ColumnDescription Problem indication
Yaw Rate
23-144Navigation System
System Diagnostic Mode (cont’d)
The table of values shown define the terms at the top of
the columns in the GPS detail screen.
3D Active satellites (Yellow Dot) If 3D is missing
follow GPS icon is
white or not shown
(see page 23-122).
PRN The satellite ID number
ST The status: 0 = cannot view or
searching,
2 = acquiring If all 0, then, follow
GPS icon is white
or not shown
troubleshooting
(see page 23-122).
AZI Azimuth, the angle (0 360) clockwise
from north
EL Elevation from the horizon
(90 deg is overhead)
C/N N/A Healthy signal is 49 52,
no signal: 27 33
ACC N/A This diagnostic checks the yaw rate sensor in the
control unit. This device detects when the vehicle turns,
and repositions the vehicle position icon on the map
screen. For more detailed information, see the yaw rate
sensor theory of operation under System Description
(see page 23-105).
 Sensor indicates the voltage output from the yaw rate sensor. It should indicate about 2.500 V when the
vehicle is stopped.
 Offset is the reference voltage or standard within the yaw rate sensor. It also should indicate about 2.500 V
when the vehicle is stopped.
 A sensor output voltage LOWER than the Offset voltage indicates that the vehicle is turning to the
right.
A sensor output voltage HIGHER than the Offset
voltage indicates that the vehicle is turning to the left.
 The yaw rate offset and sensor should both indicate about 2.500 V when the vehicle is stopped. If either
reads zero or 5.000 V, replace the navigation unit.
08/08/21 14:07:32 61SNR030_230_0147
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
µ
µ
Tire Calibration
23-146Navigation System
System Diagnostic Mode (cont’d)
Return
Set
Reset
CCW CW
Tuning 0.0%
ANG-Disp 0° Return
Auto Tuning OFF
Level0
xx.xx%
Set
Study
Tire Cal. TuningTire Calibrate
ON
OFF
1. Stationary test: If the VP icon spins in place and the ANG-Disp value slowly increases or decreases in
value, the yaw rate sensor is defective. Replace the
navigation unit.
2. Road test: Drive the vehicle on a very straight road. Enter the diagnostic mode, select Yaw rate, and
touch the Tuning button. While driving down a
straight road, the white dots should trace a straight
line across the screen. However, if you are driving
on a straight road, and you notice the dots
constantly dropping down or heading up as you
drive, the navigation unit’s yaw sensor is defective.
You can touch Reset to clear ANG-Disp, and dotted
line.
3. If either test fails, please enter ‘‘Yaw rate sensor defective’’ for the problem description, on the
‘‘Navigation core return form’’. As the vehicle moves, the navigation system receives
speed pulses from the ECM/PCM. These pulses are
converted using a conversion factor to a mph speed
that moves the vehicle position (VP) on the map. The
navigation system has an internal tuning function that
generates and refines this factor based on actual
driving. The Level indicates the status of the tuning. At
navigation initialization, it begins at 0, and increases to
10 as the navigation system is used.
 The Auto Tuning is factory set to ON, and should remain on.
 The Study indicates the tuning status. If it is less than 10, the unit is still calibrating.
 The Tire-Cal. Tuning and Set should not be used. It is for factory use only.
08/08/21 14:07:33 61SNR030_230_0149
ProCarManuals.com
DYNOMITE -2009-

Î
ÎÎ
Î
Functional Setup
’06 model
’07-08 modelsLog Data
23-147
Functional Setup
Log Data
GPS Send Time Demo Mode Mic Level
Solar Angle
Functional Setup
Log Data
GPS Send Time Demo Mode Mic Level
Solar Angle
Save Users MemoryReturn
Return
Log Data
Log DataReturn
PC Card is not inserted.
Return
Logging VP Data OFF
ON OFF
Select the item you want to check.
LogData
 GPS Send Time
 Demo Mode
 Mic Level
 Solar Angle
 Save Users Memory (’07-08 models) This screen allows the factory to collect log data to
troubleshoot navigation system issues.
 There is no card in the PC card Slot, the screen appears as:
 However, if the factory provides a PC card, insert it into the card slot (label side up). Follow the factory
logging VP data procedure for gathering test data and
properly ending the test.
(cont’d)
08/08/21 14:07:33 61SNR030_230_0150
ProCarManuals.com
DYNOMITE -2009-

Î
ÎÎ
GPS Send Time
Demo Mode
Mic Level
23-148Navigation System
System Diagnostic Mode (cont’d)
Send GPS TimeReturn
GPS Time
Second
Year
Day Hour
Minute
xxxx.xx.xx xx:xx:xx
Set
xxxx
xx
Month xx
xx
xx
xx
Demo Mode
OFF
Demo
Speed Rate 150 ms ON OFFReturn
Return
Steering Switch Mic Level
Mic Level
BACK
This screen is for factory use only. It allows adjustment
of the GPS time. This display updates in real time.
 GPS Time is the time as received from the GPS satellites. It is in Greenwich Mean Time (GMT).
 Date, Hour, Minute, and Set should not be used.
This screen allows the navigation system to drive a
route, when the vehicle is stationary. Typical
applications include auto shows, and other events.
This feature allows a visitor to enter a destination, and
see the system drive to the destination. No speed signal
is needed.  To initiate the mode, select ON.
 Changing the speed rate in ms (millisec onds) is
optional, and represents the time between updates of
the VP (vehicle position) movement.
– When you increase the rate, the VP slows down because it is updated (moved) at a slower rate.
– When you decrease the rate, VP is faster because it is updated (moved) more frequently.
– 1500 ms is VP at its slowest in demo mode.
– 150 ms is VP at its fastest in demo mode (Default).
 At key off, the setting automatically returns to the default of Off. This diagnostic screen allows you to independently test
the microphone and the navigation TALK and BACK
buttons. They are used to activate the voice control
system. The microphone is located near the map light
in the ceiling. It is directional, and works best if the
voice is coming from the drivers seat.
 Press the navigation TALK button on the steering wheel, wait unit you hear a beep, and in a normal
voice say ‘‘testing’’. The TALK indicator on the screen
should momentarily turn green, and the text ‘‘Now
Recording...’’ should appear in yellow. If the talk
indicator on the screen does not briefly turn green,
then check the wiring from the navigation TALK
button to the navigation unit.
 If there is no Mic Level movement when you speak, then you should check the wire running from the
microphone to the navigation unit.
 If the mic level bar is full or almost full wit hout you
speaking or other back ground noise, replace the
microphone and recheck.
 PressthenavigationBACKbuttononthesteering wheel. The Cancel indicator on the screen should
momentarily turn green. If it does not briefly turn
green, then check the wiring from the steering wheel
navigation BACK button to the navigation unit.
NOTE: The mic level should reach the 6th bar.
08/08/21 14:08:37 61SNR030_230_0151
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
Solar angleVersion
23-149
Solar Angle
Manual Tuning
Angle Direction
Reliability
33.0
Vehicle 143.0 307.0
3
OFF
ON
DownLoad
ReturnVersionReturn
Program Flash 0.99.20.
Program Disc 0.99.0800 IPL 0.230.000
APL 0.200.122
DBOOT 0.241.122
System uCom 0.910.000
Model SNRA
OFF
This screen graphically displays the sun’s position as
determined by GPS.
This screen is for factory use only, and allows
simulation of this feature for development purposes.
 The manual tuning button should always be OFF
 The Angle is the angle that the sun (shown with the red dot) is above the horizon.
 The vehicle value represents the angle, clockwise from North, to the direction that the vehicle position
(VP) icon is pointing (always points straight up).
 The direction value is the angle, measured clockwise from the VP (straight up) to the suns position.
 The reliability ranges from 1 to 3, and represents the accuracy of the Vehicle Position relative to the sun. This screen displays the current version of the program,
and allows the loading of a new version of the program
either from a CD/DVD or from a PC card.
The Program Flash version should always be greater
than or equal to the Program Disc version. IPL, APL,
DBOOT, and system ucomare for factory use only.
The Model code is SNR and is for factory use only. This
code is stored on a chip in the navigation unit.
Therefore, every model has a unique part number for
the navigation unit.
NOTE: If any model number other than SNR is
displayed, replace the navigation unit with the correct
part. The model code tells the navigation unit what
software to load off the DVD.
Do not use Download, unless instructed to do so by the
factory.
(cont’d)
08/08/21 14:08:37 61SNR030_230_0152
ProCarManuals.com
DYNOMITE -2009-

ÎÎ
Î


Save Users Memory
23-150Navigation System
System Diagnostic Mode (cont’d)
Return
EXPORT
IMPORT
Save Users Memory
Return
Yes No
Return
Yes NoSave Users Memory Export User Data
Save Users Memory Import User Data
When replacing the navigation unit, this function allows
the dealer to transfer the client’s personal data to the
new navigation unit. The transferred information
includes their Setup settings, and personal addresses.
The dealer inserts a PC card to the navigation unit, and
then selects the Save Users Memory function. The two
functions in this diagnostic screen are EXPORT and
IMPORT. EXPORT saves the client’s data to the PC card,
andIMPORTmovesthePCcardfilestothenew
navigation unit.
Before starting this function, see the PC Card FAQs for
information regarding PC cards, how to use this
function. 1. Select EXPORT button to move the client’s data
from the original navigation unit to the PC card.
Select YES on the Export User Data Confirmation
screen. The process takes only a couple of seconds.
The system stores two files on the card.
NOTE: If the EXPORT button is grayed out, check
the PC card’s edge connector, and the pins inside
the navigation unit (with a flashlight) for damage.
2. After installing the client’s original DVD in the new navigation unit, allow the system to boot up. Insert
the PC card in the new navigation unit and enter the
Save Users Memory in the navigation system
diagnostic mode.
3. Select IMPORT button to move the two files stored by the Export process from the PC card to the new
navigation unit. Select YES on the Import User Data
Confirmation screen. When the transfer is finished
(a few seconds) the system automatically reboots.
After the system reboots, remove the PC card from
the PC card slot.
NOTE: If the IMPORT button is grayed out, check if
the Model and the Program Flash shown on the
Version screen are the same for the two navigation
units.
08/08/21 14:08:37 61SNR030_230_0153
ProCarManuals.com
DYNOMITE -2009-

PC Card FAQs
QuestionAnswer
23-151
Wheredowebuytheflashmemoryor
adaptors, and what do we ask for?You need a PCMCIA type II adaptor and a flash memory chip. You can
purchase them at a computer, or office supply store. The card is the
same size and shape as the PC card in the HDS. Adaptors that accept
multiple flash types are not recommended.
What memory flash chips will work
with what adaptors? The flash memory devices that have been tested include Compact Flash
(CF), and ATA style (like the card in the HDS). Other card types and flash
memory chips may work, but have not been tested.
What capacity card do I need for this
function? A memory chip with capacity of 64 MB to 2 GB will work. The two files
moved to the PC card during export are less than a Megabyte in size.
Should the dealer have a dedicated PC
card for the Export and Import
navigation function? Yes, treat the PC card as a dedicated special tool that you can use any
time you need to transfer the navigation personal files to a new
navigation unit on ’07 and later vehicles.
What device can I use to maintain the
PC card, and delete files? Any computer store sells USB style card readers that accept the PC card,
and allow you to do file maintenance on your PC card. Most laptops also
accept the PC card.
Can we move the client’s data to
different models? No, the files are model specific and will only load into a navigation unit
with the same part number.
Can we move the client’s data to the
same vehicle with a different software
version (like moving from version 4.41
to version 4.51)? The client’s files can only be transferred to a new navigation unit if the
Model and the Program Flash shown on the Version screen are the same.
Files cannot be transferred to the different model and different versions.
Will other files on the PC card like
images or music files prevent the
Export/Import function from working? No, the system simply adds two small files that are recognized by the
new navigation unit when performing the import function. However, it
the PC card is full, the Export function won’t work correctly.
Do I have to delete the files on the PC
card after each transfer of the
personal data? After the transfer of personal data to the new navigation unit, the files
remain on the PC card. Since this is confidential information, Acura
recommends deleting these files after the transfer. Please note that each
time you export navigation files of the same model and version, the files
are overwritten. Over time the PC card accumulates two files for each
version of the 8 or so Acura navigation models.
If the memory card needs formatting,
what format should I use? It is unlikely that the PC card will ever need formatting, however, if it
does, use the FAT (file allocation table) file system.
I can’t enter the navigation diagnostic
mode to do the Export/Import function.
How can I transfer the personal data? Some internal navigation unit ECU failures may make it impossible to
use the Export/Import function.
(cont’d)
08/08/21 14:08:38 61SNR030_230_0154
ProCarManuals.com
DYNOMITE -2009-

QuestionAnswer
23-152Navigation System
System Diagnostic Mode (cont’d)










Why wont the Export or Import
functions work or are grayed out?
What do I check as part of
troubleshooting?
The card may not be fully inserted into the slot. Eject the PC card, and
inspect for warping or damage to the edge connector. Never use
excessive force to insert a PC card. This can result in damage to the
pins in the rear of the slot.
The PC card may not contain files that are recognized by the new
navigation unit. Navigation data can only be transferred between
navigation units with the same Model code, and with the same navi
Program flash version.
The flash memory chip type may not be accepted by the system. Only
Compact Flash and ATA cards have been tested.
The card’s PCMCIA adaptor may prevent a known-
good card from
being recognized Avoid multi-slot type PCMCIA adaptors that accept
several different flash memory types.
The card may be full and as a result the files are stored, but without
any data. Export and import appear to function, but move nothing.
Delete unused files from the PC card.
There may not be any files on the PC card. If the PC card has a write
protection switch, make sure it is turned off before using the Export
function.
Although flash memory chips are reliable, occasionally they develop
bad sectors or other formatting errors that prevents them from
accepting files. The PC card should be reformatted using the FAT
format.
The PC card may have been formatted using the format NTFS. Only the
FAT format is accepted by the system.
Hard Disc Drive (HDD) cards may not work properly in the system and
can overheat or quit functioning, particularly in a hot vehicle. They are
not recommended.
Before performing the Import function, ensure that the original
navigation DVD is loaded into the new navigation unit and working
properly.
08/08/21 14:08:38 61SNR030_230_0155
ProCarManuals.com
DYNOMITE -2009-

µ
Error Message Table
Screen Error MessageSolution
23-153
Navigation system is unable to acquire a proper
GPS signal.Make sure there is nothing on the dashboard blocking the GPS
antenna. If not, move the vehicle to an open space away from
tall buildings, trees, etc. Aftermarket metallic window tinting
and other aftermarket devices can affect the GPS reception.
Navigation is open or No DVD disc installed.
Please check system. Make sure the correct white-labeled navigation DVD is
installed with the label side up and the navigation display is
closed.
DVD reading error (incorrect DVD disc) place
consult your dealer. Verify correct color (white) DVD installed.
Display temp is too high. System will shut down
until display cools down. This message appears briefly when the display temperature is
too high, and the display turns off until the temperature cools
down. The system turns back on when the display cools down.
Outside temperature is low, system will take a
while to start up. The temperature is below 30 °C and the navigation ECU has
difficulties reading the navigation DVD. The system will start
up when the temperature warms up.
DVD disc reading error (unformatted), please
consult your dealer. Check the navigation DVD source for deep scratches or other
damage. Make sure you are using an official Honda
navigation DVD (white in color). The system cannot read other
mapping databases or video DVDs. Check online for any
service publications to update the navigation system.
Route has not been completed. Please try again
from a different location. Routing to or from a place (new area) that is not in the
database. Try planning a different route to or from a different
location.
No alternate route found. Original route will be
guided. No alternate route method was found. The original route will
be used.
This destination cannot be found in database. The destination was not found in the database. Try another destination nearby, or select the destination with the joystick.
08/08/21 14:08:38 61SNR030_230_0156
ProCarManuals.com
DYNOMITE -2009-



(#'#
 )
23-154 Navigation System
CD, DVD, and PC Card Removal/Installation
A
A
D
B
C
If the displays Open/Close button does not work, you
must manually open the display to obtain the client’s
Navigation DVD, CD and possibly their PC card. Follow
the step below:
1. Remove the navigation unit from the vehicle (see page 23-155).
2. On the bench, carefully pull the display (A) straight out (about 1/2 inch).
3. Fold down the display as shown in the diagram below. 4. Push the PC card eject button (A) to eject the client’s
PC card (if installed). Power is not required for this
function.
5. Remove the plastic cover (B) the navigation DVD slot.
6. With the display open, temporarily reconnect the unit in the dash (to power it up).
7. Push the CD eject button (C), and navigation DVD eject button (D) (the button is behind the plastic
cover and works only when the unit is powered)
and remove the discs (holding the discs by their
edges to avoid fingerprints). To avoid scratches,
place the navigation DVD, and client’s CD in a jewel
case if available.
8. Re-attach the plastic cover that hides the navigation DVD slot.
9. Close the display by first returning the display to the upward position, and then pushing the entire
display straight back into the unit.
10. After installing the new navigation unit, re-insert the navigation DVD, the client’s CD, and PC card.
08/08/21 14:08:38 61SNR030_230_0157
ProCarManuals.com
DYNOMITE -2009-
