DODGE RAM 1500 1998 2.G Workshop Manual

C131 (5.7L/DIESEL) - GRAY (HEADLAMP AND
DASH SIDE)
CAV CIRCUIT
A1 T316 16YL/GY (ELECTRONIC TRANS-
FER CASE)
A2 D200 20WT/LG (ELECTRONIC TRANS-
FER CASE)
A3 T313 20YL/LG (ELECTRONIC TRANS-
FER CASE)
A4 D202 20WT (ELECTRONIC TRANSFER
CASE)
A5 T885 20YL/GY (ELECTRONIC TRANS-
FER CASE)
A6 D201 20WT/DG (ELECTRONIC TRANS-
FER CASE)
A7 D203 20WT/BR (ELECTRONIC TRANS-
FER CASE)
A8 T315 16YL/BR (ELECTRONIC TRANS-
FER CASE)
B1 -
B2 D20 20WT/LG
B3 D21 20WT/BR
B4 V32 20VT/YL (DIESEL)
B5 T117 20DG/YL (DIESEL A/T)
B6 V36 20VT/YL (DIESEL A/T)
B7 T917 20YL/TN (DIESEL A/T)
B8 -
C1 A961 14RD (DIESEL)
C2 B22 20DG/WT (5.7L)
C2 V35 20VT/OR (DIESEL A/T)
C3 F855 20PK/YL (5.7L)
C3 B29 20DG/WT (DIESEL)
C4 F856 20YL/PK (5.7L)
C4 F856 18YL/PK (DIESEL)
C5 K160 18BR/OR (DIESEL)
C6 K161 18BR/LB (DIESEL)
C7 V37 20VT (DIESEL)
C8 K25 18DB/VT (DIESEL)
C200 - (HVAC SIDE)
CAV CIRCUIT
1 C70 10DB/YL
2 C34 20DB/LB
3 C71 16DB/BR
4 C32 20DB/TN
5 C73 14DB/VT
6 C72 16DB/OR
7 C7 10DB
8 C29 20DB
9 C21 20DB/LG (EXCEPT BASE A/C)
10 C121 20DB/DG
11 C33 20LB/BR
12 C61 20DB/LG
12 C33 20LB/BR (DUAL ZONE)
13 C801 20DB/OR
8W - 80 - 22 8W-80 CONNECTOR PIN-OUTSDR

C200 - (I/P SIDE)
CAV CIRCUIT
1 C70 10DB/YL
2 C34 20DB/LB
3 C71 16DB/BR
4 C32 20DB/TN
5 C73 14DB/VT
6 C72 16DB/OR
7 C7 10DB
8 C29 20DB
9 C21 20DB/LG
10 C121 20DB/DG
11 C61 20DB/LG
12 C33 20LB/BR (SLT)
13 C801 20DB/OR
C201 - WHITE (HEADLINER SIDE)
CAV CIRCUIT
1 D25 20WT/VT (PREMIUM)
2 Z13 20BK/WT (PREMIUM)
3 L50 20WT/TN
4 Z350 20BK/TN
5 A919 20RD (PREMIUM)
6 F21 20PK/DG (PREMIUM)
7 L14 20WT/TN
8 Z964 20BK
9 M20 20YL/LB
10 M22 20YL/OR (PREMIUM)
11 L1 20WT/LG (PREMIUM)
12 M288 20YL/GY (PREMIUM)
C201 - WHITE (I/P SIDE)
CAV CIRCUIT
1 D25 20WT/VT (PREMIUM)
2 Z13 18BK/WT
3 L50 18WT/TN
4 Z350 18BK/TN
5 A919 20RD (PREMIUM)
6 F21 20PK/DG
7 L14 20WT/TN
8 Z964 18BK
9 M20 20YL/LB
10 M22 20YL/OR
11 L1 20WT/LG
12 M288 18YL/GY
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 23

C202 - BLACK (FRONT FASCIA SIDE)
CAV CIRCUIT
1 L89 18WT/YL
2 Z926 18BK
C202 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 L89 18WT/YL
2 Z926 18BK
C206 - (CLEARANCE LAMPS SIDE)
CAV CIRCUIT
1 L70 20WT/GY
2 Z946 20BK
C206 - (I/P SIDE)
CAV CIRCUIT
1 L70 18WT/GY
2 Z946 18BK
C207 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 A34 16RD/WT
2 E11 20OR/DB
3 F21 20PK/DG
4 T315 16YL/BR
5 D25 20VT/DB
6 T885 20YL/GY
7 D200 20WT/LG
8 T316 16YL/GY
9 D202 20WT/VT
10 D201 20WT/DG
11 T41 20YL/DB
12 T313 20YL/LG
13 D203 20WT/BR
14 Z905 16BK
8W - 80 - 24 8W-80 CONNECTOR PIN-OUTSDR

C207 - (TRANSFER CASE CONTROL MODULE
SIDE)
CAV CIRCUIT
1 A34 16RD/WT
2 E11 20OR/DB
3 F21 20PK/DG
4 T315 16YL/BR
5 D25 20VT/DB
6 T885 20YL/GY
7 D200 20WT/LG
8 T316 16YL/GY
9 D202 20WT/VT
10 D201 20WT/DG
11 T41 20YL/DB
12 T313 20YL/LG
13 D203 20WT/BR
14 Z905 16BK
C216 - (CHASSIS SIDE)
CAV CIRCUIT
1 B4 18DG/GY
2 B3 18DG/YL
3 L678 18BR
4 L53 18DG/WT
5 L62 18WT/YL
6 K900 18DB/DG
8 L70 18WT/GY
C216 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 B4 20DG/GY
2 B3 20DG/YL
3 L678 18BR
4 L53 18DG/WT
5 L62 18WT/YL
6 K900 20DB/DG
7 N4 18DB/WT
8 L70 18WT/GY
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 25

C217 - BLACK (CHASSIS SIDE)
CAV CIRCUIT
1 L673 18YL
2 B40 14DG (TRAILER TOW)
3 A100 14RD/VT (TRAILER TOW)
4 L7 18WT/YL
5 A109 14OR/RD
6 L50 18WT/TN
7 Z927 12BK/OR
8-
9-
10 L54 18WT/LG
11 L63 18WT/DG
12 L1 18WT/LG
13 L674 18LG
14 Z928 16BK
C217 - BLACK (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 L673 18YL
2 B40 14DG (TRAILER TOW)
3 A100 14RD/VT (TRAILER TOW)
4 L7 18WT/YL
5 A109 16OR/RD (GAS)
6 L50 18WT/TN
7 Z927 14BK/OR
8-
9-
10 L54 18WT/LG
11 L63 18WT/DG
12 L1 18WT/LG
13 L674 18LG
14 Z928 16BK
C218 - (BODY SIDE)
CAV CIRCUIT
1-
2 A405 18RD/DB
3 C16 16DB/GY (SLT)
4 A930 18RD (SLT)
5-
6-
7-
8-
9 A210 12OR/RD (SLT)
10 -
11 -
12 C15 16DB/WT (SLT)
8W - 80 - 26 8W-80 CONNECTOR PIN-OUTSDR

C218 - NATURAL (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1-
2 A405 18RD/DB
3 C16 16DB/GY (EXCEPT 3.7L BASE)
4 A930 18RD (EXCEPT 3.7L BASE)
5-
6-
7-
8-
9 A210 12OR/RD (EXCEPT 3.7L BASE)
10 -
11 -
12 C15 16DB/WT (EXCEPT 3.7L BASE)
C219 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 C110 20DB/LB (TRAILER TOW)
2 D15 18WT/DG (NGC)
3 L50 18WT/TN
4 F1 16PK/WT (NGC)
5 D21 20WT/BR
6 A103 18GY/RD
7 T751 16YL
8 D20 20WT/LG
9 E11 20OR/DB (ELECTRONIC TRANSFER
CASE)
10 A970 10RD
11 A991 10RD (TRAILER TOW)
12 -
13 -
14 -
15 -
16 V38 20VT/OR (5.7L)
17 V37 20VT
18 T6 20DG (GAS/DIESEL A/T)
19 L70 18WT/GY
20 F21 20PK/DG
21 V32 20VT/YL
22 -
23 A921 16RD
24 B25 20DG/WT
25 F202 20PK/GY (5.7L)
25 V30 20VT/WT (GAS EXCEPT 5.7L/DIE-
SEL A/T)
26 A114 18GY/RD
27 L1 18WT/LG
28 -
29 -
30 V937 20VT/BR (5.7L)
30 K900 20DB/DG (EXCEPT 5.7L)
31 A944 20RD
32 F504 20GY/PK
33 A941 18RD
34 -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 27

C219 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
35 -
36 F984 18PK/YL
37 -
38 F951 16PK/LG
39 T917 20YL/TN (DIESEL A/T)
40 -
41 A951 16RD
42 F202 20PK/GY
43 A72 18RD/OR (TRAILER TOW)
44 D16 18WT/OR (GAS)
45 -
46 K77 18BR/WT (MAUAL TRANSFER
CASE)
47 T117 20DG/YL (MANUAL TRANSFER
CASE EXCEPT NGC)
48 A205 18RD/OR
49 A116 18YL/RD
50 -
51 -
52 -
53 R79 20LB/VT (NGC EXCEPT 5.7L ABS)
54 R81 20LB/WT (NGC EXCEPT 5.7L ABS)
55 -
56 F100 18PK/VT
57 R80 20VT/LB (NGC EXCEPT 5.7L ABS)
58 R82 20WT/LB (NGC EXCEPT 5.7L ABS)
59 -
60 A981 14RD
61 F982 14PK/YL
62 -
63 -
64 -
65 -
66 F922 16PK/YL
67 F201 18PK/OR
68 L89 18WT/YL (TRAILER TOW)
69 B29 20DG/WT
70 A919 20RD
71 -
72 D25 20VT/PK
73 F983 20PK/YL
74 -
8W - 80 - 28 8W-80 CONNECTOR PIN-OUTSDR

C219 - (I/P SIDE)
CAV CIRCUIT
1 C110 20DB/LB (EXCEPT BASE)
2 D15 18WT/DG
3 L50 18WT/TN
4 F1 16PK/WT
5 D21 18WT/BR
6 A103 18GY/RD
7 T751 16YL
8 D20 20WT/LG
9 E11 20OR/DB (EXCEPT BASE)
10 A970 10RD
11 A991 10RD
12 -
13 -
14 -
15 -
16 -
16 V38 20VT/OR
17 V37 20VT
18 T6 20DG
19 L70 18WT/GY
20 F21 20PK/DG
21 V32 20VT/YL
22 -
23 A921 16RD
24 B25 20DG/WT
25 V30 20VT/WT
26 A114 18GY/RD
27 L1 20WT/LG
28 -
29 -
30 V937 20VT/BR
31 A944 20RD
32 F504 20GY/PK
33 A941 18RD
34 -
35 -
36 F984 18PK/YL
37 -
38 F951 16PK/LG
39 T917 20YL/TN
40 -
41 A951 16RD
42 F202 20PK/GY (EXCEPT BASE)
43 A72 18RD/OR (EXCEPT BASE)
44 D16 18WT/OR
45 -
46 K77 18BR/WT
47 T117 20DG/YL
48 A205 18RD/OR
49 A116 18YL/RD
50 -
51 -
52 -
53
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 29

C219 - (I/P SIDE)
CAV CIRCUIT
54
55 -
56 F100 18PK/VT
57
58
59 -
60 A981 14RD
61 F982 14PK/YL
62 -
63 -
64 -
65 -
66 F922 16PK/YL
67 F201 18PK/OR
68 L89 20WT/YL (EXCEPT BASE)
69 B29 20DG/WT
70 A919 20RD
71 -
72 D25 20WT/VT
73 F983 20PK/YL
74 -
C220 - (I/P SIDE)
CAV CIRCUIT
1 F983 20PK/YL
2 X295 18GY/DG
3-
4 X153 18DG/YL
5 G75 20VT
6 G77 20VT/GY
7 X155 18DG/LB
8 G10 20VT/LG
9 G163 20VT/LB (SLT)
10 X205 18GY/LG
11 P5 18TN/OR (SLT)
12 F100 18PK/VT
13 F201 18PK/OR
14 -
15 -
16 -
17 P393 18LG (SLT)
18 G161 20VT/DG (SLT)
19 -
20 P1 18TN/LG (SLT)
21 -
22 F30 12PK/YL (SLT)
23 -
24 -
8W - 80 - 30 8W-80 CONNECTOR PIN-OUTSDR

C220 - NATURAL (BODY SIDE)
CAV CIRCUIT
1 F983 20PK/YL
2 X295 18GY/DG
3-
4 X153 18DG/YL
5 G75 20VT
6 G77 20VT/OR
7 X155 18DG/LB
8 G10 20VT/LG
9 G163 20VT/LB (SLT)
10 X205 18GY/LG
11 P5 18TN/OR (SLT)
12 F100 18PK/VT
13 F201 18PK/OR
14 -
15 -
16 -
17 P393 18LG (SLT)
18 G161 20VT/DG (SLT)
19 -
20 P1 18TN/LG (SLT)
21 -
22 F30 12PK/YL (SLT)
23 -
24 -
C250 (HANDS FREE) - (I/P SIDE)
CAV CIRCUIT
1 X712 18DG/LB
2 X735 22NA
3 X792 18LB/DG
4 X835 18OR/GY
5 X730 18GY/YL
6 X793 18DG/YL
7 X722 18LB/DG
8-
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 31
