97
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
PROTECTING THE
ENVIRONMENT
The devices for curtailing petrol engine
emissions are the following:
❒three-way catalytic converter;
❒Lambda sensor;
❒fuel evaporation system.
In addition, do not let the engine run, even
for a test, with one or more spark plugs
disconnected.
The devices for curtailing diesel fuel en-
gine emissions are the following:
❒oxidising catalytic converter;
❒exhaust gas recirculation system
(E.G.R.);
❒diesel particulate filter (DPF). When refuelling, position the cap on the
device inside the flap as shown in the fig-
ure.
If the doors are locked, press the door un-
lock button
´on central panel to refuel.
The fuel filler cap is re-locked when the
doors are locked.
fig. 125F0L0181m
Do not put naked flames or
lighted cigarettes near the
fuel filler hole as there is a danger of
fire. Do not bend too close to the hole
either so as not to breathe in harmful
vapours.
WARNING
During normal service the
diesel particulate filter (DPF)
reaches high temperatures. Do not
therefore park the car over inflam-
mable materials (grass, dry leaves,
pine needles, etc.): fire hazard.
WARNING
During normal service the
catalyst reaches high tem-
peratures. Do not therefore park the
car over inflammable materials (grass,
dry leaves, pine needles, etc.): fire
hazard.
WARNING
062-098 Croma TRW GB 20-11-2006 15:01 Pagina 97

186
WARNING
LIGHTS AND
MESSAGES
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
30 60 90 120 150 180
●●●●●●
●●●●●●
●●
●●●●●●
●●●●●●
●
●
●
●
●
●●●
●●●
●●●
●●●●●●
●●●●●●
(●)(●)(●)(●)(●)(●)
●●●●●●
●●●
●●●●●●
Thousands of km
Check exhaust emissions (petrol versions)
Check exhaust emissions/smoke (Multijet versions)
Check antievaporation system (petrol versions)
Check engine control system operation (through diagnostic socket)
Check and top up, if required, automatic transmission oil level
Replace accessory drive belt/s (Multijet versions / petrol exclude 1.8)
Replace accessory drive belt/s (1.8 petrol versions)
Replace timing belt (Multijet versions)O
Replace timing belt (1.8 petrol versions)O
Change spark plugs (petrol versions exclude 1.8)
Change spark plugs (1.8 petrol versions)
Replace diesel fuel filter (Multijet versions)
Change air cleaner cartridge (petrol versions)
Change air cleaner cartridge (Multijet versions)
Change engine oil and oil filter (petrol versions)
Change engine oil and oil filter (Multijet versions - DPF)*
Change engine oil and oil filter (Multijet versions without DPF)
Change brake fluid (or every 2 years)
Change pollen filter (or every year)
Oregardless of the km covered, the timing belt shall be replaced every 4 years for particularly demanding use
(cold climates, driving in the city, idling for a long time) or in any case every 5 years
* Engine oil and oil filter shall actually be changed according to the conditions of use of the car and it is indicated by the relevant warning light
or message (where provided) on the instrument panel (see section “Warning lights and messages”).
183-206 Croma TRW GB 20-11-2006 15:03 Pagina 186

211
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
ENGINE
1.8 2.2 2.2 a.t.
GENERAL FEATURES
Engine code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel
939A4000
Otto
4 in line
80.5 x 88.2
1796
10.5 : 1
103
140
6300
175
17.8
3800
BOSCH FQR 8 LEU2
Unleaded
petrol 95 RON
(Specification EN228)194A1000
Otto
4 in line
86 x 94.6
2198
10.0 : 1
108
147
5800
203
20.7
4000
AC DELCO HLR8STEX
Unleaded
petrol 95 RON
(Specification EN228)194A1000
Otto
4 in line
86 x 94.6
2198
10.0 : 1
108
147
5800
203
20.7
4000
AC DELCO HLR8STEX
Unleaded
petrol 95 RON
(Specification EN228)
207-231 Croma TRW GB 20-11-2006 15:04 Pagina 211

234
WARNING
LIGHTS AND
MESSAGES
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
– "table" setting .................................. 32
Side/taillights
– control ............................................. 54
– front bulb replacement ................. 163
– rear bulb replacement .................. 165
Sunroof.................................................... 70
Smart washing ...................................... 57
Snow chains .......................................... 135
Sound system ....................................... 92
Spark plugs
– type ................................................... 211
Starting the engine
– bump starting ................................. 151
– diesel engines ................................. 121
– ignition switch ................................ 17
– jump starting .................................. 150
– petrol engines ................................ 120
– stopping the engine ...................... 122
– warming up the engine ................ 122
Steering ................................................... 214
Steering column lock .......................... 17
Steering wheel adjustment ................ 35
Storing the car ..................................... 136
Sun visors .............................................. 69
Suspensions ........................................... 214
Symbols .................................................. 7
Table ..................................................... 32
Tailgate ................................................... 76
Technical specifications ....................... 207
Third brake light .................................. 166
Tools ...................................................... 153
Top speeds ............................................ 221
Towing a trailer
– tow hitch installation .................... 132
Towing the car ..................................... 181T.P.M.S. system ..................................... 91
Transmission ........................................ 213
Tyre pressure ......................... 218-219
Tyres
– changing ........................................... 151
– snow tyres ...................................... 134
– standard ........................................... 217
– understanding tyre marking......... 215
Universal Isofix child restraint
system ................................................. 109
Using the manual gearbox ................. 124
Using the automatic gearbox ............ 125
Ventilation ........................................... 39
Volumetric protection ........................ 13
Warning lights and messages........... 137
Weights ................................................. 222
Wheel geometry................................... 215
Wheel replacement ............................ 151
Wheels
– changing ........................................... 151
– spare wheel .................................... 217
Window washing .................................. 57
Windows (cleaning) ............................. 205
Windscreen and rear window
wiper blades ....................................... 202
Windscreen washer
– control ............................................. 57
– fluid level ......................................... 195
Windscreen wipers
– blades ............................................... 202
– control ............................................. 57
– nozzles ............................................. 203
Windscreen/rear window/
headlight washer fluid level ............. 195 Rear ceiling lights
– bulb replacement .......................... 169
– control .............................................. 62
Rear fog lights
– bulb replacement .......................... 164
– control button ............................... 64
Rear window washer
– control ............................................. 59
– fluid level ......................................... 195
Rear window wipers
– blades ............................................... 202
– control ............................................. 59
– nozzles ............................................. 203
Rearview mirrors
– door mirrors .................................. 36
– driving mirror ................................ 36
– electric ............................................. 36
Refuelling ............................................... 224
Rev. counter ......................................... 18
Reversing light ...................................... 164
Rims
– understanding rim marking .......... 215
Roof rack/ski rack ................................ 84
Safety devices ....................................... 99
Seat adjustment ................................... 31
Seat belts
– general warnings ........................... 103
– load limiters ..................................... 102
– maintenance ................................... 104
– use .................................................... 100
Seats
– cleaning ............................................ 205
– electrically adjustable front
seats ................................................... 33
– manually adjustable front seats ... 31
