Page 87 of 282
77
V I S I B I L I T Y
V
Special position of the
windscreen wipers
In the minute following switching off
of the ignition, any action on the stalk
positions the wipers in the centre of
the windscreen.
This action enables you to position
the wiper blades for winter parking,
cleaning or replacement.
To park the wipers after this has
been done, switch on the ignition
and operate the stalk. For optimum and lasting wiping of
t h e " fl a t - b l a d e " w i p e r b l a d e s , i t i s
advisable to:
- handle them with care,
- clean them regularly using soapy water,
- change them approximately every 6 months,
- avoid using them to retain card- board on the windscreen. COURTESY LAMPS
Selection and control of the various
passenger compartment lamps.
1. Front courtesy
lamp
2. Map reading
lamps
Front courtesy lamp In this position, the courtesy
lamp comes on gradually: Permanently off.
Permanent lighting.
In permanent lighting mode, differ-
ent lighting times are available:
- with the ignition off, approxi- mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- with the engine running, unlim- ited.
- when the vehicle is unlocked,
- when a door or the boot is opened,
- when the key is removed from the ignition,
- when the remote control locking button is activated, in order to lo-
cate your vehicle. It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is
closed.
Map reading lamps
With the ignition on, press the
corresponding switch.
Page 88 of 282
78
V I S I B I L I T Y
V
This comes on automatically when
the boot is opened and switches
off automatically when the boot is
closed.
Different lighting times are available:
- when the ignition is off, approxi-mately ten minutes,
- in energy economy mode, ap- proximately thirty seconds,
- when the engine is running, no limit.
The sill lighting is at the bottom of
each door panel.
The lamps come on automatically
when a door is opened and switch
off automatically when all of the
doors are closed.
BOOT LIGHTING Sill illumination
Page 90 of 282
80
VI
F I T T I N G S
ILLUMINATED GLOVE BOX
This has areas for storing a bottle of
w a t e r , t h e v e h i c l e ' s h a n d b o o k p a c k ,
etc.
I t s l i d h a s a r e a s f o r s t o r i n g a p e n , a
p a i r o f s p e c t a c l e s , t o k e n s , c a r d s , a
c a n , f r a g r a n c e c a r t r i d g e s . . .
T o o p e n t h e g l o v e b o x , r a i s e t h e
handle and lower the lid.
REFRIGERATED GLOVEBOX
I t m a y b e r e f r i g e r a t e d , d e p e n d i n g o n
y o u r v e h i c l e ’ s e q u i p m e n t , b y a v e n -
tilation duct that can be closed off
manually.
W i t h t h e a i r c o n d i t i o n i n g , t h i s d u c t
distributes the same cooled air as
the vents in the passenger compart-
ment.
T h e r e f r i g e r a t i o n o f y o u r g l o v e b o x
only operates when the engine is
running and the air conditioning is
on.
The lamp comes on au-
tomatically when the lid is
opened. F o r s a f e t y r e a s o n s , t h e
g l o v e b o x s h o u l d r e m a i n
closed when the vehicle is
moving.
Page 96 of 282
80
VI
F I T T I N G S
ILLUMINATED GLOVE BOX
This has areas for storing a bottle of
w a t e r , t h e v e h i c l e ' s h a n d b o o k p a c k ,
etc.
I t s l i d h a s a r e a s f o r s t o r i n g a p e n , a
p a i r o f s p e c t a c l e s , t o k e n s , c a r d s , a
c a n , f r a g r a n c e c a r t r i d g e s . . .
T o o p e n t h e g l o v e b o x , r a i s e t h e
handle and lower the lid.
REFRIGERATED GLOVEBOX
I t m a y b e r e f r i g e r a t e d , d e p e n d i n g o n
y o u r v e h i c l e ’ s e q u i p m e n t , b y a v e n -
tilation duct that can be closed off
manually.
W i t h t h e a i r c o n d i t i o n i n g , t h i s d u c t
distributes the same cooled air as
the vents in the passenger compart-
ment.
T h e r e f r i g e r a t i o n o f y o u r g l o v e b o x
only operates when the engine is
running and the air conditioning is
on.
The lamp comes on au-
tomatically when the lid is
opened. F o r s a f e t y r e a s o n s , t h e
g l o v e b o x s h o u l d r e m a i n
closed when the vehicle is
moving.
Page 117 of 282
98
VIII
S A F E T Y
TRAJECTORY CONTROL SYSTEMS
Anti-skid regulation (ASR) and
electronic stability programme
(ESP)
The anti-skid regulation (also known
as Traction Control) optimises
traction to prevent skidding of the
wheels, by acting on the brakes of
the driving wheels and on the en-
gine.
The electronic stability programme
acts on the brake of one or more
wheels and on the engine to keep
the vehicle on the trajectory required
by the driver.
Activation
These systems are activated auto-
matically each time the vehicle is
started.
They come into operation in the event
of a grip or trajectory problem. T h i s i s i n d i c a t e d b y fl a s h i n g
of this warning lamp on the
instrument panel. Deactivation
I n e x c e p t i o n a l c o n d i t i o n s ( s t a r t i n g a
vehicle which is bogged down, stuck
in snow, on soft ground...), it may be
advisable to deactivate the ASR and
ESP systems, so that the wheels
can move freely and regain grip.
Press the "ESP OFF" button,
located in the centre of the
dashboard. Reactivation
These systems are reactivated au-
tomatically each time the ignition is
switched back on or from 30 mph
(50 km/h).
Press the "ESP OFF" button again
to reactivate them manually.
If this warning lamp comes
on in the instrument panel
and the indicator lamp on the
button comes on, this indi-
cates that the ASR and ESP
systems are deactivated. Operating fault
If this warning lamp comes
on, accompanied by an au-
dible signal and a message
on the multifunction screen,
this indicates a malfunction of these
systems.
Have the systems checked by a
CITROËN dealer.
T h e E S P / A S R s y s t e m s o f f e r e x -
ceptional safety in normal driving,
but this should not encourage the
d r i v e r t o t a k e e x t r a r i s k s o r d r i v e a t
high speed.
The correct functioning of these
systems depends on observation
of the manufacturer's recommen-
dations regarding the wheels (tyres
and rims), the braking components,
the electronic components and the
CITROËN assembly and operation
procedures.
After an impact, have these sys-
tems checked by a CITROËN
dealer.
Page 126 of 282
106
IX
D R I V I N G
PARKING BRAKE
Mechanical brake to hold the vehicle
when stationary.
Applying
Pull the parking brake to immobi-
lise your vehicle.
Releasing
Pull on the handle and press
the button to release the parking
brake.
When the vehicle is being driven,
if this warning lamp and the STOP
warning lamp come on, accompa-
nied by an audible signal and a mes-
sage on the multi-function screen,
this indicates that the parking brake
is still on or has not been properly
released.
When parking on a slope, direct your
wheels against the pavement, pull
the parking brake on and engage
a gear.
5-SPEED MANUAL GEARBOX
Starting the vehicle
Check that the gear lever is in
neutral.
Do not touch the accelerator.
For Diesel engines: turn the
key to position M and wait until
the pre-heating warning lamp
switches off if it has come on.
Operate the starter, turning the
key until the engine starts (no
more than ten seconds).
In temperatures lower than 0 °C,
declutch whilst turning the starter
to facilitate starting. Engaging reverse gear
Push the gear lever to the
right then rearwards.
Only engage reverse gear when
the vehicle is stationary with the
engine at idle.
Page 127 of 282
107
IX
D R I V I N G
(6-SPEED) ELECTRONIC GEARBOX SYSTEM
The (6-speed) electronic gearbox of-
fers a choice between the comfort of
fully automatic operation or the driving
pleasure of manual gear changing.
Therefore, you have a choice of two
driving modes:
- the automatic mode for auto-
matic control of the gears by the
gearbox,
- the sequential mode for manu-
al changing of the gears by the
driver.
6-SPEED MANUAL GEARBOX
Engaging reverse gear
Raise the ring A under the knob
and push the gear lever to the
left then forwards.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle. Mode selection
automatic mode: selector in po-
sition A .
manual mode: selector in posi-
tion M .
In automatic mode, instant manual
operation is possible any time you
action one of the paddles "+" or "-".
As a safety precaution and to facili-
tate starting of the engine:
- always select neutral,
- press the clutch pedal.
Page 128 of 282
107
IX
D R I V I N G
(6-SPEED) ELECTRONIC GEARBOX SYSTEM
The (6-speed) electronic gearbox of-
fers a choice between the comfort of
fully automatic operation or the driving
pleasure of manual gear changing.
Therefore, you have a choice of two
driving modes:
- the automatic mode for auto-
matic control of the gears by the
gearbox,
- the sequential mode for manu-
al changing of the gears by the
driver.
6-SPEED MANUAL GEARBOX
Engaging reverse gear
Raise the ring A under the knob
and push the gear lever to the
left then forwards.
Only engage reverse gear when the
vehicle is stationary with the engine
at idle. Mode selection
automatic mode: selector in po-
sition A .
manual mode: selector in posi-
tion M .
In automatic mode, instant manual
operation is possible any time you
action one of the paddles "+" or "-".
As a safety precaution and to facili-
tate starting of the engine:
- always select neutral,
- press the clutch pedal.
Page 129 of 282
108
IX
D R I V I N G
Displays on the instrument
panel
- The selector position is displayed in the instrument panel, on the
left on multifunction screens A
and C and on the right on the
NaviDrive multifunction screen.
- A background-lit position grille associated with the selector al-
lows you to view the position se-
lected. Moving off
When the ignition is on, light-
ing of the service warning lamp,
accompanied by
an audible
sig-
nal and the message "Gearbox
faulty" indicates a malfunction.
Consult a CITROËN dealer.
For safety:
Position N can only be disen-
gaged if you are pressing the
brake pedal.
If the gearbox is in position N
but the selector position is dif-
ferent, reposition the selec-
tor on N in order to be able to
start.
To start the engine, the selector
has to be in position N .
P r e s s fi r m l y o n t h e b r a k e p e d a l .
Operate the starter.
When the engine is running,
place the selector on R , A or M
as desired.
Check, in the instrument panel,
the position engaged.
Release the brake pedal and ac-
celerate.
If the selector is not in position N ,
and/or if the brake pedal is not
pressed, the corresponding warning
lamp(s) are displayed and a mes-
sage informs you that at least one of
these two conditions is not met.
In this case, the engine will not start,
recommence the above procedure.
Engaging reverse gear
To engage reverse gear, move the
selector to R .
Only attempt to
select
reverse gear
when the vehicle is stationary.
If the vehicle is moving rapidly, if an in-
advertent attempt to engage reverse
gear is made, the warning lamp N will
fl a s h a n d y o u r v e h i c l e w i l l g o a u t o -
matically into neutral. To re-engage a
gear, you have only to reposition the
selector on A , M or R .
Reverse gear
Page 130 of 282
109
IX
D R I V I N G
Neutral
Changing to neutral
To change to neutral, move the se-
lector to N . If the vehicle is mov-
ing, do not select this position even
momentarily. Automatic mode
Changing to automatic mode
To change to automatic mode, move
the selector to A . Manual mode
Changing to manual mode
Manual mode activates when you
move the selector to M .
Pull the paddle " + " to change up
a gear.
Pull the paddle " - " to change
down a gear.
When the engine is running, before
accelerating to move the vehicle,
make sure that the position engaged
on the selector grille or in the instru-
ment panel is either: R , A or M
Do not leave the vehicle with the en-
gine running in R , A or M .
