DODGE RAM 1500 1998 2.G Workshop Manual DRIVE CHAIN
Examine the drive chain and shaft bearings.
replace the chain if stretched, distorted, or if any of
the links bind. Replace the bearings if rough, or
noisy.
LOW RANGE ANNULUS GEAR
Inspect

Page 2132 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (3) Using Installer 6436 and Handle C-4171 (Fig.
45), remove front output shaft bearing.
(4) Start front output shaft bearing in case. Then
seat bearing with Handle C-4171 and Installer 6953.
(5) Inst

Page 2133 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (9) Install new bearing with Tool Handle C-4171
and Installer 5066 (Fig. 48). The bearing bore is
chamfered at the top. Install the bearing so it is
flush with the lower edge of this chamfer (Fig. 49)

Page 2134 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INPUT AND PLANETARY GEAR
(1) Lubricate gears and thrust washers (Fig. 52)
with recommended transmission fluid.
(2) Install first thrust washer in low range gear
(Fig. 52). Be sure washer tabs are prop

Page 2135 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual SHIFT FORKS AND MAINSHAFT
(1) Lubricate mainshaft splines with recommended
transmission fluid.
(2) Install the mode hub (Fig. 55) onto the output
shaft.
(3) Install the mode hub retaining ring (Fig. 5

Page 2136 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (7) Install the drive sprocket thrust washer (Fig.
60) onto the output shaft.
(8) Install the drive sprocket retaining ring (Fig.
61) onto the output shaft.(9) Lubricate sector shaft with transmission

Page 2137 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (11) Assemble and install range fork and hub (Fig.
64). Be sure hub is properly seated in low range gear
and engaged to the input gear.
(12) Align and insert range fork pin in shift sector
slot.
(13)

Page 2138 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (18) Install range lever on sector shaft (Fig. 68).
(19) Install washer and nut on sector shaft to
secure shift lever. Apply 1-2 drops MopartLock N
Seal, or equivalent, to nut threads before installa

Page 2139 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (5) Install drive chain around mainshaft sprocket
(Fig. 73). Then position front sprocket over front
shaft.
(6) Raise mainshaft about 2.54 cm (one inch) and
seat front sprocket on front output shaft.

Page 2140 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (2) Align oil pump with mainshaft and align shift
rail with bore in rear case. Then install rear case and
oil pump assembly (Fig. 77).
(3) Install 4-5 rear case-to front case bolts (Fig. 78)
to hold r
