DRIVER HEATED SEAT CUSHION - BLUE 4 WAY
CAV CIRCUIT FUNCTION
1 P131 16RD/DG LEFT SEAT HEATER B(+) DRIVER
2 Z2 18BK/LG GROUND
3 P144 20BK/WT SEAT TEMPERATURE 5V SUPPLY
4 P141 20TN/LB LEFT SEAT TEMPERATURE SENSOR INPUT
DRIVER HEATED SEAT SWITCH - RED 6 WAY
CAV CIRCUIT FUNCTION
1 P137 20DG LEFT SEAT LOW HEAT LED DRIVER
2 E2 22OR PANEL LAMPS FEED
3 Z3 20BK/OR GROUND
4 F15 20DB FUSED IGNITION SWITCH OUTPUT (RUN)
5 P139 20WT LEFT SEAT HIGH HEAT LED DRIVER
6 P7 20LB/BK DRIVER HEATED SEAT SWITCH
DRIVER LUMBAR MOTOR-2WAY
CAV CIRCUIT FUNCTION
1 P106 16DG/WT LUMBAR MOTOR FORWARD
2 P107 16OR/BK LUMBAR MOTOR REARWARD
DRIVER POWER SEAT FRONT VERTICAL MOTOR (CLUB CAB) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
B P19 16YL/LG LEFT POWER SEAT FRONT UP
A P21 16RD/LG LEFT POWER SEAT FRONT DOWN
DRIVER POWER SEAT FRONT VERTICAL MOTOR (STANDARD CAB)-2WAY
CAV CIRCUIT FUNCTION
1 P19 14YL/LG LEFT SEAT FRONT UP
2 P21 14RD/LG LEFT SEAT FRONT DOWN
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 37

ENGINE CONTROL MODULE (DIESEL) - 50 WAY
CAV CIRCUIT FUNCTION
1 H104 18BR/OR IDLE VALIDATION SWITCH NO. 1
2 K244 20YL/DB CUMMINS BUS (+)
3 K6 18VT/WT 5V SUPPLY
4 K14 18BK/DB SENSOR GROUND
5 F18 18LG/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
6 G60 18GY/BK ENGINE OIL PRESSURE SENSOR SIGNAL
7 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
8 G12 18GY/RD MANIFOLD AIR PRESSURE SENSOR SIGNAL
9- -
10 K7 18OR 5V SUPPLY
11 K104 18BK/LB SENSOR GROUND
12 K246 20YL/DG CUMMINS BUS (-)
13 K242 20WT DATA LINK (+) FUEL INJECTION PUMP
14 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
15 K135 18YL/WT TRANSFER PUMP SUPPLY
16 H105 18LG/DB IDLE VALIDATION SWITCH NO. 2
17 K124 18GY CAMSHAFT POSITION SENSOR SIGNAL
18 K48 18DG FUEL INJECTION PUMP SYNC SIGNAL
19 - -
20 - -
21 K1 18DG/RD WATER IN FUEL SENSOR SIGNAL
22 V37 18RD/LG SPEED CONTROL SWITCH SIGNAL
23 K240 20BK DATA LINK (-) FUEL INJECTOR PUMP
24 V32 18YL/RD BRAKE SWITCH SENSE
25 H102 18LB/BK ACCELERATOR PEDAL POSITION SENSOR SIGNAL
26 G113 18OR PTO SWITCH SENSE
27 - -
28 K22 18OR/DB ACCELERATOR PEDAL POSITION SENSOR SIGNAL
29 S21 18YL/BK AIR INTAKE HEATER RELAY NO.1
30 Z12 18BK/TN GROUND
31 H101 18DB/WT ACCELERATOR PEDAL POSITION SENSOR SUPPLY
32 H103 18BK/YL ACCELERATOR PEDAL POSITION SENSOR GROUND
33 K45 18LB/RD FUEL SHUT-OFF SIGNAL
34 K44 18VT/OR LOW IDLE SELECT
35 K135 18YL/WT TRANSFER PUMP SUPPLY
36 K131 18BR/WT FUEL INJECTOR PUMP RELAY CONTROL
37 G85 18OR/BK WAIT-TO-START WARNING INDICATOR DRIVER
38 D21 18PK/DB SCI TRANSMIT
39 D20 18DG SCI RECEIVE
40 D2 18WT/BK CCD BUS (-)
41 D1 18VT/BR CCD BUS (+)
42 K247 20DB CUMMINS BUS SHIELD
43 G7 18WT/OR VEHICLE SPEED SENSOR SIGNAL
44 K243 20OR/BR DATA LINK SHIELD FUEL INJECTOR PUMP
45 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
46 - -
47 S22 18OR/BK AIR INTAKE HEATER RELAY CONTROL NO. 2
48 A14 18RD/WT FUSED B(+)
49 Z12 18BK/TN GROUND
50 A14 18RD/WT FUSED B(+)
8W - 80 - 40 8W-80 CONNECTOR PIN-OUTSBR/BE

ENGINE COOLANT TEMPERATURE SENSOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
B K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
A K104 18BK/LB SENSOR GROUND
ENGINE COOLANT TEMPERATURE SENSOR (GAS)-2WAY
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 K2 18TN/BK ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
ENGINE OIL PRESSURE SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
A K7 18OR 5V SUPPLY
B K104 18BK/LB SENSOR GROUND
C G60 18GY/BK ENGINE OIL PRESSURE SENSOR SIGNAL
ENGINE OIL PRESSURE SENSOR (GAS)-2WAY
CAV CIRCUIT FUNCTION
1 K4 20BK/LB SENSOR GROUND
2 G60 18GY/OR ENGINE OIL PRESSURE SENSOR SIGNAL
EVAP/PURGE SOLENOID-2WAY
CAV CIRCUIT FUNCTION
1 K52 18PK/WT EVAPORATIVE EMISSION SOLENOID CONTROL
2 F12 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
FRONT WASHER PUMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 V10 16BR WASHER SWITCH SENSE
2 Z1 20BK GROUND
FRONT WASHER PUMP - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 V10 16BR WASHER SWITCH SENSE
2 Z1 20BK GROUND
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 41

GENERATOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K20 18DG GENERATOR FIELD
2 T125 18DB GENERATOR SOURCE
GLOVE BOX LAMP AND SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 M1 22PK FUSED B(+)
2 Z3 22BK/OR GROUND
HEADLAMP SWITCH C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 L7 16BK/YL HEADLAMP SWITCH OUTPUT
2 F33 16PK/RD FUSED B(+)
3 G26 22LB KEY-IN IGNITION SWITCH SENSE
4 G75 22TN (BASE) DRIVER DOOR AJAR SWITCH SENSE
4 Z3 22BK/OR (HIGHLINE/PREMIUM) GROUND
5 Z3 18BK/OR GROUND
6 L2 18LG HEADLAMP SWITCH OUTPUT
7 L39 22LB FOG LAMP SWITCH OUTPUT
8 E17 18YL/BK DAY BRIGHTNESS SENSE
9 Z3 20BK/OR GROUND
10 M22 22WT ILLUMINATED ENTRY SWITCH SENSE
11 M3 22PK/DB CARGO LAMP DRIVER
12 M2 22YL COURTESY LAMPS DRIVER
13 M11 22PK/LB (HIGHLINE/PREMIUM) COURTESY LAMPS SWITCH OUTPUT
13 M22 22WT (BASE) ILLUMINATED ENTRY SWITCH SENSE
14 E1 18TN PANEL LAMPS DIMMER SWITCH SIGNAL
HEADLAMP SWITCH C2-2WAY
CAV CIRCUIT FUNCTION
1 Z3 20BK/OR GROUND
2 L35 22BR/YL FOG LAMP RELAY OUTPUT
HEATED MIRROR SWITCH-3WAY
CAV CIRCUIT FUNCTION
1 F15 22DB FUSED IGNITION SWITCH OUTPUT (RUN)
2 Z3 22BK/OR GROUND
3 C16 22LB/YL HEATED MIRROR
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 45

HIGH NOTE HORN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/RD HORN RELAY OUTPUT
2 Z1 18BK GROUND
IDLE AIR CONTROL MOTOR - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K39 18GY/RD IDLE AIR CONTROL NO. 1 DRIVER
2 K60 18YL/BK IDLE AIR CONTROL NO. 2 DRIVER
3 K40 18BR/WT IDLE AIR CONTROL NO. 3 DRIVER
4 K59 18VT/BK IDLE AIR CONTROL NO. 4 DRIVER
IGNITION COIL (3.9L/5.2L/5.9L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 14DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
2 K19 16BK/GY IGNITION COIL NO. 1 DRIVER
IGNITION COIL 4 PACK (8.0L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K17 18DB/WT IGNITION COIL NO. 2 DRIVER
2 A142 14DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
3 K18 18RD/BK IGNITION COIL NO. 3 DRIVER
IGNITION COIL 6 PACK (8.0L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
2 A142 14DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
3 K32 18YL/GY IGNITION COIL NO. 4 DRIVER
4 K43 18DG/GY IGNITION COIL NO. 5 DRIVER
8W - 80 - 46 8W-80 CONNECTOR PIN-OUTSBR/BE

IGNITION SWITCH C1 - BLACK 7 WAY
CAV CIRCUIT FUNCTION
1 A41 14YL IGNITION SWITCH OUTPUT (START)
2 A21 12DB IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 A2 14PK/BK FUSED B(+)
5 A22 14BK/OR IGNITION SWITCH OUTPUT (RUN)
6 A31 12BK/WT IGNITION SWITCH OUTPUT (RUN-ACC)
7 A1 10RD FUSED B(+)
IGNITION SWITCH C2 - GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 Z3 22BK/OR ((HIGHLINE/PREMIUM)) GROUND
1 G75 22TN (BASE) DRIVER DOOR AJAR SWITCH SENSE
2 G26 22LB KEY-IN IGNITION SWITCH SENSE
3- -
4- -
INSTRUMENT CLUSTER C1 - 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 G5 22DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
3 G11 22WT/LG PARK BRAKE SWITCH SENSE
4 Z2 20BK/LG GROUND
5 Z3 20BK/OR GROUND
6 F73 20YL FUSED B(+)
7- -
8 G85 22OR/BK (DIESEL) WAIT-TO-START WARNING INDICATOR DRIVER
9 D2 20WT/BK CCD BUS (-)
10 D1 20VT/BR CCD BUS (+)
INSTRUMENT CLUSTER C2 - 10 WAY
CAV CIRCUIT FUNCTION
1 E2 22OR PANEL LAMPS FEED
2 G29 22BK/WT WASHER FLUID SWITCH SENSE
3 G10 22LG/RD SEAT BELT SWITCH SENSE
4- -
5 E17 18YL/BK DAY BRIGHTNESS SENSE
6 L61 18LG LEFT TURN SIGNAL
7 G13 22DB/RD CHIME REQUEST SIGNAL
8 L60 18TN RIGHT TURN SIGNAL
9 G34 16RD/GY HIGH BEAM INDICATOR DRIVER
10 G107 22GY 4WD SWITCH SENSE
INTAKE AIR HEATER RELAYS (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 S22 18OR/BK AIR INTAKE HEATER RELAY CONTROL NO. 2
2 Z12 18BK/TN GROUND
3 S21 18YL/BK AIR INTAKE HEATER RELAY CONTROL NO. 1
4 Z12 18BK/TN GROUND
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 47

JOINT CONNECTOR NO.5-NATURAL 22 WAY
CAV CIRCUIT FUNCTION
1 M1 20PK FUSED B(+)
2 M1 22PK FUSED B(+)
3 M1 22PK FUSED B(+)
4 Z3 20BK/OR GROUND
5 Z3 18BK/OR GROUND
6 Z3 22BK/OR GROUND
7 Z3 18BK/OR GROUND
8 E2 22OR PANEL LAMPS FEED
9 E2 22OR PANEL LAMPS FEED
10 E2 22OR PANEL LAMPS FEED
11 - -
12 M1 22PK FUSED B(+)
13 M1 22PK FUSED B(+)
14 Z3 20BK/OR (HEATED SEATS) GROUND
15 Z3 20BK/OR (HEATED SEATS) GROUND
16 Z3 22BK/OR (EXCEPT BASE/MIDLINE) GROUND
17 Z3 22BK/OR (EXCEPT BASE/MIDLINE) GROUND
18 - -
19 - -
20 E2 22OR PANEL LAMPS FEED
21 E2 22OR PANEL LAMPS FEED
22 E2 22OR PANEL LAMPS FEED
JOINT CONNECTOR NO.6-NATURAL 22 WAY
CAV CIRCUIT FUNCTION
1 V10 16BR WASHER SWITCH SENSE
2 V10 16BR WASHER SWITCH SENSE
3 V10 16BR WASHER SWITCH SENSE
4- -
5- -
6 Z9 16BK/VT GROUND
7 Z9 16BK/VT (EXCEPT BASE/LOWLINE) GROUND
8 G26 22LB KEY-IN IGNITION SWITCH SENSE
9 G26 22LB KEY-IN IGNITION SWITCH SENSE
10 G26 22LB KEY-IN IGNITION SWITCH SENSE
11 - -
12 - -
13 - -
14 L50 16WT/TN BRAKE LAMP SWITCH OUTPUT
15 L50 16WT/TN BRAKE LAMP SWITCH OUTPUT
16 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
17 L50 18WT/TN BRAKE LAMP SWITCH OUTPUT
18 Z9 16BK/VT (EXCEPT BASE/LOWLINE) GROUND
19 Z9 20BK/VT (SLT+/HIGHLINE) GROUND
20 X3 20BK/RD (EXCEPT BASE/MIDLINE) HORN RELAY CONTROL
20 M22 22WT (BASE/MIDLINE) ILLUMINATED ENTRY SWITCH SENSE
21 X3 20BK/RD (EXCEPT BASE/MIDLINE) HORN RELAY CONTROL
21 M22 22WT (BASE/MIDLINE) ILLUMINATED ENTRY SWITCH SENSE
22 M22 22WT (BASE/MIDLINE) ILLUMINATED ENTRY SWITCH SENSE
22 X3 20BK/RD (EXCEPT BASE/MIDLINE) HORN RELAY CONTROL
8W - 80 - 50 8W-80 CONNECTOR PIN-OUTSBR/BE

JOINT CONNECTOR NO.7-NATURAL 22 WAY
CAV CIRCUIT FUNCTION
1 D1 18VT/BR CCD BUS (+)
2 D1 18VT/BR CCD BUS (+)
3 D1 20VT/BR CCD BUS (+)
4 D2 18WT/BK CCD BUS (-)
5 D2 18WT/BK CCD BUS (-)
6 D2 20WT/BK CCD BUS (-)
7 D2 20WT/BK CCD BUS (-)
8 D1 20VT/BR CCD BUS (+)
9 D1 20VT/BR CCD BUS (+)
10 D1 20VT/BR CCD BUS (+)
11 D1 20VT/BR CCD BUS (+)
12 D1 20VT/BR CCD BUS (+)
13 D1 20VT/BR CCD BUS (+)
14 D2 20WT/BK CCD BUS (-)
15 D2 20WT/BK CCD BUS (-)
16 D2 20WT/BK CCD BUS (-)
17 D2 20WT/BK (REMOTE RADIO) CCD BUS (-)
18 - -
19 - -
20 D1 20VT/BR (REMOTE RADIO) CCD BUS (+)
21 - -
22 - -
JOINT CONNECTOR NO.8-NATURAL 22 WAY
CAV CIRCUIT FUNCTION
1 E17 18YL/BK DAY BRIGHTNESS SENSE
2 E17 18YL/BK DAY BRIGHTNESS SENSE
3 E17 18YL/BK DAY BRIGHTNESS SENSE
4 F15 18DB FUSED IGNITION SWITCH OUTPUT (RUN)
5 F15 22DB FUSED IGNITION SWITCH OUTPUT (RUN)
6 E2 22OR (HEATED SEATS) PANEL LAMPS FEED
6 G75 22TN (BASE/MIDLINE) DRIVER DOOR AJAR SWITCH SENSE
7 E2 22OR (HEATED SEATS) PANEL LAMPS FEED
7 G75 22TN (BASE/MIDLINE) DRIVER DOOR AJAR SWITCH SENSE
8 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
9 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
10 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 M2 22YL COURTESY LAMPS DRIVER
12 M2 22YL COURTESY LAMPS DRIVER
13 M2 22YL COURTESY LAMPS DRIVER
14 F15 22DB FUSED IGNITION SWITCH OUTPUT (RUN)
15 F15 22DB FUSED IGNITION SWITCH OUTPUT (RUN)
16 F15 22DB FUSED IGNITION SWITCH OUTPUT (RUN)
17 F15 20DB (HEATED SEATS) FUSED IGNITION SWITCH OUTPUT (RUN)
18 G75 22TN (BASE/MIDLINE) DRIVER DOOR AJAR SWITCH SENSE
18 E2 22OR (HEATED SEATS) PANEL LAMPS FEED
19 E2 22OR (HEATED SEATS) PANEL LAMPS FEED
19 G75 22TN (BASE/MIDLINE) DRIVER DOOR AJAR SWITCH SENSE
20 Z6 18BK/PK GROUND
21 Z6 18BK/PK GROUND
22 Z6 18BK/PK GROUND
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 51

JUNCTION BLOCK C1 - BLUE 15 WAY
CAV CIRCUIT FUNCTION
1- -
2 G31 20VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
3 A20 20RD/DB FUSED IGNITION SWITCH OUTPUT (RUN)
4 L61 18LG LEFT TURN SIGNAL
5 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
6- -
7- -
8- -
9 L7 18BK/YL PARK LAMP RELAY OUTPUT
10 F18 20LG/BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 L1 18VT/BK BACK-UP LAMP FEED
12 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
14 G32 20BK/VT SENSOR GROUND
15 - -
JUNCTION BLOCK C2 - NATURAL 6 WAY
CAV CIRCUIT FUNCTION
1 A7 10RD/BK FUSED B(+)
2 L9 16BK/VT FUSED FLASHER FEED
3 M1 20PK FUSED B(+)
4- -
5 L60 18TN RIGHT TURN SIGNAL
6- -
JUNCTION BLOCK C3 - 14 WAY
CAV CIRCUIT FUNCTION
1 G32 22BK/LB SENSOR GROUND
2 Z2 20BK/LG GROUND
3 M2 22YL COURTESY LAMPS DRIVER
4- -
5 G31 22VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
6 M1 22PK (BASE) FUSED B(+)
6 M1 20PK (HIGHLINE) FUSED B(+)
7- -
8 L7 18BK/YL (CLEARANCE/ID LAMPS) PARK LAMP RELAY OUTPUT
9- -
10 - -
11 L1 20VT/BK BACK-UP LAMP FEED
12 - -
13 Z3 18BK (HIGHLINE) GROUND
14 F12 20DB/WT (HIGHLINE) FUSED IGNITION SWITCH OUTPUT (RUN-START)
8W - 80 - 52 8W-80 CONNECTOR PIN-OUTSBR/BE

JUNCTION BLOCK C4 - BROWN 11 WAY
CAV CIRCUIT FUNCTION
1 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
3 X12 16RD/WT FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 L61 18LG LEFT TURN SIGNAL
5 F12 22DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
6 F12 22DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
7- -
8- -
9 E1 18TN PANEL LAMPS DIMMER SWITCH SIGNAL
10 - -
11 - -
JUNCTION BLOCK C5 - GREEN 8 WAY
CAV CIRCUIT FUNCTION
1 V6 16DB (EXCEPT BASE/MIDLINE) FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2 L61 18LG LEFT TURN SIGNAL
3 X60 16DG/RD FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 V6 16DB FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
5- -
6 M2 22YL COURTESY LAMPS DRIVER
7 E2 22OR PANEL LAMPS FEED
8 G5 22DB/WT FUSED IGNITION SWITCH OUTPUT (RUN-START)
JUNCTION BLOCK C6 - BLACK 6 WAY
CAV CIRCUIT FUNCTION
1 A35 16DB (SLT) FUSED B(+)
2- -
3- -
4 L19 16PK HAZARD FLASHER SIGNAL
5 F235 16RD B(+) TO HEATED SEAT MODULE
6 L10 18BR/LG FUSED IGNITION SWITCH OUTPUT (RUN)
JUNCTION BLOCK C7 - LT. GRAY 13 WAY
CAV CIRCUIT FUNCTION
1 L60 18TN RIGHT TURN SIGNAL
2- -
3 Z3 18BK/WT GROUND
4 L60 18TN RIGHT TURN SIGNAL
5- -
6- -
7 P132 16OR/BK (SLT/BASE/MIDLINE) HEATED SEAT ENABLE
8 Z2 22BK/LG GROUND
9 M1 22PK FUSED B(+)
10 F35 18RD FUSED B(+)
11 F35 22RD FUSED B(+)
12 A35 16DB (SLT) FUSED B(+)
13 L6 16RD/GY FLASHER OUTPUT
BR/BE8W-80 CONNECTOR PIN-OUTS 8W - 80 - 53
