Citroen C5 2009.5 (RD/TD) / 2.G Owner's Manual
Manufacturer: CITROEN, Model Year: 2009.5, Model line: C5, Model: Citroen C5 2009.5 (RD/TD) / 2.GPages: 314, PDF Size: 19.25 MB
Page 191 of 314
XI
1 7 2
P R A C T I C A L I N F O R M A T I O N
Sidelamps
R e m o v e t h e p r o t e c t i v e c a p A .
P u l l t h e b u l b h o l d e r t o r e m o v e i t .
R e p l a c e t h e b u l b a n d r e fi t t h e
b u l b h o l d e r .
R e fi t t h e p r o t e c t i v e c a p A . Dipped beam
R e m o v e t h e p r o t e c t i v e c a p B .
D i s c o n n e c t t h e c o n n e c t o r b y
p r e s s i n g i t b e t w e e n t h e t h u m b
a n d i n d e x fi n g e r .
F r e e t h e b u l b f r o m i t s t w o m e t a l
c l a m p s .
T a k e o u t t h e b u l b .
R e p l a c e t h e b u l b , e x e r t i n g a
s l i g h t a x i a l f o r c e .
R e fi t t h e c o n n e c t o r , u n t i l i t i s a l l
t h e w a y i n .
R e fi t t h e p r o t e c t i v e c a p B . Directional lamp
R e m o v e t h e p r o t e c t i v e c a p C .
D i s c o n n e c t t h e c o n n e c t o r b y
p r e s s i n g i t b e t w e e n t h e t h u m b
a n d i n d e x fi n g e r .
F r e e t h e b u l b f r o m i t s t w o m e t a l
c l a m p s .
T a k e o u t t h e b u l b .
R e p l a c e t h e b u l b , e x e r t i n g a
s l i g h t a x i a l f o r c e .
R e fi t t h e c o n n e c t o r , u n t i l i t i s a l l
t h e w a y i n .
R e fi t t h e p r o t e c t i v e c a p C .
Page 192 of 314
XI
173
P R A C T I C A L I N F O R M A T I O N
Front foglamp
R e m o v e t h e fi x i n g s c r e w o f
cover A u s i n g a t o r x t o o l , t i p t h e
c o v e r o v e r a n d r e m o v e .
R e m o v e t h e fi x i n g s c r e w o f
l a m p B u s i n g a t o r x t o o l a n d p u l l
t h e h e a d l a m p u n i t t o r e m o v e i t
f r o m t h e b u m p e r .
Disconnect the connector D .
R e m o v e t h e b u l b b y p e r f o r m i n g
a q u a r t e r o f a t u r n .
R e p l a c e t h e b u l b .
R e fi t t h e c o n n e c t o r D .
R e fi t t h e h e a d l a m p u n i t i n t h e
b u m p e r .
S c r e w t h e h e a d l a m p u n i t i n .
Position the cover using its guides
a n d s c r e w i n .
Bulbs: H 8
Direction indicators
R e m o v e t h e fi x i n g s c r e w o f
cover A u s i n g a t o r x t o o l , t i p t h e
c o v e r o v e r a n d r e m o v e .
R e m o v e t h e fi x i n g s c r e w o f
l a m p B u s i n g a t o r x t o o l a n d p u l l
t h e h e a d l a m p u n i t t o r e m o v e i t
f r o m t h e b u m p e r .
Detach the bulb C b y p r e s s i n g
on bars 1 and 2 .
D i s c o n n e c t t h e c o n n e c t o r ( p u l l
w h i l s t p r e s s i n g o n t h e g r e y
t o n g u e u s i n g a fl a t s c r e w d r i v e r ) .
R e p l a c e t h e b u l b .
R e fi t t h e c o n n e c t o r ( p u s h t h e
g r e y t o n g u e i n w e l l ) .
R e fi t t h e h e a d l a m p u n i t i n t h e
b u m p e r .
S c r e w t h e h e a d l a m p u n i t i n .
Position the cover using its
g u i d e s a n d s c r e w i n .
Bulbs: H P 2 4 W
Page 193 of 314
XI
174
P R A C T I C A L I N F O R M A T I O N
T h e s i d e r e p e a t e r i s s e a l e d .
I f t h e b u l b i s f a u l t y , r e p l a c e t h e s i d e
r e p e a t e r .
C o n s u l t a C I T R O Ë N d e a l e r .
Side repeaters
Rear lamps (Saloon)
I d e n t i f y t h e f a i l e d b u l b .
1. Brake
lamps and sidelamps:
P 2 1 W / 5 W
2. Sidelamps: R 5 W
3. Reversing lamp: H 2 1 W
4. Foglamps: H 2 1 W
5. Direction indicators: P 2 1 W
O p e n t h e b o o t .
U s i n g a fl a t s c r e w d r i v e r , r e m o v e
t h e 3 c l i p s w h i c h fi x t h e t r i m i n
t h e l a m p a r e a .
P a r t i a l l y r e m o v e t h e t r i m F .
Disconnect the connector G .
Boot-mounted lamps
Detach the bulb holder H .
R e p l a c e t h e b u l b .
R e fi t t h e b u l b h o l d e r H .
R e fi t t h e c o n n e c t o r G .
R e p l a c e a n d fi x t h e t r i m F with its
c l i p s .
W h e n r e fi t t i n g , t a k e c a r e n o t t o
trap the electrical cables.
Page 194 of 314
XI
174
P R A C T I C A L I N F O R M A T I O N
T h e s i d e r e p e a t e r i s s e a l e d .
I f t h e b u l b i s f a u l t y , r e p l a c e t h e s i d e
r e p e a t e r .
C o n s u l t a C I T R O Ë N d e a l e r .
Side repeaters
Rear lamps (Saloon)
I d e n t i f y t h e f a i l e d b u l b .
1. Brake
lamps and sidelamps:
P 2 1 W / 5 W
2. Sidelamps: R 5 W
3. Reversing lamp: H 2 1 W
4. Foglamps: H 2 1 W
5. Direction indicators: P 2 1 W
O p e n t h e b o o t .
U s i n g a fl a t s c r e w d r i v e r , r e m o v e
t h e 3 c l i p s w h i c h fi x t h e t r i m i n
t h e l a m p a r e a .
P a r t i a l l y r e m o v e t h e t r i m F .
Disconnect the connector G .
Boot-mounted lamps
Detach the bulb holder H .
R e p l a c e t h e b u l b .
R e fi t t h e b u l b h o l d e r H .
R e fi t t h e c o n n e c t o r G .
R e p l a c e a n d fi x t h e t r i m F with its
c l i p s .
W h e n r e fi t t i n g , t a k e c a r e n o t t o
trap the electrical cables.
Page 195 of 314
XI
1 7 5
P R A C T I C A L I N F O R M A T I O N
Wing-mounted lamps
R e m o v e t h e l a t e r a l b o o t t r i m fl a p A .
T o d o s o , p u l l i t t o w a r d s t h e i n s i d e
o f t h e b o o t , t h e n p u l l i t u p w a r d s .
Disconnect connector B .
U n s c r e w t h e 2 fi x i n g s C .
R e m o v e t h e l a m p f r o m i t s h o u s i n g .
Detach the bulb holder D .
R e p l a c e t h e b u l b .
R e fi t t h e b u l b h o l d e r D .
P l a c e t h e l a m p i n i t s h o u s i n g .
S c r e w i n t h e 2 fi x i n g s C .
R e fi t c o n n e c t o r B .
R e fi t t h e t r i m A .
You can use the wheelbrace to screw
o r u n s c r e w t h e fi x i n g s C .
Page 196 of 314
XI
176
P R A C T I C A L I N F O R M A T I O N
Boot-mounted lamps
O p e n t h e b o o t .
U s i n g a fl a t s c r e w d r i v e r , r e m o v e
t h e 3 c l i p s w h i c h fi x t h e t r i m i n
t h e l a m p a r e a .
P a r t i a l l y r e m o v e t h e t r i m F .
Disconnect the connector G .
Rear lamps (Tourer)
I d e n t i f y t h e f a i l e d b u l b .
1. Brake
lamps and sidelamps:
P 2 1 W / 5 W
2. Sidelamps: R 5 W
3. Reversing lamp: H 2 1 W
4. Foglamps: H 2 1 W
5. Direction indicators: P 2 1 W
Detach the bulb holder H .
R e p l a c e t h e b u l b .
R e fi t t h e b u l b h o l d e r H .
R e fi t t h e c o n n e c t o r G .
R e p l a c e a n d fi x t h e t r i m F with its
c l i p s .
Page 197 of 314
XI
177
P R A C T I C A L I N F O R M A T I O N
Wing-mounted lamps
R e m o v e t h e l a t e r a l b o o t t r i m A .
T o d o s o :
Pull it towards towards the inside
o f t h e b o o t .
P u l l i t u p w a r d s .
Disconnect the connector B .
U n s c r e w t h e fi x i n g s c r e w C .
R e m o v e t h e l a m p f r o m i t s h o u s i n g .
Detach the bulb holder D .
R e p l a c e t h e f a u l t y b u l b .
R e fi t t h e b u l b h o l d e r D .
P l a c e t h e l a m p i n i t s h o u s i n g .
S c r e w i n t h e fi x i n g s c r e w C .
R e fi t t h e c o n n e c t o r B .
R e fi t t h e t r i m A .
You can use the wheelbrace to screw o r u n s c r e w t h e fi x i n g s c r e w C .
Page 198 of 314
XI
1 7 8
P R A C T I C A L I N F O R M A T I O N
Number plate lamps (W5W)
Insert a thin screwdriver into one
o f t h e e x t e r n a l h o l e s o f t h e l e n s .
P u s h i t o u t w a r d s t o u n c l i p i t . Third brake lamp (diodes)
F o r t h e r e p l a c e m e n t o f t h i s t y p e o f
d i o d e l a m p , c o n t a c t a C I T R O Ë N
d e a l e r .
R e m o v e t h e l e n s .
C h a n g e t h e f a u l t y b u l b .
Page 199 of 314
XI
179
P R A C T I C A L I N F O R M A T I O N
Interior lamps
Roof lamps
U n c l i p t h e t r a n s p a r e n t c o v e r o f
t h e r o o f l a m p t o r e a c h t h e b u l b .
Bulb: W 5 W
Rear reading lamps (Tourer)
Detach the cover of the reading
l a m p t o a c c e s s t h e b u l b .
Bulb: W 5 W
Map reading lamp
D e t a c h t h e c o v e r .
I f n e c e s s a r y , d e t a c h t h e p a r t i t i o n
o f t h e a f f e c t e d m a p r e a d i n g l a m p . Boot lamp
Detach the cover and use a
W 5 W b u l b .
Pavement lighting
D e t a c h t h e c o v e r a n d u s e a W 5 W
b u l b . Floor lighting
D e t a c h t h e c o v e r a n d u s e a W 5 W
b u l b .
Glovebox
D e t a c h t h e c o v e r a n d u s e a W 5 W
b u l b .
Page 200 of 314
XI
1 8 0
P R A C T I C A L I N F O R M A T I O N
CHANGING A FUSE
P r o c e d u r e f o r r e p l a c i n g a f a u l t y f u s e
w i t h a n e w f u s e t o r e c t i f y a f a i l u r e o f
t h e c o r r e s p o n d i n g f u n c t i o n .
T h e 2 f u s e b o x e s a r e l o c a t e d b e l o w
t h e d a s h b o a r d a n d u n d e r t h e b o n n e t .
Replacing a fuse
B e f o r e r e p l a c i n g a f u s e , y o u s h o u l d
ascertain the cause of the fault and
h a v e i t r e m e d i e d . t h e n u m b e r s o f t h e
f u s e s a r e i n d i c a t e d o n t h e f u s e b o x .
R e p l a c e t h e f u s e t h a t h a s b l o w n
w i t h o n e o f t h e s a m e r a t i n g ( s a m e
c o l o u r ) .
U s e t h e s p e c i a l p l i e r s 1 p l a c e d o n
t h e fl a p c l o s e t o t h e f u s e b o x e s . T h e
fl a p a l s o h o l d s s p a r e f u s e s .
Good Failed
Pliers 1 Fuses under the dashboard
Access to the fuses
o p e n t h e g l o v e b o x t h e n u n c l i p
t h e a c c e s s c o v e r .
F u s e b o x C
F u s e b o x
A
R e p l a c e m e n t fuses and p l i e r s 1
F u s e b o x B
