Citroen C5 2000 (DC/DE) / 1.G Owner's Manual
Manufacturer: CITROEN, Model Year: 2000, Model line: C5, Model: Citroen C5 2000 (DC/DE) / 1.GPages: 259, PDF Size: 2.29 MB
Page 221 of 259
Downloaded from www.Manualslib.com manuals search engine 218
AXLES
SUSPENSION
STEERING
SUSPENSION
Rear suspension
Tightening torques m.daN.
(13) Subframe rear fixing11.5 ± 1.1
(14)Rear rubber mounting fixing on bodyshell8 ± 1.2
(15) Anti-roll bar fixing13.1 ± 1.4
(16) Front fixing of subframe on bodyshell11.5 ± 1.1
NOTE : (13) and (16)Face and threads greased.
(17)Arm shaft fixing14.9 ± 1.3
(18) Hub nut25 ± 2.5
(19) Wheel fixing9 ± 1
Hydractive 3+ hydraulic suspension (Power steering)
Suspension piston diameter= 37 mm.
Anti-roll bar diameter
- Saloon= 21.5 mm
- Estate= 22 mm.
Anti-roll bar colour reference
- Saloon= Blue
- Estate= Green
B3DP08NDB3DP08PD
Page 222 of 259
Downloaded from www.Manualslib.com manuals search engine 219
AXLES
SUSPENSION
STEERING
SUSPENSION
Height control
Tightening torques m.daN.
(20)Collars0.6
B3CP06TD
Page 223 of 259
Downloaded from www.Manualslib.com manuals search engine 220
AXLES
SUSPENSION
STEERING
AXLE GEOMETRY
Front axle Rear axle
Vehicle
All typesTracking
(Adjustable)
0 to - 3 mm
0° to - 0° 27'3° 03' ± 30' 0° ± 30' 12° 56' ± 30'4 ± 1.5 mm
0° 41' ± 0° 13'- 1° ± 20' ( Non adjustable) (Adjustable) ( Non adjustable) Castor CamberKing pin
inclinationTracking Camber
B3CP02UC
A > B =Negative figure : – = TOE-OUT A < B = Positive figure : + = TOE-IN NOTE
Page 224 of 259
Downloaded from www.Manualslib.com manuals search engine 221
AXLES
SUSPENSION
STEERING
SPECIFICATIONS OF POWER-ASSISTED STEERING
Engines : 6FZ-RFN-RLZ-XFX-RHY-RHZ-4HX
Tightening torques m.daN.
(1) Steering wheel fixing2 ± 0.3
(2) Column fixing on mounting2.3 ± 0.4
(3) Column fixing on mounting2.3 ± 0.2
(4) Cardan fixing2.3 ± 0.3
(5) Ball-joint fixing on pivot3.5 ± 0.6
(6)Link rod lock nut6 ± 0.4
(7) Valve fixing on cover2.3 ± 0.1
(8)Piping fixing on ram0.8 ± 0.8
(9) Mechanism fixing on subframe8 ± 0.9
(10) Steering rack ball-joint9 ± 0.9
Quantity of oil = 4,3 litres
Quality of oil = TOTAL FLUIDE LDS
B3EP124DB3EP125D
Page 225 of 259
Downloaded from www.Manualslib.com manuals search engine SPECIFICATIONS OF POWER-ASSISTED STEERING
222
Engines : 6FZ - RFN - RLZ - XFX - RHY - RHZ - 4HX
AXLES
SUSPENSION
STEERING
B3EP127D
Engines
Engines
6FZ RFR RJX
RHY RHZ 4HX
XFXZF
SAGINAWFalling
Constant100 bars 129 mm Supplier Flow type Adjustment pressure Pulley diameter Steering rack
travel
(mm)Pinion RackNumber of
turns of the
wheelSteering
ratio
Inner OuterAngle of lock Number of teeth
6FZ RFR
RJX RHY RHZ2x83
XFX 4HX2x74 3 34.29° 31.58°50.4/139.74° 35.65°
9333.3
Tightening torques m.daN
Engines EW-DW ES9J4
(12) Vis(13) Vis
(14) Vis2.2 ± 0.3 2.5 ± 0.6
Engine XFX : A converter, integral with the valve,
modulates the assistance according to the vehicle
speed.
Length of steering rods (Adjustment)
between ball-joints =362 mm.
Power-assisted steering hydraulic circuit.
The oil supplies both the steering circuit and the
suspension circuit. Petrol engine : A power-assisted steering pressure switch
is installed on the hydraulic piping, between the high
pressure pump and the steering valve.
Page 226 of 259
Downloaded from www.Manualslib.com manuals search engine 223
BRAKES
22.2 (Valve type)
254
BOSCH ZO 54/55 BOSCH ZO 57/56 BOSCH ZO
BIR 54 BIR 57 57/28BIR 57
266 283 288
22/20 26/24 28/26
ABEXABEXTEXTAR
949/1 949/1 T 4110
PSA - 32 (Double piston)
276
14/12
ABEX or TEXTAR
949/1 or T 4110
BRAKE SPECIFICATIONS
Master cylinder
Master-vac
ØCaliper/piston
makes
FRmm
Brake discNon-ventilated
Ventilated
Disc thickness/min. thickness
Brake pad grade
ØCylinder or caliper
mmDrum / Ø max.
Brake disc Non-ventilated
RR
Disc thickness/min. thickness
Make
Brake lining grade1.8i 16V2.0i 16V 2.0 HPi 3.0i V6
6FZRFN RLZ XFX
Engine type
Page 227 of 259
Downloaded from www.Manualslib.com manuals search engine 224
BRAKES
22.2 (Valve type)
254
BOSCH ZO 57/26 BIR BOSCH ZO 57/28 BIR
57 57
283 288
26/24 28/26
TEXTAR
T4110
PSA - 32 (Double Piston)
276
14/12
TEXTAR or ABEX
T 4110 or 949/1
BRAKE SPECIFICATIONS
Master cylinder
Master-vac
ØCaliper/piston
makes
FRmm
Brake discNon-ventilated
Ventilated
Disc thickness/min. thickness
Brake pad grade
ØCylinder or caliper
mmDrum / Ø max.
Brake disc Non-ventilated
RR
Disc thickness/min. thickness
Make
Brake lining grade2.0 HDi2.2 HDi
RHYRHZ 4HX
Engine type
Page 228 of 259
Downloaded from www.Manualslib.com manuals search engine 225
BRAKES
BRAKE SPECIFICATIONS
Braking system specifications
- Braking circuit at «X».
- Front brakes with ventilated discs.
- Rear brakes with non-ventilated discs.
- Handbrake lever controlling cables acting on the
front wheels.
- The compensator and main brake limiter functions
are assured by the ABS EBD system fitted as
standard at the factory on all versions.
NOTE : EBD = Electronic Brakeforce Distribution Braking circuit
B3FP12WD
Page 229 of 259
Downloaded from www.Manualslib.com manuals search engine BRAKE SPECIFICATIONS
Braking circuit diagram
(a) Hydraulic circuit.
(b) Electrical circuit.
(1)Master cylinder in tandem.
(2) Braking servo.
(3) Brake caliper.
(4) Hub equipped with a bearing with an integral magnetic wheel
(48 pairs of poles).
(5) Wheel sensor.
(6) Brake fluid level sensor.
(7)Hydraulic block plus ECU.
(8) Stoplamp switch.
(9)Instrument panel.
(10) Diagnostic socket.
(11) Built-in systems interface (BSI).
B3GP02HP
BRAKES
226
Page 230 of 259
Downloaded from www.Manualslib.com manuals search engine BRAKE SPECIFICATIONS
(7) Hydraulic block
Elements
Electronic ABS MK.6047way connector.
ECU7 ITT - A Alone on the hydraulic block.
BASR MK.60 Changing only the ECU is prohibited.
2 way black connector.
Front wheel The sensors are inductive-type.
5 ITT - A 96 332 952 80 Mounted on the pivot.
sensor
Non-adjustable airgap :0.2 à 1.5 mm.
Tightening torque : 0.8 ± 0.2 m.daN
2way black connector.
Rear wheel The sensors are inductive-type.
sensor96 332 954 80 Mounted on the brake caliper support.
Non-adjustable airgap :0.15 à 1.6 mm.
Tightening torque : 0.8 ± 0.2 m.daN
Hub
4 SNRHub equipped with a bearing with an integral
bearing magnetic wheel (48pairs of poles).
ABS MK.60
Hydraulic 96 371 711 80 Installed on the front LH wheelarch.
block7 TEVES
BASK MK.604adjustment channels.
96 371 712 80 Ref. SupplierPart No.
Observations
B3FP12XC
BRAKES
227
