1
FIAT PANDA 100HP
This Supplement describes the main fea-
tures of Fiat Panda 100HPtogether
with a few instructions for use. For all oth-
er information not contained herein, re-
fer to the Owner Handbook this Supple-
ment is attached to.CONTENTS
DASHBOARD ................................................................................................................... 2
INSTRUMENT PANEL ..................................................................................................... 3
INSTRUMENTS.................................................................................................................. 4
SPORT FUNCTION ......................................................................................................... 6
USING THE MANUAL GEARBOX ............................................................................... 6
DRIVING STYLE ............................................................................................................... 7
WARNING LIGHTS AND MESSAGES ....................................................................... 7
TYPES OF BULBS .............................................................................................................. 7
JACKING THE CAR .......................................................................................................... 8
SERVICE SCHEDULE........................................................................................................ 9
CHECKING FLUID LEVELS............................................................................................. 11
ENGINE CODES - BODYWORK VERSIONS ........................................................... 14
ENGINE ............................................................................................................................... 14
TRANSMISSION ............................................................................................................... 15
BRAKES ................................................................................................................................ 15
WHEELS AND TYRES...................................................................................................... 16
DIMENSIONS......................................................................................................................17
WEIGHTS............................................................................................................................ 18
CAPACITIES ....................................................................................................................... 19
PERFORMANCE................................................................................................................ 19
FUEL CONSUMPTION .................................................................................................... 20
CO
2EMISSIONS ............................................................................................................... 20
603_97_390 Panda 100 HP GB:603_97_390 Panda 100 HP GB 7-10-2009 17:06 Pagina 1
Page 20 of 22
19
FIAT PANDA 100HP
Fiat Panda 100HP
35
5
4.50
2.75
2.90
1.65
0.55
1.80
CAPACITIES
Fuel tank: litresincluding a reserve of: litres
Engine cooling system: litres
Engine sump: litres
Engine sump and filter: litres
Gearbox/differential casing: litres
Hydraulic brake circuit: kg
Windscreen and rear window
washer fluid reservoir: litresSpecified fuels and
recommended products
Unleaded petrol with no less than 95
R.O.N.
Mixture of distilled water and
PARAFLU
UPat 50%
SELENIA 20K
TUTELA CAR TECHNYX
TUTELA TOP 4
Mixture of water and
TUTELA PROFESSIONAL SC 35
PERFORMANCE
Top admitted speed after initial car use in km/h.
Fiat Panda 100HP185
