DODGE CHALLENGER SRT 2015 3.G Owners Manual

The SRT Drive Modes main screen displays the current
drive mode and real-time status of the vehicle’s perfor-
mance configuration. The selectable Drive Modes buttons
are Track, Sport, Custom, or Default and will be high-
lighted when displaying the current configuration. Infor-
mation shown below each drive mode button will indi-
cate the actual status of each system, along with a graphic
that displays the status of the vehicle’s components. The
color red indicates “Track,” orange “Sport,” and yellow
“Street.” If the system status shown does not match the
current drive mode set up, a message will be displayed
indicating which values are not matching the current
mode and why.
NOTE:ESC Full-Off can be activated across all of the
Drive Mode features by pushing and holding the ESC Off
button on the instrument panel switch bank for five
seconds. Listed below are the available Drive Modes:
Track Mode
Pressing the “Track” button on the touchscreen will
activate the configuration for typical track driving. The
Drive Modes (Track)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 289

Transmission, Traction, Steering, and Suspension systems
are all set to their “Track” settings highlighted in red. The
Paddle Shifters are enabled.
Sport Mode
Pressing the “Sport” button on the touchscreen will
activate the configuration for typical enthusiast driving.
The Traction, Transmission, Steering, and Suspension
systems are all set to their “Sport” settings highlighted in
orange. The Paddle Shifters are enabled.
Drive Modes (Sport)
290 UNDERSTANDING YOUR INSTRUMENT PANEL

Default ModeThe vehicle will start in Default Mode unless Valet mode
is active. This mode is for typical driving conditions
where the Traction and Transmission will be operating in
their Street settings, which cannot be changed while in
this mode. The Steering and Suspension can be config-
ured in either the “Street,” “Sport,” or “Track” modes and
the Paddle Shifters may be enabled or disabled while in
this mode.
Drive Modes (Default)
4
UNDERSTANDING YOUR INSTRUMENT PANEL 291

Custom Mode
The Custom Mode may be selected quickly by pushing
the SRT button on the instrument panel switch bank two
times, or pressing the “Custom” button on the touch-
screen. Custom Mode allows the you to create a customconfiguration that is saved for quick selection of your
favorite settings. While in Custom Mode, the Horse-
power, Traction, Transmission, Steering, Suspension, and
Paddle Shifter settings are shown in their current con-
figuration.
Custom Mode
Custom Mode Set-Up — 6.4L Example
292 UNDERSTANDING YOUR INSTRUMENT PANEL

While in the Custom Drive Mode screen, press the
“Custom Set-Up” button on the touchscreen to access the
selectable options. In the Custom Mode Set-Up screen the
individual current configuration will be displayed. Select
which mode suits your driving needs for a custom
driving experience.
Custom Mode Set-Up Info
Within the Custom Mode Set-Up screen, press the “info”
button on the touchscreen then use the left / right arrows
to scroll through all the available Drive Mode systems
giving you a description of their operation and current
configuration.Horsepower — If Equipped With 6.2L Supercharged
Engine
Horsepower — 6.2L Supercharged Engine Only
4
UNDERSTANDING YOUR INSTRUMENT PANEL 293

•700+
Press the “700+” button on the touchscreen to modify the
output power of the engine to 700+ horsepower.
NOTE: This selection is only available with the RED
RKE Key Fob.
• 500
Press the “500” button on the touchscreen to modify the
output power of the engine to 500 horsepower.
NOTE: This selection is available with the RED or
BLACK RKE Key Fob. Transmission — If Equipped With 8 Speed
Transmission
•
Track
Press the “Track” button on the touchscreen to provide
the fastest shift speeds and will have the highest comfort
trade-off.
Transmission
294 UNDERSTANDING YOUR INSTRUMENT PANEL

•Sport
Press the “Sport” button on the touchscreen to provide
faster shift speeds and will have a moderate comfort
trade-off.
• Street
Press the “Street” button on the touchscreen to provide a
balance of shift speed and comfort for typical daily
driving. Paddle Shifters
•
ON
Press the “ON” button on the touchscreen to enable
steering wheel paddle shifters.
Paddle Shifters
4
UNDERSTANDING YOUR INSTRUMENT PANEL 295

•OFF
Press the “OFF” button on the touchscreen to disable
steering wheel paddle shifters.
Traction •
Track
Press the “Track” button on the touchscreen to modify
traction control to optimize track performance with the
least stability control.
• Sport
Press the “Sport” button on the touchscreen to turn off
traction control and reduce stability control.
• Street
Press the “Street” button on the touchscreen to provide
full traction control and full stability control.
Traction
296 UNDERSTANDING YOUR INSTRUMENT PANEL

Suspension•Track
Press the “Track” button on the touchscreen to provide
the firmest possible suspension stiffness with the highest
amount of comfort trade-off.
• Sport
Press the “Sport” button on the touchscreen to provide a
firmer suspension stiffness with moderate comfort trade-off.
•Street
Press the “Street” button on the touchscreen to provide a
balance of suspension stiffness and ride comfort for
typical daily driving.
Suspension
4
UNDERSTANDING YOUR INSTRUMENT PANEL 297

Steering — If Equipped With 6.4L Engine
•Track
Press the “Track” button on the touchscreen to adjust the
steering effort to the highest level.
• Sport
Press the “Sport” button on the touchscreen to adjust the
steering effort to the higher level.
• Street
Press the “Street button on the touchscreen to adjust the
steering effort to the lowest level.Race Options
Press the “Race Options” button on the touchscreen
while in the Drive Modes screen, to display the vehicle’s
Race Options
298 UNDERSTANDING YOUR INSTRUMENT PANEL
