ACURA CSX 2006 Service Repair Manual





M/T model
A/T model
5-38 Engine Assembly
Side Engine Mount Bracket Replacement (cont’d)
12x1.25mm
74 N·m
(7.5 kgf·m, 54 lbf·ft)
12x1.25mm
74 N·m
(7.5 kgf·m, 54 lbf·ft) 14x1.5mm
93 N·m
(9.5 kgf·m, 69 lbf·ft)
14. Tighten the transmission mounting bolt and nuts. 15. Raise the vehicle on the lift.
16. Tighten the lower torque rod mounting bolt.
17. Lower the vehicle on the lift.
18. Install the air cleaner assembly (see page 11-345).
08/08/21 14:21:10 61SNR030_050_0038
ProCarManuals.com
DYNOMITE -2009-






M/T model
A/T model
5-39
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft) 12x1.25mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
19. Install the upper torque rod, then tighten the new
upper torque rod mounting bolts in the numbered
sequence shown. 20. Raise the vehicle on the lift.
21. M/T model: Tighten the front mount mounting bolt.
22. Install the splash shield (see step 40 on page 5-20).
Replace.
Replace.
Replace.
Replace.
08/08/21 14:21:10 61SNR030_050_0039
ProCarManuals.com
DYNOMITE -2009-


(#'
 )
M/T model
5-40Engine Assembly
Front Engine Mount Replacement
12x1.5mm
64 N·m
(6.5 kgf·m, 47 lbf·ft)
12x1.25mm
74 N·m
(7.5 kgf·m,
54 lbf·ft)
A
1. Raise the vehicle on the lift.
2. Remove the splash shield (see step 25 on page 5-5).
3. Remove the front mount (A).
4. Install the front mount, then tighten the new frontmount mounting bolts in the numbered sequence
shown.
5. Install the splash shield (see step 40 on page 5-20).
Replace. Replace.
08/08/21 14:21:11 61SNR030_050_0040
ProCarManuals.com
DYNOMITE -2009-

(#'
/)
Engine Mechanical
Cylinder Head
........................................................................................................................................
................................................ ............................................. ...................................... .............
.................................................... ................................................ .................
.................................
................................................. ....................................................................... ...............................
.............................................. ................................
................................
............................................................ .....................
................................
....................................... ..............................
................................................... ....................
.......................................................... ..............
.......................................... ......................................... ................
.............................
..........................................
..............................................
................................................................
........................................................................
................................................ ............................................. ...................................... .............
.................................................... ................................................ .................
.................................
................................................. ....................................................................... ...............................
.............................................. ................................
................................
............................................................ .....................
................................
....................................... ..............................
................................................... ....................
.......................................................... ..............
.......................................... ......................................... ................
.............................
..........................................
..............................................
Special Tools
. 6-2
Component Location Index . 6-3
Engine Compression Inspection . 6-7
VTEC Rocker Arm Test . 6-8
VTC Actuator Inspection . 6-11
Valve Clearance Adjustment . 6-12
Crankshaft Pulley Removal and Installation . 6-16
Cam Chain Removal . 6-18
Cam Chain Installation . 6-21
Auto-tensioner Removal and Installation . 6-29
Chain Case Oil Seal Installation . 6-31
Cam Chain Inspection . 6-32
CKP Pulse Plate Replacement . 6-34
Cylinder Head Cover Removal . 6-36
Cylinder Head Cover Installation . 6-37
Cylinder Head Removal . 6-38
CMP Pulse Plate A Replacement . 6-41
CMP Pulse Plate B Replacement . 6-41
VTC Actuator, Exhaust Camshaft Sprocket Replacement . 6-42
Cylinder Head Inspection for Warpage . 6-43
Rocker Arm Assembly Removal . 6-43
Rocker Arm and Shaft Disassembly/Reassembly . 6-46
Rocker Arm and Shaft Inspection . 6-48
Camshaft Inspection . 6-50
Valve, Spring, and Valve Seal Removal . 6-54
Valve Inspection . 6-55
Valve Stem-to-Guide Clearance Inspection . 6-55
Valve Guide Replacement . 6-56
Valve Seat Reconditioning . 6-58
Valve, Spring, and Valve Seal Installation . 6-59
Rocker Arm Assembly Installation . 6-60
Cylinder Head Installation . 6-62
Sealing Bolt Installation . 6-66
08/08/21 14:26:12 61SNR030_060_0001
ProCarManuals.com
DYNOMITE -2009-

















(#'
%)Ref. No. Tool Number Description Qty
6-2
Cylinder Head
Special Tools
07AAB-RWCA120
Camshaft Lock Pin Set 1
07AAJ-PNAA101 Air Pressure Regulator 1
07HAH-PJ7A100 Valve Guide Reamer, 5.5 mm 1
07JAA-001020A Socket, 19 mm 1
07JAB-001020A Holder Handle 1
07MAA-PR70110 Adjuster 1
07MAA-PR70120 Locknut Wrench 1
07NAB-001040A Holder Attachment, 50 mm 1
07PAD-0010000 Stem Seal Driver 1
07ZAJ-PNAA101 VTEC Air Adapter 2
07ZAJ-PNAA200 VTEC Air Stopper 1
07ZAJ-PNAA300 Air Joint Adapter 1
07742-0010100 Valve Guide Driver, 5.5 mm 1
07746-0010400 Attachment, 52 x 55 mm 1
07749-0010000 Driver 1
07757-PJ1010A Valve Spring Compressor Attachment 1
08/08/21 14:26:14 61SNR030_060_0002
ProCarManuals.com
DYNOMITE -2009-

Î
(#'
)
6-3
Component Location Index
IGNITION COIL COVERCAM CHAIN
GUIDE A O-RING
CHAIN CASE COVER
CRANKSHAFT POSITION
(CKP) SENSOR
TENSIONER ARM
CRANKSHAFT PULLEY
CYLINDER HEAD COVER
CAM CHAIN
VARIABLE VALVE
TIMING CONTROL
(VTC) OIL CONTROL
SOLENOID VALVE
CRANKSHAFT PULLEY BOLT
CKP PULSE PLATE
AUTO-TENSIONER CAM CHAIN GUIDE B
CHAIN CASE
O-RING
(cont’d)
Removal and Installation,
page 6-16
Removal, page 6-36
Installation, page 6-37
Removal, page 6-18
Installation, page 6-21
Inspection, page 6-32
Removal and Installation,page 6-16
Replacement, page 6-34
Removal, page 6-29
Installation, page 6-30
08/08/21 14:26:17 61SNR030_060_0003
ProCarManuals.com
DYNOMITE -2009-

ÎK20Z2 engine
6-4Cylinder Head
Component Location Index (cont’d)
CAM CHAIN GUIDE B
INTAKE CAMSHAFT VTC ACTUATOR
EXHAUST CAMSHAFT
SPROCKET EXHAUST CAMSHAFT
ROCKER ARM ASSEMBLY
CAMSHAFT HOLDERS
DOWEL PINS
CAMSHAFT POSITION
(CMP) SENSOR A
(INTAKE) O-RING
DOWEL PINS
O-RING
CMP PULSE PLATE B
CMP PULSE PLATE A
CAMSHAFT POSITION
(CMP) SENSOR B
(EXHAUST) Inspection, page 6-50
Inspection, page 6-11
Replacement,page 6-42
Replacement, page 6-42 Inspection, page 6-50
VTEC Rocker Arm Test, page 6-8
Rocker Arm Assembly Removal, page 6-43
Rocker Arm and Shaft Disassembly/
Reassembly, page 6-46
Rocker Arm and Shaft Inspection, page 6-48
Rocker Arm Assembly Installation, page 6-60
Replacement,
page 6-41
Replacement, page 6-41
08/08/21 14:26:20 61SNR030_060_0004
ProCarManuals.com
DYNOMITE -2009-

ÎK20Z3 engine
6-5
CAM CHAIN GUIDE B
EXHAUST CAMSHAFT
SPROCKET
EXHAUST CAMSHAFT
CAMSHAFT HOLDERS
DOWEL PINS
CAMSHAFT POSITION
(CMP) SENSOR A
(INTAKE)
CMP SENSOR B
(EXHAUST)
O-RING
DOWEL PINS
O-RING
CMP PULSE PLATE A INTAKE CAMSHAFT
VTC ACTUATOR
CMP PULSE PLATE B 6 x 32 mm FLANGE BOLT
(Not on all engines)
ROCKER ARM ASSEMBLY
(cont’d)
Replacement,page 6-42
Inspection, page 6-52
Replacement,
page 6-41 Inspection, page 6-52
Inspection,page 6-11
Replacement, page 6-42
Replacement,
page 6-41
VTEC Rocker Arm Test,page 6-9
Rocker Arm Assembly Removal, page 6-44
Rocker Arm and Shaft Disassembly/ Reassembly, page 6-47
Rocker Arm and Shaft Inspection, page 6-49
Rocker Arm Assembly Installation, page 6-61
08/08/21 14:26:24 61SNR030_060_0005
ProCarManuals.com
DYNOMITE -2009-

Î
6-6Cylinder Head
Component Location Index (cont’d)
CYLINDER HEAD BOLT
INTAKE VALVE SPRINGINTAKE VALVE SEAL
INTAKE VALVE GUIDE
VTC STRAINER
VTC FILTER
CYLINDER HEAD
EXHAUST VALVE
INTAKE VALVE
CYLINDER HEAD GASKET
ROCKER ARM OIL CONTROL
SOLENOID FILTER EXHAUST VALVE
SEAL
EXHAUST VALVE SPRING SPRING RETAINER
VALVE COTTERS
VALVE SPRING
SEAT
EXHAUST VALVE GUIDE
HEAT SHIELDROCKER ARM OIL
CONTROL SOLENOID Inspection, page 6-62
Removal, page 6-54
Installation, page 6-59Replacement, page 6-56
Removal, page 6-38
Inspection, page 6-43
Installation, page 6-62
Removal, page 6-54
Inspection, page 6-55
Installation, page 6-60
08/08/21 14:26:26 61SNR030_060_0006
ProCarManuals.com
DYNOMITE -2009-


(#'
")Compression Pressure:
Above 930 kPa (9.5 kgf/cm , 135 psi)
Maximum Variation:
Within 200 kPa (2.0 kgf/cm , 28 psi)
2
2
6-7
Engine Compression Inspection
NOTE: After this inspection, you must reset the engine
control module (ECM)/powertrain control module
(PCM), otherwise the ECM/PCM will continue to stop
the fuel injectors from operating. 1. Warm up the engine to normal operating temperature (cooling fan comes on).
2. Turn the ignition switch to LOCK (0).
3. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 on page 11-3).
4. Turn the ignition switch to ON (II).
5. Make sure the HDS communicates with the vehicle and the ECM/PCM. If it does not communicate,
troubleshoot the DLC circuit (see page 11- 204).
6. Select ALL INJECTORS STOP in the PGM-FI, INSPECTION menu with the HDS.
7. Turn the ignition switch to LOCK (0).
8. Remove the four ignition coils (see page 4-21).
9. Remove the four spark plugs.
10. Attach the compression gauge to a spark plug hole. 11. Step on the accelerator pedal to open the throttle
fully, then crank the engine with the starter motor,
and measure the compression.
12. Measure the compression on the remaining cylinders.
13. If the compression is not within specifications, check the following items, then remeasure the
compression.
 Incorrect valve clearance
 Confirmation of cam timing
 Damaged or worn cam lobes
 Damaged or worn valves and seats
 Damaged cylinder head gasket
 Damaged or worn piston rings
 Damaged or worn piston and cylinder bore
14. Remove the compression gauge from the spark plug hole.
15. Install the four spark plugs.
16. Install the four ignition coils (see page 4-21).
17. Select the ECM/PCM reset (see page 11-4) in the PGM-FI INSPECTION menu to cancel ALL
INJECTORS STOP with the HDS.
08/08/21 14:26:27 61SNR030_060_0007
