FORD CROWN VICTORIA 1997 1.G Owners Manual

170 % [GF08400( GV)12/95]
half page art:0010213-FThe positions of the gearshift
*
[GF08700( ALL)01/96]
Once the gearshift is secure in the desired
position, release the brake pedal and use the
accelerator as necessary.
%*
[GF08800( ALL)05/96]
R (Reverse)
*
[GF08900( ALL)05/96]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[GF09000( ALL)01/96]
N (Neutral)
[GF09100( ALL)12/95]
As in P (Park), there is no power transferred
through the transmission. However, the final
drive is not locked so the wheels are free to
rotate. The vehicle may be started in the N
position, but the ignition key cannot be
removed.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

171 %
*
[GF09200( ALL)05/96]
Driving
[GF09300( GV)12/95]
Your vehicle's gearshift is on the steering
column. The Transmission Control Switch (TCS)
is located on the end of the gearshift lever. The
Transmission Control Indicator Light (O/D OFF)
is located on the instrument panel. You can put
the gearshift lever in any of the several
positions.
[GF09600( GV)12/95]
The O/D OFF light is off (not illuminated)
during normal vehicle operation. This allows the
transmission to upshift and downshift from 1st
through 4th gears. When the TCS is pressed, the
Transmission Control Indicator Light will
illuminate (O/D OFF) on the instrument panel.
When this O/D OFF is illuminated the
transmission will upshift and downshift from 1st
through 3rd gears.
[GF09800( ALL)12/95]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
*
[GF09900( BCGV)05/96]
To return the transmission to normal operation
(1st through 4th gear) depress the TCS again.
This switch may be used to cancel overdrive any
time the vehicle is being driven. Each time your
vehicle is started, the overdrive system will
automatically be in the normal overdrive mode
and the light will not be illuminated.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

172 %
*
[GF10100( GV)05/96]
When to usej(Overdrive)
*
[GF10300( ALL)12/95]
Overdrive is the usual driving position for an
automatic overdrive transmission. It works the
same way Drive works, automatically upshifting
or downshifting as the vehicle speeds or slows.
*
[GF10400( ALL)12/95]
However, Overdrive also shifts into a fourth
gear Ðan overdrive gear Ð when your vehicle
cruises at an appropriate consistent speed for
any length of time. This fourth gear will increase
your fuel economy when you travel at cruising
speeds.
[GF10600( GV)12/95]
When to usej(Overdrive) Ð with
Transmission Control Switch activated
(TCS)
[GF10800( GV)12/95]
Overdrive may not be appropriate for certain
terrain. If the transmission shifts back and forth
between Third and Fourth gears while you are
driving on hilly roads or if your vehicle does
not have adequate power for climbing hills,
press the TCS located on the shift lever.
*
[GF10900( BCGV)12/95]
You can depress the TCS at any speed.
*
[GF11100( ALL)05/96]
When to use 2 (Second)
*
[GF11200( ALL)12/95]
Use 2 (Second) for start-up on slippery roads or
to give you more engine braking to slow your
vehicle on downgrades.
*
[GF11300( ALL)05/96]
When to use 1 (Low)
*
[GF11400( ALL)12/95]
Use 1 (Low) when driving down steep grades. It
gives more engine braking to slow your vehicle
than 2 (Second) on the downgrades. You can
upshift from 1 (Low) to 2 (Second) or from 1
(Low) to Overdrive at any speed.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

173
*
[GF11500( ALL)05/96]
P (Park)
*
[GF11600( ALL)12/95]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transmission and prevents the rear wheels from
rotating.
*
[GF11700( ALL)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[GF11800( ALL)05/96]
RWARNING
Never leave your vehicle unattended
while it is running.
*
[GF11900( GV)12/95]
You can tell a column-mounted gearshift is
securely latched in P (Park) if the lever is
adjacent to the P (Park) and you cannot move it
without pulling it toward you and rotating it
downward.
%
*
[GF15500( ALL)01/96]
Driving With a Heavy Load
*
[GF15600( ALL)01/96]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
% [GF15700( ALL)12/95]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or the door latch
post pillar.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

174
*
[GF15800( ALL)01/96]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limits than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[GF15900( ALL)01/96]
RWARNING
Do not exceed the GVWR or the GAWR
specified on the Safety Compliance
Certification Label.
%*
[GF16000( ALL)01/96]
Limiting Your Vehicle's Load
*
[GF16100( ALL)12/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[GF16200( ALL)01/96]
To figure the weight of your vehicle's load, add
the weights of:
*
[GF16300( ALL)01/96]
q
the driver and passengers
*
[GF16400( ALL)01/96]
q
luggage and any other items that you put in
your vehicle
*
[GF16600( ALL)01/96]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
*
[GF16700( ALL)01/96]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[GF16800( ALL)01/96]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[GF16900( ALL)01/96]
2. Then weigh your vehicle with the driver,
passengers and luggage.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

175
*
[GF17000( ALL)01/96]
3. Subtract the first reading from the second to
figure the total weight of the load.
*
[GF17100( ALL)11/92]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
*
[GF17200( ALL)01/96]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
*
[GF17300( ALL)01/96]
RWARNING
Improper distribution of your vehicle's
load or carrying weight in excess of the
amount shown on the tire decal can cause
rapid tire wear or loss of vehicle control.
%
*
[GF17500( GV)05/96]
Trailer Towing
*
[GF17505( GV)05/96]
Your vehicle is not equipped to tow. No towing
packages are available through Ford or
Lincoln/Mercury dealers.
%
*
[GF23600( ALL)01/96]
Driving Under Special Conditions
%*
[GF23700( ALL)01/96]
Tips for Safe Driving
*
[GF23800( ALL)01/96]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[GF23900( ALL)01/96]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

176 %
*
[GF24000( ALL)01/96]
Driving in Bad Weather
%*
[GF24100( ALL)01/96]
Slippery roads
*
[GF24200( ALL)01/96]
Drive cautiously on wet or snowy roads:
*
[GF24300( ALL)01/96]
q
Do not quickly move the steering wheel
unless necessary.
*
[GF24400( ALL)01/96]
q
Drive slower than you normally would.
*
[GF24500( ALL)01/96]
q
Do not use speed control.
*
[GF24600( ALL)01/96]
q
Give your vehicle more distance to stop.
[GF24700( ALL)04/96]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[GF24800( ALL)01/96]
q
Consider using one of the lower gears.
*
[GF25000( BCGV)01/96]
RWARNING
To avoid skidding and losing control on
slippery roads, do not downshift into 1
(First) when you are moving faster than
20 mph (30 km/h).
*
[GF25100( ALL)05/96]
RWARNING
Do not use the speed control in heavy
traffic or on roads that are winding,
slippery, or unpaved.
[GF25200( GV)12/95]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
(2 [Second] gear is the recommended forward
gear) and reverse gears. At the same time, press
lightly on the accelerator.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

177
*
[GF25400( ALL)05/96]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
[GF25500( ALL)12/95]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transmission, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[GF25600( ALL)01/96]
High water
*
[GF25700( ALL)01/96]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
*
[GF25800( ALL)01/96]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[GF25900( ALL)01/96]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
File:09rcgfv.ex
Update:Mon Sep 23 12:37:37 1996

179
Roadside Emergencies
[ER00175( ALL)03/96]
Hazard Flashers
*
[ER00200( ALL)01/96]
The flashers work whether your vehicle is
running or not. The flashers work for up to two
hours when the battery is fully charged and in
good condition without draining the battery
excessively. If the flashers run for longer than
two hours or if the battery is not fully charged,
the battery can be drained.
% [ER00300( GV)12/95]Fuses, High Current Fuses, Fuse
Links, and Circuit Breakers
*
[ER00500( ALL)05/96]
Fuses (conventional and high current) and circuit
breakers protect your vehicle's wiring system
from overloading. If electrical parts in your
vehicle are not working, the system may have
been overloaded and blown a fuse or tripped a
circuit breaker. Before you replace or repair any
electrical parts, check the appropriate fuses
(conventional and high current) or circuit
breakers.
*
[ER00600( ALL)12/95]
The following charts tell you which fuses or
circuit breakers protect the wiring for each
electrical part of your vehicle. If a fuse blows or
a circuit breaker opens a circuit,allthe parts of
your vehicle that use that circuit will not work.
File:10rcerv.ex
Update:Wed Jun 19 10:32:02 1996

180
*
[ER00700( ALL)05/96]
Once you have determined which fuses or circuit
breakers to check, follow the procedures under
Checking and replacing fusesorChecking and
replacing circuit breakersin this chapter.
[ER01200( GV)12/95]
half page art:0011155-C
The instrument panel fuse panel
File:10rcerv.ex
Update:Wed Jun 19 10:32:02 1996
