Acura RL 2000 3.5 Owner's Manual

Audi
o Syste m

3. To install a CD, pull the tab out to
remove the tray from the maga-
zine.

4. Put a CD on a tray with the printed

surface up as shown.

5. Reinstall the tray in the magazine.

Repeat this procedure for the oth- er five trays.

6. Store all six trays in the magazine,

and then reinstall the magazine in
the CD changer as shown in the il-
lustration.

7. Slide the lid closed until it clicks.
Comfor t an d Convenienc e Feature s
TA
B
TRAY

Audi
o Syste m
Protectin g Compac t Disc s

Handle a CD by its edges; never

touch either surface. Contamination

from fingerprints, liquids, felt-tip
pens, and labels can cause the CD to
not play properly, or possibly jam in

the drive. When a CD is not being played, store
it in its case to protect it from dust
and other contamination. To prevent
warpage, keep CDs out of direct sunlight and extreme heat.
To clean a disc, use a clean soft cloth. Wipe across the disc from the centerto the outside edge. A new CD may be rough on the
inner and outer edges. The small
plastic pieces causing this roughness
can flake off and fall on the re-
cording surface of the disc, causingskipping or other problems. Remove
these pieces by rubbing the inner and outer edges with the side of a
pencil or pen.
Never try to insert foreign objects in
the CD player or the magazine.

Comfor t an d Convenienc e Feature s

Audi
o Syste m

C D Change r Erro r Indication s
If you see an error indication in the
display while operating the CD
changer, find the cause in the chart
to the right. If you cannot clear the
error indication, take the car to your
Acura dealer.
Comfor t an d Convenienc e Feature s

Audi
o Syste m

Remot e Audi o Control s
AUDIO/C H
BUTTO N
Two controls for the audio system are mounted in the steering wheel
hub. These let you control basic
functions without removing your
hand from the wheel. The top and bottom buttons adjust the volume up or down
Press the proper button and hold it
until the desired volume is reached,
then release it.
The AUDIO/CH button has three functions, depending on whether you are listening to the radio, or playing a
cassette or CD.
If you are listening to the radio, use
the AUDIO/CH button to change stations. Each time you press this
button, the system advances to the next preset station on the band you
are listening to. You will see the
number of the selected Preset button
in the display. To change bands,
press the AM/FM button on the audio system's front panel. If you are playing a cassette, use the
AUDIO/CH button to advance to the next selection. You will see "FF"
blinking in the display when you press the AUDIO/CH button. Thesystem fast forwards until it senses a
silent period, then goes back to
PLAY.
If you are playing a CD, the system skips to the beginning of the next
track each time you push the
AUDIO/CH button. You will see the disc and track number in the display.
Comfor t an d Convenienc e Feature s

Audi
o Syste m

Thef t Protectio n
Your car's audio system will disable itself if it is disconnected fromelectrical power for any reason. To
make it work again, the user must
enter a specific five-digit code in the
Preset buttons. Because there are
hundreds of number combinations possible from five digits, making thesystem work without knowing the
exact code is nearly impossible.
You should have received a card that lists your audio system's code
number and serial number. It is bestto store this card in a safe place at
home. In addition, you should write
the audio system's serial number in this Owner's Manual. If you should
happen to lose the card, you must obtain the code number from your
Acura dealer. To do this, you will need the system's serial number. If your car's battery is disconnected
or goes dead, or the radio fuse is
removed, the audio system will disable itself. If this happens, you
will see "Code" in the frequency display the next time you turn on the
system. Use the Preset buttons to
enter the five-digit code. If it is
entered correctly, the radio will start

playing.

If you make a mistake entering the
code, do not start over or try to correct your mistake. Complete the
five-digit sequence, then enter the correct code. You have three tries to
enter the correct code. If you are
unsuccessful in three attempts, you
must then leave the system on for one hour before trying again. You will have to store your favorite
stations in the Preset buttons after
the system begins working. Your original settings were lost when
power was disconnected.
Comfor t an d Convenienc e Feature s

Securit
y Syste m

The security system helps to protect your car and valuables from theft.
The horn sounds and a combination of headlights, parking lights, side
marker lights and taillights flashes if
someone attempts to break into your
car or remove the radio. This alarm continues for two minutes, then the
system resets. To reset an alarming
system before the two minutes have
elapsed, unlock either front door
with the key or the remote
transmitter.
The security system sets auto- matically fifteen seconds after you
lock the doors, hood, and trunk. For
the system to activate, you must lock
the doors from the outside with the key, lock tab, door lock switch, or
remote transmitter. The security
system light next to the driver's door
lock starts blinking immediately to show you the system is setting itself. SECURIT
Y SYSTE M LIGH T
Once the security system is set,
opening any door (without using the
key or the remote transmitter), or the hood, will cause it to alarm. It
also alarms if the radio is removed
from the dashboard or the wiring is
cut.
With the system set, you can still
open the trunk with the master key
or the remote transmitter without
triggering the alarm. The alarm will sound if the trunk lock is forced, or
the trunk is opened with the trunk
release button on the driver's door.
The security system will not set if the hood, trunk, or any door is not
fully closed. If the system will not set,check the Door and Brake Lamp
Monitor on the instrument panel (see page 57 ), to see if the doors
and trunk are fully closed. Since it is
not part of the monitor display,
manually check the hood.
Do not attempt to alter this system
or add other devices to it.
Comfor t an d Convenienc e Feature s

164

Before
Driving
Before you begin driving your Acura,
you should know what gasoline to use, and how to check the levels of
important fluids. You also need to
know how to properly store luggage or packages. The information in this
section will help you. If you plan to
add any accessories to your car,
please read the information in this section first. Break-in Period.............................. 166
Gasoline.......................................... 166
Service Station Procedures .......... 167 Filling the Fuel Tank................. 167Opening the Hood..................... 168
Oil Check................................ 169
Engine Coolant Check.......... 170
Fuel Economy................................ 171 Car Condition............................. 171
Driving Habits............................ 171
Accessories and Modifications.... 172 Carrying Cargo.............................. 174

Before Drivin g

Break-i
n Period , Gasolin e

Break-i n Perio d
Help assure your car's future
reliability and performance by paying
extra attention to how you drive
during the first 600 miles (1,000 km).
During this period:
Avoid full-throttle starts and rapid

acceleration.

Avoid hard braking. New brakesneed to be broken-in by moderate
use for the first 200 miles (300

km).

You should follow these same re- commendations with an overhauled
or exchanged engine, or when the
brakes are relined.

Gasolin e

Your Acura is designed to operate on premium unleaded gasoline with apump octane number of 91 or higher.
If you are unable to find premium
unleaded gasoline, you may substi-
tute an unleaded regular gasoline.
The engine will compensate for the lower octane, but you may notice aslight decrease in power as a result.
We recommend gasolines containing detergent additives that help prevent
fuel system and engine deposits.
Using gasoline containing lead will
damage your car's emissions
controls. This contributes to air
pollution. In Canada, some gasolines contain
an octane-enhancing additive called
MMT. If you use such gasolines,
your emissions control system performance may deteriorate andthe Malfunction Indicator Lamp on
your instrument panel may turn on. If this happens, contact your
authorized Acura dealer for service.

Befor e Drivin g

Servic
e Statio n Procedure s

Fillin g th e Fuel Tank
1. Because the fuel fill cap is on the
driver's side of the car, park with
that side closest to the service
station pumps.

2. Open the fuel fill door by pulling

on the handle to the left of the
driver's seat.

FUE L FIL L CA P 3. Remove the fuel fill cap slowly.

You may hear a hissing sound as
pressure inside the tank escapes.
Place the cap in the holder on the
fuel fill door.

4. Stop filling the tank after the fuel

nozzle automatically clicks off. Do
not try to "top off" the tank, leave
some room for the fuel to expand
with temperature changes.

Your car has an on-board refueling
vapor recovery system to help
keep fuel vapors from going into
the atmosphere. If the fuel pump
keeps clicking off even though thetank is not full, there may be a
problem with this system. Consult
your dealer.

CONTINUED

Befor e Drivin g

Pul
l
Gasoline is highly flammable

and explosive. You can be
burned or seriously injured

when handling fuel.

Stop the engine and keep

heat, sparks, and flame away.
Handle fuel only outdoors.

Wipe up spills immediately.
