DAEWOO LACETTI 2004 Service Repair Manual

LITHING SYSTEMS 9B – 45
DAEWOO V–121 BL4
Installation Procedure
1. Install the replacement bulb into the bulb housing.
2. Install the bulb housing.
3. Connect the negative battery cable.

9B – 46ILITHING SYSTEMS
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
HEADLAMPS–ON REMINDER CHIME
When the headlamp switch is in the headlamps–on or
parking lamps–on position, voltage is applied to the chime
module. When the ignition is in ON, ACC or START, volt-
age is applied through the fuse block to the module. These
two voltages are sensed, and the chime module is not
sounded.
When the ignition is not in ON, ACC or START, the module
loses voltage. The chime module senses change. If the
voltage is still available, it is applied to sound the chime.
The chime can be turned off by turning the headlamp
switch off. The module no longer senses voltage from the
headlamp switch, so the chime module does not sound.
HEADLAMPS
The headlamps are controlled by the multifunction lever
located on the left side of the steering column. They will
come on with the ignition switch in any position. Turning
the headlamp switch to the first position turns on the park-
ing lamps, the license plate lamps and the instrument pan-
el illumination. Turning the switch to the second position
turns on all of the previous lamps and the headlamps.
Turning the switch to the OFF position turns off all the
lamps.
Headlamp high beams and low beams are also controlled
by this lever. When the headlamps are on, pushing the le-
ver away from the driver until the switch clicks changes the
lamp from low beam to high beam. An indicator lamp on
the instrument cluster assembly will come on when the
high beam headlamps are on. To return the headlamps to
low beam, pull the lever toward the driver.
The headlamps must be aimed for proper illumination of
the road. Headlamp aim should be checked whenever a
new headlamp assembly is installed, or whenever service
repairs to the front end area may have disturbed the head-
lamp assembly or its mountings.
DAYTIME RUNNING LAMPS
The Daytime Running Lamps (DRL) will come on when:
S The ignition is ON.
S The light is OFF.
S The parking brake is released.
When the exterior lights are on, the DRL will turn off. To
turn the DRL off when idling, apply the parking brake.
PARKING AND TURN SIGNAL LAMPS
The parking lamps can be turned on by turning the lighting
switch to the first position. The parking lamps can be
turned off by turning the switch to the OFF position.When the turn signals are activated, the front and rear turn
signal lamps flash to signal a turn. The turn signals work
only when the ignition is ON.
The turn signals are controlled by the light switch on the
left side of the steering column. Moving the lever all the
way up or down (past the detent) will turn on the front and
rear turn signals. When the turn is completed, the lever will
return to horizontal and the turn signals will stop flashing.
For changing lanes, or for shallow turns in which the steer-
ing wheel does not turn far enough to cancel the signal,
move the signal lever only to the first detent and hold it
there. When the lever is released, it will return to horizontal
and the turn signals will cancel.
FOG LAMPS
The fog lamp switch is on the instrument panel to the right
of the steering column. To use the fog lamps, first turn on
the headlamps or the parking lamps. Then push the fog
lamp switch. The indicator light in the switch will illuminate
to indicate that the fog lamps are on. Push the switch again
to turn off the fog lamps. The indicator light will then go off.
The fog lamps should not be used as a substitute for the
headlamps.
The fog lamps must be aimed for proper illumination of the
road. Fog lamp aim should be checked when a new bulb
is installed or if service or repairs in the front end area may
have disturbed the fog lamp mountings.
REAR COMBINATION LAMPS
The taillamps, stoplamps, turn signal lamps and backup
lamp are one assembly.
Turning on either the headlamps or the parking lamps will
also turn on the taillamps. When the brake pedal is
pushed, the taillamps will glow brighter to serve as sto-
plamps.
The center high–mounted stoplamp is located in the rear
window and will come on when the brake pedal is pressed.
LICENSE PLATE LAMP
The license plate lamps will come on when the headlamps
or the parking lamps are on. The license plate lamps are
mounted above the license plate.
INTERIOR COURTESY LAMP
The courtesy lamp is located on the headliner just behind
the front seats. The lamp switch has three positions. If the
switch is left in the center position, the lamp will go on
whenever a door is opened and go off when it is closed.
In the ON position, the lamp will stay on until it is turned off.
In the OFF position, the lamp will not come on, even when
a door is opened.
LUGGAGE COMPARTMENT LAMP
The luggage compartment lamp is located under the deck
lid sill plate on the notchback. The lamp is located on the
left–side wheelhouse trim panel on the hatchback. It will
come on whenever the luggage compartment is opened.

LITHING SYSTEMS 9B – 47
DAEWOO V–121 BL4
BACKUP LAMPS
The backup lamps are located in the rear combination
lamps They will come on when the transaxle is shifted into
reverse. On a vehicle with an automatic transaxle, the
backup lamps are activated by the neutral safety backup
(NSBU) switch. On a vehicle with a manual transaxle, they
are activated by a reverse switch which is part of the trans-
axle.

SECTION : 9C
HORN(S)
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9C–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9C–1. . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9C–2 . . . . .
Horn Wiring System 9C–2. . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9C–3 . . . . . . . . . . . . . . . ON–VEHICLE SERVICE 9C–3. . . . . . . . . . . . . . . . . . . . .
Horn(s) 9C–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9C–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn(s) 9C–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Horn Bolt2015–

9C – 2IHORN(S)
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
HORN WIRING SYSTEM

HORN(S) 9C – 3
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
HORN(S)
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the electrical connector.
3. Remove the bolt and the horn. (Left horn shown,
right horn similar, if equipped.)
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the horn with the bolt.
Tighten
Tighten the horn bolt to 20 NSm (15 lb–ft). (Left horn
shown, right horn similar, if equipped.)
2. Connect the electrical connector.
3. Connect the negative battery cable.

9C – 4IHORN(S)
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
HORN(S)
The horns are located under the hood. They are attached
near the radiator at the front of the vehicle. The horns are
actuated by pressing the steering wheel pad, which
grounds the horns’ electrical circuit.

SECTION : 9D
WIPERS/WASHER SYSTEMS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9D–1 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9D–1. . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9D–2 . . . . .
Wipers and Washer System 9D–2. . . . . . . . . . . . . . . . .
Wipers and Washer System 9D–3. . . . . . . . . . . . . . . . .
Wipers and Washer System (HatchBack) 9D–4. . . . .
Wipers and Washer System (HatchBack) 9D–5. . . . .
DIAGNOSIS9D–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 9D–6. . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer System 9D–10. . . . . . . . . . . . . . . .
Rear Window Wiper (Hatchback) 9D–11. . . . . . . . . . .
Rear Window Washer System (Hatchback) 9D–13. . .
MAINTENANCE AND REPAIR9D–14 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9D–14. . . . . . . . . . . . . . . . . . . .
Windshield Wiper Arm 9D–14. . . . . . . . . . . . . . . . . . . . . Windshield Wiper Motor 9D–14. . . . . . . . . . . . . . . . . . .
Windshield Wiper Blade 9D–15. . . . . . . . . . . . . . . . . . .
Windshield Wiper Blade Insert 9D–16. . . . . . . . . . . . . .
Windshield Washer Reservoir 9D–16. . . . . . . . . . . . . .
Windshield Washer Pump(s) 9D–17. . . . . . . . . . . . . . .
Windshield Washer Nozzles 9D–18. . . . . . . . . . . . . . . .
Windshield Washer Hoses 9D–18. . . . . . . . . . . . . . . . .
Rear Window Wiper Arm (HATCHBACK) 9D–19. . . .
Rear Window Wiper Motor (HATCHBACK) 9D–20. . .
Rear Window Washer Nozzle (HATCHBACK) 9D–20
GENERAL DESCRIPTION AND SYSTEM
OPERATION9D–22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper System 9D–22. . . . . . . . . . . . . . . . . .
Windshield Washer System 9D–22. . . . . . . . . . . . . . . .
Rear Window Wiper/Washer System 9D–22. . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNSmLb–FtLb–In
Front Wheel Well Splash Shield Bolts1.5–13
Washer Fluid Reservoir Bolts8–71
Wiper Arm Linkage Nut5–44
Wiper Arm Nut2216–
Wiper Motor Bolts8–71
Rear Wiper Arm Nut11–97

9D – 2IWIPERS/WASHER SYSTEMS
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
WIPERS AND WASHER SYSTEM

WIPERS/WASHER SYSTEMS 9D – 3
DAEWOO V–121 BL4
WIPERS AND WASHER SYSTEM
