Restoring motorcycle
to useRemove the protective wax
coating.
Clean the motorcycle.
Install a charged battery.
Before starting: work
through the checklist.
8129zCare
Page 132 of 165
Page 133 of 165
Technical data
Troubleshooting chart........ 132
Threaded fasteners . . . ........ 133
Engine ....................... 134
Riding specifications . ........ 136
Clutch ....................... 136
Transmission . . . .............. 136
Final drive . ................... 137
Running gear . . . .............. 137
Brakes ....................... 138
Wheels and tyres ............. 138
Electrics . . ................... 139
Frame ....................... 141
Dimensions .................. 141
Weights . . . ................... 142
9131zTechnical data
Page 134 of 165
Troubleshooting chartEngine does not start at all or is difficult to start.Possible causeRemedyKill switch activated. Kill switch in operating position (run).
Side stand extended and gear engaged. Retract the side stand ( 64).
Gear engaged and clutch not disengaged Select neutral or pull clutch lever( 64).
Clutch pulled when ignition was OFF Switch on the ignition, then pull the clutch
lever.
No fuel in tank. Refuelling ( 78)
Battery not adequately charged. Charging battery when connected ( 120)
9132zTechnical data
Page 135 of 165
Threaded fastenersActivityType of threaded connection Tightening
torquesFront wheel
Front brake caliper, wheel carrier
installedM8 x 32 -10.9
30 Nm (Left)
M8 x 32 -10.9 30 Nm (Right)
Clamping screw for quick-release
axle in wheel carrier M8 x 30
19 Nm
Quick-release axle in threaded
bush M24 x 1.5
50 Nm
Rear wheel
Rear wheel to wheel flange M10 x 1.25 (length 40 mm) 60 Nm
Silencer to rear footrest, right M8 x 30 28 Nm
Silencer to manifold M8 - 10.9 self-locking, Optimoly TA 35 Nm
9133zTechnical data
Page 136 of 165
EngineEngine, typeTransversely mounted, four-cylinder
four-stroke in-line engine tilted 55° forward,
with four valves per cylinder, two overhead
camshafts with cam followers; liquid cooled,
with electronic fuel injection, integrated
six-speed cassette gearbox, dry-sump
lubrication.
Effective displacement 1157 cm
3
Cylinder bore79 mm
Piston stroke 59 mm
Compression ratio 13 : 1
Nominal output 120 kW, At: 10250 min
-1
with OE Power reduction:74 kW, At: 7000 min
-1
with OE Power reduction:79 kW, At: 8750 min
-1
Max. torque127 Nm, At: 8250 min
-1
with OE Power reduction:110 Nm, At: 5250 min
-1
with OE Power reduction:103 Nm, At: 4500 min
-1
Maximum permissible engine speed11000 min
-1
Idle speed1150
±50
min
-1
9134zTechnical data
Page 137 of 165
Fuel
Recommended fuel gradeSuper Plus, unleaded
98 ROZ
Fuel grade, usable with power- and
consumption-related restrictions Super unleaded
95 ROZ
Fuel tank capacity 19 l, Usable
4 l, Including reserve of
Engine oil
Engine oil capacity, total 3.5 l, With filter change
0.5 l, Difference between MIN / MAX marks
Lubricant Castrol GPS 10W-40 (SAE 10W40; API SG;
JASO MA)
Oil grades Mineral engine oils of API classification SF to
SH. BMW Motorrad recommends not using oil
additives, because they can have a detriment-
al effect on clutch operation.
Permissible viscosity classes
SAE 5 W- 30 -20...20 °C, Use in winter
SAE 10 W-40 -10...30 °C, At low temperatures
9135zTechnical data
Page 138 of 165
Riding specificationsTop speed>200 km/h
Acceleration 0-100 km/h 2.9 sClutchClutch, typeMultiplate clutch running in oil bathTransmissionGearbox, typeClaw-shift 6-speed cassette gearbox, integ-
rated into engine block
Gear ratios
Total gear ratio, 1st gear 2.521
Total gear ratio, 2nd gear 1.842
Total gear ratio, 3rd gear 1.455
Total gear ratio, 4th gear 1.287
Total gear ratio, 5th gear 1.143
Total gear ratio, 6th gear 1.015
9136zTechnical data
Page 139 of 165
Final driveRear wheel drive, typeShaft drive with bevel gears
Final drive gear ratio 2.91 : 1Running gearFront suspension, typeDouble leading link
Front suspension, total suspension travel 115 mm, Static 125 mm, Dynamic
Rear suspension, type Single-tube gas-pressure shock absorber
Rear suspension, total suspension travel 135 mm, At wheel
9137zTechnical data
Page 140 of 165
BrakesFront brake, typeHydraulically operated twin disc brake with 4-
piston fixed calipers and floating brake discs
Front brake pads, material Sintered metal
Rear brake, type Hydraulically operated disc brake with
2-piston floating caliper and fixed disc
Rear brake pads, material Organic materialWheels and tyresFront wheel, typeCast aluminium, MT H2
Front wheel, rim size 3.50" x 17"
Front wheel, tyre designation 120/70 ZR17
Rear wheel, type Cast aluminium, MT H2
Rear wheel, rim size 5.50" x 17"
with OE Sports wheel: 6.00" x 17"
Rear wheel, tyre designation 180/55 ZR17
with OE Sports wheel: 190/50 ZR17
Tyre pressures
Front wheel, tyre pressure 2.5 bar, When cold
Rear wheel, tyre pressure 2.9 bar, When cold
9138zTechnical data
