If the indicator comes on repeatedly,
even though it may go of f as you
continue driving, have the vehicle
checked by your dealer as soon as
possible.
If this indicator comes on
while driving, it means one
of the engine’s emissions control
systems may have a problem. Even
though you may f eel no dif f erence in
your vehicle’s perf ormance, it can
reduce your f uel economy and cause
increased emissions. Continued
operation may cause serious damage. Your vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics f or the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.
If the battery in your vehicle has
been disconnected or gone dead,
thesecodesmaybeerased.Ittakes
several days of driving under various
conditions to set the codes again.
If your vehicle has an automatic
transmission, the malf unction
indicator lamp may also come on
with the ‘‘D’’ indicator.
If you have recently ref ueled your
vehicle, the indicator coming on
could be due to a loose or missing
f uel f ill cap. Tighten the cap until it
clicks at least once. Tightening the
cap will not turn the indicator of f
immediately; it can take several days
of normal driving.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display.
CONT INUED
Readiness Code
Malf unction Indicator L amp
T aking Care of t he Unexpect ed
597
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
12/07/20 11:47:00 31TK4640_602
2013 TL

ÎIf the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads.
However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will f eel the brake
pedal go down much f arther bef ore
the vehicle begins to slow down, and
you will have to press harder on the
pedal. You will also see a ‘‘LOW BRAKE
FLUID’’ message on the multi-
inf ormation display.
You will also see a ‘‘CHECK BRAKE
SYSTEM’’ message on the multi-
inf ormation display when this
indicator comes on.
To check if they are set, turn the
ignition switch to the ON (II)
position (set the power mode to ON,
on models with keyless access
system), without starting the engine.
The malf unction indicator lamp will
come on f or 20 seconds. If it then
goes of f , the readiness codes are set.
If it blinks f ive times, the readiness
codes are not set. If possible, do not
take your vehicle f or an emissions
test until the readiness codes are set.
Refer to
for
more information (see page ). If the brake system indicator comes
on while driving, the brake f luid level
is probably low. Press lightly on the
brake pedal to see if it f eels normal.
If it does, check the brake f luid level
thenexttimeyoustopataservice
station (see page ). The brake system indicator normally
comes on when you turn the ignition
switch to the ON (II) position, and
as a reminder to check the parking
brake. It will stay on if you do not
f ully release the parking brake.
626 553
Brake System
Indicator
Emissions T esting
Malf unction Indicator L amp, Brake System Indicator
598
Canada
U.S.
12/07/20 11:47:08 31TK4640_603
T aking Care of t he Unexpect ed
Î
Mod els eq uip ped wit h th e keyless
a cce ss sy ste m have an en gin e sta rt/
s to p butto n in ste ad of an ignition
s w it c h .O N Mod e is th e eq uiv ale n t of
O N (II) . F or m ore in fo rm atio n ,se e
p ag es
and .
:
184 187
2013 TL

If the fuel fill door release button
does not work, use the release lever
inside the left maintenance
lid in the trunk.To open the f uel f ill door, pull the
release lever rearward.
Slow down by shif ting to a lower
gear, and pull to the side of the road
when it is saf e. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it towed and repaired by
your dealer as soon as possible (see
on page ).
If you must drive the vehicle a short
distance in this condition, drive
slowly and caref ully.
If the ABS indicator and the VSA
system indicator come on with
the brake system indicator, have
your vehicle inspected by your
dealer immediately.
If you also cannot unlock the trunk
due to the power door lock system
malf unction, see page and open
the trunk manually.
607
155
Opening the Fuel
Fill Door Manually
Emergency T owing
Brake System Indicator, Opening the Fuel Fill Door Manually
T aking Care of t he Unexpect ed
599
RELEASE LEVER
MAINTENANCE LID
12/07/20 11:47:16 31TK4640_604
2013 TL

The vehicle’s f uses are contained in
threefuseboxes.
The interior f use box is located
under the dashboard on the driver’s
side. The f use label is attached
under the steering column.The passenger’s side interior f use
box is on the lower passenger’s side
panel. To remove the f use box lid,
put your f inger in the notch on the
lid, and pull it upward slightly, then
pull it toward you and take it out of
its hinges.The under-hood fuse box is on the
driver’s side next to the air
cleaner housing.
To access the under-hood f use box,
remove the lef t-side engine
compartment cover (see page ).
To access the fuse box, turn the
knob on the under cover one-
quarter turn and pull the front of
the cover straight down to remove
it from the dashboard. 542
Fuses
600
FUSE LABEL
NOTCH
DRIVER’S SIDE
PASSENGER’S SIDE
UNDER-HOOD
AIR CLEANER HOUSING
TAB
12/07/20 11:47:24 31TK4640_605
T aking Care of t he Unexpect ed
2013 TL

Î
If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pages, and , or the diagram on
thefuseboxlidorthefuselabel,
which f use or f uses control that
component. Check those f uses f irst,
but check all the f uses bef ore
deciding that a blown f use is not the
cause. Replace any blown f uses and
check if the device works. Remove the cover from the
Check each of the large f uses in
the under-hood f use box by
looking at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
Turn the ignition switch to the
LOCK (0) position.
Make sure the headlights and all
other accessories are of f .
3.
1.
2.
604 605 606
CONT INUED
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
601
FUSE
BLOWN
12/07/20 11:47:32 31TK4640_606
ÎModels equipped with the
keyless access system have an engine
start/stop button instead of
an ignition switch. VEHICLE OFF
(LOCK) Mode is the equivalent of
LOCK (0).
For more information,
see pages and .
:
184 187
fuse box.
2013 TL

Look f or a blown wire inside the
f use. If it is blown, replace it with
one of the spare f uses of the same
rating or lower.
Check the smaller f uses in the
under-hood f use box and all the
fuses in the interior fuse boxes by
pulling out each one with the f use
pullerprovidedonthebackof the
under-hood f use box cover.
Also check the combined f use box in
the under-hood f use box.
5.
4.
Fuses
602
BLOWN
FUSE PULLER
BLOWN
12/07/20 11:47:37 31TK4640_607
T aking Care of t he Unexpect ed
2013 TL

If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the f use with one of the
correct rating as soon as you can.
Your vehicle has spare fuses
on the back of the under-hood fuse
box cover. 6.
Fuses
T aking Care of t he Unexpect ed
603
FUSE PULLER SPARE FUSES
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
12/07/20 11:47:43 31TK4640_608
2013 TL

µ
µ
µ
µ
µ
µ
µ
µµ
µ
µ
µ
µ
µ
µ
µ µ
µ
µ
Î
Î
Î
Î
Î
Î
Î
Î
Î Î
No.
Circuits Protected
No.
Amps. Amps.
Circuits Protected Circuits Protected
No. Amps.
11
12
21
22
23
24
25
26 IG Main
Sub Fan Motor
Sub Fan Motor
Driver’s Side Fuse Box
Main Fan Motor
Driver’s Side Light Main
Wiper Motor
Passenger’s Side Light Main
31
32
33
34
35
36
37
38
120 A
40 A
70 A
40 A
30 A
40 A
30 A
30 A 50 A
40 A
30 A
60 A
40 A
30 A
30 A
30 A
30 A
Battery
Passenger’s Side Fuse Box
EPS
ABS/VSA MTR
ABS/VSA
Passenger’s Side Fuse Box
Option
Headlight Washer
SH-AWD Rear Defroster
Not Used
Not Used
Not Used
Heater Motor
Hazard
Horn and Stop
Keyless Access System
Battery Sensor
IG Coil
FI Sub
Back Up
Interior Lights
FI Main
DBW
Back Up FI ECU
MG Clutch
Radiator Fan Timer
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21 40 A
40 A
15 A
20 A
7.5 A
7.5 A 15 A
15 A
10 A
7.5 A 15 A
15 A
7.5 A
7.5 A
7.5 A
If equipped Used on SH-AWD models
1:
2:
3: Used on 2WD models
1
2
1
2
3
1 1
Fuse Locations
604
UNDER-HOOD FUSE BOX
12/08/08 20:03:07 31TK4640_609
T aking Care of t he Unexpect ed
2013 TL

µ
µ
µ
Î
Î
Î Î
Î
No. Amps.
Circuits Protected
Amps.
No. Circuits Protected
CONT INUED
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
3210 A
10 A
7.5 A 15 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
20 A
20 A
20 A
15 A
20 A
15 A
10 A
10 A
10 A
7.5 A 15 A
7.5 A
Blind Spot Information
System
SH-AWD
Washer
Wiper
ODS
ABS/VSA
Not Used
Starter Relay
Fuel Pump
7.5 A
7.5 A
20 A
7.5 A
7.5 A
7.5 A
7.5 A 20 A
1
2
3
4
5
6
7
8
9 VB SOL
SRS
Meter
ACG
Not Used
Daytime Running Lights
A/C
Accessory, Key, Lock
Accessory
Driver’s Power Seat Sliding
Moonroof
Driver’s Power Seat Reclining
Rear Left Power Window
Front ACC Socket
Driver’s Power Window
Driver’s Side Door Lock
FrontLeftFogLight
Lef t Side Small Lights
(Exterior)
Left Headlight High Beam
TPMS
Left Headlight Low Beam
Not Used
STS
: If equipped
Fuse Locations
T aking Care of t he Unexpect ed
605
INTERIOR FUSE BOX
Driver’s side
12/07/20 11:47:59 31TK4640_610
2013 TL

µµ
µ
µ
µ
µ
µÎ
Î
No. Amps. Circuits Protected
Amps.
No. Circuits Protected
1
2
3
4
5
610 A
10 A
10 A
15 A
7.5 A Right Headlight High Beam
Right Side Small Lights
(Exterior)
Right Front Fog Light
Right Headlight Low Beam
Not Used
Interior Lights 20 A
20 A
10 A
20 A
10 A
20 A
20 A
15 A
7.5 A 20 A
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 Not Used
Passenger’s Power Seat
Reclining
Passenger’s Power Seat
Sliding
Right Side Door Lock
Rear Passenger’s Side
Power Window
Keyless Access System
Front Passenger’s Power
Window
Not Used
Premium amplifier
Console ACC Socket
Not Used
Lumbar Support
Seat Heaters
Not Used
Not Used
Not Used
: If equipped
Fuse Locations
606
INTERIOR FUSE BOX
Passenger’s side
12/07/20 11:48:05 31TK4640_611
T aking Care of t he Unexpect ed
2013 TL
