BRAKESBRAKE SPECIFICATIONS
Brake pedal carriage Front brake Rear brake
(15)Fixing on bodyshell1.8 ± 0.25
(16) Servo fixing 2.1 ± 0.1(12)Caliper fixing on pivot12± 1.8
(13)Yoke fixing on caliper3.1± 0.1(14) Rear caliper fixing on suspension arm 7 ± 0.7
Tightening torques (m.daN).
B3FP130CB3FP12YCB3FP12ZC
Page 232 of 259
Downloaded from www.Manualslib.com manuals search engine B3FP12JD
HANDBRAKE (Adjustment)
Adjustment
- Remove the rear ashtray from the handbrake console.
- (1) Nut for adjusting the tension of the handbrake
cables.
- Raise and support the vehicle with the front wheels
hanging free.
- Check the correct routing of the brake cables under the
vehicle.
- Apply and release the handbrake 10 times.
- Set the handbrake to the 5th notch.
- Tighten the nut (1) until the front brakes are applied.
- Pull the handbrake lever vigorously4 to 5 times.
- Set the handbrake to the 5th notch.
- Check that the front brakes are applied.
- With the handbrake released, check that the wheels
can be turned freely by hand.
- Lower the vehicle.
- Refit the rear ashtray to the handbrake console.
229BRAKES
Page 233 of 259
Downloaded from www.Manualslib.com manuals search engine B3FP139CB3FP13AC
BLEEDING AND FILLING THE BRAKING SYSTEM
Tools.
[1] Generic bleeding apparatus: "LURO" or similar.
[2] PROXIA station: 4165-T.
[3] LEXIA station: 4171-T.
Bleeding, filling.
Draining the brake fluid reservoir.
- Drain the brake fluid reservoir (1) to the maximum (if necessary, use a clean syringe).
- Disconnect the connector (3).
- Uncouple the pipe (2).
- Remove the reservoir (1) by separating the lugs «a»from the shaft (4).
- Empty the brake fluid reservoir(1).
- Clean the brake fluid reservoir (1).
Remove :
- The brake fluid reservoir (1).
- The shaft (4).
- Couple the pipe(2).
- Reconnect the connector(3).
BRAKES
230
Page 234 of 259
Downloaded from www.Manualslib.com manuals search engine B3FP13BCAB3FP13CC
BLEEDING AND FILLING THE BRAKING SYSTEM
Bleeding, filling (continued).
Filling the braking system.
WARNING : Use only those hydraulic fluids that are approved and recommended.
- Fill the brake fluid reservoir (1).
Bleeding the braking system.
WARNING: During the bleeding operation, take care to maintain the level of brake fluid in the reser-
voir and to top it up, using only brake fluid that is clean and clear.
Bleeding the primary circuit.
WARNING: The ABS should not be active during the bleeding operation.
- Front brake caliper: Bleed screw(5).
- Rear brake caliper: Bleed screw (6).
- Bleed each wheel cylinder, proceeding in the following order :
Front LH wheel.
Front RH wheel.
Rear LH wheel.
Rear RH wheel.BRAKES
231
Page 235 of 259
Downloaded from www.Manualslib.com manuals search engine B3FP13DC
BRAKES
232
BLEEDING AND FILLING THE BRAKING SYSTEM
Bleeding, filling (continued).
With the bleeding apparatus
- Connect the bleeding apparatus [1] on the brake fluid reservoir (1).
- Adjust the apparatus pressure to 2 Bars.
For each circuit :
- Connect a transparent tube onto the bleed screw, submerge the other end of the tube in a clean container.
- Open the bleed screw, wait until the fluid is flowing out without air bubbles.
- Close the bleed screw.
- Remove the bleeding apparatus [1].
- Check the brake fluid level(Should be between «DANGER» level and«MAXI» level).
- Fill if necessary with the approved and recommended synthetic brake fluid.
Without the bleeding apparatus.
NOTE : Two operators are necessary.
For each circuit :
- Apply the brake pedal to place the circuit under pressure.
- Connect a transparent tube onto the bleed screw, submerge the other end of the tube in a clean container.
- Open the bleed screw, wait until the fluid is flowing out without air bubbles.
- Close the bleed screw.
- Remove the tool [1].
NOTE : Recommence the process a second time if that is necessary.
- Check the brake fluid level, (Should be between «DANGER»level and «MAXI»level).
- Fill if necessary with the approved and recommended synthetic brake fluid.
Page 236 of 259
Downloaded from www.Manualslib.com manuals search engine 233
BRAKES
BLEEDING AND FILLING THE BRAKING SYSTEM
Bleeding, filling (continued).
Bleeding the secondary circuit.
NOTE : The bleeding apparatus is connected on the brake reservoir.
- Use LEXIAorPROXIAdiagnostic tools.
Select the menu corresponding to the vehicle :
- ABS menu.
- ESP menu.
- Follow the instructions on the diagnostic tool.
- At the end of the bleeding process, check and top up, if necessary, the brake fluid level.
- Check that the brake pedal travel has not been lengthened, otherwise repeat the bleeding procedure.
- Remove the tools.
Page 237 of 259
Downloaded from www.Manualslib.com manuals search engine B4CP01FP
234
HYDRAULIC
SYSTEM
HYDRAULIC SPECIFICATIONS
Location of components
(A)High pressure hydraulic circuit.
(B)Low pressure hydraulic circuit.
(C)Electric circuit.
(21)Built-in Hydro-electronic Interface (BHI).
(22) Front slimline sphere.
(23) Front suspension cylinder.
(24)Rear slimline sphere.
(25)Rear suspension cylinder.
(26)Front hydractive 3+ regulator accumulator.
(27)Front hydractive 3+ regulator.
(28)Rear hydractive 3+ regulator accumulator.
(29)Rear hydractive 3+ regulator
(30) Front height sensor.
(31)Rear height sensor.
(32) LDS fluid reservoir .
(33) Suspension switch.
Page 238 of 259
Downloaded from www.Manualslib.com manuals search engine 235
HYDRAULIC
SYSTEM
B4BP01BC
HYDRAULIC SPECIFICATIONS
Reservoir
Reference Function Component
"d"InductionBuilt-in Hydro-electronic. Interface (BHI).
Power steering pump
"e"Built-in Hydro-electronic. Interface (BHI).
"f"Return Power steering pump
"c"Suspension cylinders
Synthetic fluid TOTAL FLUIDE LDS.
Capacity of the circuit 4.3 litres.
Page 239 of 259
Downloaded from www.Manualslib.com manuals search engine B3BP169P
HYDRAULIC
SYSTEM
236
HYDRAULIC SPECIFICATIONS
Built-in Hydro-electronic Interface (BHI).
Ref. Component Specifications
(36)Electric motor 2350 ± 150 rpm
Hydraulic unit comprising :
Pump with 5 axial pistons Throughput = 0.7 l/min at 2300 rpm
(35)- Anti-pulse hydropneumatic Diameters of the pistons = 6.35 mm
accumulator Safety valve rating = 180 Bars
A safety valve
(34)Electronic control unit
4 electrovalves:
Front suspension inlet The vehicle’s anti-sink function
(37)Rear suspension inlet is assured
Front suspension exhaust by the exhaust electrovalves
Rear suspension exhaust
Page 240 of 259
Downloaded from www.Manualslib.com manuals search engine HYDRAULIC
SYSTEM
237
B4BP01CDB4DP003D
HYDRAULIC SPECIFICATIONS
Hydractive 3+ regulator
(40) Slimline sphere.
(39) Hydractive regulator.
(38) Electrovalve.
(41) Depressurisation screw.Hydraulic unions
ReferenceTube diameter Tightening torque
(mm) m.daN
G 3.5
1.5 ± 0.3
H 6.35
J 10 2.5 ± 0.5
