FIAT PANDA 2009 169 / 2.G LPG Supplement Manual

21
FIAT PANDA LPG
supply pressures of pumps in the net-
work, pumps with different sup-
ply/stop specifications, tank not com-
pletely in reserve condition.
It should be remembered that when using
a fuel such as LPG the range is very vari-
able because, as well as driving and car
maintenance conditions, it also depends
on the different composition of the gas
which can vary not only seasonally but al-
so from supplier to supplier. LPG is, in ef-
fect, a composition of gas (butane and
propane) mixed in a way that may not be
standardized.
BOOT CAPACITY
Capacity with vehicle unladen (V.D.A. standards) in dm3
One-piece and split rear seat
Under rear parcel shelf with rear backrest in normal position
To waist level with rear backrest folded over
Max. to the roof with rear backrest folded over
Max. to the roof with rear backrest folded over (with sun roof)
Volume of the load carrying compartment (2-seater VAN version)
Volume of the load carrying compartment (4-seater VAN version)187
471
841
796
1000
256
CAPACITIES
Petrol
Petrol . . . . . . . . . . . . . . . . . litres 35
– including a reserve of . . . litres 5
LPG
– maximum refuelling
capacity (*) . . . . . . . litres 31/27 (▲)
(▲) VAN version
(*) The value already takes into account
the 80% filling limit of the tank and the
residual fluid necessary for the priming and
is the maximum permitted refilling. This
value may undergo slight changes
from one refilling operation to the
next due to: differences between the The trip meter indication on range is indica-
tive and refers to petrol operation only.
During LPG operation, the Instant con-
sumption and Average consumption read-
ings are not significant, whereas all other
functions remain valid.
IMPORTANT Only use LPG for mo-
tor vehicles.
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 21

22
FIAT PANDA LPG
FUEL CONSUMPTION
The fuel consumption figures given in the
table below are determined on the basis
of the homologation tests set down by
specific European Directives.
The procedures below are followed for
measuring consumption:
– urban cycle: begins with cold starting,
then follows a driving path simulating the
usage of the vehicle in town;
– extra-urban cycle: driving that simulates
using the vehicle out of town with fre-
quent acceleration in all gears; the speed
varies from 0 to 120 km/h;
– combined consumption: the weighting is
around 37% urban cycle and 63% extra-
urban cycle.IMPORTANT The type of route, traffic
situations, weather conditions, driving
style, general car condition, trim lev-
el/equipment/accessories, use of the cli-
mate control system, vehicle load, roof
rack and other situations that affect air
drag may lead to different fuel consump-
tion levels than those measured. (See
Saving fuel in the Starting and driving
chapter in the handbook).
LPG range
With reference to the combined con-
sumption figures, the range while running
on LPG is 433 km (378 km for the VAN
version).
According to the European Directive in force
Petrol LPG
(litres x 100 km) (litres x 100 km)
Urban 7.0 9.0
Extra-urban 4.6 5.9
Combined 5.5 7.0
If, when refuelling with LPG,
there is an irregularity and the
tank is filled to more than the
31litres (27 litres for the VAN
version) (allowing for a surplus of 2 litres)
get help immediately from a Fiat Deal-
er. Periodically (at least once every six
months) it is advisable to let the LPG
in the tank run out and, at the first re-
fuelling, check that it does not exceed
the maximum permitted capacity.
The LPG supply system is
equipped with a "consump-
tion" function linked to the LED display
of LPG level on the switch; this function
activates only after a consistent varia-
tion in fuel level has been detected. You
are therefore advised to fill up with fu-
el at the first LPG refuelling to obtain a
more precise indication of the “level".
WARNING
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 22

CO2EMISSIONS
The CO2emission figures in the table below refer to combined fuel consumption.
According to the current
European Directive (g/km)
LPG . . . . . . . . . . . . . . . . . . . . . . . . . 114
Petrol . . . . . . . . . . . . . . . . . . . . . . . 129
FLUIDS AND LUBRICANTS
CHARACTERISTICS OF PRODUCTS
Use Quality specifications of fluids and lubricants Fluids and lubricants Interval
for correct car operation original replacements
Lubricants
for petrol/
LPG-engines
For petrol engines running on LPG, we recommend using the original product formulated specifically for the type of use.
The use of products with specifications below ACEA C3 – SAE 5W-40 could cause damage to the engine not covered
by the warranty.According to annual
maintenance and in-
spection schedule
SELENIA
MULTIPOWER
GAS 5W-40
Contractual
Technical Reference
N° F922.E09
SAE 5W-40 ACEA C3
grade totally synthetic lubricant.
FIAT 9.55535-T2specification
23
FIAT PANDA LPG
603_97_595GB PANDA GPL Euro 5 16-12-2009 12:58 Pagina 23

Fiat Group Automobiles S.p.A. – Customer Services – Technical Services – Service Engineering
Largo Senatore G. Agnelli, 5 – 10040 Volvera – Torino (Italia)
Print No 530.04.595GB - 11/2009 - 1 Edition
