to raise it to the maximum level
mark on the dipstick.Tightening torques:Engine oil drain bolt:10 N·m (1.0 kgf·m, 7.4 lb·ft)
Engine oil tank drain bolt: 16 N·m (1.6 kgf·m, 12 lb·ft)
1. Engine oil tank filler cap
2. O-ring
3. Cylinder head cap
3
2
1
2
UBAS7AE0.book Page 22 Wednesday, June 19, 2019 11:51 AM

9-23
9
TIPBe sure to wipe off spilled oil on any parts af-
ter the engine and exhaust system have
cooled down. 16. Install and tighten the engine oil tank fillercap.
17. Start the engine and let it idle for several minutes. During this time, check for oil
leakage. If any oil leaks are found, stop
the engine and check for the cause.
18. Stop the engine, wait at least ten minutes, and then check the oil level one last time.
19. Install the engine oil tank cover by install- ing the bolts.
20. Install the panel.
To change the engine oil and oil filter
1. Park the vehicle on a level surface.
2. Loosen the left and right side panels by removing the bolt as shown. 3. Remove the rear bottom panel by remov-
ing the bolts.
1. Left side panel
2. Right side panel
3. Bolt
3
1
3
2
UBAS7AE0.book Page 23 Wednesday, June 19, 2019 11:51 AM
