CHEVROLET TRACKER 2003 2.G Owners Manual

:(Outside Air):Slide the lower right lever to the
right for outside air. With the lever in this position,
outside air will circulate throughout your vehicle.
?(Recirculation):Slide the lower right lever to the
left for recirculated air. With the lever in this position
outside air and odors can be prevented from entering
your vehicle and also helps heat or cool the air
inside your vehicle more quickly.
If the lever is in the middle of the two positions, you will
have both outside and recirculated air inside your
vehicle.
If you are in city traffic, your vehicle is stopped and
idling or the weather is hot, the system may be switched
from the outside air mode to the recirculation mode.
To help prevent the air inside of your vehicle from
becoming too stale, be sure to return to outside air
periodically.
Temperature Control:Slide the lever located on the
lower left side to change the temperature. Move it to
the right for warmer air and to the left for cooler
air. Without air conditioning, the air temperature cannot
be less than the outside air temperature.Air Conditioning (A/C):Press the air conditioning
(A/C) button to turn the air-conditioning system on or off.
When A/C is pressed, an indicator light in the button
will come on to let you know that the air conditioning is
activated.
On hot days, open the windows to let hot inside air
escape; then close them. This helps to reduce the time
it takes for your vehicle to cool down. It also helps
the system to operate more efficiently.
For quick cool down on hot days:
1. Select the vent mode.
2. Select the recirculation mode.
3. Select A/C.
4. Select the coolest temperature.
5. Select the highest fan speed.
The air-conditioning system removes moisture from the
air, so you may sometimes notice a small amount of
water dripping underneath your vehicle while idling
or after turning off the engine. This is normal.
3-19

Defogging and Defrosting
Fog on the inside of windows is a result of high humidity
(moisture) condensing on the cool window glass.
This can be minimized if the climate control system is
used properly. There are two modes to clear fog or frost
from your windshield. Use the defog mode to clear
the windows of fog or moisture and warm the
passengers. Use the defrost mode to remove fog or
frost from the windshield more quickly.
-(Defog):This mode directs the air between the
windshield, side windows, instrument panel outlets and
the ¯oor outlets. The air-conditioning compressor
will run automatically in this setting without pressing
A/C, unless the outside temperature is at or below
freezing.
1(Defrost):This mode directs the air to the
windshield and the side windows. The air-conditioning
compressor will run automatically in this setting without
pressing A/C, unless the outside temperature is at or
below freezing. Do not drive the vehicle until all the
windows are clear.
Rear Window Defogger
If your vehicle has this feature, the rear window defogger
uses a warming grid to clear fog from the rear window.
The button is located
on the center of the
instrument panel, near the
vehicle's comfort controls.
The rear window defogger will only work when the
ignition is in ON.
=(Rear Defogger):Press the defogger button to turn
the rear window defogger on or off. An indicator light
in the button will come on to let your know that the rear
window defogger is activated. Be sure to clear as
much snow from the rear window as possible.
3-20

The rear window defogger will turn off automatically
about 15 minutes after the button is pressed.
The defogger can also be turned off by pressing the
button again or by turning off the engine.
Notice:Using a razor blade or sharp object to clear
the inside rear window may damage the rear
window defogger. Repairs would not be covered by
your warranty. Do not clear the inside of the rear
window with sharp objects.
Outlet Adjustment
Use the air outlets located
in the center and outboard
sides of the instrument
panel, to change the
direction and amount of
the air ¯owing through
the vents.
Operation Tips
·Clear away any ice, snow or leaves from the air
inlets at the base of the windshield that may
block the ¯ow of air into your vehicle.
·Use of non-GM approved hood de¯ectors may
adversely affect the performance of the system.
·Keep the path under the front seats clear of objects
to help circulate the air inside of your vehicle more
effectively.
·If the air¯ow seems low when the fan is at the
highest setting, the passenger compartment
air ®lters, if equipped, may need to be replaced.
For more information, see ªPassenger Compartment
Air Filterº following and
Short Trip/City Scheduled
Maintenance on page 6-7.
3-21

Passenger Compartment Air Filter
All models come equipped from the factory with a slot in
the ventilation system that is ready to accept passenger
compartment air ®lters. These ®lters are available for
purchase from your dealer. You will need to install two
®lters to provide the proper ®ltration.
Both outside and recirculated air ¯ows through these
®lters and removes certain contaminates including pollen
and dust particles.
Reductions in air¯ow which occur more quickly in dusty
areas, may indicate that the ®lters need to be replaced
earlier than listed in the maintenance schedule. For how
often to replace your air ®lters, see
Maintenance
Requirements on page 6-2.
The access panel for the air ®lters is behind the
glove box.To install the air ®lters, do the following:
1. Lower the glove box door, then push in the sides of
the glove box to completely lower the door to allow
access to the slot where the air ®lters will be
installed.
3-22

2. Lift the top tab on the cover to remove the ®lter
cover.3. Install the lower ®lter by dropping it down into the slot.
The grooves on the two ®lters must be lined up with
each other as well as with the ventilation housing in
order to install the ®lters properly. The tabs on the
®lters should face outward towards you and should
be at the top of the ®lters. The arrows on the ®lters
should point to the driver's side of the vehicle.
4. Then line up the grooves of the second ®lter with the
lower one and slide it in on top of the lower one.
5. Reverse the steps to remove the air ®lters and
then install new ones.
Once you remove the ®lter, if you choose not to replace
it, it will not damage your vehicle. However, the air
will no longer be ®ltered.
3-23

Warning Lights, Gages and
Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause
an expensive repair or replacement. Paying attention
to your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on brie¯y when you start the engine
just to let you know they're working. If you are familiar
with this section, you should not be alarmed when
this happens.Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages
and warning lights work together to let you know when
there's a problem with your vehicle.
When one of the warning lights comes on and stays on
when you are driving, or when one of the gages
shows there may be a problem, check the section
that tells you what to do about it. Please follow this
manual's advice. Waiting to do repairs can be
costly ± and even dangerous. So please get to know
your warning lights and gages. They're a big help.
3-24

Instrument Panel Cluster
Your instrument cluster is designed to let you know at a glance how your vehicle is running. You'll know how fast
you're going, about how much fuel you have left, and many other things you'll need to know to drive safely and
economically.
United States cluster shown, Canada similar
3-25

Speedometer and Odometer
Your speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
Your odometer shows how far your vehicle has
been driven, in either miles (used in the United States)
or kilometers (used in Canada).
Your vehicle's odometer is tamper-resistant.
You may wonder what happens if your vehicle needs a
new odometer installed. The new one is set at zero.
Then a label is attached on the driver's door to show
the old reading and when the new one was installed.
Trip Odometer
The trip odometer can tell you how far your vehicle has
been driven since you last set the trip odometer to
zero. The button located to the right of the odometer
display allows you to switch between the odometer
and the two trip odometers. Press the button once to
switch to TRIP A and again to switch to TRIP B.
To return the display to the odometer reading,
press the trip odometer button again.
To set the trip odometers to zero, press and hold
the button.
Tachometer
The tachometer shows engine speed in thousands of
revolutions per minute (rpm). You can use it while
driving to select correct shift points. The tachometer
may not return to zero when the engine is not running.
Notice:If you operate the engine with the
tachometer in the shaded warning area, your vehicle
could be damaged, and the damages would not
be covered by your warranty. Do not operate
the engine with the tachometer in the shaded
warning area.
Safety Belt Reminder Light
When the key is turned to ON or START, a tone will
come on for several seconds to remind people to fasten
their safety belts, unless the driver's safety belt is
already buckled.
The safety belt light will
also come on and stay on
until the driver's belt is
buckled.
3-26

Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks
the air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag modules, and the crash
sensing and diagnostic module. For more information
on the air bag system, see
Supplemental Restraint
System (SRS) on page 1-54.
This light will come on
when you start your
vehicle, and it will ¯ash
for a few seconds.
Then the light should go
out. This means the
system is ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air
bag system may not work properly. Have your vehicle
serviced right away.
{CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not in¯ate in a crash, or they
could even in¯ate without a crash. To help
avoid injury to yourself or others, have your
vehicle serviced right away if the air bag
readiness light stays on after you start your
vehicle.
The air bag readiness light should ¯ash for a few
seconds when you turn the ignition key to ON. If the
light doesn't come on then, have it ®xed so it will
be ready to warn you if there is a problem.
3-27

Charging System Light
This light will come on
brie¯y when you turn on the
ignition, but the engine is
not running, as a check to
show you it is working.
Then it should go out when
the engine starts.
If the light stays on or comes on while you are driving,
you may have a problem with the electrical charging
system. It could indicate that you have an electrical
problem. Have it checked right away. Driving while this
light is on could drain your battery.
If you must drive a short distance with this light on, be
certain to turn off all your accessories, such as the radio
and air conditioner.
Brake System Warning Light
When the ignition is on, the brake system warning light
will come on when you set your parking brake. The
light will stay on if your parking brake doesn't release
fully. If it stays on after your parking brake is fully
released, it means you have a brake problem.
Your vehicle's hydraulic brake system is divided into two
parts. If one part isn't working, the other part can still
work and stop you. For good braking, though, you need
both parts working well.
If the warning light comes on, there could be a brake
problem. Have your brake system inspected right away.
3-28
