II
C O M F O R T
51
Electric mode (driver's seat only)
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Push the control forwards or rearwards
t o m o v e t h e s e a t t o t h e p o s i t i o n r e q u i r e d . Driver's seat cushion height and
angle adjustment
P u l l o r p u s h t h e f r o n t o f t h e c o n t r o l t o r a i s e
o r l o w e r t h e f r o n t o f t h e s e a t c u s h i o n .
P u l l o r p u s h t h e r e a r o f t h e c o n t r o l t o r a i s e
o r l o w e r t h e r e a r o f t h e s e a t c u s h i o n .
P u l l o r p u s h t h e e n t i r e c o n t r o l t o r a i s e o r
l o w e r t h e e n t i r e s e a t c u s h i o n . Seat back angle adjustment
Tilt the control forwards or rearwards to
s t r a i g h t e n o r t i l t t h e s e a t b a c k .
FRONT SEATS
To avoid discharging the battery, use
the electric mode with the engine
r u n n i n g .
Page 52 of 230
II
!
C O M F O R T
52
Front armrest
You can move the console housing cover
i n o r d e r t o u s e i t a s a n a r m r e s t .
With the engine running , tilt the button
t o t h e p o s i t i o n r e q u i r e d .
T h e t e m p e r a t u r e o f t h e s e a t i s r e g u l a t e d
a u t o m a t i c a l l y .
T h e r e a r e t w o s e t t i n g p o s i t i o n s :
- " H I " : H i g h h e a t i n g
- "LO": Low heating
When the button is in the intermediate
p o s i t i o n , t h e h e a t i n g i s s w i t c h e d o f f .
The indicator lights A comes on when
t h e s y s t e m i s a c t i v a t e d .
Heated seats adjustment
T o r a i s e t h e h e a d r e s t r a i n t , p u l l i t u p w a r d s .
T o l o w e r t h e h e a d r e s t r a i n t , p u s h i t
d o w n w a r d s p r e s s i n g t h e h e i g h t a d j u s t -
m e n t b u t t o n a t t h e s a m e t i m e .
To remove the head restraint, bring it to
t h e u p p e r m o s t p o s i t i o n t h e n r e m o v e i t
p r e s s i n g t h e h e i g h t a d j u s t m e n t b u t t o n
a t t h e s a m e t i m e .
T o r e fi t t h e h e a d r e s t r a i n t , e n g a g e t h e
stems of the head restraint in the holes
p r e s s i n g t h e h e i g h t a d j u s t m e n t b u t t o n
a t t h e s a m e t i m e .
Head restraint height adjustment
Never drive with the removed
head restraints in the vehicle as
they could be thrown around the
v e h i c l e o n s h a r p b r a k i n g . T h e y m u s t
b e i n p l a c e a n d a d j u s t e d c o r r e c t l y .
After installing the head restraint,
check that the height adjustment but-
t o n i s l o c k e d c o r r e c t l y .
The adjustment is correct when the
t o p o f t h e h e a d r e s t r a i n t i s a l i g n e d
w i t h t h e t o p o f t h e h e a d o f t h e s e a t e d
p e r s o n .
Page 53 of 230
II!
C O M F O R T
53
REAR SEATS (ROW 2)
Seat back angle adjustment
P u l l t h e c o n t r o l a n d a d j u s t .
When the seat back is at the correct angle,
r e l e a s e t h e c o n t r o l .
Sit in the centre of the rear bench seat
to check that the two seats are at the
same level and that the angle of their
s e a t b a c k s i s t h e s a m e .
F o r w a r d s - b a c k w a r d s a d j u s t m e n t
Pull the control towards the outside and
a d j u s t .
When your seat is at the correct dis-
t a n c e , r e l e a s e t h e c o n t r o l .
To ensure that the seat is secured cor-
rectly, move it forwards and backwards
s l i g h t l y w i t h o u t u s i n g t h e c o n t r o l . When manoeuvring the seats,
e n s u r e t h a t n o p e r s o n o r o b j e c t
is in the vicinity of the moving
p a r t s t o a v o i d a n y r i s k o f i n j u r y o r
d a m a g e .
T o p r e v e n t t h e s e a t b a c k f r o m m o v -
i n g f o r w a r d s s h a r p l y a n d k n o c k i n g
y o u , p r e s s o n i t w i t h y o u r b a c k o r
p u s h i t w i t h y o u r h a n d w h i l e o p e r a t -
i n g t h e l e v e r .
The rear seats can be folded in two
p a r t s ( 1 / 3 - 2 / 3 ) .
Page 54 of 230
II
C O M F O R T
54
Rear armrest
L o w e r t h e a r m r e s t t o u s e i t .
T o r e t u r n t o t h e i n i t i a l c o n fi g u r a t i o n ,
p u s h t h e a r m r e s t u n t i l i t l o c k s i n i t s v e r -
t i c a l p o s i t i o n .
A c c e s s t o t h e t h i r d r o w
T h e p a s s e n g e r g a i n s a c c e s s t o t h e
third row of seats by tilting a second
r o w s e a t .
T o p u t t h i s s e a t b a c k i n p l a c e , r e f e r t o
t h e f o l l o w i n g p a g e s .
Page 55 of 230
II
!
C O M F O R T
55
F o l d i n g t h e s e c o n d r o w *
1. Raise the rear seat lever A , or
Pull the button in the boot B for at least one second, or
P u l l t h e r e a r s e a t r e l e a s i n g s t r a p C t o w a r d s y o u .
2. T h e s e a t b a c k s f o l d f o r w a r d s t h e n t h e c u s h i o n r i s e s a n d f o l d s f o r w a r d s .
3. A f t e r c a r r y i n g o u t t h e s e o p e r a t i o n s , p r e s s o n t h e s e a t l i g h t l y t o c h e c k t h a t i t i s s e c u r e d c o r r e c t l y .
B e f o r e f o l d i n g t h e s e a t s , l o w e r t h e h e a d r e s t r a i n t s f u l l y .
B e f o r e f o l d i n g t h e s e a t b a c k s f o r w a r d s , i n s e r t t h e s e a t b e l t b
u c k l e s i n t h e s l o t s p r o v i d e d f o r t h i s p u r p o s e i n t h e r e a r s e a t
c u s h i o n .
Before
folding
the
seats
,
ensure that no object
or person is hindering
the execution of the operations.
D o n o t p l a c e l u g g a g e o n t h e f o l d e d s e a t s .
* A c c o r d i n g t o v e r s i o n .
Page 56 of 230
II
C O M F O R T
56
R e t u r n i n g t h e s e c o n d r o w t o t h e n o r m a l p o s i t i o n
1. L o w e r t h e s e a t p u l l i n g s i m u l t a n e -
o u s l y o n t h e r e l e a s i n g s t r a p A lo-
cated at the rear of the cushion and
s u p p o r t i n g t h e s e a t w i t h y o u r h a n d .
F o r c e m a y b e n e c e s s a r y t o c a r r y o u t t h e s e o p e r a t i o n s .
O n v e h i c l e s fi t t e d w i t h a t h i r d r o w , t h e r e a r o f t h e c u s h i o n o f t h e s e c o n d r o w i s fi t t e d w i t h a l o w l i g h t B .
W h e n t h e r e l e a s i n g s t r a p i s p u l l e d , t h e l i g h t c o m e s o n f o r a p p r o x i m a t e l y 1 0 s e c o n d s t o l i g h t t h e fl o o r a t t h e b a s e o f t h e
t h i r d r o w .
2. P r e s s o n t h e c u s h i o n t o p u t i t i n
p l a c e u n t i l i t e n g a g e s .
3. P u l l t h e s e a t b a c k u p r i g h t p u l l i n g s i -
m u l t a n e o u s l y o n t h e r e l e a s i n g s t r a p
l o c a t e d a t t h e r e a r o f t h e s e a t b a c k .
4. A f t e r p u t t i n g t h e s e a t b a c k b a c k i n
p l a c e , p u s h t h e s e a t a n d t h e s e a t
back lightly to ensure that they are
s e c u r e d c o r r e c t l y .
Page 57 of 230
II
C O M F O R T
57
" L o w e r e d s e a t s " c o n f i g u r a t i o n
1. R e m o v e t h e h e a d r e s t r a i n t s f r o m t h e f r o n t s e a t s .
2. R a i s e t h e r e a r a r m r e s t a n d r e m o v e t h e l o a d s p a c e c o v e r .
3. M o v e t h e r e a r s e a t s a s f a r b a c k a s p o s s i b l e .
4. M o v e t h e f r o n t s e a t s a s f a r f o r w a r d a s p o s s i b l e a n d t i l t t h e i r s e a t b a c k s f u l l y .
5. T i l t t h e s e a t b a c k o f t h e r e a r s e a t s .
T o r e t u r n t h e s e a t s t o t h e i r n o r m a l p o s i t i o n , c a r r y o u t t h e s e o p e r a t i o n s i n r e v e r s e o r d e r .
Page 58 of 230
II
C O M F O R T
58
REAR BENCH SEAT (ROW 3)
T h e r e a r b e n c h s e a t c a n b e f o l d e d . I t
r e t r a c t s i n t o a l o c a t i o n i n t h e fl o o r o f t h e
v e h i c l e . The label on the bench seat back illus-
t r a t e s t h e v a r i o u s s t e p s t o t h e f o l l o w e d
when unfolding and folding the rear
b e n c h s e a t .
1. O p e n t h e t a i l g a t e a n d t h e l o w e r t a i l -
g a t e ( r e f e r t o t h e " A c c e s s " s e c t i o n ) .
2. Pull the cover A from the rear and
fi x i t t o t h e s e a t b a c k u s i n g t h e p r e s s
stud of the band B .
Unfolding the bench seat
For comfort, it is advisable to fold the
b e n c h s e a t w h e n i t s i s n o t i s u s e .
Page 59 of 230
II
C O M F O R T
59
3. P u l l t h e b l a c k s t r a p C located at the centre
o f t h e s e a t b a c k t o r a i s e t h e s e a t b a c k .
4. P u l l t h e b l a c k s t r a p D to release the
b e n c h s e a t c u s h i o n .
5. T i l t t h e b e n c h s e a t r e a r w a r d s .
6. R a i s e t h e h e a d r e s t r a i n t s .
7. L i f t a n d p u s h t h e b e n c h s e a t a s -
s e m b l y f o r w a r d s u n t i l i t l o c k s .
U n d o t h e p r e s s s t u d o f b a n d B to re-
l e a s e t h e c o v e r .
Page 60 of 230
II
C O M F O R T
60
1. O p e n t h e t a i l g a t e a n d t h e l o w e r t a i l -
g a t e ( r e f e r t o t h e " A c c e s s " s e c t i o n ) .
2. Lift the cover A a n d fi x i t t o t h e s e a t
b a c k u s i n g t h e p r e s s s t u d o f t h e
band B .
3. Unlock the head restraints by slid-
ing the controls C and fold them
o n t o t h e s e a t b a c k .
4. P u l l t h e g r e y s t r a p D and bring the
b e n c h s e a t t o w a r d s y o u . P r e s s o n
t h e b e n c h s e a t t o l o c k i t .
5. T i l t a n d p u s h t h e b e n c h s e a t f o r -
w a r d s .
6. P u l l t h e b l a c k s t r a p E located at the
centre of the seat back to fold the
s e a t b a c k .
U n d o t h e p r e s s s t u d o f t h e b a n d B to
p u t t h e c o v e r b a c k i n p l a c e .
Folding the bench seat
