DODGE RAM 1500 1998 2.G Workshop Manual

AUTOMATIC DAY/NIGHT MIRROR C1 (EXCEPT BASE)-7WAY
CAV CIRCUIT FUNCTION
1 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z13 20BK/WT GROUND
3 L1 20WT/LG BACKUP LAMP FEED
4- -
5- -
6- -
7- -
AUTOMATIC DAY/NIGHT MIRROR C2 (TELEMATICS) - 12 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 X722 20LB/DG MICROPHONE 2 IN (+)
5 X735 20BR HANDSFREE MICROPHONE SHIELD
6 X712 20DG/LB MICROPHONE 1 IN (+)
7 X793 20DG/YL HANDSFREE MICROPHONE HSD FEED
8- -
9 X730 20GY/YL VOICE RECOGNITION/PHONE SWITCH SIGNAL
10 - -
11 X835 20OR/GY SENSOR GROUND
12 X792 20LB/DG MICROPHONE IN (-)
BACKUP LAMP SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
A L1 18WT/LG BACKUP LAMP FEED
B L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
BATTERY TEMPERATURE SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K25 18DB/VT BATT TEMP SIGNAL
2 K900 20DB/DG SENSOR GROUND
8W - 80 - 12 8W-80 CONNECTOR PIN-OUTSDR

BLEND DOOR ACTUATOR (SINGLE ZONE)-2WAY
CAV CIRCUIT FUNCTION
1 C34 20DB/LB COMMON DOOR DRIVER
2 C61 20DB/LG BLEND DOOR DRIVER
BLOWER MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C70 10DB/YL BLOWER MOTOR HIGH DRIVER
2 C7 10DB BLOWER MOTOR FEED
BLOWER MOTOR RESISTOR BLOCK - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 C72 16DB/OR BLOWER MOTOR M1 DRIVER
2 C70 12DB/YL BLOWER MOTOR HIGH DRIVER
3 C71 16DB/BR BLOWER MOTOR LOW DRIVER
4 C73 14DB/VT BLOWER MOTOR M2 DRIVER
BRAKE FLUID LEVEL SWITCH - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B20 20DG/OR BRAKE FLUID LEVEL SWITCH SENSE
2 Z420 20BK/OR GROUND
BRAKE LAMP SWITCH-6WAY
CAV CIRCUIT FUNCTION
1 A103 18GY/RD FUSED B(+)
2 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
3 V30 20VT/WT S/C BRAKE SWITCH OUTPUT
3 V30 20VT/WT (5.7L) FUSED IGNITION SWITCH (RUN-START)
4 V32 20VT/YL SPEED CONTROL SUPPLY
4 V32 20VT/YL (5.7L) BRAKE SWITCH NO. 2 SIGNAL
5 Z429 20BK/OR GROUND
6 B29 20DG/WT BRAKE SWITCH SIGNAL
6 B29 20DG/WT (5.7L) BRAKE SWITCH NO. 1 SIGNAL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 13

BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K32 18DB/YL BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
CONTROL
2 Z101 18BK/VT GROUND
C102 (NGC) - (AMBIENT TEMPERATURE SEN-
SOR SIDE)
CAV CIRCUIT
1 G31 20VT/LG
2 K900 20DB/DG
C103 - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 Z470 20BK/LB
2 A114 18GY/RD
C106 (5.7L A/T) - (ENGINE SIDE)
CAV CIRCUIT
1 K11 18BR/YL
2 K12 18BR/DB
3 K13 18BR/LB
4 K14 18BR/TN
5 K38 18BR/OR
6 K58 18BR/VT
7 K26 18BR/YL
8 K28 18BR/LB
9 K19 18DB/DG
10 K17 18DB/TN
11 K18 18DB/OR
12 K15 18DB/GY
13 K16 18DB/YL
14 K10 18DB/OR
15 K97 18BR
16 K98 18DB/YL
8W - 80 - 14 8W-80 CONNECTOR PIN-OUTSDR

C106 (5.7L A/T) - (INTAKE AIR FUEL MODULE
SIDE)
CAV CIRCUIT
1 K11 18BR/YL
2 K12 18BR/DB
3 K13 18BR/LB
4 K14 18BR/TN
5 K38 18BR/OR
6 K58 18BR/VT
7 K26 18BR/YL
8 K28 18BR/LB
9 K19 18DB/DG
10 K17 18DB/TN
11 K18 18DB/OR
12 K15 18DB/GY
13 K16 18DB/YL
14 K10 18DB/OR
15 K97 18BR
16 K98 18DB/YL
C107 (5.7L) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 K900 18DB/DG
2 K1 18VT/BR
3 K21 18DB/LG
4 K922 18BR/DB
5 F856 18YL/PK
6 K447 18TN/YL
7 K342 16BR/WT
8 F855 18PK/YL
9 K2 18VT/OR
10 K122 18BR/DG
11 K22 18BR/OR
12 -
13 K448 18TN/OR
14 K342 16BR/WT
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 15

C107 (5.7L) - BLACK (INTAKE AIR FUEL MOD-
ULE SIDE)
CAV CIRCUIT
1 K900 18DB/DG
2 K1 18VT/BR
3 K21 18DB/LG
4 K922 18BR/DB
5 F856 18YL/PK
6 K447 18TN/YL
7 K342 16BR/WT
8 F855 18PK/YL
9 K2 18VT/OR
10 K122 18BR/DG
11 K22 18BR/OR
12 -
13 K448 18TN/OR
14 K342 16BR/WT
C108 (DIESEL) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 B22 18DG/YL
2 C13 18LB/OR
3 A961 14RD
4 K25 18DB/VT
5 N4 18DB/WT
6 D25 18WT/VT
7-
8 V32 18VT/YL (M/T)
9 K174 18BR/YL
10 -
11 K176 18BR/OR
12 K23 18BR/WT (M/T)
13 K852 18BR/VT (M/T)
14 K167 18BR/YL (M/T)
C108 (DIESEL) - BLACK (TRANSMISSION SIDE)
CAV CIRCUIT
1 B22 20DG/YL
2 C13 20LB/OR
3 A961 14RD
4 K25 18DB/VT
5 N4 18DB/WT
6 D25 20WT/VT
7-
8 V32 20VT/YL (M/T)
9 K174 18BR/YL
10 -
11 K176 18BR/OR
12 K23 20BR/WT (M/T)
13 K852 20BR/LB (M/T)
14 K167 20BR/YL (M/T)
8W - 80 - 16 8W-80 CONNECTOR PIN-OUTSDR

C109 (DIESEL) - LT GRAY (ENGINE SIDE)
CAV CIRCUIT
1 V35 18VT/OR
2 V32 18VT/YL
3 T41 18YL/DB
4 T6 18DG
5 T118 18DG
6 T9 18DG/TN
7-
8 T38 18YL/BR
9 T75 18YL/LB
10 T54 18DG/OR
11 T515 18YL/DB
12 V36 18VT/YL
13 T14 18DG/BR
14 T13 18DG/VT
C109 (DIESEL) - LT GRAY (TRANSMISSION
SIDE)
CAV CIRCUIT
1 V35 20VT/OR
2 V32 20VT/YL
3 T41 20YL/DB
4 T6 20DG
5 T118 18DG
6 T9 18DG/TN
7-
8 T38 18YL/BR
9 T75 18YL/LB
10 T54 18DG/OR
11 T515 20YL/DB
12 V36 20VT/YL
13 T14 18DG/BR
14 T13 18DG/VT
C110 (DIESEL) - BLACK (ENGINE SIDE)
CAV CIRCUIT
1 C3 18DB/YL
2 B29 18DG/WT
3-
4 K900 18DB/DG
5 V37 18VT
6 K160 18BR/OR
7 K161 18BR/LB
8 F856 18YL/PK
9 D20 18WT/LG
10 D21 18WT/BR
10 D21 18PK
11 F202 18PK/GY
12 K29 18WT/BR (M/T)
13 K854 18VT/BR (M/T)
14 K400 18BR/VT (M/T)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 17

C110 (DIESEL) - BLACK (TRANSMISSION SIDE)
CAV CIRCUIT
1 C3 20DB/YL
2 B29 20DG/WT
3-
4 K900 20DB/DG
5 V37 20VT
6 K160 18BR/OR
7 K161 18BR/LB
8 F856 18YL/PK
9 D20 20WT/LG
10 D21 20WT/BR
11 F202 20PK/GY
12 K29 20WT/BR (M/T)
13 K854 20VT/BR (M/T)
14 K400 20BR/VT (M/T)
C112 (DIESEL A/T) - (ENGINE SIDE)
CAV CIRCUIT
1 C3 18DB/YL
2 A961 14RD
3 K615 18VT/WT
4 K616 18BR/YL
C112 (DIESEL A/T) - (TRANSMISSION SIDE)
CAV CIRCUIT
1 C3 18DB/YL
2 A961 14RD
3 K615 18VT/WT
4 K616 18BR/YL
C112 (DIESEL M/T) - (ENGINE SIDE)
CAV CIRCUIT
1 C3 18DB/YL
2 A961 14RD
3 K615 18BR/WT
4 K616 18BR/YL
5 K167 18BR/YL
6 K23 18BR/WT
7 K852 18BR/VT
8 K29 18WT/BR
8W - 80 - 18 8W-80 CONNECTOR PIN-OUTSDR

C112 (DIESEL M/T) - (TRANSMISSION SIDE)
CAV CIRCUIT
1 C3 18DB/YL
2 A961 14RD
3 K615 18BR/WT
4 K616 18BR/YL
5 K167 18BR/YL
6 K23 18BR/WT
7 K852 18BR/VT
8 K29 18WT/BR
C130 (DIESEL) - (TRANSMISSION SIDE)
CAV CIRCUIT
A1 -
A2 C3 20DB/YL
A3 T41 20YL/DB (A/T)
A4 K400 20BR/VT (M/T)
A5 K900 20DB/DG
A6 K29 20WT/BR (M/T)
A7 K852 20BR/LB (M/T)
A8 Z901 18BK (MANUAL TRANSFER
CASE)
B1 T16 18YL/OR (A/T)
B2 L1 18WT/LG
B3 L10 18WT/GY
B4 F202 20PK/GY
B5 B22 20DG/YL
B6 T515 20YL/DB (A/T)
B7 K77 18BR/WT (MANUAL TRANSFER
CASE)
B8 N4 18DB/WT
C1 K174 18BR/YL
C2 C13 20LB/OR
C3 D25 20WT/VT
C4 K854 20VT/BR (M/T)
C5 K167 20BR/YL (M/T)
C6 K23 20BR/WT (M/T)
C7 T6 20DG (A/T)
C8 K176 18BR/OR
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 19

C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS-
FER CASE) - (HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 D20 20WT/LG
2 D21 20WT/BR
3-
4-
C131 (3.7L/4.7L EXCEPT ELECTRONIC TRANS-
FER CASE) - DK GRAY (ENGINE SIDE)
CAV CIRCUIT
1 D20 18WT/LG
2 D21 18WT/BR
3-
4-
C131 (4.7L ELECTRONIC TRANSFER CASE) -
(ENGINE SIDE)
CAV CIRCUIT
1 T316 16YL/GY
2 D200 20WT/LG
3 T313 20YL/LG
4 D202 20WT/VT
5 T885 20YL/GY
6 D201 20WT/DG
7 D203 20WT/BR
8 T315 16YL/BR
9 D20 18WT/LG (4.7L)
10 D21 18WT/BR (4.7L)
11
12
8W - 80 - 20 8W-80 CONNECTOR PIN-OUTSDR

C131 (4.7L ELECTRONIC TRANSFER CASE) -
(HEADLAMP AND DASH SIDE)
CAV CIRCUIT
1 T316 16YL/GY
2 D200 20WT/LG
3 T313 20YL/LG
4 D202 20WT/VT
5 T885 20YL/GY
6 D201 20WT/DG
7 D203 20WT/BR
8 T315 16YL/BR
9 D20 20WT/LG (4.7L)
10 D21 20WT/BR (4.7L)
11
12
C131 (5.7L/DIESEL) - GRAY (ENGINE SIDE)
CAV CIRCUIT
A1 T316 16YL/GY (ELECTRONIC TRANS-
FER CASE)
A2 D200 20WT/LG (ELECTRONIC TRANS-
FER CASE)
A3 T313 20YL/LG (ELECTRONIC TRANS-
FER CASE)
A4 D202 20WT/VT (ELECTRONIC TRANS-
FER CASE)
A5 T885 20YL/GY (ELECTRONIC TRANS-
FER CASE)
A6 D201 20WT/DG (ELECTRONIC TRANS-
FER CASE)
A7 D203 20WT/BR (ELECTRONIC TRANS-
FER CASE)
A8 T315 16YL/BR (ELECTRONIC TRANS-
FER CASE)
B1 -
B2 D20 20WT/LG
B3 D21 20WT/BR
B4 V32 20VT/YL (DIESEL)
B5 T117 20DG/YL (DIESEL A/T)
B6 V36 20VT/YL (DIESEL A/T)
B7 T917 20YL/TN (DIESEL A/T)
B8 -
C1 A961 14RD (DIESEL)
C2 B22 20DG/WT (5.7L)
C3 F855 18PK/YL (5.7L)
C3 B29 20DG/WT (DIESEL)
C4 F856 18YL/PK (5.7L)
C5 K160 18BR/OR (DIESEL)
C6 K161 18BR/LB (DIESEL)
C7 V37 20VT (DIESEL)
C8 K25 18DB/VT (DIESEL)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 21
