II
!
C O M F O R T
71 * O n 5 - s e a t v e r s i o n o n l y .
R a i s e t h e b o o t fl o o r t o g a i n a c c e s s t o
t h i s c o m p a r t m e n t .
Right-hand side enclosed storage
compartment
T h i s s t o r a g e c o m p a r t m e n t c o n t a i n s t h e
t o o l s f o r c h a n g i n g a w h e e l . S t o r a g e c o m p a r t m e n t i n t h e fl o o r *
12 volt socket (120 W max)
There are four stowing rings in the boot
for securing luggage:
- t w o r i n g s a r e l o c a t e d o n t h e b o o t fl o o r ,
- two rings are located on the rear s i d e p i l l a r s .
T h i s o p e r a t e s w h e n t h e i g n i t i o n s w i t c h
i s i n t h e " O N " o r " A C C " p o s i t i o n .
Lift the cover to gain access to the
s o c k e t .
C h e c k t h a t t h e e l e c t r i c a l e q u i p -
m e n t o p e r a t e s w i t h 1 2 v o l t s a n d
t h a t i t s m a x i m u m e l e c t r i c a l p o w e r
i s 1 2 0 W .
T h e p r o l o n g e d u s e o f e l e c t r i c a l e q u i p -
ment without running the engine may
d i s c h a r g e t h e b a t t e r y .
S t o w i n g r i n g s
Page 72 of 230
II
!
C O M F O R T
72
Second installation position.
T h e l o a d s p a c e c o v e r c a n b e s e c u r e d
i n t w o d i f f e r e n t p o s i t i o n s B , so that the
r o w 2 s e a t b a c k s c a n b e t i l t e d .
1. R o l l u p t h e l o a d s p a c e c o v e r .
2. Move one of the slides C towards
the inside of the vehicle and insert
the tab D in the installation hole to
b e u s e d .
M o v e t h e o p p o s i t e s l i d e i n t h e s a m e w a y .
3. A f t e r c h a n g i n g t h e p o s i t i o n , c h e c k
t h a t t h e l o a d s p a c e c o v e r i s s e c u r e d
c o r r e c t l y . Removing the load space cover.
1. R o l l u p t h e l o a d s p a c e c o v e r .
2. Move one of the slides C towards the
i n s i d e o f t h e v e h i c l e a n d r a i s e i t .
R e l e a s e t h e o p p o s i t e s l i d e i n t h e s a m e w a y .
T o p u t t h e l o a d s p a c e c o v e r i n p l a c e , c a r r y
o u t t h e o p e r a t i o n s i n r e v e r s e o r d e r .
Load space cover
U n r o l l t h e l o a d s p a c e c o v e r a n d i n s t a l l i t
in the securing groove A .
T o s t o r e t h e l o a d s p a c e c o v e r , r e l e a s e
i t f r o m t h e s e c u r i n g g r o o v e , i t r o l l s u p t o
i t s i n i t i a l p o s i t i o n .
T a k e c a r e n o t t o p l a c e h e a v y
o b j e c t s o n t h e l o a d s p a c e c o v e r
w h e n i t i s u n f o l d e d .
T h e l o a d s p a c e c o v e r c a n b e s t o r e d
along the lower tailgate, unless audio
e q u i p m e n t i s p r e s e n t .
Page 73 of 230
III
A C C E S S
73
Unfolding the key
First press button A to unfold the
key.
Unlocking the vehicle
Press the open padlock to
unlock the vehicle.
Unlocking using the remote control
REMOTE CONTROL KEY
System which permits central unlock-
ing or locking of the vehicle using the
lock or from a distance. It also folds and
unfolds the mirrors, closes the electric
windows and starts the vehicle, as well
as providing protection against theft.
Locking the vehicle
Unlocking using the key
Turn the key to the right in the driver's
door lock to unlock the vehicle.
Press the closed padlock
to lock the vehicle.
If one of the doors or the tailgate is
still open, the central locking will not
take place.
U n l o c k i n g i s c o n fi r m e d b y t h e i n t e r i o r
lighting which comes on for approxi-
mately 15 seconds and the direction
i n d i c a t o r s w h i c h fl a s h
twice .
If you press the open padlock twice in
succession within 30 seconds after
unlocking the vehicle, the exterior mir-
rors unfold.
Normal locking using the key
Turn the key to the left in the driver's
door lock to lock the vehicle.
L o c k i n g i s c o n fi r m e d b y t h e d i r e c t i o n
indicators which come on
once .
If you press the closed padlock twice
in succession within 30 seconds after
locking the vehicle, the exterior mirrors
fold.
An extended press on the closed
padlock within 30 seconds after locking
the vehicle permits automatic closing of
the windows.
Normal locking using the remote
control
Page 74 of 230
III
A C C E S S
74
The vehicle will relock automatically
after thirty seconds unless a door or
the tailgate is opened. This function
prevents inadvertent unlocking.
The duration which precedes the au-
tomatic relocking of the vehicle can
b e c o n fi g u r e d v i a t h e c o l o u r d i s p l a y
"Equipment" menu.
Folding the key
First press button A to fold the key. Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the igni-
tion is switched on, this code must be
recognised to permit starting.
This electronic engine immobiliser locks
the engine management system a few
moments after the ignition is switched
off and prevents starting of the engine
by anyone who does not have the key.
Anti-theft protection
In the event of a malfunction and if
your vehicle does not start; contact a
CITROËN dealer as soon as possible.
Page 75 of 230
III
A C C E S S
75
Starting the vehicle
Insert the key in the ignition switch.
Operate the starter by turning the
key to position 4 (START) .
When the engine turns over, release
the key. The ignition switch is placed
in position 3 (ON) automatically.
Switching the vehicle off
Park the vehicle.
While pressing the key, turn it
towards you to position 1 (LOCK) .
Remove the key from the ignition
switch. Changing the battery
Battery reference: CR1616/3 volts.
Unclip the casing using a coin at the
notch.
S l i d e t h e fl a t b a t t e r y o u t o f i t s h o u s i n g .
Slide the new battery into its hous-
ing observing the original direction.
Clip the casing.
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
Page 76 of 230
III
!
A C C E S S
76
Do not throw the remote control batteries away, they contain metals which are harmful to the environment.
Take them to an approved collection point.
Keys
Make a careful note of the number of each key. This number is coded on the label attached to the key.
If the keys are lost, a CITROËN dealer can supply you with ne w keys.
Remote control
The high frequency remote control is a sensitive system; do not o perate it while it is in your pocket as there is a possibility
that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk
of stopping it from working.
The remote control does not operate when the key is in the i gnition, even when the ignition is switched off.
Locking the vehicle
D r i v i n g w i t h t h e d o o r s l o c k e d m a y m a k e a c c e s s t o t h e p a s s e n g e r c o m p a r t m e n t b y t h e e m e r g e n c y s e r v i c e s m o r e d i f fi c u l t
in an emergency.
As a safety precaution (with children on board), remove the key fro m the ignition when you leave the vehicle, even for a
short time.
Anti-theft protection
D o n o t m a k e a n y m o d i fi c a t i o n s t o t h e e l e c t r o n i c e n g i n e i m m o b i l i s e r s y s t e m , t h i s c o u l d c a u s e m a l f u n c t i o n s .
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure tha t the keys in your possession are the only ones which
can start the vehicle.
Page 77 of 230
III
A C C E S S
74
The vehicle will relock automatically
after thirty seconds unless a door or
the tailgate is opened. This function
prevents inadvertent unlocking.
The duration which precedes the au-
tomatic relocking of the vehicle can
b e c o n fi g u r e d v i a t h e c o l o u r d i s p l a y
"Equipment" menu.
Folding the key
First press button A to fold the key. Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the igni-
tion is switched on, this code must be
recognised to permit starting.
This electronic engine immobiliser locks
the engine management system a few
moments after the ignition is switched
off and prevents starting of the engine
by anyone who does not have the key.
Anti-theft protection
In the event of a malfunction and if
your vehicle does not start; contact a
CITROËN dealer as soon as possible.
Page 78 of 230
III
!
A C C E S S
76
Do not throw the remote control batteries away, they contain metals which are harmful to the environment.
Take them to an approved collection point.
Keys
Make a careful note of the number of each key. This number is coded on the label attached to the key.
If the keys are lost, a CITROËN dealer can supply you with ne w keys.
Remote control
The high frequency remote control is a sensitive system; do not o perate it while it is in your pocket as there is a possibility
that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk
of stopping it from working.
The remote control does not operate when the key is in the i gnition, even when the ignition is switched off.
Locking the vehicle
D r i v i n g w i t h t h e d o o r s l o c k e d m a y m a k e a c c e s s t o t h e p a s s e n g e r c o m p a r t m e n t b y t h e e m e r g e n c y s e r v i c e s m o r e d i f fi c u l t
in an emergency.
As a safety precaution (with children on board), remove the key fro m the ignition when you leave the vehicle, even for a
short time.
Anti-theft protection
D o n o t m a k e a n y m o d i fi c a t i o n s t o t h e e l e c t r o n i c e n g i n e i m m o b i l i s e r s y s t e m , t h i s c o u l d c a u s e m a l f u n c t i o n s .
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure tha t the keys in your possession are the only ones which
can start the vehicle.
Page 79 of 230
III
A C C E S S
75
Starting the vehicle
Insert the key in the ignition switch.
Operate the starter by turning the
key to position 4 (START) .
When the engine turns over, release
the key. The ignition switch is placed
in position 3 (ON) automatically.
Switching the vehicle off
Park the vehicle.
While pressing the key, turn it
towards you to position 1 (LOCK) .
Remove the key from the ignition
switch. Changing the battery
Battery reference: CR1616/3 volts.
Unclip the casing using a coin at the
notch.
S l i d e t h e fl a t b a t t e r y o u t o f i t s h o u s i n g .
Slide the new battery into its hous-
ing observing the original direction.
Clip the casing.
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
Page 80 of 230
III
A C C E S S
77
The electric window switches can
b e c o n fi g u r e d v i a t h e c o l o u r d i s p l a y
"Equipment" menu.
The electric window switches re-
main operational for approximate-
ly 30 seconds after the ignition is
switched off and the switch on the
driver's door remains operational for
a further 30 seconds when the door
is opened.
The windows can no longer be
opened or closed after the driver's
door is closed.
The rear windows do not lower fully.
ELECTRIC WINDOWS
1. Driver's electric window switch.
2.
Passenger's electric window switch.
3. Rear right electric window switch.
4. Rear left electric window switch.
5. Disarming of the passenger and
rear electric window switches. In the event of unwanted opening of
the window on closing (for example
in the presence of frost), reinitialise
the electric windows (refer to the cor-
responding paragraph).
Safety auto-reverse
In automatic mode, when the window
rises and meets an obstacle, it stops
and lowers again.
Operation
With the ignition on, you have two op-
tions:
-
manual mode
Press the switch gently to open or
pull it gently to close. The window
stops as soon as the switch is
released.
- automatic mode
Press the switch fully to open or
pull it fully to close. The window
opens or closes completely when
the switch is released.
Pressing the switch again stops
the movement of the window.
System which opens or closes a window
m a n u a l l y o r a u t o m a t i c a l l y . I t i s fi t t e d w i t h
a system which provides protection if an
obstacle is detected on one-touch models
and a deactivation system to prevent mis-
use of the rear controls.
