FIAT PANDA 2009 169 / 2.G LPG Supplement Manual

11
FIAT PANDA LPG
PAPER FILTER
The filter fig. 5, located on the pressure
regulator outlet pipe, has the task of fil-
tering the LPG in a gaseous state during
the LPG injectors supply stage.
fig. 5F0Z0809m
LPG INJECTORS
There are four injectors fig. 6, specially
designed for LPG, mounted on the intake
manifold near the cylinder head, one for
each inlet duct; they are supplied with LPG
in a gaseous state at a constant pressure
and are controlled by a specific electron-
ic control unit.
A gas pressure and temperature sensor
mounted on the injectors sends an ap-
propriate electrical signal in order to de-
termine the LPG injection time.
fig. 6F0Z0806m
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 11

12
FIAT PANDA LPG
ELECTRONIC
CONTROL UNIT
The vehicle has a dedicated electronic
control unit for the LPG system; it uses
the incoming signals from the petrol in-
jection control unit and converts them in-
to signals for the injection of the LPG.
The control unit for the injectors has the
same strategy as the petrol control unit
(phased, sequential, multipoint).
LPG/PETROL SWITCH
The LPG/petrol switch fig. 7is located on
the protective fuse flap (left side of the
dashboard) and includes:
A. LPG/petrol operating mode request
button;
B. LPG gauge: 5 leds of which 4 green and
1 red to indicate the reserve. The red LED
only comes on when the last green LED
goes out.
The red LED indicates the reserve con-
dition;
ON. LPG operation mode indicator:
green LED on continuously, under the
buttonA;
OFF. petrol operation mode indicator:
yellow LED on continuously, under the
buttonA.
IMPORTANT When the ignition key is
turned to the MARposition the LEDs on
the ignition switch come on in accordance
with the following rule:
–with petrol operation mode se-
lected: yellow LED OFF activation;
–with LPG operation selected: all
LEDs on the switch are on continuously
and the green LED ONflashes.To select the type of fuel system desired
(LPG or petrol), press button A-fig. 7.
To change the type of fuel system, it is ad-
visable to operate the button with the ve-
hicle stationary and the engine running or,
whilst driving, after having released the ac-
celerator.
If the switching takes place during accel-
eration or pick-up, there may be a brief
flat spot (fall in power).
fig. 7F0Z0807m
Do not switch between the
two operating modes whilst
starting the engine.
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 12

13
FIAT PANDA LPG
Switch from petrol to LPG
With petrol fuel supply: press the button
A-fig. 7, the switch to LPG will take place
automatically at the first significant accel-
eration.
During switching:
– the LPG gauge Bcomes on;
– the yellow LED OFF goes out (petrol
operating mode);
– the green LED ON comes on switch-
ing from intermittent to on constantly
(LPG operating mode).
There are 5 LEDs B(1 red and 4 green)
on the left of the switch that display the
amount of LPG in the tank.
When the amount of LPG remaining goes
below about 1/5 of the capacity of the
tank, only the red (reserve) LED remains
on to signal the need for refuelling.
IMPORTANT In the case of starting at
outside temperatures of below -10 °C, the
switching times from petrol to LPG in-
crease to allow the pressure regulator to
become warm enough.IMPORTANT The buzzer warns the dri-
ver that the engine is running on petrol;
therefore he must refuel with LPG before
it runs out.
THE buzzer can be deactivated by press-
ing the switching button A.
Do not switch between the
two operating modes whilst
starting the engine. Switching from LPG to petrol
With LPG supply: press the buttonA-
fig. 7.
During switching:
– the LPG gauge Bgoes out;
– the yellow LED OFF comes on con-
stantly (petrol operating mode);
– the green LED ON goes out (LPG op-
erating mode).
LPG run out
If the LPG runs out, switching to petrol
takes place automatically with:
– the yellow LED OFF on constantly;
– the green LED ON flashing;
– an acoustic warning from the switch
buzzer (fast frequency).
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 13

14
FIAT PANDA LPG
FUEL CUT-OFF SWITCH
In the case of LPG operation as well, the
safety switch is triggered if the car is in-
volved in an impact immediately cutting off
the supply (safety solenoid valve closed)
and causing the engine to cut out.
For further information, see the “Fuel cut
off switch” paragraph in the “Knowing
your car” chapter in the Owner Hand-
book.
STARTING THE ENGINE
The engine is always started on petrol
even with the switch in the LPG position
(green LED flashing, yellow LED on con-
stantly) and switches from petrol to LPG
automatically soon after.
There must therefore always be some
petrol in the tank to protect the petrol
pump.
To carry out the starting manoeuvre cor-
rectly, see the warnings and advice in the
Owner’s Handbook under the chapter
Starting the engine enclosed with this
Supplement.
In this situation, you can con-
tinue driving, with the car run-
ning on petrol (excluding the
LPG fuel system). To turn off
the acoustic warning press button A:
the green LED ON will go out and the
yellow LED OFF will remain on con-
stantly. Go to a Fiat Dealer as soon as
possible to have the system checked.
System failure signalling
The car has a self-diagnosis system capa-
ble of signalling any malfunctions in the
LPG fuel system through the green LED
ON fig. 7flashing. In the case of faults that
could affect the correct operation of the
engine, the LPG control unit will auto-
matically switch from LPG operation to
running on petrol.
This condition will be shown by:
– the yellow LED OFF on constantly;
– the green LED ON flashing;
– an acoustic warning from the switch
buzzer (slow frequency).
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 14

15
FIAT PANDA LPG
AT THE FILLING
STATION
LPG filler fitting
The gas filler is located next to the petrol
filler cap. It has a one-way valve, located
in the actual filler body.
To access the filler B-fig. 8, open the ac-
cess hatch Aand undo the cap C.
Observe the following precautions during
the refuelling operation:
– switch off the engine;
– apply the handbrake;
– turn the ignition key to the STOPpo-
sition;
– do not smoke;
– hand the special adaptor over to the
qualified LPG refuelling personnel.
IMPORTANT Before refuelling with LPG,
the qualified personnel should make sure
that the adaptor is correctly tightened on-
to the filler fitting.
IMPORTANT Depending on the country,
there are two types of adaptors for refu-
elling pumps. The adaptor that comes with
the car in a special case is specifically de-
signed for the country in which the car is
sold. If you are in a different country, find
out what type of adaptor is used there.
WHEELS
Wheel repair
The car does not have a spare wheel but
comes with a quick tyre repair kit known
as Fix&Go.
The kit is located on the left side of the
luggage compartment and is fastened by
Velcro.
For use, see the instructions in the main
Owner Handbook associated with this
supplement.
The tool box fig. 9is located under the
driver’s seat and fastened by Velcro.
FUSE REPLACEMENT
The LPG system components are protec-
ted by specific fuses. Contact a Fiat Dea-
lership if a fuse needs replacing.
For all other fuses, consult the Owner
Handbook that this supplement comes
with.
fig. 8F0Z0808m
fig. 9F0Z0607m
IMPORTANT Only use LPG for mo-
tor vehicles.
IMPORTANT Look after the LPG
adaptor carefully so that it does not
get damaged.
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 15

16
FIAT PANDA LPG
SCHEDULED SERVICING PLAN
Additional operations to the Servicing Plan in the Owner Handbook.
Thousands of kilometres
Visual check on conditions: LPG piping and connectors and
LPG tank fastening
Replacement of filter inside the pressure regulator
Paper filter replacement (LPG in gaseous state)
Check operation and parameters of fuel supply system
using self-diagnostic socket
Check mechanical tappet clearance and restore if necessary20 40 60 80 100 120 140 160 180
●●●●● ●●●●
●
●●●●● ●●●●
●●●●● ●●●●
●●●●● ●●●●
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 16

17
FIAT PANDA LPG
ENGINE
ENGINE CODE – BODYWORK VERSIONS
Engine code Bodywork version
1.2188A4000 169AXB1A G0BU (*)
169CXB1A NY (❑)
169CXB1A PY (▲)
(*) 4-seater version
(❑) 2-seater VAN version
(▲) 4-seater VAN version
IDENTIFICATION PLATE (STAGE 2)
(for versions/markets, where provided)
Following the installation of the LPG system components, a plate (Stage 2) is fitted to the left side of the luggage compartment rear
floor, that contains the following information:
– Name of manufacturer;
– Homologation number (Stage 2);
– Vehicle type identification codes;
– Vehicle weights;
– Engine type;
– Bodywork version code.
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 17

18
FIAT PANDA LPG
LPG FUEL SYSTEM
Electronic injection with special LPG injec-
tors.
Type: Multipoint phased sequential.
Stoichiometric metering of the air/gas mix-
ture.
Engine idle speed: 750 ± 50 rpm
The LPG injection system is controlled by
a dedicated control unit (connected to the
petrol unit) using the sensors already on
the car.
IGNITION
Static advance, electronic, integrated with
the injection.
PERFORMANCE
Top speed in km/h.
Running on petrol: 155
Running on LPG: 155
Modifications or repairs to
the fuel feed system that are
not carried out properly or do not
take the system technical specifica-
tions into account can cause mal-
functions leading to fire risk.
IMPORTANT
GENERAL FEATURES 1.2
Engine identification code 188A4000
Bodywork version code 169AXB1A G0BU
Cycle Otto
Number and layout of cylinders 4 in line
Piston bore and stroke mm 70.8 x 78.86
Total capacity cm31242
Compression ratio 9.8 : 1
LPG Petrol
kW 44 44
Max. EEC power HP 60 60
at a speed of rpm 5000 5000
Nm 102 102
Max. EEC torque kgm 10.4 10.4
at a speed of rpm 3000 3000
Spark plugs NGK DCPR7E-N-10
BOSCH YR7DEU
Fuel
LPGUnleaded
petrol
95 RON
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 18

19
FIAT PANDA LPG
WEIGHTS
(1) In the presence of optional equipment the unladen weight increases and, as a result, the payload decreases in relation to the
maximum permitted loads.
(2) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load carrying plat-
form within the maximum permitted loads.
(**) 2-seater VAN version.
(❒) 4-seater VAN version.
Weights (kg) for versions
Unladen weight (with all fluids, fuel tank
filled to 90% and without optional equipment)
Payload including the driver (1):
Maximum permitted loads (2)
– front axle:
– rear axle:
– total:
Towable loads:
– braked trailer:
– non-braked trailer:
Maximum permitted load on the roof:
Maximum load on the ball:1.2
860/875 (*) / 885 (❒)
445/505 (*) / 505 (❒)
730
660/760 (*) / 760 (❒)
1305/1380 (*) / 1390 (❒)
800
400
50
60
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 19

20
FIAT PANDA LPG
F0Z0707m
DIMENSIONS
fig. 10
Versions A B C D E F G H
1.23538 713 2299 526 1540/1578(*) 135715781366
(*) With longitudinal bars Dimensions are expressed in mm and re-
fer to the vehicle fitted with its original
tyres.
Height is measured with the vehicle un-
laden.
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 20
