CONDENSER FAN (NGC) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z823 16BK/DG GROUND
2 C123 16LB/WT CONDENSER FAN RELAY OUTPUT
CONTROLLER ANITLOCK BRAKE C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 B4 20DG/GY REAR WHEEL SPEED SENSOR (+)
2 B222 20DG/WT (ETC) VEHICLE SPEED SIGNAL NO. 2
3 D25 20WT/VT PCI BUS
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 B9 20DG/LG (ETC) LEFT FRONT WHEEL SPEED SENSOR (+)
6 Z107 12BK/DG GROUND
7 A111 14DG/RD FUSED B(+)
8 B3 20DG/YL REAR WHEEL SPEED SENSOR (-)
9 B29 20DG/WT BRAKE SWITCH SIGNAL
10 B8 20DG/TN (ETC) LEFT FRONT WHEEL SPEED SENSOR (-)
11 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
12 B22 20DG/YL VEHICLE SPEED SIGNAL NO. 1
13 Z127 12BK/DG (ABS) GROUND
14 A111 14DG/RD (ABS) FUSED B(+)
CONTROLLER ANTILOCK BRAKE C2 (ABS) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 B9 20DG/LG LEFT FRONT WHEEL SPEED SENSOR (+)
2 B8 20DG/TN LEFT FRONT WHEEL SPEED SENSOR (-)
3 B6 20DG/WT RIGHT FRONT WHEEL SPEED SENSOR (-)
4 B7 20DG/VT RIGHT FRONT WHEEL SPEED SENSOR (+)
CRANKSHAFT POSITION SENSOR (3.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTSDR

CRANKSHAFT POSITION SENSOR (4.7L)-3WAY
CAV CIRCUIT FUNCTION
1 K24 20BR/LB CKP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F855 20PK/YL 5 VOLT SUPPLY
CRANKSHAFT POSITION SENSOR (5.7L)-3WAY
CAV CIRCUIT FUNCTION
1 F855 20PK/YL 5 VOLT SUPPLY
2 K900 20DB/DG SENSOR GROUND
3 K24 20BR/LB CKP SIGNAL
CRANKSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 K853 18DB/BR 5 VOLT SUPPLY
2 K975 18BR/BK SENSOR GROUND
2 K975 18BR/OR SENSOR GROUND
3 K24 18BR/LB CKP SIGNAL
3 K24 18LB/BR CKP SIGNAL
CYLINDER LOCK SWITCH-DRIVER (PREMIUM)-2WAY
CAV CIRCUIT FUNCTION
1 G163 20VT/LB DRIVER CYLINDER LOCK SWITCH MUX
2 Z463 20BK/LB GROUND
DATA LINK CONNECTOR - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1- -
2 D25 20WT/VT PCI BUS
3- -
4 Z11 18BK/LG GROUND
5 Z111 18BK/WT GROUND
6- -
7 D21 18WT/BR SCI TRANSMIT (PCM)
8- -
9 D16 18WT/OR SCI RECEIVE (TCM)
10 - -
11 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 53

DATA LINK CONNECTOR - BLACK 16 WAY
CAV CIRCUIT FUNCTION
12 D20 20WT/LG SCI RECEIVE (PCM)
13 - -
14 - -
15 D15 18WT/DG SCI TRANSMIT (TCM)
16 A114 18GY/RD FUSED B(+)
DATA LINK CONNECTOR-ENGINE (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 D72 18WT/LB CCD BUS (+)
2 D71 18WT/DB CCD BUS (-)
3 Z816 14BK (A/T) GROUND
3 Z11 14BK/LG (M/T) GROUND
DOME LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1- -
2 M20 20YL/LB COURTESY LAMPS DRIVER
3 Z964 20BK GROUND
DOOR AJAR SWITCH-DRIVER - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G75 20VT DRIVER DOOR AJAR SWITCH SENSE
2 Z75 20BK/VT GROUND
DOOR AJAR SWITCH-LEFT REAR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE
2 Z79 20LG/BK GROUND
8W - 80 - 54 8W-80 CONNECTOR PIN-OUTSDR

DOOR AJAR SWITCH-PASSENGER - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z74 20BK/WT GROUND
DOOR AJAR SWITCH-RIGHT REAR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G76 20VT/GY RIGHT REAR DOOR AJAR SWITCH SENSE
2 Z72 20LG/BK GROUND
DOOR LOCK MOTOR/AJAR SWITCH-DRIVER - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G75 20VT DRIVER DOOR AJAR SWITCH SENSE
2 Z75 20BK/VT GROUND
3 P1 18TN/LG DOOR UNLOCK DRIVER LEFT FRONT
4 P393 18LG DOOR LOCK DRIVER LEFT DOORS
DOOR LOCK MOTOR/AJAR SWITCH-LEFT REAR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G77 20VT/GY LEFT REAR DOOR AJAR SWITCH SENSE
2 Z79 20LG/BK GROUND
3 P5 18TN/OR DOOR UNLOCK DRIVER LEFT REAR
4 P393 18LG DOOR LOCK DRIVER LEFT DOORS
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 55

DOOR LOCK MOTOR/AJAR SWITCH-PASSENGER - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G74 20VT/WT PASSENGER DOOR AJAR SWITCH SENSE
2 Z74 20BK/WT GROUND
3 G778 18VT/LB DOOR UNLOCK DRIVER RIGHT DOORS
4 P392 18LG/DB DOOR LOCK DRIVER RIGHT DOORS
DOOR LOCK MOTOR/AJAR SWITCH-RIGHT REAR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G76 20VT/GY (VIRTUAL) RIGHT REAR DOOR AJAR SWITCH SENSE
2 Z72 20LG/BK (VIRTUAL) GROUND
3 G778 18TN/OR (VIRTUAL) DOOR UNLOCK DRIVER RIGHT DOORS
4 P392 18LG (VIRTUAL) DOOR LOCK DRIVER RIGHT DOORS
DOOR LOCK SWITCH-PASSENGER-6WAY
CAV CIRCUIT FUNCTION
1 G160 20VT/LG PASSENGER DOOR LOCK SWITCH MUX
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4- -
5 Z461 20BK/DG GROUND
6- -
DRIVER BLEND DOOR ACTUATOR (DUAL ZONE)-2WAY
CAV CIRCUIT FUNCTION
1 C61 20DB/LG BLEND DOOR DRIVER
2 C34 20DB/LB COMMON DOOR DRIVER
8W - 80 - 56 8W-80 CONNECTOR PIN-OUTSDR

DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57

ELECTRIC BRAKE PROVISION-4WAY
CAV CIRCUIT FUNCTION
A A400 14TN/RD FUSED B(+)
B B40 14DG TRAILER TOW BRAKE B(+)
C L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
D Z998 18BK GROUND
ELECTRIC THROTTLE CONTROL MODULE - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 K22 18BR/OR TP NO. 1 SIGNAL
2 F855 18PK/YL 5 VOLT SUPPLY
3 K447 18TN/YL ETC MOTOR (+)
4 K122 18BR/DG TP NO. 2 SIGNAL
5 K448 18TN/OR ETC MOTOR (-)
6 K922 18BR/DB TP SENSOR RETURN
ENGINE CONTROL MODULE C1 (DIESEL) - 60 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 D72 18WT/LB CCD BUS (+)
5 D71 18WT/DB CCD BUS (-)
6 K65 18BR/LB FUEL PUMP RELAY RETURN
7 K20 18BR/GY GEN FIELD CONTROL
8- -
9- -
10 - -
11 K2 18TN/BK (A/T) ECT SIGNAL
11 K2 18VT/OR (M/T) ECT SIGNAL
12 K181 18BR/YL FUEL PUMP DRIVER
13 - -
14 K22 18BR/WT (A/T) TP SIGNAL
14 K23 18DB/WT (M/T) APPS NO. 1 SIGNAL
15 K21 18DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
16 - -
16 K29 18WT/BR (M/T) APPS NO. 2 SIGNAL
17 - -
18 - -
19 K31 18BR FUEL PUMP RELAY CONTROL
20 - -
21 - -
22 K24 18LB/BR (A/T) CKP SIGNAL
22 K24 18BR/LB (M/T) CKP SIGNAL
23 K914 18RD/WT (A/T) SENSOR GROUND
23 K914 18BR/WT (M/T) SENSOR GROUND
24 K44 18DB/GY CMP SIGNAL
25 K668 18LG (A/T) SUPPLY VOLTAGE
25 K688 18BR (M/T) SUPPLY VOLTAGE
8W - 80 - 58 8W-80 CONNECTOR PIN-OUTSDR

ENGINE CONTROL MODULE C1 (DIESEL) - 60 WAY
CAV CIRCUIT FUNCTION
26 C918 18BK/LB A/C PRESSURE SENSOR GROUND
27 K853 18DB/BR 5 VOLT SUPPLY
28 - -
29 K690 18DG/YL (A/T) INLET AIR TEMPERATURE/PRESSURE RETURN
29 K690 18BR/YL (M/T) INLET AIR TEMPERATURE/PRESSURE RETURN
30 K11 16WT/DB (A/T) INJECTOR CONTROL NO. 1
30 K11 16BR/YL (M/T) INJECTOR CONTROL NO.1
31 G123 18VT/LG WATER IN FUEL SENSOR SIGNAL
32 K916 18BR/OR SENSOR GROUND
33 K922 18LG/OR (A/T) THROTTLE POSITION SENSOR RETURN
33 K167 18BR/YL (M/T) APPS NO. 1 RETURN
34 K565 18OR IDLE SWITCH
35 - -
36 K14 16BR/TN INJECTOR CONTROL NO. 4
37 - -
38 - -
39 - -
40 K13 16TN (A/T) INJECTOR CONTROL NO. 3
40 K13 16BR/LB (M/T) INJECTOR CONTROL NO.3
41 - -
42 K851 18VT/PK (A/T) 5-VOLT SUPPLY
42 K852 18BR/VT (M/T) APPS 1 5-VOLT SUPPLY
43 K37 18LB (A/T) BOOST PRESSURE SENSOR SIGNAL
43 K37 18BR/OR (M/T) BOOST PRESSURE SENSOR SIGNAL
44 K556 18OR/BR NOT IDLE SWITCH
45 N2 18DB/YL LIFT PUMP FEED
46 K58 16BR/VT INJECTOR CONTROL NO. 6
47 - -
48 - -
49 - -
50 K12 16BR/DB INJECTOR CONTROL NO. 2
51 - -
52 K975 18BR/BK (A/T) SENSOR GROUND
52 K975 18BR/OR (M/T) SENSOR GROUND
53 K915 18VT/RD FUEL RAIL SENSOR RETURN
54 F855 18PK/YL 5 VOLT SUPPLY
55 - -
56 K38 16GY (A/T) INJECTOR CONTROL NO. 5
56 K38 16BR/OR (M/T) INJECTOR CONTROL NO. 5
57 K229 16TN/PK (A/T) ENG-INJECTOR HIGH SIDE DRIVER-BANK 2
57 K229 16BR/LB (M/T) ENG-INJECTOR HIGH SIDE DRIVER-BANK 2
58 - -
59 K227 16BR/LG ENG-INJECTOR HIGH SIDE DRIVER-BANK 1
60 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 59

ENGINE CONTROL MODULE C2 (DIESEL) - 50 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 K615 18VT/WT INLET AIR TEMPERATURE SENSE
3 K615 18BR/WT (M/T) INLET AIR TEMPERATURE SENSE
4 V35 18VT/OR (A/T) S/C VENT CONTROL
5 K176 18BR/OR INTAKE AIR HEATER RELAY NO 2 CONTROL
6 K174 18BR/YL INTAKE AIR HEATER RELAY NO 1 CONTROL
7 V32 18VT/YL (A/T) SPEED CONTROL SUPPLY
8- -
9 T41 18YL/DB (A/T) PARK/NEUTRAL POSITION SWITCH SENSE (T41)
10 K161 18BR/LB FAN SPEED SENSOR
11 B22 18DG/YL VEHICLE SPEED SENSOR SIGNAL NO. 1
12 G6 18VT/GY OIL PRESSURE SIGNAL
13 T6 18DG (A/T) TOW/HAUL OVERDRIVE OFF SWITCH SENSE
14 T118 18DG (A/T) GOVERNOR PRESSURE SOLENOID CONTROL
15 T9 18DG/TN (A/T) 3-4 SOLENIOD CONTROL
16 D21 18WT/BR SCI TRANSMIT (PCM)
16 D21 18PK (M/T) SCI TRANSMIT
17 - -
18 T38 18YL/BR (A/T) GOVERNOR PRESSURE SENSOR SIGNAL
19 D20 18WT/LG SCI RECEIVE (PCM)
20 A209 16RD FUSED B(+)
21 Z902 16BK GROUND
22 - -
23 F856 18YL/PK 5 VOLT SUPPLY
24 K900 18DB/DG SENSOR GROUND
25 T75 18YL/LB (A/T) TORQUE CONVERTER CLUTCH SOLENOID CONTROL
26 N4 18DB/WT FUEL LEVEL SENSOR SIGNAL
27 - -
28 D25 18WT/VT PCI BUS
29 T54 18DG/OR (A/T) TRANSMISSION TEMPERATURE SENSOR SIGNAL
30 A209 16RD FUSED B(+)
31 T515 18YL/DB (A/T) TRANSMISSION CONTROL RELAY CONTROL
32 F202 18PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
33 K854 18VT/BR (M/T) 5 VOLT SUPPLY
34 V36 18VT/YL (A/T) S/C VACUUM CONTROL
35 K616 18BR/YL INLET AIR PRESSURE SENSE
36 V32 18VT/YL (M/T) SPEED CONTROL SUPPLY
37 B29 18DG/WT BRAKE SWITCH SIGNAL
38 - -
39 - -
40 A209 16RD FUSED B(+)
41 C13 18LB/OR A/C CLUTCH RELAY CONTROL
42 - -
43 K160 18BR/OR PARK LOCKOUT SOLENOID CONTROL
44 T14 18DG/BR (A/T) OUTPUT SPEED SENSOR SIGNAL
45 T13 18DG/VT (A/T) SENSOR GROUND
46 V37 18VT S/C SWITCH NO. 1 SIGNAL
47 K25 18DB/VT BATT TEMP SIGNAL
48 K400 18BR/VT (M/T) APPS NO.2 RETURN
49 Z902 16BK GROUND
50 Z902 16BK GROUND
8W - 80 - 60 8W-80 CONNECTOR PIN-OUTSDR

ENGINE COOLANT TEMPERATURE SENSOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
A K914 18RD/WT SENSOR GROUND
A K914 18BR/WT SENSOR GROUND
B K2 18TN/BK ECT SIGNAL
B K2 18VT/OR ECT SIGNAL
ENGINE COOLANT TEMPERATURE SENSOR (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG SENSOR GROUND
2 K2 18VT/OR ECT SIGNAL
ENGINE OIL PRESSURE SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 G6 18VT/GY OIL PRESSURE SIGNAL
2- -
EVAP/PURGE SOLENOID (NGC)-2WAY
CAV CIRCUIT FUNCTION
1 K52 18DB/WT EVAP PURGE CONTROL
2 K70 18DB/BR EVAP PURGE RETURN
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 61
