YAMAHA YZ85 2022 Workshop Manual

Periodic maintenance an d a djustment
7-2
7
EAU90301
Perio dic maintenance an d lu brication chartThe following chart is intended as a general guide to maintenance and lubrication. Bear in mind that such factors as weath-
er, terrain, geographical location, and individual usage will alter the required maintenance and lubrication intervals. If you
are in doubt as to what intervals to follow in maintaining and lubricating your motorcycle, consult your Yamaha dealer.TIPItems marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical
skills.NO. ITEM ROUTINEAfter
break-
in Every race Every thir
d
race Every fifth
race As require
d
1 *Piston • Check piston for carbon deposits and
cracks or damage.
• Clean. √√
•Replace. √√
2 *Piston rin gs • Check piston ring end gap and rings for
damage. √√
•Replace. √√
3 *Piston pin an
d small
en d b earin g • Check piston pin and small end bearing for
damage. √
•Replace. √
4 *Cylin der hea d • Check cylinder head for carbon deposits.
• Clean.
√√
• Check cylinder head gasket for damage.
• Tighten cylinder head nuts if necessary. √√
• Replace cylinder head gasket. √
5 *Cylin der • Check cylinder for score marks or wear.
• Clean.
√√
•Replace. √
UB4B83E0.book Page 2 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-3
7
6 *YPVS • Check YPVS for carbon deposits and
cracks or damage. √√
• Clean. √√
7 *Clutch • Check clutch housing, friction plates,
clutch plates and clutch springs for wear
or damage.
•Adjust. √√
• Replace. √
8 *Transmission • Change the transmission oil.
√√
• Check transmission for damage. √
• Replace bearings. √
9 *Shift forks, g
uide bars,
shift cam • Check all parts for wear and damage.
• Replace if necessary.
√
10 *Rotor nut (flywheel
ma
gneto) •Tighten.
√√
11 *Kickstarter system • Check idle gear for damage.
• Replace if necessary. √
12 *Exhaust system • Check exhaust pipe and muffler for carbon
deposits. √√
• Clean. √
13 *Crankshaft • Check crankshaft for carbon deposits and
damage. √√
• Clean. √√
14 *Car buretor • Check carburetor settings and for obstruc-
tions. √√
• Adjust and clean. √√
NO. ITEM
ROUTINEAfter
break-
in Every race Every thir
d
race Every fifth
race As require
d
UB4B83E0.book Page 3 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-4
7
15 Spark plu g• Check condition.
• Clean and regap.
√√
•Replace. √
16 *Drive chain • Check chain slack, alignment and condi-
tion.
• Adjust and thoroughly lubricate chain with Yamaha chain and cable lube or equiva-
lent. √√
•Replace. √
17 *Coolin g system • Check coolant level and for leakage.
√√
• Check hoses for cracks or damage. √
• Check radiator cap spring operation. √
• Change coolant. Every 2 years √
18 *Chassis fasteners • Check all chassis fitting and fasteners.
• Correct or tighten if necessary. √√
19 Air filter element • Clean.
√√
•Replace. √
20 *Frame • Clean and check for damage. √√
21 *Fuel line • Clean and check for leakage. √√
22 *Brakes • Adjust lever position and pedal height.
• Lubricate pivot points.
• Check brake disk surface.
• Check fluid level and for leakage.
• Tighten brake disk bolts, caliper bolts,
master cylinder bolts and union bolts. √√
• Replace brake pads. √
• Replace brake fluid. Every year √
NO. ITEM ROUTINE
After
break-
in Every race Every thir
d
race Every fifth
race As require
d
UB4B83E0.book Page 4 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-5
7
23 *Front fork • Check operation and for oil leakage.
• Adjust if necessary.
• Clean dust seal and lubricate with lithium-
soap-based grease. √√
• Replace fork oil. √√
• Replace oil seals. √
24 *Shock ab
sorber as-
sem bly • Check operation and adjust.
• Tighten if necessary.
√√
• Lubricate with lithium-soap-based grease. √√
(After
washing
the motor-
cycle or rid- ing in the rain.)
25 *Drive chain roller an
d
support g uide • Check for wear or damage.
• Replace if necessary.
√
26 *Rear suspension • Check operation and tighten if necessary.
√√
• Lubricate with molybdenum disulfide grease. √√
27 *Swin
garm pivot bear-
in gs • Check bearing assemblies for looseness.
• Lubricate with molybdenum disulfide
grease. √√
28 *Steerin g hea d • Check operation, free play, and tighten if
necessary. √√
• Clean and lubricate with lithium-soap- based grease. √
• Replace bearings. √
NO. ITEM
ROUTINEAfter
break-
in Every race Every thir
d
race Every fifth
race As require
dUB4B83E0.book Page 5 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-6
7
EAU42012
TIP Hydraulic brake service
• Regularly check and, if necessary, correct the brake fluid levels.
• Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged.29 *Tires an d wheels • Check tire air pressure, wheel runout,
spokes for looseness, and tires for wear. √√
• Tighten sprocket bolts if necessary. √√
• Check wheel bearings for looseness. √
• Lubricate wheel bearings with lithium- soap-based grease. √
• Replace wheel bearings. √
30 *Movin
g parts an d ca-
b les • Lubricate.
√√
31 *Throttle grip • Check operation.
• Check throttle grip free play, and adjust if
necessary.
• Lubricate cable and grip housing. √√
NO. ITEM ROUTINE
After
break-
in Every race Every thir
d
race Every fifth
race As require
d
UB4B83E0.book Page 6 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-7
7
EAU84450
Checkin g the spark plu gThe spark plug is an important engine
component, which is easy to check.
Since heat and deposits will cause any
spark plug to slowly erode, the spark
plug should be removed and checked
in accordance with the periodic main-
tenance and lubrication chart. In addi-
tion, the condition of the spark plug
can reveal the condition of the engine.
To remove the spark plu g
1. Remove the spark plug cap.
2. Remove the spark plug as shown, with a spark plug wrench available
at a Yamaha dealer. To check the spark plu
g
1. Check that the porcelain insulator around the center electrode of the
spark plug is a medium-to-light
tan (the ideal color when the vehi-
cle is ridden normally).
TIPIf the spark plug shows a distinctly dif-
ferent color, the engine could be oper-
ating improperly. Do not attempt to
diagnose such problems yourself. In-
stead, have a Yamaha dealer check
the vehicle.
2. Check the spark plug for electrodeerosion and excessive carbon or
other deposits, and replace it if
necessary.
3. Measure the spark plug gap with a wire thickness gauge and, if nec-
essary, adjust the gap to specifi-
cation.
1. Spark plug cap
1
1. Spark plug wrench
1 1
Specifie d spark plu g:
NGK/BR10EG1. Spark plug gapSpark plu g g ap:
0.5–0.6 mm (0.020–0.024 in)
UB4B83E0.book Page 7 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-8
7
To install the spark plu
g
1. Clean the surface of the spark plug gasket and its mating sur-
face, and then wipe off any grime
from the spark plug threads.
2. Install the spark plug with the spark plug wrench, and then tight-
en it to the specified torque.
TIPIf a torque wrench is not available
when installing a spark plug, a good
estimate of the correct torque is 1/4…
1/2 turn past finger tight. However, the
spark plug should be tightened to the
specified torque as soon as possible.3. Install the spark plug cap asshown.
EAU4144C
Transmission oilThe transmission must be checked for
oil leakage before each ride. If any
leakage is found, have a Yamaha deal-
er check and repair the motorcycle. In
addition, the transmission oil must be
changed at the intervals specified in
the periodic maintenance and lubrica-
tion chart.1. Start the engine, warm it up for several minutes, and then turn it
off.
2. Place the motorcycle on a level surface and hold it in an upright
position.
3. Place an oil pan under the trans- mission case to collect the used
oil.
4. Remove the transmission oil filler cap and its O-ring, and then re-
move the transmission oil drain
bolt and its gasket to drain the oil
from the transmission.
Tightenin g torque:
Spark plug: 20 N·m (2.0 kgf·m, 15 lb·ft)
1. Spark plug cap
1
UB4B83E0.book Page 8 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-9
7
5. Install the drain bolt and its new
gasket, and then tighten the bolt
to the specified torque.
6. Refill with the specified amount of the recommended transmission
oil.
NOTICE
ECA10453
In or der to prevent clutch slip-
pa ge (since the transmission oil
also lu bricates the clutch), d o
not mix any chemical additives.
Do not use oils with a d iesel
specification of “CD” or oils of a
hi gher quality than specifie d. In
a ddition, do not use oils la beled
“ENERGY CONSERVING II” or
hi gher.
 Make sure that no forei gn mate-
rial enters the transmission.7. Check the O-ring for damage, and replace it if necessary.
8. Install and tighten the transmis- sion oil filler cap and its O-ring.
9. Start the engine, and then let it idle for several minutes while checking
it for oil leakage. If oil is leaking,
immediately turn the engine off
and check for the cause.
EAU20071
CoolantThe coolant level should be checked
before each ride. In addition, the cool-
ant must be changed at the intervals
specified in the periodic maintenance
and lubrication chart.
EAUM1296
To check the coolant level1. Place the vehicle on a level sur- face and hold it in an upright posi-
tion.TIPThe coolant level must be
checked on a cold engine since
the level varies with engine tem-
perature.
 Make sure that the vehicle is posi-
tioned straight up when checking
the coolant level. A slight tilt to the
side can result in a false reading.2. Remove the radiator cap and
check the coolant level in the radi-
ator. WARNING! Never attempt
to remove the ra diator cap
when the en gine is hot.
[EWA10382]
1. Transmission oil filler cap
2. O-ring
3. Transmission oil drain bolt
4. GasketTi ghtenin g torque:
Transmission oil drain bolt: 10 N·m (1.0 kgf·m, 7.4 lb·ft)
12
4
3
Recommen ded transmission oil:
Motor oil SAE 10W-40 type SG or
higher
Oil chan ge quantity:
0.50 L (0.53 US qt, 0.44 Imp.qt)
UB4B83E0.book Page 9 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-10
7
TIPThe coolant should be at the bottom of
the radiator filler neck. The level will
change with variation of engine tem-
perature.
3. If the coolant is below the correct
coolant level, add coolant, and
then install the radiator cap.
NOTICE: If coolant is not avail-
a b le, use d istilled water or soft
tap water instea d. Do not use
har d water or salt water since it
is harmful to the en gine. If water
has been used instead of cool-
ant, replace it with coolant as
soon as possi ble, otherwise the
coolin g system will not b e pro-
tected against frost an d corro-
sion. If water has b een added to
the coolant, have a Yamaha
d ealer check the antifreeze con-
tent of the coolant as soon as
possi ble, otherwise the effec-
tiveness of the coolant will be
re duce d.
[ECA10473]
EAUM1318
To change the coolant
1. Place the vehicle on a level sur- face and let the engine cool if nec-
essary.
2. Place a container under the en- gine to collect the used coolant. 3. Remove the radiator cap, and
then the coolant drain bolt and its
gasket to drain the cooling sys-
tem. WARNING! Never attempt
to remove the ra diator cap
when the en gine is hot.
[EWA10382]
1. Radiator cap
1. Correct coolant level
11
1
1. Radiator cap
1. Coolant drain bolt
2. Gasket
11
2
1
UB4B83E0.book Page 10 Thursday, September 9, 2021 8:47 AM

Periodic maintenance an d a djustment
7-11
7 4. After the coolant is completely
drained, thoroughly flush the cool-
ing system with clean tap water.
5. Install the coolant drain bolt and its new gasket, and then tighten
the bolt to the specified torque.
6. Pour the recommended coolant into the radiator until it is full.
7. Install the radiator cap, start the engine, let it idle for several min-
utes, and then turn it off.
8. Remove the radiator cap to check the coolant level in the radiator. If
necessary, add sufficient coolant until it reaches the bottom of the
radiator filler neck, and then install
the radiator cap.
9. Start the engine, and then check the vehicle for coolant leakage. If
coolant is leaking, have a Yamaha
dealer check the cooling system.
EAU48394
Cleanin g the air filter elementThe air filter element should be cleaned
or replaced at the intervals specified in
the periodic maintenance and lubrica-
tion chart. Clean or, if necessary, re-
place the air filter element more
frequently if you are riding in unusually
wet or dusty areas.
1. Remove the seat. (See page 4-7.)
2. Remove the air filter element by removing the wing bolt and its
washer.
3. Remove the sponge material from the air filter element frame.
Tightenin g torque:
Coolant drain bolt: 10 N·m (1.0 kgf·m, 7.4 lb·ft)
Antifreeze/water mixture ratio: 1:1
Recommen ded antifreeze:
High-quality ethylene glycol anti-
freeze containing corrosion inhibi-
tors for aluminum engines
Coolant quantity: Radiator (including all routes):0.50 L (0.53 US qt, 0.44 Imp.qt)
1. Wing bolt
2. Washer
3. Air filter element
1 1
3 32
UB4B83E0.book Page 11 Thursday, September 9, 2021 8:47 AM
