Driver’s and passenger’s airbags have been designed and calibrated to
improve the protection of a person wearing seat belts.
At their maximum inflation, their volume fills most of the space between
the steering wheel and the driver and between the dashboard and the
passenger.
In minor front crashes (for which the restraining action of the seat belts
is sufficient), the airbags will not deploy. Also in this case it is of vital
importance to wear the seat belts since in case of front crash they
guarantee proper positioning of the car occupant.
DRIVER’S FRONT AIRBAG
It consists of an instant-inflating cushion contained in a special recess in
the centre of the steering wheel.
PASSENGER’S FRONT AIRBAG
It consists of an instant-inflating cushion contained in a special recess in
the dashboard; its volume is bigger than the driver’s one.
F0E0221m
F0E0222m
WARNINGSERIOUS DANGER: The car is fitted with airbag on passenger’s side. Never place
cradle child’s seats on the front passenger seat of cars fitted with passenger’s
airbag since the airbag activation could cause serious injuries, even mortal. In the
case of need, always deactivate the passenger’s airbag when a child’s seat is placed
on the front seat. The front passenger seat shall be adjusted in the most backward
position to prevent any contact between child’s seat and dashboard. Even if not
compulsory by law, you are recommended to reactivate the airbag immediately as
soon as child transport is no longer necessary.

131
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
MANUAL DEACTIVATION OF PASSENGER’S FRONT
AIRBAG
Should it be absolutely necessary to carry a child on the front seat, the
passenger’s airbag on the car can be deactivated.
Deactivation/reactivation takes place with ignition key at STOP and
operating it in the special key switch set in dashboard box on driver’s
side.
The key can be inserted and removed in both positions.
IMPORTANT Operate the switch only when the engine is not running
and the ignition key is removed.
The key-operated switch has two positions:
❒passenger’s front airbag activated (ON position
P): warning light F
on instrument cluster off; it is absolutely prohibited to carry a child on
the front seat.
❒passenger’s front airbag deactivated (OFF position
F): warning light
Fon instrument cluster on; it is possible to carry a child protected
by special restraint system on the front seat.
Warning light
Fon the cluster stays on permanently until the
passenger’s airbag is reactivated.
Deactivation of the passenger’s front airbag does not inhibit operation of
the side airbag.
F0E0105m
F0E0642m

133
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
IMPORTANT The front airbags and/or side bags may
be deployed if the car is subject to heavy knocks or
accidents involving the underbody area, such as for
example violent shocks against steps, kerbs or
obstacles, falling of the car in big holes or sags in the
road.
IMPORTANT When the airbag inflates it emits a small
amount of dusts. These dusts are harmless and is not
the beginning of a fire; then the unfold cushion surface
and the car interiors can be covered by a dusty
remains: this dust can irritate skin and eyes. In case of
contact, wash yourself using neutral soap and water.
IMPORTANT Should an accident occur in which any
of the safety devices is activated, take the car to a Fiat
Dealership to have the devices activated replaced and
to have the system checked.All control, check, repair and replacement operations
concerning the airbags must be carried out c/o Fiat
Dealership only.
If you are having the car scrapped, have the airbag
system deactivated at a Fiat Dealership first. If the car
changes ownership, the new owner must be informed
of the method of use of airbags and the above
warnings and also be given this “Owner Handbook”.
IMPORTANT The triggering of pretensioners, front
airbags and side bags is decided in a differentiated
manner by the electronic control unit, depending on
the type of crash. The failure to deploy one or more
of them does not mean that the system is not working
properly.
WARNING
WARNING
Never rest head, arms and elbows on the door, on the windows and in the
windowbag area to prevent possible injuries during the inflation phase. Expiration dates of pyrotechnic charge and coil contact are indicated on the label
inside the lower oddment compartment. As these dates approach, contact Fiat
Dealership to have them replaced.
WARNINGNever lean head, arms and elbows out of window.

152
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
152
W W
A A
R R
N N
I I
N N
G G
L L
I I
G G
H H
T T
S S
A A
N N
D D
M M
E E
S S
S S
A A
G G
E E
S S
GENERAL INFORMATION .............................................. 153
ENGINE COOLANT TOO HOT ................................... 154
LOW BRAKE FLUID LEVEL .............................................. 154
BATTERY NOT RECHARGING PROPERLY ............... 155
SEAT BELTS NOT FASTENED ......................................... 155
AIRBAG FAILURE ................................................................ 155
DOORS OPEN ..................................................................... 156
FRONT BRAKES PADS WORN....................................... 156
LOW ENGINE OIL PRESSURE ........................................ 156
ABS (WHEEL ANTI-LOCKING SYSTEM) FAILURE.... 157
EBD (ELECTRONIC BRAKE FORCE DISTRIBUTOR)
FAILURE .................................................................................. 157
ESP SYSTEM ........................................................................... 157
EOBD / INJECTION SYSTEM FAILURE.......................... 158
FIAT CODE ........................................................................... 159
POSSIBLE ICE ON ROAD ................................................ 159INERTIAL FUEL CUT-OFF SWITCH .............................. 159
EXHAUST OIL ..................................................................... 160
DIESEL PARTICULATE FILTER CLOGGED ................. 161
GLOW PLUGS ..................................................................... 162
DIRECTION INDICATORS ............................................. 162
PASSENGER SIDE AIRBAG DEACTIVATED ............... 162
OUTSIDE LIGHTS ............................................................... 163
MAIN BEAM HEADLIGHTS ............................................. 163
SERVICE ................................................................................. 163
WARNING LIGHT FAILURE ........................................... 163
WATER IN DIESEL FUEL FILTER .................................... 163

155
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
155
Warning Messagelight on panel on display
BATTERY NOT RECHARGING PROPERLY (red)
Turning the key to MAR the warning light on the dial turns on, but it should go out as soon as the
engine is started.
If the warning light stays on together with the message, contact a Fiat Dealership as soon as pos-
sible to prevent draining the battery.
SEAT BELTS NOT FASTENED (red)
(Only for right-hand drive versions)
The warning light on the dial turns on glowing steadily when, with ignition key at MAR, the dri-
ver’s seat belt is not fastened correctly.
AIRBAG FAILURE (red)
Turning the ignition key to MAR the warning light on the dial turns on, but it should go off after
about 4 seconds. The warning light will stay on to indicate an airbag failure.
¬ w
<
WARNINGIf when turning the ignition key to MAR, the warning light ¬does not turn on or if
it stays on when travelling there could be a failure in safety systems; in this event
air bags or pretensioners could not trigger in case of impact or, in a minor number
of cases, they could trigger accidentally. Contact Fiat Dealership immediately to
have the system checked.
The failure of the warning light ¬(warning light off) is also indicated by the
flashing for more than the normal 4 seconds of the passenger’s front airbag
deactivated warning light
F.
WARNING

162
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
162
Warning Messagelight on panel on display
GLOW PLUGS (amber)
(diesel versions)
When the ignition key is turned to MAR. The warning light will go off when glow plugs reach the
prescribed temperature.
DIRECTION INDICATORS (green)
(flashing)
When the direction indicator stalk is operated.
FRONT PASSENGER AIRBAG DEACTIVATED (amber)
Warning light will come on when front passenger airbag is deactivated.
With front passenger airbag on, turning the ignition key to MAR, the warning light shall flash for
about 4 seconds and then go off.
F
m
RE
WARNINGWarning light Findicates also warning light ¬failures. This is indicated by
intermittent flashing, over 4 seconds, of warning light F. In this event warning
light ¬could not indicate safety system failures. In addition, the airbag system
will deactivate automatically the passenger's airbags (side bag, where provided and
front airbag). Contact immediately Fiat Dealership to have the system checked.
