After refitting the battery, the Stop &Start system will only be active after several hours depending on the climaticconditions and the state of charge of the battery (up to about 8 hours).
)Connect the red cable to the positive
terminal (+) of the flat battery A , then to the positive terminal (+) of the slave battery B .)Connect one end of the green or blackcable to the negative terminal (-) of the slave battery B.


Starting using another
battery
)
Disconnect the battery from the vehicle, if necessary.
)
Follow the instructions for use provided by
the manufacturer of the charger. ) Reconnect starting with the negative
terminal (-). ) Check that the terminals and connectorsare clean. If they are covered with sulphate (whitish or greenish deposit), remove themand clean them.


Charging the battery using
a battery charger
)
Connect the other end of the green or blackcable to the ear th point C
on your vehicle (engine mounting).)
Operate the star ter, let the engine run.)
Wait until the engine returns to idle and disconnect the cables.

The batteries contain harmful substances such as sulphuric acid and lead. They must be disposed of inaccordance with regulations and must not, in any circumstances, be discarded with household waste.
Take used remote control batteriesand vehicle batteries to a special collection point.

Do not reverse the polarity and use only a 12 V charger.
Do not disconnect the terminals whilethe engine is running.
Do not charge the batteries without disconnecting the terminals first.
Do not push the vehicle to star t the engine if it is fitted with the 6 -speed electronic gearbox.


It is advisable to disconnect the battery if the vehicle is to be left unused for more than one month.


Following reconnectionof the battery

Following reconnection of the battery, switch
on the ignition and wait 1 minute before star tingto permit initialisation of the electronic systems.However, if problems remain following this
operation, contact a CITROËN dealer or aqualified workshop.
Referring to the corresponding section, you
must yourself reinitialise:


- the remote control key,

- the panoramic sunroof blind,

- the
GPS satellite navigation system.









Load reduction mode
System which manages the use of certainfunctions according to the level of charge
remaining in the battery.
When the vehicle is being driven, the load
reduction function temporarily deactivates cer tain functions, such as the air conditioning,
the heated rear screen...
The deactivated functions are reactivated
automatically as soon as conditions permit.
Do not attempt to charge the highvoltage battery.


Before disconnecting the battery

Wait 2 minutes after switching off the ignitionbefore disconnecting the battery.

Close the windows and the doors beforedisconnecting the battery.

221Practical information
System which manages the duration of use of
certain functions to conserve a sufficient level
of charge in the battery.
After the engine has stopped, you can still use
functions such as the audio and telematics system, windscreen wipers, dipped beam
headlamps, cour tesy lamps, etc. for amaximum combined duration of thirty minutes.








Energy economy mode
Switching to economy mode

A message then appears in the instrument panel screen indicating that the vehicle has
switched to economy mode and the active
functions are put on standby.
If a telephone call is being made at this time,it will be maintained for around 10 minutes with
the Bluetooth hands-free system of your audio
system.


Exiting economy mode

These functions are reactivated automatically
next time the vehicle is driven.) In order to resume the use of thesefunctions immediately, star t the engine and
let it run:
- for less than ten minutes, to use
the equipment for approximatelyfive minutes,
- for more than ten minutes, to use theequipment for up to approximately
thirty minutes.

Let the engine run for the duration specified
to ensure that the battery charge is sufficient.
Do not repeatedly and continuously restar t theengine in order to charge the battery.
A flat battery prevents the engine from star ting (refer to the "Battery" section).

Changing a wiper blade
Before removing a front
wi
per blade
Removin
g
)
Raise the corresponding wiper arm. )
Unclip the wiper blade and remove it.



Fitting
)
Put the corresponding new wiper blade in
place and clip it.) Fold down the wiper arm carefully.


After fitting a front wiper
blade
) Switch on the ignition. )
Operate the wiper stalk again to park the
wiper blades.







Recovering the
vehicle on
a fl at-bed


Procedure for having your vehicle recovered on
a flat bed lorry or trailer.
Always recover the vehicle on a flat bed lorry or trailer.Never tow the vehicle with the four wheels on the ground (or the front or rear wheels only), you risk damaging the transmission.Place the gear lever in position N and switch off the engine ( Ready
lamp off).
)Within one minute after switching off
the ignition, operate the wiper stalk to position the wiper blades ver tically on
the windscreen.

223Practical information
From the front
From the rear





Access to the tools

The towing eye is installed in the boot under
the floor.
To gain access to it: )open the boot, )remove the towing eye, located in the
tool box.

)
On the front bumper, unclip the cover by
pressing at the bottom to disengage thesecuring lugs.) Screw the towing eye in fully.)
Install the towing system.)
Switch on the hazard warning lamps.
)
On the rear bumper, unclip the cover bylevering at the left with the point of the
towing eye. ) Screw the towing eye in fully. )
Install the towing system. )
Switch on the hazard warning lamps.
)Place the gear lever in neutral -position N.Failure to obser ve this special condition could result in damageto certain braking components and the absence of braking assistancethe next time the engine is started.



When towing with the engine off, there is no longer any braking or steering assistance.

Towing a trailer, ...


Towbar suitable for the attachment of a trailer
with additional lighting and signalling.
Your vehicle is primarily designed for
transporting people and luggage, but it mayalso be used for towing a trailer.

When not towing a trailer, remove thequickly-detachable tow ball beforedriving, so as to avoid masking the
central rear lamp.
Maximum trailer weight
You must not tow a trailer weighing more
than 500 k
g.







Vehicle recovery
Before doing any work, with the ignition on, press the brake pedal and put the gear lever inposition N
, then switch off the hybrid system.
Th
e front or rear wheels must not be on the ground, use a flat-bed lorry or trailer to recover
the vehicle.
Use the towing eyes only to pull avehicle out or to pull it onto a flat-bed. If necessary because access to thevehicle is difficult, it can be moved a few dozen metres at a speed not exceeding6 mph (10 km/h).

225
Practical information
We recommend the use of genuine
CITROËN towbars and their harnesses that have been tested and approvedfrom the design stage of your vehicle,and that the fitting of the towbar is
entrusted to a CITROËN dealer or aqualified workshop.
If the towbar is not fitted by a CITROËN dealer, it is imperative that it isfitted in accordance with the vehiclemanufacturer's instructions.
Driving advice
Distribution of loads
)
Distribute the load in the trailer so that the
heaviest items are as close as possible to
the axle and the nose wei
ght approaches the
maximum permitted without exceeding it.
Air density decreases with altitude,
thus reducing engine performance.
Above 1 000 metres, the maximum towed
load must be reduced by 10 % for every1 000 metres of altitude.
Refer to the "Technical Data" section for details
of the weights and towed loads which apply toyour vehicle.
Side wind
)
Take into account the increased sensitivityto side wind.

Cooling
To w i ng a trailer on a slope increases the
temperature of the coolant.
As the fan is electricall
y controlled, its cooling capacity is not dependent on the engine speed. )
To lower the engine speed, reduce your
speed.
)If the warning lamp and the
STOP
warning lamp come on,
stop the vehicle and switch off
the en
gine as soon as possible.

Braking

To w i ng a trailer increases the braking distance.
To avoid overheating of the brakes on a long
mountain type of descent, the use of engine
braking is recommended.


Tyres
)
Check the tyre pressures of the towing
vehicle and of the trailer, obser ving the
recommended pressures.



Lighting
)
Check the electrical lighting and signalling on the trailer.

The rear parking sensors will be deactivated automatically if a genuineCITROËN towbar is used.


Driving with a trailer places greater demands on the towing vehicle and the driver must take par ticular care. The maximum towed load on a lon
g incline
depends on the gradient and the ambienttemperature.
In all cases, keep a check on the coolant
temperature.

Fitting roof bars
rack, for a loading height not exceeding40 cm (with the exception of bicycle carriers): 70kg.
If the height exceeds 40 cm, adapt the
speed of the vehicle to the profile of theroad to avoid damaging the roof bars and the fixings on the roof.
Be sure to refer to national legislation in order to comply with the regulations for transporting objects which are longer than the vehicle. When
fitting transverse roof bars, take care toposition them correctly: Use accessories recommended by CITROËN obser ving the manufacturer'srecommendations and fitting instructions so as to avoid the risk of damaging the body (deformation,scratches, ...).
)Remove the cap using an allenTM key. )Put the bars into position then fit and
tighten the securing screws.

227Practical information





Accessories
A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
They are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.



"Comfort":

door deflectors, side window blinds, rear screen blind, isotherm module, coat hanger fixed to head restraint, mobile reading lamp, mirror for caravan, parking sensors...


"Transport systems":

child seats and booster cushions, boot carpet,
boot liner, boot net, boot spacers, transverse
roof bars, bic
ycle carrier, ski carrier, roof boxes,
towbars, wiring harnesses...
If a towbar and wiring harness are fitted
outside the CITROËN dealer network, theinstallation must be done using the vehicle's electrical pre-equipment and fitted following the manufacturer's recommendations.
"Styling":
gear lever knobs, aluminium foot rest, alloy wheels, chrome mirror shells, chrome door aperture finishers...

*
To avoid an
y risk of jamming the pedals:
- ensure that mats are correctly positionedand secured,
- never fit one mat on top of another.
"Security and safety":
anti-intrusion alarm, anti-tilt unit, stolen
vehicle tracking system, child seats and
booster cushions, breathalyser, first aid kit, fire
extinguisher, warning triangle, high visibility
vest, wheel security bolts, snow chains,non-slip covers...
"Protection":

mats * , seat covers compatible with lateral
airbags, mud flaps, door protective mouldings,bumper protection strips, vehicle cover...
The rear bodywork has been designedto avoid spray.

The fitting of electrical equipment or accessories which are not recommended by CITROËN may resultin a failure of your vehicle's electronicsystem and excessive electricalconsumption.
Please note this precaution. You are advised to contact a CITROËNrepresentative to be shown the range of recommended equipment and accessories.


Installation of radio communication transmitters

Before installing any after-market radiocommunication transmitter, you can contact a CITROËN dealer for the specification of transmitters which can be fitted (frequency, maximum power, aerial position, specific installation requirements), in line with the Vehicle Electromagnetic Compatibility Directive (2004/10 4/EC).
Depending on the legislation in force in the country, it may be compulsoryto have a high visibility safety vest,warning triangle and spare bulbs andfuses available in the vehicle.
B
y visiting a CITROËN dealer you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products in the "TECHNATURE" range,
products for topping up (screenwash...), paint
touch-up pens and aerosols for the exact colour
of
your vehicle, refills (sealant car tridge for the
temporary puncture repair kit...), ...
"Multimedia":
audio systems, steering mounted audio controls, speakers, Hi-Fi module, Bluetooth hands-free system, por table satellite navigationsystem, semi-integral suppor t bracket for portable navigation system, speed camera
detector, USB Box, reversing camera, por table
video screen, por table video support bracket,
230 V/50 Hz socket, 230 V/12 V adaptor,
Wi-Fi on board...
