Page 1591 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual CLEANING
1. Clean oil pan in solvent and wipe dry with a clean cloth.
2. Clean the oil pan gasket surface.DO NOTuse a grinder wheel or other abrasive tool to clean sealing surface.
3. Clean oil screen

Page 1592 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 1. If removed, install stud at position No. 9.
2. Position the oil pan and install the mounting bolts
and nut. Tighten the mounting bolts and nut to 15
Nꞏm (11 ft. lbs.) in the sequence shown .
3. L

Page 1593 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual SWITCH-OIL PRESSURE
DESCRIPTION
The 3 wire, solid-state engine oil pressure sensor (sending unit) is located in an engine oil pressure gallery.
OPERATION
The oil pressure sensor uses three circuits. T

Page 1594 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual PUMP-ENGINE OIL
REMOVAL
1. Remove the oil pan and pick-up tube (Refer to 9 - ENGINE/LUBRICATION/OILPA N - R E M O VA L ) .
2. Remove the timing chain cover (Refer to 9 - ENGINE/VALVE TIMING/TIMING BEL

Page 1595 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 5. Measure the thickness of the inner rotor. If the
inner rotor thickness measures at 12.005 mm
(0.472 in.) or less then the oil pump assembly must
be replaced.
6. Slide outer rotor (2) into the body

Page 1596 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 8. Place a straight edge (1) across the body of the oil
pump (between the bolt holes), if a feeler gauge (2)
of .095 mm (0.0038 in.) or greater can be inserted
between the straightedge and the rotors,

Page 1597 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual FILTER-ENGINE OIL
REMOVAL
All engines are equipped with a high quality full-flow,
disposable type oil filter (1). DaimlerChrysler Corpora-
tion recommends a Mopar
or equivalent oil filter be
used.
1.

Page 1598 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual OIL
STANDARD PROCEDURE - ENGINE OIL SERVICE
The engine oil level indicator (1) is located at the right
rear of the engine on the 3.7L/4.7L engines.
CRANKCASE OIL LEVEL INSPECTION
CAUTION: Do not overf

Page 1599 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual 10. Stop engine and inspect oil level.
NOTE:
Care should be exercised when disposing used engine oil after it has been drained from a vehicle engine.
Refer to the WARNING at beginning of this section.

Page 1600 of 5267

DODGE RAM SRT-10 2006  Service Repair Manual MANIFOLD-INTAKE
DESCRIPTION
The intake manifold (2) is made of a composite mate-
rial and features 300 mm (11.811 in.) long runners
which maximizes low end torque. The intake manifold
uses single plan
