DODGE RAM 1500 1998 2.G Workshop Manual

C250 (HANDS FREE) - BLACK (HEADLINER
SIDE)
CAV CIRCUIT
1 X712 20DG/LB
2 X735 20BR
3 X792 20LB/DG
4 X835 20OR/GY
5 X730 20GY/YL
6 X793 20DG/YL
7 X722 20LB/DG
8-
C301 - (BODY SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 P195 18LG/YL (SLT)
3 P72 18TN/GY (SLT)
4 X154 18GY/YL
5 X156 18GY/LB
6 P74 18TN/OR (SLT)
7 Q15 12OR/LB (SLT)
8-
9-
10 Z74 20BK/WT
C301 - (BODY SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 P195 18LG/YL (SLT)
3 P72 18TN/GY (SLT)
4 X154 18GY/YL
5 X156 18GY/LB
6 P74 18TN/OR (SLT)
7 Q15 14OR/LB (SLT)
8-
9-
10 Z74 20BK/WT (BASE)
10 Z461 20BK/DG (SLT)
8W - 80 - 32 8W-80 CONNECTOR PIN-OUTSDR

C301 - (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 P195 18LG/YL (POWER WINDOWS/
LOCKS)
3 P72 18TN/GY (POWER WINDOWS/
LOCKS)
4 X154 18GY/YL
5 X156 18GY/LB
6 P74 18TN/OR (POWER WINDOWS/
LOCKS)
7 Q15 14OR/LB (POWER WINDOWS/
LOCKS)
8-
9-
10 Z74 20BK/WT (EXCEPT POWER WIN-
DOWS/LOCKS)
10 Z461 20BK/DG (POWER WINDOWS/
LOCKS)
C302 (SLT) - (BODY SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9 G162 20VT/LB
10 P392 18LG/DB
11 Z216 18BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 33

C302 - BLACK (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9-
10 P392 18LG/DB
11 Z216 20BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
C304 - (BODY SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (SLT)
3 P72 18TN/GY (SLT)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (SLT)
7 F30 12PK/YL (SLT)
8 Q15 12OR/LB (SLT)
9 A930 18RD (SLT)
10 Z75 20BK/VT
C304 - (DRIVER DOOR SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (POWER WINDOW/
LOCKS)
3 P72 20TN/GY (POWER WINDOW/
LOCKS EXCEPT SECURITY)
3 P72 18 TN/GY (SECURITY)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (POWER WINDOW/
LOCKS)
7 F30 14PK/YL (POWER WINDOW/
LOCKS)
8 Q15 14OR/LB (POWER WINDOW/
LOCKS)
9 A930 18RD (POWER WINDOW/LOCKS)
10 Z75 20BK/VT (EXCEPT SECURITY)
10 Z463 20BK/LB (SECURITY)
8W - 80 - 34 8W-80 CONNECTOR PIN-OUTSDR

C305 (SLT) - (BODY SIDE)
CAV CIRCUIT
1 C16 18DB/GY
2 Q16 14OR/TN
3 Q26 14OR/GY
4 P393 18LG
5-
6 P1 18TN/LG
7 Z461 14BK/DG
8 Q612 14OR/DB
9-
10 G161 20VT/DG
11 G163 20VT/LB
12 Q412 14OR/LB
13 Q611 14OR/GY
14 Q411 14OR/WT
15 -
16 -
C305 (SLT) - BLACK (DRIVER DOOR SIDE)
CAV CIRCUIT
1 C16 18DB/GY
2 Q16 14OR/TN
3 Q26 14OR/GY
4 P393 18LG
5-
6 P1 18TN/LG
7 Z461 14BK/DG
8 Q612 14OR/DB
9-
10 G161 20VT/DG
11 G163 20VT/LB
12 Q412 14OR/LB
13 Q611 14OR/GY
14 Q411 14OR/WT
15 -
16 -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 35

C306 - (REAR DOOR SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/GY
3 P393 18LG (POWER WINDOW/LOCKS)
4 P5 18TN/OR (POWER WINDOW/LOCKS)
5 Q15 14OR/LB (POWER WINDOW/
LOCKS)
6 Q411 14OR/WT (POWER WINDOW/
LOCKS)
7 Q611 14OR/GY (POWER WINDOW/
LOCKS)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C306 - NATURAL (BODY SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/OR
3 P393 18LG (SLT)
4 P5 18TN/OR (SLT)
5 Q15 14OR/LB (SLT)
6 Q411 14OR/WT (SLT)
7 Q611 14OR/GY (SLT)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C308 - (BODY SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 G162 20VT/LB (SLT)
3 D25 20WT/VT
4 X154 18GY/YL
5 G160 20VT/LG (SLT)
6 G76 20TN/YL
7 F201 18PK/OR
8 P392 18LG/DB (SLT)
9 G778 18VT/LB (SLT)
10 F21 20PK/DG (SLT)
11 -
12 -
13 -
14 X206 18DG/LG
15 X296 18DG/GY
16 -
17 -
18 Z105 18BK
19 X156 18GY/LB
8W - 80 - 36 8W-80 CONNECTOR PIN-OUTSDR

C308 - (I/P SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2-
3-
4 X154 18GY/YL
5 G160 20VT/LG (SLT)
6 G76 20VT/YL
7-
8 P392 18LG/DB (SLT)
9 G778 18VT/LB (SLT)
10 F21 20PK/DG
11 -
12 -
13 -
14 X206 18DG/LG
15 X296 18DG/GY
16 -
17 -
18 -
19 X156 18GY/LB
C309 - NATURAL (BODY SIDE)
CAV CIRCUIT
1-
2 P7 20LG/DG
3 P81 20TN/LB
4-
5 P84 20TN/VT
6 P8 20LG/WT
7 P82 20TN/DG
8 P83 20TN/WT
C309 - NATURAL (I/P SIDE)
CAV CIRCUIT
1-
2 P7 20LG/DG
3 P81 20TN/LB
4-
5 P84 20TN/VT
6 P8 20LG/WT
7 P82 20TN/DG
8 P83 20TN/WT
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 37

C311 - (BODY SIDE)
CAV CIRCUIT
1 Z918 14BK (BASE)
1 Z939 14BK (EXCEPT BASE)
2 A210 12OR/RD (EXCEPT BASE)
3 G10 20VT/LG
3 G10 20LG/RD
4 A405 18RD/DB
5 Z951 20BK
6
C311 - (DRIVER SEAT SIDE)
CAV CIRCUIT
1 Z939 14BK
2 A210 12OR/RD
3 G10 20VT/LG
4 A405 12RD/DB
5 Z951 20BK
6-
C313 - (DRIVER SEAT SIDE)
CAV CIRCUIT
1 P105 12LG
2 P13 12LG/OR
3 P21 12LG/TN
4 P15 12LG/BR
5 P107 12LG/WT
6 P11 12LG/YL
7 A210 12OR/RD
8 Z939 14BK
9 P17 12LG/DG
10 P19 12LG/LB
11 -
12 -
8W - 80 - 38 8W-80 CONNECTOR PIN-OUTSDR

C313 - (DRIVER SEAT SWITCH SIDE)
CAV CIRCUIT
1 P105 12LG
2 P13 12LG/OR
3 P21 12LG/TN
4 P15 12LG/BR
5 P107 12LG/WT
6 P11 12LG/YL
7 A210 12OR/RD
8 Z939 14BK
9 P17 12LG/DG
10 P19 12LG/LB
11 -
12 -
C315 - (DRIVER SEAT SIDE)
CAV CIRCUIT
1 A405 12RD/DB
2 P54 20OR/LG (HEATED SEATS)
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT (HEATED SEATS)
6 P89 20LG/OR (HEATED SEATS)
C315 - (JUMPER SIDE)
CAV CIRCUIT
1 A405 12RD/DB
2 P54 20OR/LG (HEATED SEATS)
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT (HEATED SEATS)
6 P89 18LG/OR (HEATED SEATS)
C316 (HEATED SEATS) - (JUMPER SIDE)
CAV CIRCUIT
1 P89 20LG/OR
2 P54 20OR/LG
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT
6-
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 39

C316 - (PASSENGER SEAT SIDE)
CAV CIRCUIT
1 P89 20LG/OR
2 P54 20OR/LG
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT
6-
C319 - (CENTER CONSOLE SIDE)
CAV CIRCUIT
1 Z939 18BK
2 A405 18RD/DB
C319 - (SEAT JUMPER SIDE)
CAV CIRCUIT
1 A405 12RD/DB (EXCEPT HEATED SEAT)
1 Z939 14BK (HEATED SEAT)
2 Z939 14BK (EXCEPT HEATED SEAT)
2 A405 12RD/DB (HEATED SEAT)
C320 - (RIGHT REAR DOOR SIDE)
CAV CIRCUIT
1 Z72 20LG/BK
2 G76 20VT/GY
3 P392 18LG (POWER WINDOW/LOCKS)
4 G778 18TN/OR (POWER WINDOW/
LOCKS)
5 Q15 14TN/LG (POWER WINDOW/
LOCKS)
6 Q412 14OR/WT (POWER WINDOW/
LOCKS)
7 Q612 14OR/GY (POWER WINDOW/
LOCKS)
8 X296 18GY/DG
9 X206 18GY/LG
10 -
8W - 80 - 40 8W-80 CONNECTOR PIN-OUTSDR

C320 - NATURAL (BODY SIDE)
CAV CIRCUIT
1 Z72 20LG/BK
2 G76 20TN/YL
3 P392 18LG/DB (EXCEPT BASE)
4 G778 18VT/LB (EXCEPT BASE)
5 Q15 14OR/LB (EXCEPT BASE)
6 Q412 14OR/LB (EXCEPT BASE)
7 Q612 14OR/DB (EXCEPT BASE)
8 X296 18DG/GY
9 X206 18DG/LG
10 -
C322 (EXCEPT HEATED SEATS) - (DRIVER SEAT
SIDE)
CAV CIRCUIT
1 A930 18RD
2 P81 20TN/LB
3 P7 20LG/DG
4 G10 20VT/LG
5 P83 20TN/WT
6 P82 20TN/DG
7 Z939 14BK
8 A210 12OR/RD
9 P8 20LG/WT
10 P84 20TN/VT
11 -
12 Z951 20BK
13 -
14 A405 12RD/DB
C322 - (BODY SIDE)
CAV CIRCUIT
1 A930 18RD
2 P81 20TN/LB
3 P7 20LG/DG
4 G10 20VT/LG
5 P83 20TN/WT
6 P82 20TN/DG
7 Z939 14BK
8 A210 12OR/RD
9 P8 20LG/WT
10 P84 20TN/VT
11 -
12 Z951 18BK
13 -
14 A405 12RD/DB
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 41
