(#') Driver’s Door
22-11
Door
POWER WINDOW MASTER SWITCH
(Has built-in control unit)
08/08/21 14:22:06 61SNR030_220_0013
ProCarManuals.com
DYNOMITE -2009-


(#') Driver’s Seat
Front Passenger’s Seat
22-12Relay and Control Unit Locations
Seat
DRIVER’S SEAT HEATER RELAY (HIGH)
DRIVER’S SEAT HEATER RELAY (LOW)
FRONT PASSENGER’S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER’S SEAT HEATER RELAY (LOW)OPDS UNIT
Wire colors: RED, ORN, GRN/RED, and BLK
Wirecolors:BRN,RED,BLK,BLK,andBLU/YEL
Wirecolors:RED,ORN,GRN/RED,andBLK
Wire colors: BRN, RED, BLK, BLK, and BLU/YEL
08/08/21 14:22:07 61SNR030_220_0014
ProCarManuals.com
DYNOMITE -2009-

µ
´
(#')
HarnessLocation
Engine Compartment Dashboard Others (Floor, Door, Trunk, and Roof)Notes
22-13
Connectors and Harnesses
Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter ‘‘C’’
for connectors, ‘‘G’’ for ground terminals, or ‘‘T’’ for non-ground terminals.
A/C wire harness C205, C504 (see page 22-56)
Battery ground cable ( ), G1 (see page 22-14)
Console subharness C551, C601, C603 (see page 22-57)
Dashboard wire harness
(View of driver’s side) C201, C202, C203, C501,
C502, C751, C752, C801
G501, G503(see page 22-28)
Dashboard wire harness
(View of middle section) C503, C506, C551
G504, G506(see page 22-30)
Dashboard wire harness
(View of passenger’s side) C504, C761, C762
G502, G505(see page 22-32)
Driver’s door subharness C754 (see page 22-46)
Driver’s door wire harness C751, C752 C753, C754 (see page 22-46)
Driver’s seat position sensor harness
(With seat heater) C602 (see page 22-52)
Driver’s seat position sensor harness
(Without seat heater) C602 (see page 22-53)
Driver’s seat wire harness C602, C604 (see page 22-52)
Engine compartment wire harness
(Left branch) C101, C102, C103
G301C201 through C205, C209
G401 (see page 22-22)
Engine compartment wire harness
(Right branch) C206, C207
G201, G202G402, G403 (see page 22-26)
Engine ground cable A T1, G2 (see page 22-14)
Engine ground cable B T2, G3 (see page 22-14)
Engine wire harness (A/T) C101, C103, C105, C106, C107
G101 (see page 22-16)
Engine wire harness (M/T) C101, C105, C106 G101 (see page 22-18)
Floor wire harness (Left branch) C204, C209, C501, C502, C506, C601, C603C602, C604, C701,
C702, C771
G601, G603(see page 22-34)
Floor wire harness (Right branch) C781, C782, C783 G602(see page 22-38)
Front passenger’s door subharness C763 (see page 22-48)
Front passenger’s door wire harness C761, C762 C763 (see page 22-48)
Front passenger’s seat wire harness
(With seat heater) C782, C783 (see page 22-54)
Left rear door wire harness C771 (see page 22-50)
ODS unit harness (With seat heater) C782 (see page 22-54)
ODS unit harness (Without seat
heater) C782 (see page 22-55)
Rear window defogger ground wire G801 (see page 22-42)
Rear wire harness (Left branch) C701, C702, C703 G701(see page 22-40)
Rear wire harness (Right branch) (see page 22-42)
Right rear door wire harness C781 (see page 22-51)
Roof wire harness (With moonroof) C801 (see page 22-44)
Roof wire harness (Without moonroof) C801 (see page 22-45)
Shift solenoid wire harness (A/T) C107 (see page 22-16)
Starter subharness ( ) C102, C106
T3, T4
T101, T102 (see page 22-20)
Trunk lid spoiler subharness (TYPE S
model) C703 (see page 22-40)
USB harness C671 (see page 22-34)
USB subharness C671 (see page 22-57)
08/08/21 14:22:07 61SNR030_220_0015
ProCarManuals.com
DYNOMITE -2009-

•••
•••

(#'
) Under-hood Fuse/Relay Box
Socket Ref Terminal Connects toNotes
22-58Fuse/Relay Boxes
Connector to Fuse/Relay Box Index
234
5
1 16
17 19
18
20
11
12
14
13 15
21
22
24
23
25
10 6
7
89
(View of front side) (View of back side)
A (ELD)21 3 Engine compartment wire harness (see page 22-22)
A/C compressor clutch relay 12 4
A/C condenser fan relay 3 4
B 22 1 Engine compartment wire harness (see page 22-22)
Blower motor relay 2 4
C 23 2 Engine compartment wire harness (see page 22-22)
D 25 8 Engine compartment wire harness (see page 22-22)
Diode (for A/C condenser fan) 9
Diode (for radiator fan) 8
E 24 10 Engine compartment wire harness (see page 22-22)
Electronic throttle control system
(ETCS) control relay 14 4
F 17 20 Engine compartment wire harness (see page 22-22)
Fan control relay 4 5
G 19 1 Engine compartment wire harness (see page 22-22)
H 20 1 Engine compartment wire harness (see page 22-22)
Ignition coil relay 7 4
J 16 4 Engine compartment wire harness (see page 22-22)
K 18 2 Engine compartment wire harness (see page 22-22)
PGM-FI main relay 1 (FI MAIN) 13 4
PGM-FI subrelay 6 4
Power mirror defogger relay 5 5
Radiator fan relay 15 4
Rear window defogger relay 1 4
T3 10Starter subharness (see page 22-20)
T101 11Starter subharness (see page 22-20)
08/08/21 14:23:02 61SNR030_220_0060
ProCarManuals.com
DYNOMITE -2009-

•••

(#'
) Under-dash Fuse/Relay Box
Socket Ref Terminal Connects toNotes
22-59
2
3
4
5
1
16
17
18
11
12
14
13
15
10 6
7
8
9 19
20
(View of front side) (View of back side)
A (Optional connector)
9 6 Not used
C 10 4 Dashboard wire harness (see page 22-28)
D 4 2 Dashboard wire harness (see page 22-28)
E 5 42 Floor wire harness (see page 22-34)
F 6 34 Engine compartment wire harness (see page 22-22)
G 7 21 Engine compartment wire harness (see page 22-22)
H (MICU service check connector) 8 3
J 20 4 Dashboard wire harness (see page 22-28)
K 12 8 Dashboard wire harness (see page 22-28)
M 13 10 Dashboard wire harness (see page 22-28)
Memory erase signal (MES) connector socket 11
N 14 14 Dashboard wire harness (see page 22-28)
P 19 10 Dashboard wire harness (see page 22-28)
PGM-FI main relay 2 (FUEL PUMP) 2 4
Power window relay 1 4
Q 17 16 Dashboard wire harness (see page 22-28)
R 15 20 Dashboard wire harness (see page 22-28)
Starter cut relay 3 4
S 16 20 Dashboard wire harness (see page 22-28)
T 18 34 Dashboard wire harness (see page 22-28)
08/08/21 14:24:02 61SNR030_220_0061
ProCarManuals.com
DYNOMITE -2009-

•••
•••
•••
•••
(#')
 Under-hood Fuse/Relay Box
Fuse
Number Amps Component(s) or Circuit(s) Protected
22-60Power Distribution
Fuse to Components Index
1 100 A
(BAT)Battery, Power distribution
70 A
(EPS) EPS control unit
250A (IG)Ignition switch
80 A
60 A
(OPTION) No. 5, No. 6, No. 7, No. 27, No. 28, No. 29, and No. 31 fuses (in the under-dash fuse/relay box)
330A (ABS MTR) ABS modulator-control unit , VSA modulator-control unit
30 A
40 A
(ABS FSR) ABS modulator-control unit , VSA modulator-control unit
450A (H/L)No. 18, No. 19, No. 20, and No. 21 fuses (in the under-dash fuse/relay box)
40 A
(P/W) No. 24, No. 25, No. 26, No. 30, No. 32, and No. 33 fuses (in the under-dash fuse/relay box), Power window relay
(in the under-dash fuse/relay box)
5 Not used
6 20 A A/C condenser fan motor (via A/C condenser fan relay)
7 20 A Radiator fan motor (via radiator fan relay)
8 30 A Noise condenser (via rear window defogger relay), Rear window defogger (via rear window defogger relay)
9 40 A Blower motor (via blower motor relay)
10 10 A MICU (turn signal/hazard warning lights circuit)
11 15 A A/F sensor (Sensor 1) (via PGM-FI subrelay), EVAP canister vent shut valve (via PGM-FI subrelay), PGM-FI subrelay, No. 15 fuse (in the under-hood fuse/relay box) (via PGM-FI subrelay)
12 15 A Brake lights, ECM/PCM, Horn, MICU
13 Not used
14 Not used
15 7.5 A A/C condenser fan relay
16 Not used
17 15 A Stereo amplifier
18 15 A Ignition coil relay, Ignition coils (via Ignition coil relay)
19 15 A CKP sensor (via PGM-FI main relay 1), CMP sensor B (via PGM-FI main relay 1), ECM/PCM, ETCS control relay, Injectors (via PGM-FI main relay 1), PGM-FI main relay 1 (FI MAIN), PGM-FI main relay 2 (FUEL PUMP)
20 7.5 A A/C compressor clutch (via A/C compressor clutch relay)
21 15 A ECM/PCM (via ETCS control relay)
22 7.5 A Ceiling light, Courtesy lights, Front individual map lights, Ignition key light, Trunk light, Vanity mirror lights
23 10 A Audio unit , Data link connector (DLC), Gauge control module (speedo), Gauge control module (tach), HandsFreeLink control unit , Immobilizer-keyless control unit, MICU, Moonroof switch, Navigation unit
1: ’06-07 models
2: ’08-09 models
3: ’06-07 Touring and Premium models
4: ’07 TYPE S and ’08-09 models
5: ’08-09 models
6: TYPE S model
7: Without navigation system
8: With navigation system
9: ’09 model with navigation system
1
2
34
3
4 34
6 5
7 9 8
08/08/21 14:24:02 61SNR030_220_0062
ProCarManuals.com
DYNOMITE -2009-


22-61
23
4 5
1 16
17
19 18
1112 14 13
15
10
6
7
8
9
202122
23
(cont’d)
08/08/21 14:24:02 61SNR030_220_0063
ProCarManuals.com
DYNOMITE -2009-

•••
•••´
´
•••
Under-dash Fuse/Relay Box
Fuse
Number Amps
Component(s) or Circuit(s) Protected
22-62Power Distribution
Fuse to Components Index (cont’d)
1 7.5 A Power mirror switch light
2 15 A ECM/PCM, Fuel pump (via PGM-FI main relay 2), Immobilizer-keyless control unit
3 10 A Alternator, CMP sensor A, ECM/PCM (via brake pedal position switch), ELD, EVAP canister purge valve, MAF
sensor/IAT sensor, Reverse lockout solenoid , Secondary HO2S (sensor 2)
4 7.5 A ABS modulator-control unit , EPS control unit, VSA modulator-control unit , Yaw rate-lateral acceleration sensor
5 15 A Seat heaters (via seat heater relays)
6 20 A Fog light relay, Fog lights (via fog light relay)
7 Not used
8 Not used
9 7.5 A ODS unit, Passenger’s airbag cutoff indicator, SRS unit
10 7.5 A Back-up light (M/T), Gauge control module (speedo), Gauge control module (tach), MICU, Shift lock solenoid (A/T), TPMS control unit
11 10 A SRS unit
12 10 A Right headlight (high beam)
13 10 A Left headlight (high beam)
14 7.5 A Audio unit light , Climate control unit light, Dash lights brightness controller and odometer select/reset switch light, Driver’s footwell light , Driver’s seat heater switch light, Glove box light, Hazard warning switch light,
Moonroof switch light, Navigation unit , Park pin switch light (A/T), Passenger’s airbag cutoff indicator light,
Passenger’s footwell light , Passenger’s seat heater switch light, Steering wheel switches light (via cable reel),
VSA OFF switch light
15 7.5 A Parking lights, Taillights, License plate lights, Side marker lights
16 10 A Right headlight (low beam) 15 A Right HID unit
17 10 A Left headlight (low beam) 15 A Left HID unit
18 20 A MICU ( B H/L HI)
19 15 A MICU ( B SMALL LT)
20 Not used
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S model
5: With HID
6: Without HID
7: TYPE S and ’08 Premium and ’09 models
8: Without navigation system
9: With navigation system
4
1 2
2
7
3
8 49
4
6
5
6
5
08/08/21 14:24:03 61SNR030_220_0064
ProCarManuals.com
DYNOMITE -2009-

´
´
•••
•••
´
•••
•••
•••

Fuse
Number Amps
Component(s) or Circuit(s) Protected
22-63
23 45
1 16 17
19
18 20
11
12 1413 15
26 27 2928 30
21 22
2423 25
36 37
38
3132
34
33
35
10
67 8
9
21 20 A MICU ( B H/L LO)
30 A MICU ( B H/L LO)
22 Not used
23 Not used
24 20 A Moonroof control unit/motor
25 20 A MICU ( B DR LOCK)
26 20 A Driver’s power window motor (via power window master switch)
27 Not used
28 15 A Console accessory power socket (via console accessory power socket relay)
29 15 A Front accessory power socket (via front accessory power socket relay)
30 20 A Front passenger’s power window motor
31 Not used
32 20 A Moonroof control unit/motor, Moonroof switch , Right rear power window motor
33 20 A Left rear power window motor
34 Not used
35 7.5 A Audio unit , Console accessory power socket relay, Front accessory power socket relay, HandsFreeLink control unit , Ignition key switch, Navigation unit , Stereo amplifier
36 10 A Climate control unit, Driver’s seat heater switch, Fan control relay and radiator fan relay (via A/C diode), Passenger’s seat heater switch, Power mirrors (via power mirror switch), Under-hood fuse/relay box (A/C
compressor clutch relay, Blower motor relay, Power mirror defogger relay, Rear window defogger relay)
37 7.5 A MICU (daytime running lights power supply)
38 30 A MICU (IG 1 WIPER)
1: ’06-07 models
2: TYPE S model
3: Without HID
4: With HID
5: ’09 model with navigation system
6: Without navigation system
7: With navigation system3
4
1
6
5 72
08/08/21 14:24:03 61SNR030_220_0065
ProCarManuals.com
DYNOMITE -2009-

µ
(#'
)
GroundComponent or Circuit Grounded
22-64Ground Distribution
Ground to Components Index
G1 Battery
G2 Engine
G3 Transmission housing
G101 A/T clutch pressure control solenoid valves A, B, C (A/T), CKP sensor, CMP sensor A, CMP sensor B, Data link connector (DLC), ECM/PCM (LG1), ECM/PCM (LG2), ECM/PCM (PG1), ECM/PCM (PG2), ECM/PCM (PGMETCS), EGR valve (K20Z2 engine), Ignition
coils, Immobilizer-keyless control unit, Rocker arm oil control solenoid, Rocker arm oil pressure switch, Transmission range
switch (A/T), VTC oil control solenoid valve
Shielding between the ECM/PCM and Knock sensor (KS) has wire.
Shielding between the ECM/PCM and Secondary HO2S (Sensor 2) has wire.
G201 Right fog light , Right front parking light, Right front side marker light, Right front turn signal light, Right headlight (high/low beams), Right HID unit , Windshield washer motor, Windshield wiper motor
G202 ABS modulator-control unit , VSA modulator-control unit
G301 A/C condenser fan motor, Blower motor relay, ELD, Left fog light , Left front parking light, Left front side marker light, Left front turn signal light, Left headlight (high/low beams), Left HID unit , Radiator fan motor (via fan control relay)
G401 Brake fluid level switch, Clutch interlock switch (M/T), Clutch pedal position switch (M/T), Hood switch, MICU (PG), Power transistor, Washer fluid level switch (G401 connects to G601 via under-dash fuse/relay box)
G402 EPS control unit
G403 Torque sensor
G501 Dash lights brightness controller and odometer select/reset switch, Driver’s door key cylinder switch, Driver’s door lock knob switch, HandsFreeLink control unit , MICU (SG), VSA OFF switch
G502 Data link connector (DLC), Front accessory power socket, Glove box light, Right power mirror defogger, Right side turn signal light
G503 Accessory power socket relays (front and console), Driver’s door lock switch, Gauge control module (tach), Left power mirror defogger, Left side turn signal light, Moonroof control unit/motor, Power mirror switch light, Power mirror switch, Power
window master switch (main switch), Power window master switch, Vanity mirror lights (driver’s and front passenger’s)
G504 Cable reel (steering wheel switches ground), Climate control unit, Front passenger’s door lock knob switch, Front passenger’s door lock switch, Gauge control module (speedo), Gauge control module (tach), Ignition key switch, Navigation unit , TPMS
control unit
G505 Audio unit , Navigation unit
G506 Memory erase signal (MES) connector, SRS unit (2 wires)
G601 A/T gear position console panel light/Park-pin switch (A/T), Console accessory power socket , Fuel pump, MICU (PG), Seat heater relays (driver’s and front passenger’s), Seat heater switches (driver’s and front passenger’s), Seat heaters (driver’s and
front passenger’s), Stereo amplifier (G601 connects to G401 via under-dash fuse/relay box)
Shielding between the left side impact sensor (FIRST) and rear safing sensor has wire.
Shielding between the SRS unit and left side impact sensor (FIRST) has wire.
G602 Driver’s seat belt buckle switch, Front passenger’s seat belt buckle switch, Left rear door lock knob switch, MICU (SG), MICU service check connector, ODS unit, Right rear door lock knob switch, Yaw rate-lateral acceleration sensor
Shielding between the right side impact sensor (FIRST) and right side impact sensor (SECOND) have wires.
Shielding between the SRS unit and right side impact sensor (FIRST) has wire.
G603 Noise condenser Shielding between the rear safing sensor and left side impact sensor (SECOND) has wire.
G701 High mount brake light, Left back-up light, Left inner taillight, Left rear side marker light, Left rear turn signal light, Left taillight/ brake light, License plate lights, Right back-up light, Right inner taillight, Right rear side marker light, Right rear turn signal light,
Right taillight/brake light, Trunk lid release actuator/Trunk lid latch switch
G801 Rear window defogger ( )
1: ’06-07 Touring and Premium models
2: ’07 TYPE S and ’08-09 models
3: ’08-09 models
4: TYPE S and ’08 premium and ’09 models
5: With HID
6: Without navigation system
7: With navigation system
8: ’09 model with navigation system
9: ’06-08 models, and ’09 model without navigation system
10: TYPE S model
4
512 4
5
82 3
7
3
67
9
10
2
08/08/21 14:24:03 61SNR030_220_0066
ProCarManuals.com
DYNOMITE -2009-
