CHEVROLET TRACKER 2003 2.G Owners Manual

Cruise Control
If your vehicle has cruise control, you can maintain a
speed of about 25 mph (40 km/h) or more without
keeping your foot on the accelerator. This can really
help on long trips. Cruise control will not set at speeds
below about 25 mph (40 km/h).
{CAUTION:
·Cruise control can be dangerous where
you can not drive safely at a steady speed.
So, do not use your cruise control on
winding roads or in heavy traffic.
·Cruise control can be dangerous on
slippery roads. On such roads, fast
changes in tire traction can cause
needless wheel spinning, and you could
lose control. Do not use cruise control on
slippery roads.
Setting Cruise Control
1. Press the CRUISE
ON/OFF button located
on the instrument panel
to turn the system on.
The indicator light in the
button will come on.
Wait at least one
second after turning
the system on before
setting a speed.
Once the CRUISE ON/OFF switch is turned on,
it will come on each time you start your vehicle until
you manually turn if off.
3-9

2. Accelerate to the speed you want, turn the end of
the lever to COAST SET and release it; the
CRUISE light will come on. Cruise will not set below
25 mph (40 km/h).
3. Take your foot off the accelerator pedal.
Resuming a Set Speed
If you set your cruise control at a desired speed then
suspend cruise by applying the brake, by pressing
the clutch pedal if you have a manual transmission or
by pressing CANCEL, you don't need to reset it.
You may resume your previously set speed by brie¯y
turning the switch to RESUME ACCEL (Accelerate),
provided your speed has not dropped below 25 mph
(40 km/h). If your speed has dropped below 25 mph
(40 km/h), accelerate to 25 mph (40 km/h) or greater
then turn the switch to RESUME ACCEL. There is
a short time delay after your speed is suspended until
you can reset the cruise control to your desired speed.
Increasing Speed While Using Cruise
Control
There are two ways to go to a higher speed.
·Use the accelerator pedal to go to a higher speed.
Turn the switch on the lever down to COAST SET
and release it. Take your foot off the accelerator
pedal. You'll now cruise at the higher speed.
·Turn the switch on the lever up to RESUME
ACCEL. Hold the switch at RESUME ACCEL until
you get up to the speed you want, then release
the switch.
3-10

Reducing Speed While Using Cruise
Control
To reduce your speed, turn the switch and hold it down
in the COAST SET position until you reach the lower
speed you want, then release the switch.
Passing Another Vehicle While Using
Cruise Control
Use the accelerator pedal to increase your speed.
When you take your foot off the pedal, your vehicle will
slow down to the cruise control speed you set earlier.
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the
hills. When going up steep hills, you may have to step
on the accelerator pedal to maintain your speed.
When going downhill, you may have to brake or shift
to a lower gear to keep your speed down. Of course,
applying the brake suspends cruise control. Many
drivers ®nd this to be too much trouble and don't use
cruise control on steep hills.
Suspending Cruise Control
There are two ways to suspend cruise control:
·Step lightly on the brake pedal, or push the clutch
pedal if you have a manual transmission.
·Push in the CANCEL button on the end of the
cruise control lever.
Ending Cruise Control
To end cruise control press CRUISE ON/OFF on the
instrument panel.
Erasing Speed Memory
Cruise control set speed memory is erased when you
turn off the CRUISE ON/OFF switch or anytime you turn
the ignition off.
3-11

Exterior Lamps
The lever on the left side of the steering column
operates the exterior lamps.
Turn the outside part of the lever to operate the lamps.The exterior lamps control has three positions:
OFF:Turn the control to this position to turn off all
lamps, except the Daytime Running Lamps (DRL) or
if the Automatic Headlamp System is working.
;(Parking Lamps):Turn the control to this position
to turn on the parking lamps, together with the
following:
·Sidemarker Lamps
·Taillamps
·License Plate Lamp
·Instrument Panel Lights
P(Headlamps):Turn the control to this position to
turn on the headlamps, together with the previously
listed lamps and lights.
3-12

Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the
day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the short
periods after dawn and before sunset. Fully functional
daytime running lamps are required on all vehicles
®rst sold in Canada.
The DRL system will make your headlamps come on at
a reduced brightness when the three following
conditions are met:
·The ignition is on with the engine running,
·the exterior lamps control is off or the parking lights
are on, and
·the parking brake is released.
When the DRL are on, only your headlamps will be on
at a reduced brightness. The taillamps, sidemarker
and other lamps won't be on. Your instrument panel
won't be lit up either.When you move the exterior lamps control to the
headlamp position, your DRL will go off and your
headlamps will come on. The other lamps that come on
with your headlamps will also come on.
When it begins to get dark, the headlamps will
automatically switch from DRL to the regular headlamps.
See ªAutomatic Headlamp Systemº following.
When you turn the exterior lamp control to off, the
regular lamps will go off and your headlamps will change
to the reduced brightness of DRL provided it is not
dark outside. DRL will also come on if only the parking
lamps are being used.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
3-13

Automatic Headlamp System
Your vehicle is equipped with an automatic light sensor
on top of the instrument panel, on the passenger's
side of the vehicle, so be sure it is not covered. If it is,
the headlamps will remain on continuously.
There is a delay in the transition between the daytime
and nighttime operation of the DRL and the Automatic
Headlamp Systems so that driving under bridges or
bright overhead street lights does not affect the system.
The DRL and Automatic Headlamp Systems will only
be affected when the light sensor sees a change
in lighting lasting longer than this delay.
When it is dark enough outside, or you are driving
through a parking garage, heavy overcast weather
or a tunnel, the system will turn on your low-beam
headlamps at normal brightness. Along with your
vehicle's headlamps, the taillamps, sidemarker, parking
lamps and the instrument panel lights will also turn
on. The radio display will dim.
As with any vehicle, you should turn on the regular
headlamps when you need them.To temporarily disable your vehicle's DRL and Automatic
Headlamp Systems functions, do the following:
1. Before turning the ignition key to ON or START,
set the parking brake.
2. Then turn the ignition key to ON or START.
·The Automatic Headlamp System will not turn on
under any conditions, even in darkness.
·The DRL will not turn on.
The DRL and Automatic Headlamp System functions will
stay off with the ignition on, until you release the parking
brake. Once the parking brake is released the DRL will
turn on if it is daylight or the Automatic Headlamp System
will turn on if it is dark enough outside.
If you turn the ignition key to ON or START and then set
the parking brake, the DRL will turn off (in all conditions)
and the Automatic Headlamp System will remain on
(if dark enough outside). Any other uses of the parking
brake after the engine is turned on will have no effect on
the normal Automatic Headlamp System operation.
Headlamps On Reminder
If you turn the ignition off, remove the key, open the
door and leave the lamps on, a tone will remind you to
turn off your lamps.
3-14

Interior Lamps
Instrument Panel Brightness
The thumbwheel for this
feature is located to the
left of the steering
wheel on the instrument
panel.
Move the thumbwheel upward to brighten the instrument
panel lights or downward to dim them.
Dome Lamp
The dome lamp operates as follows:
OFF:This position is to the left when you are sitting in
the driver's seat. The dome lamp will stay off even
when a door is opened.
Center:The lamp will come on when a door is opened.
The dome lamp will turn off while all doors are shut.
ON:This position is to the right when you are sitting in
the driver's seat. The dome lamp will turn on and
stay on whether or not a door is open.
3-15

Entry Lighting
If your vehicle has remote keyless entry, it is equipped
with an entry lighting feature that controls your dome
lamp (and cargo lamp, if equipped). For the dome lamp
to operate as described below, the switch must be in
the middle position:
Your interior lamps will come on and stay on for a set
time whenever you press the UNLOCK button on
the remote keyless entry transmitter.
If you open any door, the lamps will stay on while
the door is open, then turn off automatically about
40 seconds after the last door is closed. If you press the
UNLOCK button on the remote keyless entry transmitter
and don't open a door, the lamps will come on and
then turn off after about 40 seconds.
The lamps will turn off immediately if you turn the
ignition key to ON. When the ignition is on, the entry
lighting feature is inactive. The interior lamps will come
on only if they are turned on by the dome lamp
switch or one of the doors is opened.
When you press the LOCK button on the remote keyless
entry transmitter, the interior lamps will come on for about
three seconds, and then shut off.
Reading Lamps
Your vehicle's inside rearview mirror may have reading
lamps.
Push the buttons on the bottom of the mirror to turn the
reading lamps on and off.
Cargo Lamp
Some four-door models are equipped with a cargo
lamp. The cargo lamp comes on when any door
is opened, and goes off when all doors are shut.
3-16

Accessory Power Outlets
If your vehicle has an accessory power outlet, you can
plug in auxiliary electrical equipment.
The accessory power outlet is located in the center
console near the parking brake.
To use the outlet, open the cover. When not using it,
always cover the outlet with the protective cap.
These circuits are protected by a fuse and have
maximum current levels.
Notice:Leaving electrical equipment on for
extended periods will drain the battery. Always turn
off electrical equipment when not in use and do
not plug in equipment that exceeds the maximum
amperage rating.
Certain power accessory plugs may not be compatible
to the power accessory outlet and could result in
blown vehicle or adapter fuses.
If you experience a problem see your dealer for
additional information on the power accessory plugs.
When adding electrical equipment, be sure to follow the
proper installation instructions included with the
equipment.
Notice:Adding any electrical equipment to your
vehicle may damage it or keep other components
from working as they should. The repairs would not
be covered by your warranty. Check with your
dealer before adding electrical equipment.
Notice:Improper use of the power outlet can cause
damage not covered by your warranty. Do not
hang any type of accessory or accessory bracket
from the plug because the power outlets are
designed for accessory power plugs only.
Ashtrays and Cigarette Lighter
To use the lighter, if equipped, the ignition key must be
in ON or ACC. Push the lighter in all the way and let
go. When it's ready, it will pop back out by itself.
Pull the door to open the ashtray. To remove it, press
down on the tab and pull the ashtray out. To reinstall the
ashtray, push it in until the tab latches.
The rear ashtray, if equipped, is on the back of the
center console. Push on the left side of the ashtray.
The ashtray will turn clockwise for usage. To remove the
rear ashtray, press down on the tab and pull it out.
Notice:If you put papers or other ¯ammable items
in the ashtray, hot cigarettes or other smoking
materials could ignite them and possibly damage
your vehicle. Never put ¯ammable items in the
ashtray.
3-17

Climate Controls
Climate Control System
With this system you can control the heating, cooling
and ventilation for your vehicle.
Operation
9
(Fan):Move the lever away from OFF to turn the
system on. Slide the top right lever to the left or right to
increase or decrease the fan speed.If the air¯ow seems low when the fan is at the
highest setting, the passenger compartment air ®lter,
if equipped, may need to be replaced. For more
information, see
Passenger Compartment Air Filter on
page 3-22andShort Trip/City Scheduled Maintenance
on page 6-7.
Slide the top left lever to the left or right to direct the
air¯ow inside of your vehicle.
To change the current mode, select one of the following:
H(Vent):This mode directs air to the instrument
panel outlets.
)(Bi-Level):This mode directs most of the air to the
instrument panel outlets, and then directs the remaining
air to the ¯oor outlets.
6(Floor):This mode directs half of the air to the
¯oor outlets with some air directed to the outboard
outlets (for the side windows) and some air directed to
the windshield.
This lever can also be used to select defog or defrost
mode. Information on defogging and defrosting can
be found later in this section.
3-18
