Alternator Reassembly
4-42Charging System
Alternator Overhaul (cont’d)
A
B
16. If you removed the pulley, put the rotor in the drive- end housing, then tighten its locknut to 110 N·m
(11.2 kgf·m, 81.0 lbf·ft).
17. Remove any grease or any oil from the slip rings.
18. Put the rear housing assembly and the drive-end housing/rotor assembly together, tighten the four
through bolts.
19. Push the brushes (A) in, then insert a pin or drill bit (B) (about 1.6 mm (0.06 in.) diameter) to hold them
there.
20. Install the brush holder assembly, and pull out the pin or drill bit.
21. Install the end cover.
22. After assembling the alternator, turn the pulley by hand to make sure the rotor turns smoothly and
without noise.
23. Install the alternator (see page 4-36) and the drive belt (see page 4-31).
08/08/21 14:10:46 61SNR030_040_0043
ProCarManuals.com
DYNOMITE -2009-

Î
Î(#'
)
4-43
Cruise Control
Component Location Index
CLUTCH PEDAL POSITION SWITCH (M/T model)
BRAKE PEDAL POSITION SWITCHCRUISE CONTROL
COMBINATION SWITCHCRUISE MAIN INDICATOR
(In the gauge control module (tach))
CRUISE CONTROL INDICATOR
(In the gauge control module (tach))
TRANSMISSION RANGE SWITCH (A/T model)
ENGINE CONTROL MODULE (ECM)/
POWERTRAIN CONTROL MODULE (PCM)
Test, page 4-50
Clutch Pedal Adjustment, page 12-8
Test, page 22-181
Pedal Height Adjustment, page 19-6Test/Replacement, page 4-49
Test, page 14-265
Replacement, page 14-267
Cruise Control Input Test, page 4-47
08/08/21 14:10:48 61SNR030_040_0044
ProCarManuals.com
DYNOMITE -2009-

(#'
)
Symptom Diagnostic procedure Also check for
4-44
Cruise Control
Symptom Troubleshooting Index




Cruise control cannot be
set
1.
2.
3.
4.Check for PGM-FI DTCs (see page 11-3).
Check the No. 3 (10 A) fuse in the under-dash fuse/relay
box.
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47). Poor ground G101 (A/T
model) or G401 (M/T
model)
Cruise control can be set,
butthecruisemain
indicator does not come
on 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the gauge control module self-diagnostic function
procedure (see page 22-241).
Do the cruise control input test (see page 4-47).
Test the cruise control main switch signal input. Faulty gauge control
module (tach)
Cruise control can be set,
but the cruise control
indicator does not come
on 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the gauge control module self-diagnostic function
procedure (see page 22-241).
Do the cruise control input test (see page 4-47).
Test the cruise control indicator signal input. Faulty gauge control
module (tach)
Vehicle does not
accelerate accordingly
when the resume/accel
button is pressed 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47).
Test the cruise control resume/accel switch signal input. Open circuit, loose or
disconnected terminal:
ORN
Set speed does not
cancel when the brake
pedal is pressed 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the brake pedal position switch test (see page
22-181).
Do the cruise control input test (see page 4-47).
Test the brake pedal position switch signal input. Short to power on
the BRN wire
Faulty brake pedal
position switch
Set speed does not
cancel (engine rpm stays
high) when the clutch
pedal is pressed (M/T
model) 1.
2.
3.
Check for PGM-FI DTCs (see page 11-3).
Do the clutch pedal position switch test (see page 4-50).
Do the cruise control input test (see page 4-47).
Test the clutch pedal position switch signal input. Short to ground in
the LT BLU wire
Faulty clutch pedal
position switch
Set speed does not
cancel when the cruise
control main button is
pressed 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47).
Test the cruise control main switch signal input. Short to power on the
YEL wire
Set speed does not
cancel when the cancel
button is pressed 1.
2.
3.Check for PGM-FI DTCs (see page 11-3).
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47).
Test the cruise control cancel switch signal input. Open circuit, loose or
disconnected
terminals: LT GRN or
ORN
08/08/21 14:10:49 61SNR030_040_0045
ProCarManuals.com
DYNOMITE -2009-

SymptomDiagnostic procedure Also check for
4-45




Set speed does not
resume when the
resume/accel button is
pressed (with the cruise
control main button
pressed on, and set
speed temporarily
canceled by pressing the
brake pedal)
1.
2.
3.
4.
Check for PGM-FI DTCs (see page 11-3).
Check the brake pedal position switch adjustment
(see page 19-6).
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47).
Test the cruise control resume/accel switch signal input.
Test the brake pedal position switch signal input. Open circuit, loose or
disconnected
terminal: ORN
Faulty brake pedal
position switch
Set speed does not
resume when the
resume/accel button is
pressed (with the cruise
control main button
pressed on, and set
speed temporarily
canceled by pressing the
clutch pedal) (M/T model) 1.
2.
3.
4.
Check for PGM-FI DTCs (see page 11-3).
Check the clutch pedal position switch adjustment
(see page 12-8).
Do the cruise control combination switch test (see page
4-49).
Do the cruise control input test (see page 4-47).
Test the cruise control resume/accel switch signal input.
Test the clutch pedal position switch signal input. Open circuit, loose or
disconnected
terminal: ORN
Faulty clutch pedal
position switch
With the ignition switch
in ON (II), and the lighting
switch turned on, the
cruise control
combination switch
illumination does not
come on Check the cruise control combination switch (see page 4-49).
08/08/21 14:10:49 61SNR030_040_0046
ProCarManuals.com
DYNOMITE -2009-

Î
(#'
)
´
µ
4-46 Cruise Control
Circuit Diagram
(A/T model) 764 5 12
G504 11
3
LIGHTS
CRUISE CONTROL INDICATOR
C21
C20
C12
12 V
5V
C4
G401 3 2 C1
A20
3
2 4
1 (50 A) No. 2
No. 19 (15 A) No. 21 (15 A)
A8
A6
C43 B28 GRY
ORN
ECM/PCM A37
A36
BAT
IG1
A39
A40
C39
C3
A41
THROTTLE BODY
TP SENSOR
No. 3
(10 A)
CRUISE MAIN INDICATOR
DRIVER
GAUGE CONTROL MODULE (TACH)
No. 12
(15 A)
UNDER-HOOD FUSE/RELAY BOX
BATTERY
No. 1 (100 A)
CPU
IG1 HOT in
ON (II) and
START (III)
CABLE
REEL
CAN-
CEL RESUME/
ACCEL
CABLE
REEL
THROTTLE
ACTUATOR
BRAKE
PEDAL
POSITION
SWITCH MULTIPLEX
INTEGRATED
CONTROL UNIT
TRANSMISSION
RANGE SWITCH SET/
DECEL
CRUISE
CONTROL
MAIN
CRUISE CONTROL
DIMMING CIRCUIT
PGM-FI
MAIN
RELAY 1
ETCS
CONTROL
RELAY
UNDER-DASH
FUSE/RELAY
BOX HORN
SWITCH
CRUISE CONTROL
COMBINATION SWITCH
IGNITION
SWITCH
IG1ETCS
ETCSRLY
IGP
MRLY CANL
CANH
BKSWNC
BKSW
TPSB
TPSA
VCC3
ETCSM
NC ATPFWD SG3
ETCSM
CRMTCLS
D8
H1 F9 F6 F5 E1
3
6
19101114
OUTPUT SHAFT
(COUNTERSHAFT)
SPEED SENSOR CLUTCH
PEDAL
POSITION
SWITCH No. 14 (7.5 A) FUSE
(UNDER-DASH
FUSE/RELAY BOX)
YEL
WHT BLU
YEL
LT BLU
BLK LT GRN ORN RED
LT GRN BRN ORN GRN WHT WHT
YEL RED
5V
BLU/WHT LT BLU BLU/YEL BLU
BLU/RED
GRN/YEL GRN RED/BLK RED/BLU
BLK
WHT
D2
F5 42 31
32
41 1
10
679 8 2
21 18 C101
(M/T model) CANL CANH
19
08/08/21 14:10:50 61SNR030_040_0047
ProCarManuals.com
DYNOMITE -2009-

(#'
)Signal to be
tested Test condition Parameter: Desired
resultPossible cause if result is not obtained
4-47
Cruise Control Input Test
NOTE: Always make sure that you have the latest Honda Diagnostic System (HDS) software before doing the input
tests.
1. Connect the HDS to the data link connector (DLC) (see step 2 on page 11-3).
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the vehicle and the engine control module (ECM)/powertrain control module (PCM). If it does not communicate, troubleshoot the DLC circuit (see page 11- 204).
4. Go to PGM-FI, and check for DTCs (see page 11-3).
5. Do the following tests while monitoring parameters in the PGM-FI DATA LIST with the HDS. NOTE: Intermittent failures are often caused by loose circuit connections. While monitoring cruise control inputs,
flex the circuit wires, and note if any of the test results change.

















Brake pedal
position
switch signal
Brake pedal pressed,
then released
CRUISE BRAKE SW
should indicate OFF
when the brake pedal is
pressed and ON when
the brake pedal is
released. Faulty brake pedal position switch
Blown No. 3 (10 A) fuse in the under-
dash fuse/relay box
An open in the wire between the ECM/
PCM and the brake pedal position switch
A wire shorted to ground between the
ECM/PCM and the brake pedal position
switch
Clutch pedal
position
switch signal
(M/T model) Clutch pedal pressed,
then released
SHIFT/CLUTCH SW
should indicate ON
when the clutch pedal
is pressed and OFF
when the clutch pedal
is released. Faulty clutch pedal position switch
An open in the wire between the ECM
and the clutch pedal position switch
A wire shorted to ground between the
ECM and the clutch pedal position
switch
Poor ground G401
Transmission
range switch
signal (A/T
model) Shift lever in D and S SHIFT/CLUTCH SW
should indicate ON in P,
R,andN,andOFFinD
and S. Faulty transmission range switch
An open in the wire between the PCM
and the transmission range switch
A wire shorted to ground between the
PCM and the transmission range switch
Poor ground G101
Cruise control
main switch
signal Cruise control main
switch pressed and
released CRUISE MASTER
(MAIN) SW should
indicate ON when the
cruise control main
buttonispressedand
OFF when the cruise
control main button is
released. Faulty cruise control combination switch
Faulty gauge control module (tach)
An open in the wire between the gauge
control module (tach) and the cruise
control combination switch
A wire shorted to ground between the
gauge control module (tach) and the
cruise control combination switch
Poor ground G504
(cont’d)
08/08/21 14:10:50 61SNR030_040_0048
ProCarManuals.com
DYNOMITE -2009-

Signal to betested Test condition Parameter: Desired
resultPossible cause if result is not obtained
4-48Cruise Control
Cruise Control Input Test (cont’d)















Set switch
signal
Set/decel button
pressed and released CRUISE SET SW
should indicate ON
when the set/decel
buttonispressedand
OFF when the set/decel
button is released. Faulty cruise control combination switch
Faulty gauge control module (tach)
An open in the wire between the gauge
control module (tach) and the cruise
control combination switch
A wire shorted to ground between the
gauge control module (tach) and the
cruise control combination switch
Resume
switch signal Resume/accel button
pressed and released CRUISE RESUME SW
should indicate ON
when the resume/accel
buttonispressedand
OFF when the resume/
accel button is released. Faulty cruise control combination switch
Faulty gauge control module (tach)
An open in the wire between the gauge
control module (tach) and the cruise
control combination switch
A wire shorted to ground between the
gauge control module (tach) and the
cruise control combination switch
Cancel switch
signal Cancel button
pressed and released CRUISE CANCEL SW
should indicate ON
when the cancel button
is pressed and OFF
when the cancel button
is released. Faulty cruise control combination switch
Faulty gauge control module (tach)
An open in the wire between the gauge
control module (tach) and the cruise
control combination switch
A wire shorted to ground between the
gauge control module (tach) and the
cruise control combination switch
Cruise control
indicator
signal Start the engine,
press the cruise
control main button
on, and drive the
vehicle to speeds
over 40 km/h
(25 mph). Set and
cancel the cruise
control. CRUISE INDICATOR
should indicate ON
when the cruise control
is set and OFF when
thecruisecontrolis
canceled.
Faulty ECM/PCM
Cruise control was not set at the test by
other malfunction
Faulty gauge control module (tach)
08/08/21 14:10:50 61SNR030_040_0049
ProCarManuals.com
DYNOMITE -2009-


Î

(#'

)
4-49
Cruise Control Combination Switch Test/Replacement
Terminal
Position Cruise control
main switch (ON) 5
37
Cancel
(PRESSED) 64
Cruise control
main switch (OFF) Set/decel
(PRESSED)
Resume/accel
(PRESSED)
SRS components are located in this area. Review the
SRS component locations (see page 24-11), and
precautions and procedures (see page 24-13), before
doing repairs or service.
1. Remove the driver’s airbag (see page 24-188).
2. Remove the steering wheel trim.
3. Remove the cruise control combination switch. 4. Check for continuity between the terminals in each
cruise control combination switch position
accordingtothetable.
 If there is continuity, and it matches the table, but the cruise control combination switch failure
occurred on the cruise control input test, check
and repair the wire harness on the switch circuit.
 If there is no continuity in one or more positions, replace the cruise control combination switch.
Wire side of
female terminals
08/08/21 14:10:51 61SNR030_040_0050
ProCarManuals.com
DYNOMITE -2009-

Î
Î(#'

)
M/T model
4-50Cruise Control
Clutch Pedal Position Switch Test
A
B
Terminal
Position
Clutch Pedal Position Switch 3
2
(PRESSED)
Clutch Pedal Position Switch (RELEASED)
1. Disconnect the clutch pedal position switch 3P
connector (A).
2. Remove the clutch pedal position switch (B).
3. Check for continuity between the terminals accordingtothetable.
 If the continuity is not as specified, replace the clutch pedal position switch (see page 12-8).
 If OK, install the clutch pedal position switch, and adjust the pedal height (see page 12-8).
Terminal side of
male terminals
08/08/21 14:10:51 61SNR030_040_0051
ProCarManuals.com
DYNOMITE -2009-

(#'
/)
Engine Mechanical
Engine Assembly
................................................................................................................................................................................. ..........................................................
...............................
............................... .................
.............................
................................................................
................................................................................................................. ..........................................................
...............................
............................... .................
.............................
Special Tools . 5-2
Engine Removal . 5-3
Engine Installation . 5-13
Side Engine Mount Replacement . 5-24
Transmission Mount Replacement . 5-29
Lower Torque Rod Replacement . 5-32
Upper Torque Rod Replacement . 5-34
Side Engine Mount Bracket Replacement . 5-35
Front Engine Mount Replacement . 5-40
08/08/21 14:20:21 61SNR030_050_0001
ProCarManuals.com
DYNOMITE -2009-
