engine Citroen DS3 2014 1.G Owner's Guide

DS3_en_Chap03_ouvertures_ed01-2014
This is indicated by lighting of the courtesy lamps   and   flashing   of   the   direction   indicators
f

or   a   few   seconds.
Locating your vehicle
F Press   the   closed   padlock   to  l
ocate   your   locked   vehicle   in   a
c

ar
 par
k.
Anti-theft protection
Electronic engine immobiliser
The key contains an electronic chip which has a  special   code.   When   the   ignition   is   switched
o

n,   this   code   must   be   recognised   in   order   for
s

tarting   to   be   possible.
This
  electronic   engine   immobiliser   locks   the
e

ngine   management   system   a   few   minutes
a

fter   the   ignition   is   switched   off   and   prevents
s

tarting   of   the   engine   by   anyone   who   does   not
h

ave   the   key.In the event of a fault, you are
informed
  by   illumination   of   this
w

arning   lamp,   an   audible   signal   and   a   message
i

n   the   screen.
In
  this   case,   your   vehicle   will   not   start;   contact
a

  CITROËN   dealer   as   soon   as   possible.-

P
osition   1:   Stop
-

P
osition   2:   Ignition
-

P
osition   3:   Starting
Ignition switch
keep safely the label attached to
the keys  given   to   you   on   acquisition   of
t

he   vehicle.

63
DS3_en_Chap03_ouvertures_ed01-2014
Starting the vehicle
F Insert  the   key   in   the   ignition   switch. T
he   system   recognises   the   starting   code.
F

T
urn   the   key   fully   towards   the   dashboard   to
p

osition 3 (Starting) .
F

W
hen   the   engine   starts,   release   the   key.F
 I mmobilise   the   vehicle.
F  T urn   the   key   fully   towards   you   to
position 1 (Stop) .
F

R
emove   the   key   from   the   ignition   switch.
Switching the vehicle off
Do not attach any heavy objects to the   key   as   this   could   weigh   down   on   it
w

hen   in   the   ignition   switch   and   cause
a

  fault.
Key reminder
If the key is left in the ignition switch, an audible   signal   sounds   when   the   driver's
d

oor   is   opened.
Access

65
DS3_en_Chap03_ouvertures_ed01-2014
Do not throw the remote control batteries   away,   they   contain   metals
w

hich   are   harmful   to   the   environment.
Take
  them   to   an   approved   collection
po

int.Lost keys
Go to a CITROËN dealer with the vehicle's registration document, your personal identification   documents   and   if   possible   the   key   code   label.
The
  CITROËN   dealer   will   be   able   to   look   up   the   key   code   and   the   transponder   code
r

equired   to   order   a   new   key.
Remote control
The high frequency remote control is a sensitive system; do not operate it while it is in your pocket   as   there   is   a   possibility   that   it   may   unlock   the   vehicle,   without   you   being   aware   of   it.
Do
  not   repeatedly   press   the   buttons   of   your   remote   control   out   of   range   and   out   of   sight   of
y

our   vehicle.   You   run   the   risk   of   stopping   it   from   working   and   the   remote   control   would   have
t

o   be   reinitialised.
No
  remote   control   can   operate   when   the   key   is   in   the   ignition   switch,   even   when   the   ignition
i

s   switched   off,   except   for   reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compartment by the emergency   services   more   difficult   in   an   emergency.
As
  a   safety   precaution,   never   leave   children   alone   in   the   vehicle,   except   for   a   very   short   period.
In
  all   cases,   it   is   essential   to   remove   the   key   from   the   ignition   switch   when   leaving
t

he vehicle.
Anti-theft protection
Do not make any modifications to the electronic engine immobiliser system; this could c ause m alfunctions.
When purchasing a second-hand vehicle
Have the pairing of all of the keys in your possession checked by a CITROËN dealer, to ensure   that   only   your   keys   can   be   used   to   open   and   start   the   vehicle.
Access

DS3_en_Chap03_ouvertures_ed01-2014
Doors
Opening
From outside
F After  unlocking   the   vehicle   using   the  r
emote   control   or   the   key,   pull   the   door
han

dle.
From inside
F Pull  the   door   lever   to   open   the   door;   this  u
nlocks   this   vehicle   completely.
closing
When a door is not closed correctly:
-
when the engine is running , this
warning lam p c omes o n, a ccompanied b

y   a   message   in   the   multifunction
 s

creen for a few seconds,
- when the vehicle is moving (speed higher   than   6   mph   (10   km/h)),   this   warning
l

amp   comes   on,   accompanied   by   an
a

udible   signal   and   a   message   in   the
m

ultifunction   screen   for   a   few   seconds.

71
DS3_en_Chap03_ouvertures_ed01-2014
boot
Opening
F After  unlocking   the   vehicle   using   the  r
emote   control   or   the   key,   press   the
o

pening   control   and   raise   the   tailgate.
closing
F Lower  the   tailgate   using   the   interior   grab  han
dle.
If
  the   tailgate   is   not   closed   correctly:
-

when the engine is running , this
warning   lamp   comes   on,   accompanied b

y   a   message   on   the   multifunction
 s

creen for a few seconds,
- when the vehicle is moving (speed above 6   mph   (10   km/h)),   this   warning   lamp   comes
o

n,   accompanied   by   an   audible   signal   and
a

  message   on   the   multifunction   screen   for
a

  few   seconds. System
  for   mechanical   unlocking   of   the   boot
i

n   the   event   of   a   battery   or   central   locking
m

alfunction.
Tailgate release
Unlocking
F Fold  back   the   rear   benchseat   to   gain  a
ccess   to   the   lock   from   inside   the   boot.
F

I
nsert   a   small   screwdriver   into   hole   A of the
lock
  to   unlock   the   tailgate.
Access

75
DS3_en_Chap04_confort_ed01-2014
Additional adjustments
Head restraint height adjustment
F To  raise   the   head   restraint,   pull   it   upwards.
F  T o   remove   the   head   restraint,   press   the
l

ug   A   and   pull   the   head   restraint   upwards.
F

T
o   put   the   head   restraint   back   in   place,
e

ngage   the   head   restraint   stems   in   the
o

penings   keeping   them   in   line   with   the   seat
b

ack.
F

T
o   lower   the   head   restraint,   press   the   lug   A
and
  the   head   restraint   at   the   same   time.The
  head   restraint   is   fitted   with   a   frame  w
ith   notches   which   prevents   it   from
l

owering;   this   is   a   safety   device   in   case
o

f   impact.
The adjustment is correct when the
upper edge of the head restraint is
level with the top of the head.
Never drive with the head restraints
removed;
  they   must   be   in   place   and
adj

usted
 c
orrectly.
Heated seats control
With the engine running, the front seats can be heated s eparately.
F

U
se   the   adjustment   dial,   placed   on   the   side
o

f each front seat, to switch on and select
the
  level   of   heating   required:
0:

  Off.
1:

  Low.
2:

  Medium.
3:

  High.
comfort

81
DS3_en_Chap04_confort_ed01-2014
Mirrors
Each fitted with an adjustable mirror glass permitting t he la teral r earward v ision n ecessary f

or   overtaking   or   parking.   They   can   also   be
f

olded   for   parking   in   confined   spaces.
demisting - def rosting Adjustment
F Move control A
  to   the   right   or   to   the   left   to  s
elect   the   corresponding   mirror.
F

M
ove control B in all four directions to
adjust.
F

R
eturn control A   to   the   central   position.
door mirrors
The objects observed are, in reality, closer   than   they   appear.
Take
  this   into   account   in   order   to
c

orrectly   judge   the   distance   of   vehicles
a

pproaching   from   behind.
Folding
F From  outside:   lock   the   vehicle   using   the  r
emote   control   or   the   key.
F

F
rom   inside:   with   the   ignition   on,   pull   the
c

ontrol A   in   the   central   position   rear wards.
Unfolding
F From  outside:   unlock   the   vehicle   using   the  r
emote   control   or   the   key.
F

F
rom   inside:   with   the   ignition   on,   pull   the
c

ontrol A   in   the   central   position   rear wards.
If

t
he
m
irrors
a
re
f
olded
u
sing
c
ontrol
A,
they will not unfold when the vehicle is
unlocked.   Pull   again   on   control   A
.
The   folding   and   unfolding   of   the   door
m

irrors   using   the   remote   control   can   be
d

eactivated by a CITR
oË
N dealer or a
qualified
 w

orkshop.
Never
  fold   or   unfold   the   electric   folding
m

irrors
 m
anually.
If your vehicle is fitted with heated
mirrors,

the

demisting-defrosting

o

perates

with

the

engine

running,

by

s

witching

on

the

heated

rear

screen

(

refer

to

the

"Rear

screen

demist-defrost"

pag

e).
comfort

DS3_en_Chap04_confort_ed01-2014
Recommendations for ventilation and air conditioning
If after an extended stop in sunshine, the   interior   temperature   is   very
h

igh,   first   ventilate   the   passenger
c

ompartment   for   a   few   moments.
Put
  the   air   flow   control   at   a   setting   high
e

nough   to   quickly   change   the   air   in   the
p

assenger
 c
ompartment.
The
  air   conditioning   system   does   not
c

ontain chlorine and does not present
any
  danger   to   the   ozone   layer.
In

order

for

these

systems

to

be

fully

effective,

follow

the

operation

and

maintenance
 g
uidelines belo
w:
F

T

o

obtain

an

even

air

distribution,

take

care

not

to

obstruct

the

exterior

air

intake

grilles

l

ocated at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as

the

air

extractor

located

in

the

boot.
F

D

o

not

cover

the

sunshine

sensor,

located

on

the

dashboard;

this

is

used

for

regulation

o

f

the

air

conditioning

system.
F

O

perate

the

air

conditioning

system

for

at

least

5

to

10

minutes,

once

or

twice

a

month

t

o

keep

it

in

per fect

working

order.
F

E

nsure

that

the

passenger

compartment

filter

is

in

good

condition

and

have

the

filter

e

lements

replaced

regularly.
 W

e

recommend

the

use

of

a

combined

passenger

compartment

filter.

Thanks

to

its

s

pecial active additive, it contributes to the purification of the air breathed by the
occupants

and

the

cleanliness

of

the

passenger

compartment

(reduction

of

allergic

s

ymptoms,

bad

odours

and

greasy

deposits).
F

T

o

ensure

correct

operation

of

the

air

conditioning

system,

you

are

also

advised

to

have

i

t

checked

regularly

as

recommended

in

the

maintenance

and

warranty

guide.
F

I

f

the

system

does

not

produce

cold

air,

switch

it

off

and

contact

a

CITROËN

dealer

or

a


qualified

workshop.
When

towing

the

maximum

load

on

a

steep

gradient

in

high

temperatures,

switching

off

the

a

ir

conditioning

increases

the

available

engine

power

and

so

improves

the

towing

ability. The condensation created by the air
conditioning
  results   in   a   discharge
o

f water under the vehicle which is
per fectly
  normal.

87
DS3_en_Chap04_confort_ed01-2014
The heating / ventilation or air conditioning systems operates with the engine running, as well as in STOP mode with Stop & Start.
1. Temperature adjustment
F Turn  the   dial   from   blue  (
cold)   to   red   (hot)   to   adjust
t

he   temperature   to   your
r

equirements.
2. Air flow adjustment
F Turn   the   dial   from   position   1
to position 5 to obtain a
comfortable
  air   flow.
F

I

f you place the air flow control
in position 0 (deactivation of the
system),
  the   temperature   is   no
l

onger   maintained   at   a   comfortable
l

evel.   However,   a   slight   flow   of   air,
d

ue
t
o
t
he
m
ovement
o
f
t
he
v
ehicle,
c

an   still   be   felt.
3. Air distribution adjustment
Windscreen and side windows.
W indscreen, side windows and
footwells.
Footwells.
Central
  and   side   vents.
The air distribution can be
adapted
  by   placing   the   dial
i

n   an   intermediate   position.
4. Air intake / Air recirculation
The intake of exterior air avoids the formation of   mist   on   the   windscreen   and   side   windows.
The recirculation of interior air insulates the
passenger
  compartment   from   exterior   odours
a

nd   smoke.
Return
  to   exterior   air   intake   as   soon   as   possible
t

o prevent deterioration of the air quality and
the
  formation   of   mist.
Manual control panel F

M
ove   the   manual   control   to
t

he   left   to   be   in   the   "recycling
i

nterior   air"   position.
F

M
ove   the   manual   control   to   the
r

ight   to   return   to   the   "fresh   air
i

ntake"   position.
comfort

DS3_en_Chap04_confort_ed01-2014
Digital air conditioningThe air conditioning operates when the engine is running, as well as in STOP mode with Stop & Start.
Automatic operation
1. Automatic "comfort" programme
Press the "AUTO"  button.  T
he "AUTO"  symbol   is   displayed.
We
  recommend   that   you   use
t

his   mode.   It   provides   optimised
a

utomatic
  control   of   all   of   the   following
f

unctions:
  passenger   compartment
t

emperature,   air   flow,   air   distribution   and   air
i

ntake,

in

accordance   with   the   comfort   value
t

hat

you

have   chosen.
This

system   is   designed   to   operate   effectively
i

n

all

seasons,   with   the   windows   closed. For
  your   comfort,   when   the   engine   is
s

witched   off,   the   settings   are   retained
u

ntil   the   engine   is   switched   on   again.
To   prevent   too   great   a   distribution   of
c

old   air   when   the   engine   is   cold,   the   air
f

low   will   only   reach   its   optimum   level
g

radually.
2. Temperature adjustment
The value indicated on the display corresponds
to
  a   level   of   comfort   and   not   to   a   temperature   in
d

egrees   Celsius   or   Fahrenheit. On
  entering   the   vehicle,   if   the   interior
i

s very cold or hot, there is no need to
change   the   value   displayed   in   order
t

o   reach   the   required   level   of   comfort.
T

he   system   corrects   the   temperature
d

ifference   automatically   and   as   quickly
a

s   possible.
Press the " 5" and " 6" buttons to
change
  this   value.   A   setting   around
t

he value 21

enables   optimum
c

omfort   to   be   obtained.   However,
d

epending   on   your   requirements,   a
s

etting   between   18   and   24   is   usual.
3. Automatic "visibility" programme
The automatic comfort programme m
ay   not   be   sufficient   for   rapid
d

emisting   or   defrosting   of   the
w

indscreen and side windows
(humidity,
  several   passengers,   ice,   etc.).
In

this

case,   select   the   automatic   visibility
p

rogramme.   The   button   3   indicator   lamp
comes

on.
The

system   automatically   controls   the   air
c

onditioning   and   the   flow   of   air   and   provides
o

ptimum

air   distribution   to   the   windscreen   and
s

ide

windows.   It   deactivates   air   recirculation   5.
To

exit

this   programme,   press   button   3   again
or "AUTO" ,
  the   indicator   lamp   on   the   button
g

oes

off

and   "AUTO"

is   displayed.
With
  Stop   &   Start,   when   demisting   has
b

een   activated,   the   STOP   mode   is   not
a

vailable.
