75
4
ERGONOMICS and COMFORT
Seats
Replacing the benchseat
Place the benchseat in the fully folded
position in its front anchorages.
Fold the benchseat in the table position,
the front and rear feet of the seat lock in
automatically.
Returning the benchseat to the sitting position
Lift up the backrest of the benchseat.
Be careful not to jam the seatbelts.
Lock the backrest by pushing it all the way
back. The red light should no longer be
visible.
Rear head restraint
The rear head restraints are removable and
have two positions:
 high, in use,
 low, storage.
To raise or lower a head restraint, pull it
forwards and slide it at the same time.
To remove it, move it to the high position,
push the tab and pull it forwards and
upwards at the same time.
To replace it, place the head restraint rods
in the holes keeping them in line with the
backrest.
Never drive with the head restraints
removed; they must be in place and
correctly adjusted.

76
Ventilation
DE-ICING AND DEMISTING
Windscreen
The ventilation outlets located at the base
of the windscreen and the side vents for the
side windows increase the effectiveness of
the de-icing and demisting. Do not obstruct
these eight air outlets.
The manual air conditioning consists of the
pollen filter and air recirculation.
The pollen filter permits continuous and
effective filtering of dust.
The air recirculation (which can be activated
by the driver or the passenger) isolates the
passenger compartment from the exterior
atmosphere. However, this position should
only be used temporarily, the norm is to
drive with the control positioned with the
exterior air intake open.
Manual mode
Direct the control to this air
distribution setting.
For faster and more effective
de-icing and demisting of the
windscreen: - increase the air flow setting,
Returning to the exterior air intake
position permits renewal of the air
in the passenger compartment.
Rear screen and mirrors de-icing
This function only operates when
the engine is running. Pressing
this button activates the rapid
demisting/de-icing of the rear
screen and mirrors. This function switches
off automatically to prevent an excessive
consumption of energy. It switches off when
the engine is switched off. Pressing this
button switches the function off.
- move the exterior air intake
control temporarily to air
recirculation.

77
4
ERGONOMICS and COMFORT
Ventilation
CORRECT USE OF THE AIR CONDITIONING
In order to be effective, the air conditioning
should only be used with the windows
closed. However, if the interior temperature
remains high after a prolonged period
parked in the sun, do not hesitate to
ventilate the passenger compartment for a
few minutes. For even air distribution, ensure that the
exterior air intake grille located at the base
of the windscreen is not obstructed and that
the side and central vents, the air outlets on
the floor and the air extractor at the rear are
open.
The air conditioning is useful in all seasons
as it eliminates condensation and air
humidity. Operate the air conditioning system for
5 to 10 minutes, once or twice a month,
to keep it in perfect working order.
Have the filter elements (air filter and
passenger compartment filter) replaced
regularly. If you drive in a dusty environment,
have them replaced twice as often.
It is normal that the condensation created by
the air conditioning system results in a flow
of water which may form a puddle under the
vehicle when parked.
If the system does not produce cold air, do
not use it and contact a CITROËN dealer . VENTS
For optimum distribution and diffusion of hot
or cool air in the passenger compartment,
there are:
- 2 adjustable central vents,
- 2 adjustable and closing side vents,
- 2 vents directed towards the floor of the vehicle.

78
Ventilation
These controls are located on the centre console.
Air conditioning
The air conditioning mode is operational
when the engine is running. The diode is lit.
Temperature adjustment
Control positioned:
- in the blue zone triggers cool
air,
Air fl ow
The force of the blown air, from
the vents, varies from 1 to the
strongest 4 . Remember to adjust
this control in order to reach the
ambient air comfort level. To switch off the
blower, place the control in position 0 .
The air supply distribution is
directed by the control turned
towards:
the side vents and the central
vents,
the side vents, the central vents
and the footwells,
the footwells,
the windscreen, the front side
windows and the footwells,
the windscreen.
Press the air blower control.
The diode lights.
The air blower control must not
be in position
0 (zero flow) for air
conditioning to be obtained.
Turn the control to the position
required. - in the red zone triggers heating
of the interior ambient air.
Air distribution

79
4
ERGONOMICS and COMFORT
Ventilation
Intake of exterior air
This is the preferred operating
position.
Recirculation of interior air
This position should only be
temporary.
Used with the air conditioning
switched on and setting of the
force of blown air (from 1 to 4), recirculation
enables you to obtain the required ambient
air comfort level with both hot or cold
settings.
Recirculation temporarily prevents exterior
odours and smoke from entering the
passenger compartment. De-icing is more
rapid in this position.
When your ambient air comfort level has
been reached, return to the intake of exterior
air position to permit renewal of the air in the
passenger compartment and demisting. This
operating mode is preferable.

80
Practical information
Smoker’s kit
Located at the base of the centre console,
this consists of a lighter and ashtray.
12 volt socket (180 W max)
An accessories socket is provided next to
the lighter.
CAB LAYOUT
Folding writing table (Van)
This is located in the centre of the fascia
panel. In the absence of a table, the vehicle
is fitted with a storage compartment.
The clip can be used to secure A5 format
documents, slips, etc.
Pull the top of the table to unfold it, push to
fold it.

81
4
ERGONOMICS and COMFORT
Practical information
Sun visor
To avoid glare from ahead, fold and direct
the sun visor down.
Toll cards, tickets, etc. can be slipped into
the sun visor on the driver ’s side.
The sun visor on the passenger ’s side may
have a courtesy mirror fitted. Storage compartment in the door trays
With recess for storing a 1 litre bottle.
Glove box
This can be used for storing a laptop
computer.
It holds the vehicle documentation.

82
Practical information
LOAD SPACE LAYOUT (VAN)
Stowing rings
There are 6 stowing rings on the rear floor to
secure your loads.

For safety reasons in the event of sharp
braking, you are advised to place heavy
objects towards the front of the load space
near the front seats.
Storage tray
A storage tray is provided at the rear left of
the load space.
Torch
A magnetic torch is provided at the rear right
of the load space.
Remove the torch from its base by rotating it
downwards by 90 degrees.
To change the 4 storage batteries
(NiMH type), remove the protective cover
from the torch.
To put the torch back in place, engage
it in the notches on the base and pivot it
upwards.
Ladder type vertical partition
Behind the driver ’s seat, a ladder type
vertical partition protects the driver against
the risk of load movement.
Partitions
Panel, glazed, mid-height panel with grille
and modular vertical grille type partitions are
offered to complement your light van.
The transportation of passengers in the
load space is not permitted.
It is advisable to immobilise the load
by fixing it securely using the stowing
rings on the floor.

83
4
ERGONOMICS and COMFORT
Practical information
Modular vertical grille
You can obtain a two-part partition grille.
Associated with the retractable seat, the
grille increases the driver ’s safety by
isolating him from the front load. Operations:
1. Place the passenger seat in the fully
folded position.
2. Pull the catch, located at the lower part of
the grille.
3. Pull the catch, located at the upper part
of the grille.
4. Pivot the grille and insert the catch in the
space provided on the backrest of the
passenger seat.

84
Practical information
LOAD SPACE LAYOUT (COMBI)
Stowing rings
There are 4 stowing rings on the rear floor to
secure your loads.
Luggage retaining net
Attached to the stowing rings, this allows
you to secure your loads.
Rear shelf
Deployed, to hide the contents of the boot
from the exterior.
Folded up, for easier access to the contents
of the boot.
Stored behind the rear benchseat, for the
vertical loading of bulky items.
Removing the shelf
Fold the shelf up.
Tilt the shelf to approximately 60°.
Unclip the side fixings of the shelf from their
brackets.
Remove the shelf.
Store the shelf folded up in the storage area
behind the rear benchseat.
To put it back in place, perform these
operations in the opposite order.
