Citroen C CROSSER DAG 2009.5 1.G Owner's Manual
Manufacturer: CITROEN, Model Year: 2009.5, Model line: C CROSSER DAG, Model: Citroen C CROSSER DAG 2009.5 1.GPages: 230, PDF Size: 7.53 MB
Page 141 of 230
IX
!
P R A C T I C A L I N F O R M A T I O N
133
CHANGING A WHEEL
1. Wheelbrace.
Used to remove the wheel trim and t h e w h e e l fi x i n g b o l t s .
2. Jack.
Used to raise the vehicle.
3. Handle.
U s e d t o e x t e n d t h e j a c k .
4. R e m o v a b l e t o w i n g e y e .
R e f e r t o t h e " T o w i n g " p a r a g r a p h .
Other accessories
Wheel with trim
When removing the wheel , remove
t h e t r i m fi r s t u s i n g t h e h a n d l e 3 , p u l l i n g
at the notch.
W h e n r e fi t t i n g t h e w h e e l , r e fi t t h e t r i m
s t a r t i n g b y p l a c i n g i t s n o t c h F (indicated
o n t h e b a c k o f t h e t r i m ) o p p o s i t e t h e
valve G a n d p r e s s o n i t s p e r i p h e r y w i t h
t h e p a l m o f y o u r h a n d .
List of tools
W h e n c h a n g i n g a w h e e l , e n s u r e
t h a t t h e f o u r w h e e l s a r e o f i d e n t i -
c a l s p e c i fi c a t i o n a n d b r a n d .
W h e n s t o r i n g , t a k e c a r e t o s e c u r e
t h e t o o l b a g
D fi r m l y u s i n g t h e fi x i n g
band C .
Access to the tools
T h e t o o l s a r e s t o r e d i n t h e s t o r a g e c o m -
p a r t m e n t i n t h e b o o t r i g h t - h a n d t r i m .
T o g a i n a c c e s s t o t h e m :
o p e n t h e b o o t ,
t u r n b u t t o n A to the left,
remove the cover B ,
r e m o v e t h e fi x i n g b a n d C a n d t a k e o u t
t h e t o o l b a g D c o n t a i n i n g t h e t o o l s ,
g r i p t h e j a c k E i n y o u r h a n d a n d r e -
m o v e i t f r o m i t s fi x i n g p o s i t i o n .
Page 142 of 230
IX
P R A C T I C A L I N F O R M A T I O N
134
Fixing the "space-saving" spare
wheel
I f y o u r v e h i c l e i s fi t t e d w i t h a l l o y
wheels, it is normal to notice that the
washers do not come into contact
w i t h t h e " s p a c e - s a v i n g " s p a r e w h e e l
w h e n t i g h t e n i n g t h e b o l t s o n fi t t i n g .
T h e w h e e l i s r e t a i n e d b y t h e c o n i c a l
contact of each bolt.
Access to the spare wheel in the 7 seat configuration
The "space-saving" s p a r e w h e e l i s i n -
s t a l l e d o n t h e o u t s i d e , u n d e r t h e b o o t ,
s u p p o r t e d b y a m e t a l c a r r i e r .
T o g a i n a c c e s s t o t h e t o o l s , r e f e r t o t h e
" A c c e s s t o t h e t o o l s " p a r a g r a p h . Putting the wheel back in place
P u t t h e w h e e l b a c k i n p l a c e i n i t s
carrier.
Lift the carrier C a n d r e p o s i t i o n t h e
hook D .
O p e n t h e l o w e r t a i l g a t e ( r e f e r t o t h e
"Access" section).
R e m o v e t h e p l a s t i c c o v e r A u s i n g
the handle 3 .
U n s c r e w t h e s p a r e w h e e l c a r r i e r r e -
t a i n i n g b o l t B u s i n g t h e w h e e l b r a c e 1 .
C l o s e t h e l o w e r t a i l g a t e ( r e f e r t o t h e
"Access" section).
Lift the carrier C to detach the hook D
then allow it to lower.
T i g h t e n t h e s p a r e w h e e l c a r r i e r r e -
t a i n i n g b o l t B f u l l y u s i n g t h e w h e e l -
brace 1 .
R e fi t t h e p l a s t i c c o v e r A , close the
l o w e r t a i l g a t e a n d s t o r e t h e t o o l s .
Removing the wheel
O p e n t h e t a i l g a t e a n d t h e l o w e r t a i l -
g a t e ( r e f e r t o t h e " A c c e s s " s e c t i o n ) .
T a k e o u t t h e h a n d l e 3 (refer to the
" A c c e s s t o t h e t o o l s " p a r a g r a p h ) .
Page 143 of 230
IX
P R A C T I C A L I N F O R M A T I O N
135
Access to the spare wheel in the 5 seat configuration
The "steel" s p a r e w h e e l i s i n s t a l l e d o n
t h e o u t s i d e , u n d e r t h e b o o t , s u p p o r t e d
b y a w i n c h a n d a p l a s t i c c a r r i e r .
T o g a i n a c c e s s t o t h e t o o l s , r e f e r t o t h e
" A c c e s s t o t h e t o o l s " p a r a g r a p h .
Fixing the "steel" spare wheel
I f y o u r v e h i c l e i s fi t t e d w i t h a l l o y
wheels, it is normal to notice that the
washers do not come into contact
w i t h t h e " s p a c e - s a v i n g " s p a r e w h e e l
w h e n t i g h t e n i n g t h e b o l t s o n fi t t i n g .
T h e w h e e l i s r e t a i n e d b y t h e c o n i c a l
contact of each bolt.
Removing the wheel
O p e n t h e t a i l g a t e a n d t h e l o w e r t a i l -
g a t e ( r e f e r t o t h e " A c c e s s " s e c t i o n ) .
T a k e o u t t h e h a n d l e 3 (refer to the
" A c c e s s t o t h e t o o l s " p a r a g r a p h ) .
R e m o v e t h e p l a s t i c c o v e r A u s i n g
the handle 3 . Putting the wheel back in place
P u t t h e w h e e l b a c k i n p l a c e i n i t s
carrier.
Pass the hook C into the chain.
O p e n t h e l o w e r t a i l g a t e ( r e f e r t o t h e
"Access" section).
U n s c r e w t h e r e t a i n i n g b o l t B fully
u s i n g t h e w h e e l b r a c e 1 , t o u n w i n d
the winch cable.
C l o s e t h e l o w e r t a i l g a t e ( r e f e r t o t h e
" Access" section).
Detach the hook C from the chain.
U n w i n d t h e w i n c h c a b l e f u l l y t o m a k e
u n h o o k i n g o f t h e c h a i n e a s i e r .
T i g h t e n t h e w i n c h r e t a i n i n g b o l t B
f u l l y u s i n g t h e w h e e l b r a c e 1 .
R e fi t t h e p l a s t i c c o v e r A , close the
l o w e r t a i l g a t e a n d s t o r e t h e t o o l s .
Page 144 of 230
IX
P R A C T I C A L I N F O R M A T I O N
136
Parking the vehicle
Immobilise the vehicle where it does
n o t b l o c k t r a f fi c : i f p o s s i b l e , p a r k t h e
v e h i c l e o n l e v e l , s t a b l e a n d n o n -
s l i p p e r y g r o u n d .
A p p l y t h e h a n d b r a k e , s w i t c h o f f t h e
i g n i t i o n a n d e n g a g e fi r s t g e a r t o l o c k
the wheels.
I f n e c e s s a r y , p l a c e a c h o c k u n d e r
t h e w h e e l d i a g o n a l l y o p p o s i t e t h e
w h e e l t o b e c h a n g e d .
N e v e r g o u n d e r n e a t h a v e h i c l e
r a i s e d u s i n g a j a c k ; u s e a s t a n d .
Removing the wheel List of operations
I f y o u r v e h i c l e i s e q u i p p e d w i t h o n e
( e q u i p m e n t a v a i l a b l e a s a n a c c e s -
s o r y ) fi t t h e a n t i - t h e f t s o c k e t 5 on
the wheelbrace 1 t o u n l o c k t h e a n t i -
theft bolt.
U n l o c k t h e o t h e r b o l t s u s i n g t h e
wheelbrace 1 o n l y .
P l a c e t h e j a c k 2 in contact with one
of the two front A or rear B locations
p r o v i d e d o n t h e u n d e r f r a m e , w h i c h -
ever is closest to the wheel to be
c h a n g e d .
E x t e n d t h e j a c k 2 u n t i l i t s b a s e p l a t e
i s i n c o n t a c t w i t h t h e g r o u n d . E n s u r e
t h a t t h e c e n t r e l i n e o f t h e j a c k b a s e
p l a t e i s d i r e c t l y b e l o w t h e l o c a t i o n A
or B u s e d .
R a i s e t h e v e h i c l e u n t i l t h e r e i s s u f fi -
c i e n t s p a c e b e t w e e n t h e w h e e l a n d
t h e g r o u n d t o a d m i t t h e s p a r e ( n o t
p u n c t u r e d ) w h e e l e a s i l y .
Remove the bolts and store them in
a c l e a n p l a c e .
Remove the wheel.
Page 145 of 230
IX
P R A C T I C A L I N F O R M A T I O N
137
After changing a wheel
W h e n u s i n g t h e " s p a c e - s a v i n g "
s p a r e w h e e l , d o n o t e x c e e d a s p e e d
o f 5 0 m p h ( 8 0 k m / h ) .
H a v e t h e t i g h t e n i n g o f t h e b o l t s a n d
t h e p r e s s u r e o f t h e s p a r e w h e e l
c h e c k e d b y a C I T R O Ë N d e a l e r w i t h -
o u t d e l a y .
H a v e t h e p u n c t u r e d w h e e l r e p a i r e d
a n d r e p l a c e i t o n t h e v e h i c l e a s s o o n
a s p o s s i b l e .
Fitting the wheel List of operations
L o w e r t h e v e h i c l e f u l l y .
F o l d t h e j a c k 2 and detach it.
L o c k t h e a n t i - t h e f t b o l t u s i n g t h e
wheelbrace 1 fi t t e d w i t h t h e a n t i -
theft socket 5 ( i f y o u r v e h i c l e i s
e q u i p p e d w i t h o n e ) .
L o c k t h e o t h e r b o l t s u s i n g t h e w h e e l -
brace 1 o n l y .
S t o r e t h e t o o l s ( r e f e r t o t h e p a r a g r a p h
"Access to the tools").
Fitting snow tyres
I f y o u e q u i p y o u r v e h i c l e w i t h s n o w
t y r e s fi t t e d o n s t e e l w h e e l r i m s , i t i s
imperative t h a t s p e c i a l b o l t s a v a i l -
a b l e f r o m y o u r C I T R O Ë N d e a l e r a r e
u s e d .
P u t t h e w h e e l i n p l a c e o n t h e h u b .
S c r e w i n t h e b o l t s b y h a n d t o t h e
s t o p .
P r e - t i g h t e n t h e a n t i - t h e f t b o l t u s -
i n g t h e w h e e l b r a c e 1 fi t t e d w i t h t h e
a n t i - t h e f t s o c k e t 5 ( i f y o u r v e h i c l e i s
e q u i p p e d w i t h o n e ) .
P r e - t i g h t e n t h e o t h e r b o l t s u s i n g t h e
wheelbrace 1 o n l y .
Page 146 of 230
IX
!
!
P R A C T I C A L I N F O R M A T I O N
1 3 8
CHANGING A BULB
H a n d l e t h e b u l b s u s i n g a d r y
cloth.
Do not clean the headlamps using
a dry or abrasive cloth, or using
detergent or solvent products, u s e
a s p o n g e a n d s o a p y w a t e r . I n s o m e c l i m a t i c c o n d i t i o n s ( e . g . l o w
t e m p e r a t u r e o r h u m i d i t y ) , t h e p r e s -
e n c e o f m i s t i n g o n t h e i n t e r n a l s u r -
f a c e o f t h e g l a s s o f t h e h e a d l a m p s
a n d r e a r l a m p s i s n o r m a l ; i t d i s a p -
p e a r s a f t e r t h e l a m p s h a v e b e e n o n
f o r a f e w m i n u t e s .
Front lights
1. Direction indicators
(PY21W - 21 W).
2. Dipped headlamps (H11 - 55 W)
or xenon bulb (D2S - 35 W).
3. Side lights (W5W - 5 W).
4. Main beam headlamps
(H7 - 55 W).
5. Front fog lamps
(H11 - 55 W). WARNING: RISK OF
ELECTROCUTION
X e n o n b u l b s m u s t b e r e p l a c e d b y a
C I T R O Ë N d e a l e r .
Page 147 of 230
IX
P R A C T I C A L I N F O R M A T I O N
139
Changing the direction indicators (1) C o l o u r e d b u l b s m u s t b e r e p l a c e d
w i t h b u l b s o f i d e n t i c a l s p e c i fi c a t i o n
a n d c o l o u r .
T u r n t h e b u l b h o l d e r A to the left
and remove it.
P u l l t h e b u l b a n d c h a n g e i t .
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order. Access to the bulbs on the left-hand
side
W h e n y o u c h a n g e a b u l b o n t h e l e f t -
h a n d s i d e , r e m o v e t h e r e l a y b o x fi x i n g
n u t
B a n d m o v e t h e r e l a y b o x t o w a r d s
the rear. Access to the bulbs on the right-
hand side
W h e n y o u c h a n g e a b u l b o n t h e r i g h t -
h a n d s i d e :
Remove the screenwash reservoir
fi x i n g C a n d m o v e t h e r e s e r v o i r t o -
wards the rear.
R e m o v e t h e c o o l a n t r e s e r v o i r fi x i n g
n u t D .
R e m o v e t h e c l i p E a n d r a i s e t h e r e s e r -
v o i r m o v i n g i t t o w a r d s t h e f r o n t .
Page 148 of 230
IX
140
Changing the side lights (3)
Unscrew the cover H .
Disconnect the connector.
T u r n t h e b u l b h o l d e r I a q u a r t e r o f a
t u r n a n d r e m o v e i t .
P u l l t h e b u l b a n d c h a n g e i t .
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order.
Unscrew the cover F .
Disconnect the connector.
T u r n t h e b u l b G t o t h e l e f t a n d r e -
move it.
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order.
Changing the dipped headlamps (2)
Changing the main beam
headlamps (4)
Unscrew the cover J .
Disconnect the connector.
M o v e a s i d e t h e s p r i n g K to release
t h e b u l b a n d r e m o v e i t .
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order.
Page 149 of 230
IX
P R A C T I C A L I N F O R M A T I O N
141
Changing the integrated direction
indicator side repeaters Changing the fog lamps (5)
P u s h t h e r e p e a t e r A towards the
rear and detach it.
U n c l i p t h e r e p e a t e r .
D i s c o n n e c t t h e r e p e a t e r c o n n e c t o r
a n d c h a n g e t h e r e p e a t e r .
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order.
T o o b t a i n r e p e a t e r s , c o n t a c t a C I T R O Ë N
dealer.
T u r n t h e w h e e l f u l l y t o w a r d s t h e o u t -
s i d e f o r e a s y a c c e s s t o t h e fl a p A
located in the wheelarch.
U s i n g a s c r e w d r i v e r , r e m o v e t h e f o u r
c l i p s B located in the wheelarch.
Page 150 of 230
IX
P R A C T I C A L I N F O R M A T I O N
142
U s i n g a s c r e w d r i v e r , r e m o v e t h e
t h r e e c l i p s C located below the
b u m p e r .
L i f t t h e a c c e s s fl a p D located in the
wheelarch and slide it downwards.
Disconnect the connector E .
T u r n t h e b u l b F t o t h e l e f t a n d r e -
move it.
T o r e fi t , c a r r y o u t t h e s e o p e r a t i o n s i n
reverse order.
