Page 61 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 33 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
170,000 km or 102 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oFlush and replace the engine coolant if not done at 60 months.
oFlush and replace the traction power inverter module (TIPM) coolant.
oReplace the spark plugs.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
102 Months or
170,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 62 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 34 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oFlush and replace the engine coolant if not done at
60 months.
oFlush and replace the traction power inverter module
(TIPM) coolant.
oReplace the spark plugs.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
170,000 km or 102 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
Page 63 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 35 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
180,000 km or 108 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oInspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
oInspect the front and rear axle fluid; change if using your vehicle for any of the
following: police, taxi, fleet, off-road or frequent trailer towing.
oInspect the brake linings; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
108 Months or
180,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 64 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 36 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oInspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
oInspect the front and rear axle fluid; change if using your
vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.
oInspect the brake linings; replace if necessary.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
180,000 km or 108 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
Page 65 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 37 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
190,000 km or 114 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
114 Months or
190,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 66 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 38 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
190,000 km or 114 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
Page 67 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 39 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
200,000 km or 120 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oReplace the engine air filter.
oInspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
oInspect the transfer case fluid; change if using your vehicle for any of the following:
police, taxi, fleet or frequent trailer towing.
oInspect the brake linings; replace if necessary.
oInspect the CV joints.
oInspect the exhaust system.
oChange the automatic transmission fluid and filter.
oReplace the accessory drive belt(s).
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
120 Months or
200,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 68 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 40 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oReplace the engine air filter.
oInspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
oInspect the transfer case fluid; change if using your vehicle
for any of the following: police, taxi, fleet or frequent
trailer towing.
oInspect the brake linings; replace if necessary.
oInspect the CV joints.
oInspect the exhaust system.
oChange the automatic transmission fluid and filter.
oReplace the accessory drive belt(s).
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
200,000 km or 120 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
