5-22Engine Assembly
Engine Installation (cont’d)
A
B
B A 6x1.0mm
10 N·m
(1.0 kgf·m, 7.2 lbf·ft) 6x1.0mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)
B
C A
51. Connect the evaporative emission (EVAP) canisterhose (A) and the brake booster vacuum hose (B).
52. Install the engine control module (ECM)/powertrain control module (PCM) bracket (A), then install the
under-hood fuse/relay box (B) to the ECM/PCM
bracket. 53. K20Z3 engine: Install the engine cover.
54. Connect the ECM/PCM connectors (A) and the
engine wire harness connector (B).
55. Install the harness clamps (C).
08/08/21 14:21:00 61SNR030_050_0022
ProCarManuals.com
DYNOMITE -2009-

ÃŽ
 ÃŽ

5-23
B
A
6x1.0mm
10 N·m
(1.0 kgf·m, 7.2 lbf·ft) A
B A
B
C
6x1.0mm
10 N·m
(1.0 kgf·m, 7.2 lbf·ft)
C
56. Install the ECM/PCM (A), then install the ECM/PCM
cover (B).
57. Connect the battery cables (A) to the under-hood fuse/relay box.
58. Install the harness clamp (B). 59. Install the pipe (A).
60. Connect the connector (B), and install the harness
clamps (C).
61. Install the under cowl-panel (see step 4 on page 20-164).
62. Install the air cleaner assembly (see page 11-345).
63. Install the front wheels.
64. Do the battery installation procedure (see page 22-69).
65. Inspect for fuel leaks. Turn the ignition switch to ON (II) (do not operate the starter) so the fuel pump
runs for about 2 seconds and pressurizes the fuel
line. Repeat this operation three times, then check
for fuel leakage at any point in the fuel line.
66. Refill the engine with engine oil (see step 4 on page 8-10).
(cont’d)
08/08/21 14:21:01 61SNR030_050_0023
ProCarManuals.com
DYNOMITE -2009-



(#'
 )
 M/T model
A/T model
5-245-24
Engine Assembly
Engine Installation (cont’d)
Side Engine Mount Replacement
67. Refill the transmission with fluid:
 Manual transmission (see step 3 on page 13-5)
 Automatic transmission (see step 3 on page14-232)
68. A/T model: Move the shift lever to each gear, and verify that the A/T gear position indicator follows
the transmission range switch.
69. M/T model: Check that the transmission shifts into gear smoothly.
70. Refill the radiator with engine coolant, and bleed the air from the cooling system with the heater
valve open (see step 6 on page 10-8).
71. Do the ECM/PCM reset procedure (see page 11-4).
72. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see page 11-4).
73. Inspect the idle speed (see page 11-309).
74. Inspect the ignition timing (see page 4-20).
75. Check the wheel alignment (see page 18-5). 1. Support the engine with a jack and wood block
under the oil pan.
2. Remove the upper torque rod.
Replace.
Replace.
Replace.
Replace.
08/08/21 14:21:01 61SNR030_050_0024
ProCarManuals.com
DYNOMITE -2009-



(#'
 )
 M/T model
A/T model
5-245-24
Engine Assembly
Engine Installation (cont’d)
Side Engine Mount Replacement
67. Refill the transmission with fluid:
 Manual transmission (see step 3 on page 13-5)
 Automatic transmission (see step 3 on page14-232)
68. A/T model: Move the shift lever to each gear, and verify that the A/T gear position indicator follows
the transmission range switch.
69. M/T model: Check that the transmission shifts into gear smoothly.
70. Refill the radiator with engine coolant, and bleed the air from the cooling system with the heater
valve open (see step 6 on page 10-8).
71. Do the ECM/PCM reset procedure (see page 11-4).
72. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see page 11-4).
73. Inspect the idle speed (see page 11-309).
74. Inspect the ignition timing (see page 4-20).
75. Check the wheel alignment (see page 18-5). 1. Support the engine with a jack and wood block
under the oil pan.
2. Remove the upper torque rod.
Replace.
Replace.
Replace.
Replace.
08/08/21 14:21:01 61SNR030_050_0024
ProCarManuals.com
DYNOMITE -2009-


ÃŽ
ÃŽ
5-25
A
B
A B
10x1.25mm
49 N·m
(5.0 kgf·m, 36 lbf·ft)
6x1.0mm
10 N·m
(1.0 kgf·m, 7.2 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft) D
A C
B
6x1.0mm
10 N·m
(1.0 kgf·m, 7.2 lbf·ft)
3. Remove the ground cable (A), then remove the side
engine mount bracket (B).
4. Remove the side engine mount stiffener (A), then remove the side engine mount (B).
5. Install the side engine mount, then install the side engine mount stiffener. 6. Install the side engine mount bracket (A), loosely
tighten the new bolt and nut (B), then loosely
tighten the bolt (C).
7. Install the ground cable (D).
8. Remove the air cleaner assembly (see page 11-345).
(cont’d)
Replace. Replace.
08/08/21 14:21:02 61SNR030_050_0025
ProCarManuals.com
DYNOMITE -2009-




M/T model
A/T model
5-26 Engine Assembly
Side Engine Mount Replacement (cont’d)
A
A A
A
9. Loosen the transmission mounting bolt and nuts (A). 10. Raise the vehicle on the lift.
11. Remove the splash shield (see step 25 on page 5-5).
12. Loosen the lower torque rod mounting bolt (A).
13. M/T model: Loosen the front mount mounting
bolt (A).
08/08/21 14:21:03 61SNR030_050_0026
ProCarManuals.com
DYNOMITE -2009-






M/T model
A/T model
5-27
12x1.25mm
72 N·m
(7.3 kgf·m, 52 lbf·ft)
14x1.5mm
74 N·m
(7.5 kgf·m, 54 lbf·ft)
12x1.25mm
74N·m(7.5kgf·m,54lbf·ft)
12x1.25mm
74 N·m
(7.5 kgf·m, 54 lbf·ft)
14. Lower the vehicle on the lift.
15. Tighten the side engine mount mounting bolts and nut. 16. Tighten the transmission mounting bolt and nuts.
(cont’d)
08/08/21 14:21:03 61SNR030_050_0027
ProCarManuals.com
DYNOMITE -2009-






M/T model
A/T model
5-28Engine Assembly
Side Engine Mount Replacement (cont’d)
14x1.5mm
93 N·m
(9.5 kgf·m, 69 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
17. Raise the vehicle on the lift.
18. Tighten the lower torque rod mounting bolt.
19. Lower the vehicle on the lift.
20. Install the air cleaner assembly (see page 11-345). 21. Install the upper torque rod, then tighten the new
upper torque rod mounting bolts in the numbered
sequence shown.
Replace.
Replace.
Replace.
Replace.
08/08/21 14:21:04 61SNR030_050_0028
ProCarManuals.com
DYNOMITE -2009-



(#'
 )
5-295-29
Transmission Mount Replacement
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft) A
22. Raise the vehicle on the lift.
23. M/T model: Tighten the front mount mounting bolt.
24. Install the splash shield (see step 40 on page 5-20).1. Loosen the upper torque rod mounting bolt (A).
2. Remove the air cleaner assembly (see page 11-345).
3. Remove the engine control module (ECM)/
powertrain control module (PCM) cover, then
remove the three bolts securing the ECM/PCM (see
step 10 on page 5-4).
4. Remove the under hood fuse/relay box from the ECM/PCM bracket, then remove the ECM/PCM
bracket(seestep13onpage5-4).
(cont’d)
08/08/21 14:21:04 61SNR030_050_0029
ProCarManuals.com
DYNOMITE -2009-



(#'
 )
5-295-29
Transmission Mount Replacement
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft) A
22. Raise the vehicle on the lift.
23. M/T model: Tighten the front mount mounting bolt.
24. Install the splash shield (see step 40 on page 5-20).1. Loosen the upper torque rod mounting bolt (A).
2. Remove the air cleaner assembly (see page 11-345).
3. Remove the engine control module (ECM)/
powertrain control module (PCM) cover, then
remove the three bolts securing the ECM/PCM (see
step 10 on page 5-4).
4. Remove the under hood fuse/relay box from the ECM/PCM bracket, then remove the ECM/PCM
bracket(seestep13onpage5-4).
(cont’d)
