engine Citroen C4 2008.5 1.G Owner's Guide

57
IV
A C C E S S

 First press button A to fold the key.
Locating your vehicle

 Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by lighting of the
courtesy lights and fl ashing of the di-
rection indicators for a few seconds. Guide-me-home lighting
A press on button
B operates the
guide-me-home lighting (lighting of
the sidelamps and dipped beams for
approximately one minute).
A second press before the end of the
timing cancels the guide-me-home
lighting.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
Deadlocking using the key

 Turn the key to the right in the
driver’s door lock to lock the
vehicle completely and hold it
in this position for more than
two seconds to close the win-
dows automatically in addition to
locking.

 Turn the key to the right again
within fi ve seconds to deadlock
the vehicle.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the exterior
mirrors fold at the same time.
Deadlocking using the
remote control

 Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows au-
tomatically in addition to
locking.

 Press the closed padlock again
within fi ve seconds to deadlock
the vehicle. Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

58
IV
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Drive position
Depending on the version of your
vehicle, the orange and red warning
lamps should also come on for a short
time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off the
ignition. Wait ten seconds then operate
the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the steer-
ing. The key can only be removed in
position S .

2. "M": Ignition switched on, the
steering is unlocked (by turning the
key to position M , move the steering
wheel gently if necessary).

3. "D": Starter position.
Never turn the key to this position
when the engine is running.
Key in ignition buzzer
If you forget to remove the key from
the ignition, a buzzer sounds when
the driver’s door is opened.
DO NOT RUN THE ENGINE IN
AN ENCLOSED SPACE OR
WHERE THERE IS INSUFFICIENT
VENTILATION.

IT IS ESSENTIAL ALWAYS TO
KEEP THE ENGINE RUNNING
IN ORDER TO RETAIN BRAKING
AND STEERING ASSISTANCE .

NEVER REMOVE THE IGNITION
KEY BEFORE THE VEHICLE
HAS COME TO A COMPLETE
STOP.
Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.

60
IV
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle’s V5 registration document and your
personal identifi cation documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a re-
placement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reinitialised. The
remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reinitialisation.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to
the electronic engine immobiliser
system; this could cause malfunc-
tions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

57
IV
A C C E S S

 First press button A to fold the key.
Locating your vehicle

 Press the closed padlock to locate
your locked vehicle in a car park.
This is indicated by lighting of the
courtesy lights and fl ashing of the di-
rection indicators for a few seconds. Guide-me-home lighting
A press on button
B operates the
guide-me-home lighting (lighting of
the sidelamps and dipped beams for
approximately one minute).
A second press before the end of the
timing cancels the guide-me-home
lighting.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip
which has a special code. When the
ignition is switched on, this code
must be recognised in order for
starting to be possible.
This electronic engine immobiliser
locks the engine management sys-
tem a few minutes after the ignition
is switched off and prevents starting
of the engine by anyone who does
not have the key.
In the event of a mal-
function, you are in-
formed by lighting of
this warning lamp, an
audible signal and a message on
the multifunction screen.
In this case, your vehicle does not
start; contact a CITROËN dealer as
soon as possible.
Folding the key
Deadlocking using the key

 Turn the key to the right in the
driver’s door lock to lock the
vehicle completely and hold it
in this position for more than
two seconds to close the win-
dows automatically in addition to
locking.

 Turn the key to the right again
within fi ve seconds to deadlock
the vehicle.
Deadlocking is confi rmed by fi xed
lighting of the direction indicators for
approximately two seconds.
According to version, the exterior
mirrors fold at the same time.
Deadlocking using the
remote control

 Press the closed pad-
lock to lock the vehicle
completely or press the
closed padlock for more
than two seconds to
close the windows au-
tomatically in addition to
locking.

 Press the closed padlock again
within fi ve seconds to deadlock
the vehicle. Deadlocking renders the exterior and
interior door controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.

60
IV
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle’s V5 registration document and your
personal identifi cation documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a re-
placement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reinitialised. The
remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reinitialisation.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to
the electronic engine immobiliser
system; this could cause malfunc-
tions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

58
IV
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Drive position
Depending on the version of your
vehicle, the orange and red warning
lamps should also come on for a short
time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off the
ignition. Wait ten seconds then operate
the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the steer-
ing. The key can only be removed in
position S .

2. "M": Ignition switched on, the
steering is unlocked (by turning the
key to position M , move the steering
wheel gently if necessary).

3. "D": Starter position.
Never turn the key to this position
when the engine is running.
Key in ignition buzzer
If you forget to remove the key from
the ignition, a buzzer sounds when
the driver’s door is opened.
DO NOT RUN THE ENGINE IN
AN ENCLOSED SPACE OR
WHERE THERE IS INSUFFICIENT
VENTILATION.

IT IS ESSENTIAL ALWAYS TO
KEEP THE ENGINE RUNNING
IN ORDER TO RETAIN BRAKING
AND STEERING ASSISTANCE .

NEVER REMOVE THE IGNITION
KEY BEFORE THE VEHICLE
HAS COME TO A COMPLETE
STOP.
Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.

67
IV
A C C E S S
BOOT

 After unlocking the vehicle com-
pletely using the remote control
or the key, push upwards on the
lever 1 , located between the
number plate lights, and raise
the tailgate.
 Lower the tailgate using one of
the two handholds 3 , located on
the interior boot trim.

 Push at the end of travel.
- when the engine is
running , this warning
lamp comes on, accom-
panied by a message on
the multifunction screen
for a few seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning lamp comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion screen for a few seconds.
If the tailgate is not closed correctly:
Opening Closing
Emergency boot lid release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking

 Fold back the rear seats to gain
access to the lock from inside
the boot.

 Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.

 Push the white part, located in-
side the lock, to the left to unlock
the boot.

68
IV
A C C E S S
DIESEL FUEL
Refuelling
A label on the inside of the fuel fi ll-
er fl ap indicates the approved fuel
quality type.
To fi ll the tank safely:

 it is imperative that you switch
off the engine,

 open the fuel fi ller fl ap,

 insert the key in the fuel tank cap
then turn it to the left. Petrol engines are designed to run
on 95 RON fuel.
However, for better vehicle perform-
ance (petrol engines), we recom-
mend 98 RON.

For petrol engines with catalytic
converter, use of unleaded fuel is
obligatory
The fi ller neck has a narrower orifi ce
to admit only petrol fi ller nozzles.

UNLEADED PETROL
When you are fi lling your fuel
tank, do not persist after the
third cutoff; this could cause
your vehicle to malfunction.
FUEL TANK

Capacity of the tank: approxi-
mately 60 litres.
Low fuel level
When the minimum level in
the fuel tank is reached, this
warning lamp in the instru-
ment panel comes on, ac-
companied by an audible signal and a
message on the multifunction screen.

You have enough fuel left to drive
approximately 30 miles (50 km).
Fuel cut-off switch
Your vehicle is equipped with a safe-
ty device which cuts off the fuel sup-
ply in the event of a collision.

69
IV
A C C E S S

If you have put in fuel that is
wrong for your vehicle, it is es-
sential to have the tank drained
before you start the engine.
A label inside the fuel fi ller fl ap indi-
cates the fuels authorised:

In winter conditions, starting
from cold may seem diffi cult.
During periods of very cold
weather we recommend the use
of 95 or 98 unleaded petrol in
preference to B85 so as to ensure
optimum starting performance.
BioFlex
Your vehicle has been designed to
operate
equally on unleaded pet-
rol (95 or 98) or on bioethanol (in
Europe this is a mixture of 85 %
ethanol and 15 % unleaded petrol,
known as E85 ).
Other than the question of the two
authorised fuels, your vehicle is
used in the same way as a tradition-
al petrol vehicle.

77
V I S I B I L I T Y
V
Special position of the
windscreen wipers
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen.
This action enables you to position
the wiper blades for winter parking,
cleaning or replacement.
To park the wipers after this has
been done, switch on the ignition
and operate the stalk. For optimum and lasting wiping of
the "fl at-blade" wiper blades, it is
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen. COURTESY LAMPS
Selection and control of the various
passenger compartment lamps.

1. Front courtesy
lamp

2. Map reading
lamps
Front courtesy lamp In this position, the courtesy
lamp comes on gradually: Permanently off.
Permanent lighting.
In permanent lighting mode, differ-
ent lighting times are available:
- with the ignition off, approxi- mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- with the engine running, unlim- ited.
- when the vehicle is unlocked,
- when a door or the boot is opened,
- when the key is removed from the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle. It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.
Map reading lamps

 With the ignition on, press the
corresponding switch.
